THE P ERFORMANCE YOU NEED ® ® 32” Soundbar SBT32600SE User’s Guide 4000458 Please read this user’s guide before using your new soundbar. 2 2 3 3 4 4 5 5 6 6 7 7 Important Safety Instructions 1. Read these instructions. Keep these instructions. 2. Heed all warnings. 3. Follow all instructions. 4. Do not use this soundbar near water. 5. Clean only with dry cloth. 6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 7. Do not install near any heat sources such as radiators,heat registers,stoves,or other apparatus (including amplifiers) that produce heat. 8. Use only attachments/accessories specified by the manufacturer. 9. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit the soundbar. 10 . Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the soundbar. When a cart is used, use caution when moving the cart/soundbar combination to avoid injury from tip-over. 11 . Unplug this soundbar during lightning storms or when unused for long periods of time. 12. Refer all servicing to qualified service personnel. Servicing is required when the soundbar has been damaged in any way, such as if the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the soundbar, it has been exposed to rain or moisture, it does not operate normally, or it has been dropped. Package Contents „Soundbar „AC-to-DC Power Adapter „RCA Cable „AC Power Cord „Remote Control „Mounting Template „User’s Guide Features „Provides powerful sound to enhance your listening experience „Sonic Emotion Absolute 3D technology* produces rich, full sound that permeates every inch of your room „Compatible with most Bluetooth ® -enabled tablets, laptops, MP3 players, and smartphones with iOS or Android™ platform „Remote for convenient controlling from a distance * Sonic Emotion Absolute 3D is the listening experience. Connections Mounting Holes (Optionally) DC IN Use the AC-to-DC power adapter and AC power cord to connect to a wall outlet. INPUT Switch to LINE, AUX, OPT (optical), COAX (coaxial), or BLUETOOTH. EQ 3D Equalizer sound options ( MUSIC, MOVIE, GAME, and 3DOFF). Volume Control (+/–) To a coaxial port (coaxial cable not supplied) To an optical port (optical cable not supplied) (G) Power On/Off LINE IN Port Connection Use a 3.5mm audio cable (not supplied) to connect to an additional audio device. AUX IN Ports Connection Use the RCA cable to connect to a TV, DVD player, game system, etc. 5 / Version 1.2 Brand / Confidential sonic emotion ag 2012 Logo Standard version 5 / Version 1.2 Brand / Confidential sonic emotion ag 2012 Logo Standard version Warnings and Precautions „To reduce the risk of electric shock, do not remove cover (or back). There are no user-serviceable parts inside. „Do not expose the soundbar to dripping or splashing liquids. Do not place objects filled with liquids (such as vases) on the soundbar. „The mains plug is used as the disconnect device. It shall remain readily operable and should not be obstructed during intended use. To completely disconnect the soundbar from supply mains, the main plug of the product shall be disconnected from the mains socket outlet completely. „Using the soundbar near fluorescent lighting may cause interference with the remote. If the soundbar is behaving erratically, move away from any fluorescent lighting. Mounting the Soundbar (Optional) For mounting the soundbar, you may need a twist drill, a marker pen or pencil, a bubble level, two screws, and two drywall anchors (optional). 1. Locate a place for mounting the soundbar. Make sure you have enough room for both ends of the soundbar to present unobstructed sound transmission. 2. Use the supplied mounting template to mark two screw hole positions. Use two screws (not supplied) with heads no bigger than the soundbar’s mounting holes. 3. Align the soundbar’s mounting holes with the screw heads and slide down to secure the soundbar. Using the Soundbar 1. Turn on your device and turn down its volume. 2. Press G to turn on the soundbar, and turn down its volume. 3. Press INPUT to switch to LINE, AUX, OPT (optical), COAX (coaxial), or BLUETOOTH mode. You can also press BLUETOOTH on the remote to go to Bluetooth mode directly. 4. Press EQ to choose a sound option or press MUSIC, MOVIE, GAME, or OFF on the remote. You can customize each option by adjusting the bass and treble sound levels, BASS +/– and TREBLE +/–. 5. After starting playback on your device, adjust the volume of the device and soundbar to a comfortable level. n Note: The soundbar enters standby mode if you pause it for more than 15 minutes or if the Bluetooth connection is broken for 15 minutes. Using the Bluetooth Function 1. After you turn on the soundbar and switch to Bluetooth mode (BLUETOOTH scrolls on the display), the soundbar searches for a Bluetooth-enabled device ( BT PAIRING scrolls on the display). 2. Activate your device’s Bluetooth function (refer to your device’s user’s guide). 4000458_UG_EN_071113.indd 1-77/16/2013 3:00:01 PM 8 8 9 9 10 10 11 11 12 12 13 13 14 14 Printed in China 07A13 4000458 © 2013. Ignition L.P. All rights reserved. Auvio is a registered trademark used by Ignition L.P. Package and user documentation are recyclable. User documentation contains recycled material. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment doe…

Text truncated - open the document above for the full version.

