iDM8N1 instruction manual Model: iDM8N1 (New Version) IB (English) Size: 153mm x 120mm Printing color: Black Date: July 17, 2013 P1 portable rechargeable Bluetooth speaker iDM8N1 Introduction Thank you for purchasing the iHome iDM8N1. This product is designed to provide high quality wireless sound for your iPad, iPhone, iPod, computer, or other Bluetooth audio device. Along with the included Quick Bluetooth Connection Guide this instruction booklet explains the basic operation and care of the unit. Please read them carefully and keep for future reference. Maintenance • Place the unit on a level surface away from sources of direct sunlight or excessive heat. • Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture. • Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as benzene, thinner or similar materials can damage the surface of the unit. P2 SRS WOW®, which features TruBass®, significantly improves the playback quality of audio, delivering a dynamic 3D entertainment experience with deep, rich bass and high frequency clarity for crisp detail. is a registered trademark of SRS Labs, Inc. TruBass technology is incorporated under license from SRS Labs, Inc. iDM8N1 FCC Information P3 FCC ID: EMOIDM8N1 IC: 986B-IDM8N1 • Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device complies with Industry Canada RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and(2) this device must accept any interference, including interference that may cause undesired operation of the device. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. iDM8N1 Table of Contents Meet Your iDM8N1.......................................................................................................1-2 Charging the Unit.............................................................................................................3 Using Bluetooth:Pairing Your Device.....................................................................................4 Playing Audio Via Bluetooth................................................................................................5 Playing Audio Via Aux.......................................................................................................6 Internal Rechargeable Lithium-ion Battery...............................................................................7 Consumer Product Safety Guide.......................................................................................8-9 Troubleshooting..............................................................................................................10 Warranty......................................................................................................................11 P4 Meet Your iDM8N1 iDM8N1 1 Off/Bluetooth/Aux-in Switch Bottom P5 Power/Charging/Pairing Indicator Light Micro USB Charging Port Charging and AUX IN via iHome cable Pairing Button Back Left Side Right Side Play/Pause Button iDM8N1 2 Included • iDM8N1 system • Micro USB to USB/3.5 mm audio cable P6 iDM8N1 Using the Charging the Unit 1. Connect the micro USB plug to the micro USB charging port on the back of the unit. 2. Connect the standard USB plug end of the cable to a power USB port on a computer or other USB charging device that is connected to power. For first time use, charge unit for about 8 hours. 3. The amber light appears while the unit is charging and turns off when unit is fully charged. If unit is not powered on when micro USB plug is connected, the amber light flashes once to indicate unit is charging. 3 P7 NOTE: When unit is on and not connected to power source, flashing amber light indicates battery needs charging. USB 2.0 iDM8N1 Using the 4 Using Bluetooth: Pairing Your Device P8 NOTE: See the iDM8N1 Bluetooth Connection Guide f…

Text truncated - open the document above for the full version.

