EW780-1383-01Video Monitor - Parent Unit

Basic operation - Parent unit Overview - Parent unit Overview - Baby unit 1 LCD display 2 Antenna 3 LED lights 4 Microphone 5 POWER 6 TALK 7 Arrow keys 8 MENU/SELECT 9 Power jack 10 VOL - / VOL + 11 VIEW /LCD ON/OFF 12 /EXIT 13 Speaker 14 Battery compartment cover 15 Stand Need help? ZoomPress to zoom in or out. Talk to your baby unitPress and hold TALK and speak to your parent unit. Your voice is transmitted to the baby unit. Release TALK when finish talking and hear your baby again. Turn off the screenPress and hold LCD ON/OFF to switch off the screen. You can still hear sound from the baby unit. Tip • Press any keys on the parent unit to turn on the screen again. Use the menuPress to enter the menu, choose a menu item, or save a setting. You can use the parent unit for advanced settings or operations, such as to play or stop the baby unit lullaby, or to adjust the baby unit sound sensitivity.While in the menu:• Press or to scroll among the menu options. • Press to select an item, or to save a setting. • Press or to scroll among the sub-menus, or to adjust a setting. • Press to return to the previous menu options without changing the current setting. • Press /EXIT to return to live video. 4 Status check 3 Positioning the baby monitor Caution • The default volume of your parent unit is level 4, and the maximum volume is level 7. If you experience high-pitched screeching noise from your baby monitor while positioning: - Make sure your baby unit and parent unit are more than 3 feet (1 meter) apart, OR - Lower the volume of your parent unit. NONO Note • T o avoid interference from other electronic devices, place your baby monitor at least 3 feet (1 meter) away from devices such as wireless routers, microwaves, cell phones and computers. Once you power on both your baby unit and parent unit, your parent unit displays image from the baby unit, and the LINK LED light turns on. The POWER LED light of baby unit turns on. Parent unit icons Main menu Sub-menu Brightness • Adjust the parent unit’s LCD brightness. Camera settings Baby unit speaker volume• Adjust the baby unit’s speaker volume. Monitoring mode (For VM350-2 only) • Single mode• Split mode• Patrol mode Lullaby / Play/Stop lullaby • Select one of the soothing sounds, or white noise. • Select one of the five melodies.• Play all melodies. • Set timer to stop playing the selected melody or soothing sound. Main menu Sub-menu Alert tones • Set the parent unit to beep when the battery is low. • Set the parent unit to beep when the link between the parent unit and the baby unit is lost. • Set the confirmation tone on or off when selecting an option in the menus. • Set the parent unit to beep when the baby unit detects sounds while in Split mode (For VM350-2 only). Temperature / • Turn on/off temperature alert tone.• Set the parent unit to beeps whenever the room temperature detected by the baby unit falls outside of the set temperature range. • Set the minimum temperature.• Set the maximum temperature.• Set temperature display in Fahrenheit ( o F) or Celsius ( o C) Main menu Sub-menu Sound activation - screen and audio / Turn on/off sound activation• Set sound activation on or off.• When it is on, and the baby unit detects no sound, the parent unit screen stays off to save power. Once a sound is detected, the parent unit screen and speaker turns on automatically, and you can see and hear your baby. The parent unit will then turn off again after 50 seconds of no sound detection. NONO Note • When the parent unit screen is off and it receives alerts, for example, link lost between parent unit and baby unit, or battery is low, the parent unit screen and speaker will turn on for 10 seconds. VOX (Voice Activated Alert) Sensitivity • You can set VOX sensitivity level to activate parent unit screen and sound when baby unit detects sounds that exceed certain levels. See Sound sensitivity and sound activation section. Main menu icons For operations and guides to help you using your video monitor, and for latest information and supports, go and check the online help topics and online FAQs. Use your smartphone or mobile device to access our online help.• Go to https://help.vtechphones.com/vm350 or https://help.vtechphones.com/vm350-2 ; OR • Scan the QR code on the right. Launch the camera app or QR code scanner app on your smartphone or tablet. Hold the device’s camera up to the QR code and frame it. Tap the notification to trigger the redirection of the online help. - If the QR code is not clearly displayed, adjust your camera’s focus by moving your device closer or further away until it is clear. You can also call our Customer Support at 1 (800) 595-9511 [in US] or 1 (800) 267-7377 [in Canada] for help. VM350 S m VM350-2 Caution • Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s crib or playpen. Specifications are subject to change without notice. © 2022 VTech Communications, Inc. All rights reserved. 06/22. VM350-X_QSG_V8. VM350 VM350-2 Full Color Video Monitor Go to www.vtechphones.com to register your product for enhanced warranty support and the latest VTech product news. 7HFKQLFDOVSHFLơFDWLRQV Credits:The Background Noise sound file was created by Caroline Ford, and is use d under the Creative Commons license. The Stream Noise sound file was created by Caroline Ford, and is use d under the Creative Commons license. The Crickets At Night sound file was created by Mike Koenig, and is used under the Creative Commons license. The Heart Beat sound file was created by Zarabadeu, and is used un der the Creative Commons license. Frequency control Crystal controlled PLL synthesizer Transmit frequency Baby unit: 2405 - 2475 MHz Parent unit: 2405 - 2475 MHz Channels 32 LCD 5” Color LCD (WQVGA 480x272 pixel) Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirements Baby unit power adapter: Outpu…