1.8V 3.3V 1.8V BlueTunes ROM audio in/out PIO0 ~ PIO14 AIO0 ~ AIO1 (BC57F687A05) RF in/out Balun/ Filter (BBF-2012-2G4S1-A6) 2.4GHz Radio Regulator Stereo Audio Codec Baseband DSP RAM Kalimba DSP PIO MCU Crystal 26MHz/10ppm EEPROM (T24C32A) JS-BTM521 Block Diagram ANT: 2402-2480 MHz Block Diagram 4000458.sch-1 - Wed Jul 31 20:13:30 2013

Guangzhou Panyu Juda Car Audio Equipment Co., Ltd. Vtrek Dewei Industrial Garden, Shibei Industrial Road, Dashi Town, Panyu Borough,Guangzhou City, Guangdong Province, China 2013-05-17 To whom it may concern, Letter of Agency I, an officer of Guangzhou Panyu Juda Car Audio Equipment Co., Ltd. do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, [Name]：Liao Xiaofei [Title]：Safety Engineer

External Photo

MMAYY 3 4 . 0 mm 60.0 mm p

1 Internal Photo 2 3 4 5 6 7 8

Technical Description The equipment under test (EUT) is a 6.0 SOUNDBAR with Bluetooth function. The EUT will operate from external power adapter. For more detail information pls. refer to the user manual. Channel List 2402 2403 2404 2405 2406 2407 2408 2409 2410 2411 2412 2413 2414 2415 2416 2417 2418 2419 2420 2421 2422 2423 2424 2425 2426 2427 2428 2429 2430 2431 2432 2433 2434 2435 2436 2437 2438 2439 2440 2441 2442 2443 2444 2445 2446 2447 2448 2449 2450 2451 2452 2453 2454 2455 2456 2457 2458 2459 2460 2461 2462 2463 2464 2465 2466 2467 2468 2469 2470 2471 2472 2473 2474 2475 2476 2477 2478 2479 2480 Modulation Type: GFSK, π/4-DQPSK，8-DPSK Bluetooth Version: 2.1 with EDR function Antenna Type: Integral antenna Antenna Gain: 0dBi The nominal radiated output power (e.i.r.p) specified: 2dBm ( Tolerance: +/- 3dB) The nominal conducted output power specified: 2dBm ( Tolerance: +/- 3dB) The function of main IC is mentioned as below. 1) IC1 acts as digital audio interface receiver 2) IC2 acts as D/A Converter 3) IC3 acts as LDO. 4) IC4 acts as DC to DC. 5) U1-A acts as differential amplifier 6) U1-B acts as differential amplifier 7) U2 acts as 3D Sound Processor 8) U3 acts as Flash Memory 9) U4 acts as LDO 10) U5 acts as EMI REDUCTION 11) U6 acts as Audio Enhancing Engine and CODEC Decoding 12) U7 acts as Audio Processor 13) U8 acts as RESET 14) U9 acts as POWER AMP 15) U10 acts as MCU 16) U11 acts as RESET 17) U12-A acts as differential amplifier 18) U12-B acts as differential amplifier 19) U13-A acts as differential amplifier 20) U13-B acts as differential amplifier 21) U14 acts as LDO 22) U15 acts as POWER AMP 23) U16-A acts as BUFFER 24) U16-B acts as BUFFER 25) U16-C acts as BUFFER 26) U16-D acts as BUFFER 27) U17 acts as LDO. 28) U18 acts as LDO 29) U19 acts as LDO. 30) U20 acts as RESET 31) U300 acts as Touch Key MCU 32) U600 acts as LED DRIVER 33) BL501 acts as Bluetooth module In Bluetooth Module: 1) U1 acts as Bluetooth chip. 2) Y1 is a 26MHz oscillator for Bluetooth chip. 3) U3 acts as EEPROM. 4) U2 is a filter.