iDM8N1 Model: iDM8N1 (New Version) IB (French) Size: 153mm x 120mm Printing color: Black Date: July 17, 2013 P1 Mode d’emploi Rechargeable Portatif Haut-parleur de Bluetooth iDM8N1 P2 Introduction Merci d’avoir acheté le modèle iDM8 de iHome. Ce produit est conçu pour livrer un son sans fil de qualité supérieure à votre iPad, iPhone, iPod, ordinateur, assistant numérique ou autre appareil audio Bluetooth. Ce guide d’instructions, ainsi que le guide de connexion rapide Bluetooth compris, vous précise les consignes de fonctionnement et d’entretien de base de votre unité. Veuillez les lire soigneusement et les conserver pour référence ultérieure. Maintenance • Placez l’appareil sur une surface plane hors des rayons directs du soleil ou de toute chaleur excessive. • Protégez vos meubles quand vous posez l’appareil sur du bois naturel ou sur une surface lacquée. Un tissu ou un autre matériau de protection doit être placé entre l’appareil et le meuble. • Nettoyez votre appareil uniquement avec un tissu doux et un peu de savon doux. Les agents nettoyants tels que le benzène ou autres détergents pourraient endommager la surface de l’appareil. SRS WOW ® , qui comprend TruBass ® , améliore considérablement la qualité de lecture audio, offrant des moments de divertissement 3D dynamique avec des graves profondes et riches et des hautes fréquences d'une clarté et précision exceptionnelles. est une marque déposée de SRS Labs, Inc. TruBass technology est incorporé sous licence de SRS Labs, Inc. iDM8N1 P3 FCC ID: EMOIDM8N1 IC: 986B-IDM8N1 Information FCC Avertissement : Tout changement ou modification apporté à cet appareil sans le consentement expresse de la partie responsable pour la conformité peut annuler le droit de l'utilisateur d'utiliser cet appareil. Remarque : Cet équipement a été testé et jugé conforme aux limitations pour un appareil numérique de Classe B, selon la Section 15 de la règlementation FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre des fréquences radio et, s'il n'est pas installé et utilisé selon les instructions, peut causer des interférences nuisibles aux communications radio. Cependant, il n'existe aucune garantie que des interférences ne se produiront pas dans une installation particulière. Si cet équipement produit des interférences nuisibles sur la réception de la radio ou de la télévision, ce que vous pouvez facilement constater en éteignant et en rallumant l'équipement, nous vous encourageons à prendre l'une ou plusieurs des mesures correctives suivantes : • Réorienter ou déplacer l’antenne réceptrice, • Éloigner davantage l'appareil du récepteur. • Branchez l’équipement sur une prise ou un circuit auquel le récepteur n’est pas branché. • Consultez votre revendeur ou un technicien radio/télévision qualifié pour plus d’informations. ppareils digitaux de Classe B compatible avec l’ICES-003 Canadien. Cet appareil répond aux exigences du paragraphe 15 de la loi de la Commission Fédérale sur les Communications. L’utilisation de cet appareil doit répondre aux deux conditions suivantes: (1) Cet appareil ne doit pas provoquer d’interférences nuisibles, et (2) cet appareil doit accepter toutes les interférences reçues, y compris les interférences pouvant provoquer un fonctionnement non désiré. Cet équipement est conforme aux limites FCC relatives à l'exposition à la radiation par radiofréquences établies pour les environnements non contrôlés. Cet émetteur ne doit pas être colocalisé ou utilisé en conjonction avec tout autre émetteur ou antenne. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio RSS-210. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. Déclaration de la FCC sur l’exposition aux radiations iDM8N1 P4 Table des matières Présentation d’iDM8N1..................................................................................................1-2 Charger le dispositif..........................................................................................................3 Utilisation de Bluetooth : Couplez votre dispositif ....................................................................4 Lecture audio via Bluetooth.................................................................................................5 Lecture audio via Aux........................................................................................................6 Batterie interne au lithium-ion rechargeable............................................................................7 Guide du consommateur sur la sécurité des produits............................................................. 8-9 Dépannage...................................................................................................................10 Garantie.......................................................................................................................11 Présentation d'iDM8N1 iDM8N1 1 Commutateur Off/Bluetooth/ Aux-in (Eteindre/Bluetooth/ Entrée auxiliaire) Partie inférieure P5 Témoin Alimentation/Charge/Cou plage Port micro USB de charge : pour charger et l’utiliser comme entrée auxiliaire via le câble iHome Bouton de couplage Face arrière Côté gauche Côté droit Touche Lecture/Pause • Système iDM8N1 • Câble audio micro USB vers USB/3,5 mm iDM8N1 2 P6 Inclus Utilisation d' iDM8N1 Recharge de l'unité 1. Branchez le connecteur micro USB dans le micro-port USB de charge…

Text truncated - open the document above for the full version.

Model Declaration Letter Date: 2013-06-13 We, the undersigning company Company Name: SDI Technologies Inc Address: 1299 Main Street, Rahway, New Jersey 07065, U.S.A Hereby confirm that the following products: Product description: Portable rechargeable bluetooth speaker Type designation: iDM8N1; iDM8N; iDM8NX; iDM8X; MF-M8 (“X” denote as color of cabinet) Brand: iHome That All versions of the Model iDM8N1; iDM8N; iDM8NX; iDM8X and MF-M8 are electrically equal and only the color of the cabinet differs because of marketing purpose. Company Name: SDI Technologies Inc Address: 1299 Main Street, Rahway, New Jersey 07065, U.S.A Telephone: 732 574-9000 E-mail: [email protected] Signature: ________________________ Name: Jasjit Singh

Neutron Engineering Inc. Project No.: 1305C225 Page 2 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 3 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 4 of 9

