EW72230AT&T 2230 2.4 GHz Digital Cordless Telephone

VTech Telecommunications Ltd

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 26, 2001
Application Purpose: Original Equipment
Date of Application: Jun 04, 2001
Equipment Note: AT&T 2230 2.4 GHz Digital Cordless Telephone
Frequency Range: 2401.05600000 - 2482.27200000
Company: VTech Telecommunications Ltd
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 2.4 GHz Cordless Telephone 2230 with Caller ID/Call Waiting 1 Please also read Part 1 — Important Product Information USER’S MANUAL Part 2 AT&T and the globe symbol are registered trademarks of AT&T Corp. licensed to Advanced American Telephones. REVISED 5/10/01 2230_book_1ATT 5/10/01 8:25 PM Page ii © 2001 Advanced American Telephones. All rights reserved. Printed in China. Issue 1AT&T 05/01 2230_book_1ATT 5/10/01 8:25 PM Page iii CONTENTS TO COME 2230_book_1ATT 5/10/01 8:25 PM Page 1 2230_book_1ATT 5/10/01 8:25 PM Page 2 About the Base and the Charger This cordless product provides you with two cordless handsets, a base station and a charger. You can charge either handset in the base or in the charger. You’ll need to connect the base to both AC power and a modular telephone jack. You’ll connect the charger to AC power only. For more installation information, please see INSTALLATION in this User Manual. About Caller Identification (Caller ID) This product has a Caller ID with Call Waiting feature that works with service from your local phone service provider. Caller ID with Call Waiting lets you see who’s calling before you answer the phone, even when you’re on another call. You may need to change your phone service to use this feature. Contact your phone service provider if: •You have both Caller ID and Call Waiting, but as separate services (you may need combined service) •You have only Caller ID service, or only Call Waiting service •You don’t subscribe to any Caller ID or Call Waiting services. You can use this product with regular Caller ID service, and you can use this product’s other features without subscribing to either Caller ID or combined Caller ID with Call Waiting service. There are fees for Caller ID services, and they may not be available in all areas. This product can provide information only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment. About Call History This phone assigns each incoming call a number from 1 to 30. The most recent call will have the lowest number. When the memory is full, the oldest call information is deleted to make room for new incoming call information. If you answer a call before call information appears on the screen, it will not be in the call history. BEFORE YOU BEGIN 3 2230_book_1ATT 5/10/01 8:25 PM Page 3 1Connect the power cord to the base and an electrical outlet not controlled by a wall switch. Use only the power cord supplied with this product. If you need a replacement, call 1 800 222-3111. 3Install the handset battery. Use only AT&T Battery 2401, SKU# 91077. INSTALLATION 4 Standard electrical outlet Modular telephone jack b) Place the battery pack in the handset. Align the metal contacts on the battery with the contacts in the battery compartment. c) Replace cover by sliding it on its track up over battery case until it snaps firmly into place. a) Remove battery compartment cover by pressing on indentation and sliding downward. 2Connect the telephone line cord. ART AND TEXT FOR POSITION ONLY STILL NEED INFORMATION TO COMPLETE THIS SECTION 2230_book_1ATT 5/10/01 8:25 PM Page 4 INSTALLATION 5 4Charge the handset battery. •Place the handset in the base (or a remote charging stand, purchased separately). •Charge the battery at least 12 hours. After the first charge, the battery will quick charge in only eight hours. 5Check for dial tone. •After the batteries are charged, lift the handset and press P; you should hear a dial tone. Belt Clip Attach belt clip to the cordless handset (optional). Headset You can use this telephone hands-free when you install a 2.5 mm headset (purchased separately). Plug the headset into the jack located on the left side of the handset (under the small rubber flap). Do not force the connection, but make sure the plug fits securely. a) Slide down into grooves to attach. b) Push up and away to remove. ART AND TEXT FOR POSITION ONLY STILL NEED INFORMATION TO COMPLETE THIS SECTION 2230_book_1ATT 5/10/01 8:25 PM Page 5 Feature Setup Menu When you set features marked with * you are setting the feature for BOTH handsets. All other features must be set separately at each handset. Press to return to the previous menu item. NOTE: If you wait more than 30 seconds without pressing a key, the handset returns to the standby screen. Handset Volume Adjusting handset volume will not affect the volume of what the other party hears. Default setting is 3. You can also adjust volume during conversation by pressing <or >. 1Press S. The screen displays 2Press 2. The screen displays 3Press S. The screen displays 4Use the keypad to enter a volume setting (0– 7) — OR — Press <or >to display desired setting. 5Press Sto save displayed setting. Ring Volume Adjust the volume of the handset ringer. Setting volume to 0turns the ringer off. Default setting is 3. 1Press S. 2Press 3. The screen displays 3Press S. FEATURE SETUP 6 >CALL LOG PHONEBOOK >HANDSET VOLUME RING VOLUME >HANDSET VOLUME >RING VOLUME RING PATTERN 2230_book_1ATT 5/10/01 8:25 PM Page 6 4Use the keypad to enter a volume setting (0– 6) — OR — Press <or >to display desired setting. 5Press Sto save displayed setting. Ring Pattern The external ring pattern sets which ringer you hear when you have an outside call. The internal ring pattern sets which ringer you hear when you have an intercom call from the other handset. External ring pattern default setting is 0; internal ring pattern default setting is 1. 1Press S. 2Press 4. The screen displays 3Press S. 4Press >then Sto set EXT RING PATTERNor INT RING PATTERN. 5Use the keypad to enter a ring pattern selection (0– 9) — OR — Press <or >to display desired setting. A sample of the displayed setting is played briefly. 6Press Sto save displayed setting. Auto Answer When this feature is on, an incoming call is connected when you lift the handset from the base or the charger (you don’t have to press P). If the handset is not in the base or charger, you do have …

Text truncated - open the document above for the full version.