1 I NTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a 6.0 SOUNDBAR with Bluetooth function. The EUT will operate from external power adapter. For more detail information pls. refer to the user manual. Modulation Type: GFSK, π/4 –DQPSK and 8-DPSK. Bluetooth Version: 2.1 with EDR function. Antenna Type: Integral antenna. Antenna Gain: 0dBi. The nominal conducted output power specified: 2dBm +/-3dB. The nominal radiated output power (e.i.r.p) specified: 2dBm (+/- 3dB) According to the KDB 447498: The minimum peak radiated emission for the EUT is 97.6dBμV/m at 3m in the frequency 2441MHz The EIRP = [(FS*D) ^2 / 30] mW = 2.4dBm which is within the production variation. The maximun peak radiated emission for the EUT is 99.6dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = 4.4dBm which is within the production variation. The maximun conducted output power specified is 5dBm = 3.2mW The source- based time-averaging conducted output power = 3.2 * Duty Cycle mW= 2.7 mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.5 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation Based on the Bluetooth Specification (BT version: 2.1 + EDR), the duty factor is dependent of packet type (DH1, DH3 and DH5).For one period for a pseudo-random hopping through all 79 RF channels, for DH5: One hop set consists of 5 TX slot and 1 RX slot. Duty factor = 5 / 6 = 0.833 This requirement is according to KDB 865664 D02 FCC ID: ESX4000458

1 2 3 4 5 6 7 8 ABCD 8 7 6 5 4 3 2 1 D CBA BTM521-VO1A Schematic Diagram Sheet:1of1 Drawn: Checked By: Date:2012-05-25 Fihonest Communication Co,Ltd Approver By: C1 15pF L1 15n C14 47nF MIC_A_P MIC_A_N MIC_B_N MIC_B_P MIC_BIAS C1322nF C116p8 C12 18pF LED_(0)LED_(1) +1V8 C1022nF 1V5_AUDIO C922nF R2 2R2 C8 2u2 +1V8 PWR VBAT C72u2 CHG L2 22uH C64u7 +1V8 C5 22nF C4 2u2 R1 2R2 C315p +1V5 C2 15p PIO_1 R3 2K2 R4 2K2 R5 2K2 C15 100nF +1V8 SCL SCL SDA SDAWP WP AO 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U3 T24C32A RF_P 64 RF_N 65 VSS_CNTR_PAD 69 NC 8 NC 40 NC 41 NC 42 NC 43 NC 44 NC 49 AU_REF_DCPL 55 SPKR_A_P 57 SPKR_A_N 56 SPK_B_N(NC) 53 SPK_B_P(NC) 54 MIC_A_P 51 MIC_A_N 52 MIC_B_N 50 MIC_B_P 48 MIC_BIAS 45 RST# 26 TEST_EN 27 LO_REF 5 AIO(1) 6 AIO(0) 7 UART_RTS 12 UART_CTS 11 UART_RX 10 UART_TX 9 SPI_CS# 30 SPI_CLK 29 SPI_MIS0 31 SPI_MOS1 28 PIO(0) 61 PIO(1) 60 PIO(2) 59 PIO(3) 58 PIO(4) 25 PIO(5) 24 PIO(6) 23 PIO(7) 22 PIO(8) 21 PIO(9) 14 PIO(11) 15 PIO(12) 18 PIO(13) 19 PIO(14) 20 LED(0) 32 LED(1) 33 XTAL_OUT 4 XTAL_IN 3 VDD_PADS 16 VDD_USB 13 VDD_PIO 62 VDD_AUDIO 47 VREGIN_L_AUDIO 46 VREGENABLE_L 68 VREGENABLE_H 35 BAT_P 38 VDD_CHG 39 VDD_BUCK_CORE 36 LX 37 VREGIN_L 1 VDD_ANA 2 VDD_CORE 34 VDD_CORE 17 VDD_RADIO 63 VDD_RADIO 66 VDD_LO 67 U1 BC57F687A05 UNBAL 1 DC 2 NC 3 BAL 4 GND 5 GND 8 GND 7 BAL 6 U2 BBF-2012-2G4S1-A6 1 2 3 4 Y1 26M PIO_12PIO_11PIO_14 TP1 RF R&D Rev No:A1 PIO_4 SPK_A_P SPK_A_N SPK_B_N SPK_B_P PIO_2PIO_5 PIO_13 PIO_9PIO_0PIO_3 Reset AIO_0UART_RTSUART_CTSUART_RXUART_TXSPI_CSBSPI_MOSISPI_MISOSPI_CLKAIO_1 RF_IN ANT: 2402-2480 MHz Circuit Diagram 4000458.sch-2 - Wed Jul 31 20:13:30 2013 4000458.sch-3 - Wed Jul 31 20:13:30 2013 4000458.sch-4 - Wed Jul 31 20:13:31 2013 4000458.sch-5 - Wed Jul 31 20:13:31 2013 4000458.sch-6 - Wed Jul 31 20:13:31 2013 4000458.sch-7 - Wed Jul 31 20:13:31 2013 4000458.sch-8 - Wed Jul 31 20:13:32 2013 4000458.sch-9 - Wed Jul 31 20:13:32 2013 4000458.sch-10 - Wed Jul 31 20:13:33 2013