Text truncated - open the document above for the full version.

vtech Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and Report & Order 22-84 located at https ://docs .fcc.gov/public/attachments/DOC-389524A 1. pdf Applicant: VTech Telecommunications Ltd. FCC ID: EW780-1383-01 To whom it may concern, Pursuant to FCC Report & Order 22-84 section IV. Interim Freeze Order, paragraphs 264, 265, and 266, as an authorized representative ofVTech Telecommunications Ltd., I attest that the equipment for which we are seeking equipment authorization through certification is not prohibited from receiving an equipment authorization; and VTech Telecommunications Ltd . is not an entity identified on the Covered List or an affiliate or subsidiary of an entity identified on the Covered List , established pursuant to 4 7 CFR§1.50002. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the company and agree to immediately notify Intertek if there is any change in the status identified above. 血 I Approbation Supervisor VTech Telecommunications Ltd. Form: RFT-AMER-TCB-OP-19m Date: 6 January 2023 Revision : l Page I of I

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Sep. 27, 2017 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Terry Chan/ Koo Wai Ip/ Kenneth Wong/ Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Jul 18, 2022 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-1383-01 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICE Report No.: HK22070215 Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: HK22070215 Equipment Photographs (External)

PU LABELSIZE: 39.9x43 mm 50# UL Approved PET VTech Customer Service 1-800-595-9511www.vtechphones.com MANUFACTURED IN CHINA Model: VM350 PU SN:XXXXXXXXXXX FCC ID: EW780-1383-01 IC: 1135B-80138301A HVIN: 35-201976PU Step 1 Step 2 A/V I.C.T.E. VTech Customer Service 1-800-595-9511www.vtechphones.com MANUFACTURED IN CHINA Model: VM350 PU SN:XXXXXXXXXXX FCC ID: EW780-1383-01 IC: 1135B-80138301A HVIN: 35-201976PU Step 1 Step 2 A/V I.C.T.E. VTech Customer Service 1-800-595-9511www.vtechphones.com MANUFACTURED IN CHINA Model: VM350-2 PU SN:XXXXXXXXXXX FCC ID: EW780-1383-01 IC: 1135B-80138301A HVIN: 35-201976PU Step 1 Step 2 A/V I.C.T.E.

INTERTEK TESTING SERVICE Report No.: HK21071753 Equipment Photographs VM350 PU (Internal) INTERTEK TESTING SERVICE Report No.: HK21071753 Equipment Photographs VM350 PU (Internal) INTERTEK TESTING SERVICE Report No.: HK21071753 Equipment Photographs VM350 PU (Internal) Antenna

INTERTEK TESTING SERVICES RF exposure - 1 of 1 For Standalone SAR test exclusion consideration, when the corresponding SAR Exclusion Threshold requirement in KDB 447498 is satisfied, standalone SAR evaluation for general population exposure conditions, by measurement or numerical simulation is not required. Description the tested model: VM350 PU EUT Description : Video Monitor - Parent Unit Model : VM350 PU Operating Configuration(s) : In front of face Operating mode (s) : Data Transmission Device Category : Portable Device Tx Frequency : 2405 – 2475 MHz Production tolerance : 12 dBm (Minimum) to 18 dBm (Maximum) Antenna gain : 2 dBi = 1.58 (num gain) Maximum source-based time- averaging duty factor : 9.7% = (9.7/100 x100%) Minimum separation distance : 5 mm Applicable FCC KDB : FCC KDB 447498 D01 v06 FCC KDB 865664 D02 v01r02 From above data, the source-based time-averaging output power is as follow: The Maximum Conducted Power = 18 dBm = 63.1 mW The Maximum conducted Power source-based time-averaging output power = (63.1 * 0.097) mW = 6.121 mW In the frequency range of 100MHz to 6GHz and test separation distance ≤ 5mm, the SAR Exclusion Threshold will be determined as follow, The SAR exclusion threshold = () )(/0.3GHzFTD× = 9.53 mW where TD = 5 mm and F(GHz) = 2.48 GHz Conclusion Since the calculated conducted source-based time-averaged output power is 6.121 mW, which is less than the SAR Exclusion Threshold at 5mm test separation distance 9.53 mW for general population and uncontrolled exposure, standalone SAR evaluation for general population exposure conditions, by measurement or numerical simulation is not required.