Model: iDM8N1 Date code location Model: iDM8N1 (New Version) Model plate Date: July 10, 2013 Size: 41W x 30H mm Print: PMS 429C (text) Material: black color PC Sheet FCC ID: EMOIDM8N1 IC: 986B-IDM8N1 Rechargeable Battery: DC 3.7V 1350mAh Service No: iDM8-A-B Mfd & Serviced by SDI Technologies Inc. Toll Free: 1-800-288-2792 www.ihomeaudio.com Patents: www.ihomeaudio.com/patents Made in China

Neutron Engineering Inc. Project No.: 1305C225 Page 4 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 5 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 6 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 7 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 8 of 9 Neutron Engineering Inc. Project No.: 1305C225 Page 9 of 9

Neutron Engineering Inc. Report No.: NEI-FICP-1-1305C225 Page 1 of 103 FCC/IC Radio Test Report FCC ID: EMOIDM8N1 IC: 986B-IDM8N1 This report concerns (check one): Original Grant Class II Change Issued Date : Jun. 07, 2013 Project No. : 1305C225 Equipment : Portable rechargeable bluetooth speaker Model Name for FCC : iDM8N1; iDM8N, iDM8NX, iDM8X, MF-M8 (“X” denote as color of cabinet) Model Name for IC : iDM8N1 Applicant : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: May. 30, 2013 Date of Test: May. 30, 2013 ~ Jun. 06, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1305C225 Page 2 of 103 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1305C225 Page 3 of 103 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . NUMBER OF HOPPING CHANNEL 55 5.1 APPLIED PROCEDURES / LIMIT 55 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 55 5.1.2 TEST PROCEDURE 55 5.1.3 DEVIATION FROM STANDARD 55 5.1.4 TEST SETUP 55 5.1.5 EUT OPERATION CONDITIONS 55 5.1.6 TEST RESULTS 56 6 . AVERAGE TIME OF OCCUPANCY 58 Neutron Engineering Inc. Report No.: NEI-FICP-1-1305C225 Page 4 of 103 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 58 6.1.1 MEASUREMENT INSTRUMENTS LIST 58 6.1.2 TEST PROCEDURE 58 6.1.3 DEVIATION FROM STANDARD 58 6.1.4 TEST SETUP 59 6.1.5 EUT OPERATION CONDITIONS 59 6.1.6 TEST RESULTS 60 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 72 7.1 APPLIED PROCEDURES / LIMIT 72 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 72 7.1.2 TEST PROCEDURE 72 7.1.3 DEVIATION FROM STANDARD 72 7.1.4 TEST SETUP 72 7.1.5 EUT OPERATION CONDITIONS 72 7.1.6 TEST RESULTS 73 8 . BANDWIDTH TEST 77 8.1 APPLIED PROCEDURES / LIMIT 77 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 77 8.1.2 TEST PROCEDURE 77 8.1.3 DEVIATION FROM STANDARD 77 8.1.4 TEST SETUP 77 8.1.5 EUT OPERATION CONDITIONS 77 8.1.6 TEST RESULTS 78 9 . PEAK OUTPUT POWER TEST 82 9.1 APPLIED PROCEDURES / LIMIT 82 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 82 9.1.2 TEST PROCEDURE 82 9.1.3 DEVIATION FROM STANDARD 82 9.1.4 TEST SETUP 82 9.1.5 EUT OPERATION CONDITIONS 82 9.1.6 TEST RESULTS 83 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 87 10.1 APPLIED PROCEDURES / LIMIT 87 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 87 10.1.2 TEST PROCEDURE 87 10.1.3 DEVIATION FROM STANDARD 87 10.1.4 TEST SETUP 87 10.1.5 EUT OPERATION CONDITIONS 87 10.1.6 TEST RESULTS 88 11 . EUT TEST PHOTO 100 Neutron Engineering Inc. Report No.: NEI-FICP-1-1305C225 Page 5 of 103 1. CERTIFICATION Equipment : Portable rechargeable bluetooth speaker Brand Name : iHome Model Name for FCC : iDM8N1; iDM8N, iDM8NX, iDM8X, MF-M8 (“X” denote as color of cabinet) Model Name for IC : iDM8N1 Applicant : SDI TECHNOLOGIES INC. Factory : Winty Industries Corporation (Shen Zhen) Co. Ltd. Address : San Lian Industry Zone. Shi Yan Town, Bao An District, ShenZhen, China Date of Test : May. 30, 2013 ~ Jun. 06, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment co…