[Antenna Information] [2.4GHz Dipole Antenna] Manufacturer Name: Vtech Address: 23/F., Tai Ping Industrial Centre, Block 1. 57 Ting Kok Road, Tai Po, Hong Kong Ordering information: Model Number Antenna Description VM350 PU 2.4GHz Dipole Antenna Specification: Frequency Range 2405-2475 MHz Maximum Gain 2 dBi Type Dipole Bandwidth 70MHz ： Nominal Impedance ~50 ohms Connectors - Dimensions 123×2.5 mm [VTECH] [2.4GHz Dipole Antenna] Antenna pattern (maximum at 2441MHz) Coordination: [VTECH] [2.4GHz Dipole Antenna] Physical Dimension: F igure 1 Physical dimension (mm)

2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 42 TEST REPORT Report Number: 22070215HKG-002 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-247 Issue 2 Equipment (Parent Unit) FCC ID: EW780-1383-01 IC: 1135B-80138301A Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Assistant Supervisor Date: September 07, 2022 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22070215HKG-002 Page 2 of 42 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2020 Edition FCC ID: EW780-1383-01 FCC Model(s): VM350 PU VM350-2 PU IC Specification Standard: RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 Amendment 2, February 2021 IC: 1135B-80138301A HVIN: 35-201976PU PMN: VM350 PU, VM350-2 PU Vtech Model(s): VM350 PU, VM350-2 PU Type of EUT: Spread Spectrum Transmitter Description of EUT: Video Monitor – Parent Unit Sample Receipt Date: July 06, 2022 Date of Test: July 06, 2022 to August 24, 2022 Report Date: September 07, 2022 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-247 Issue 2 Certification. TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22070215HKG-002 Page 3 of 42 TABLE OF CONTENTS 1.0 TEST RESULTS SUMMARY & STATEMENT OF COMPLIANCE ............................................ 4 1.1 Summary of Test Results ................................................................................................. 4 1.2 Statement of Compliance ................................................................................................ 4 2.0 GENERAL DESCRIPTION ................................................................................................ 5 2.1 Product Description......................................................................................................... 5 2.2 Test Methodology ........................................................................................................... 5 2.3 Test Facility ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ..................................................................................... 6 3.1 Justification ..................................................................................................................... 6 3.2 EUT Exercising Software .................................................................................................. 7 3.3 Details of EUT and Description of Accessories ................................................................. 8 3.4 Measurement Uncertainty .............................................................................................. 8 4.0 TEST RESULTS ............................................................................................................... 9 4.1 Maximum Conducted Output Power at Antenna Terminals ........................................... 9 4.2 Maximum 20 dB RF Bandwidth ..................................................................................... 12 4.3 Minimum Number of Hopping Frequencies .................................................................. 15 4.4 Minimum Hopping Channel Carrier Frequency Separation ........................................... 17 4.5 Average Channel Occupancy Time ................................................................................ 19 4.6 Out of Band Conducted Emissions ................................................................................ 21 4.7 Field Strength Calculation.............................................................................................. 27 4.8 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions ............... 28 4.8.1 Radiated Emission Configuration Photograph ............................................................ 29 4.8.2 Radiated Emission Data .............................................................................................. 29 4.8.3 Radiated Emission Test Setup ..................................................................................... 30 4.9 AC Power Line Conducted Emission .............................................................................. 35 4.9.1 AC Power Line Conducted Emission Configuration Photograph ................................. 35 4.9.2 AC Power Line Conducted Emission Data .....................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No: HK22070215 i Configuration Photographs Worst-Case Line-Conducted Emissions (Front View) Baby Unit INTERTEK TESTING SERVICE Report No: HK22070215 ii Configuration Photographs Worst-Case Line-Conducted Emissions (Rear View) INTERTEK TESTING SERVICE Report No: HK22070215 iii Configuration Photographs Worst-Case Line-Conducted Emissions (Side View)

INTERTEK TESTING SERVICE Report No: HK22070215 Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22070215 Configuration Photographs Worst-Case Radiated Emissions (Rear View) INTERTEK TESTING SERVICE Report No: HK22070215 Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22070215 Configuration Photographs Worst-Case Radiated Emissions (Rear View)
