EW780-1385-00Video Baby Monitor

Note • This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not be used as such. Test your baby monitor You may test the baby monitor before initial use, and at regular times thereafter. Caution • For hearing protection, make sure the parent unit is more than 3 feet (1 meter) away from both baby units. If you hear any high- pitched noise, move the parent unit further until the noise stops. You can also press VOL on the parent unit to reduce the noise. 1. Make sure your baby unit and parent unit are on. 2. The parent unit displays images from the baby unit. • Speak towards the microphone of the baby unit. You will hear the sound at the parent unit. 3. If you have two baby units, view the image from one of them by switching cameras via menu. Then, repeat step 2. Note • When the parent unit displays No link to Camera, and the POWER LED light flashes, move the parent unit closer to the baby units (observe the minimum distance of 3 feet / 1 meter). Tip • Increase the speaker volume of the parent unit if you cannot hear the sounds transmitted from the baby units. Positioning the baby monitor Caution • Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s crib or playpen. Note • To avoid interference from other electronic devices, place your baby monitor at least 3 feet (1 meter) away from devices such as wireless routers, microwaves, cell phones and computers. 1. Place the baby units more than 3 feet (1 meter) away from your baby. 2. Adjust the angle of the baby unit camera to aim at your baby. 3. Place the parent unit more than 3 feet (1 meter) away from the baby units to avoid screeching noise. Caution • The default volume of your parent unit is level 3, and the maximum volume is level 5. If you experience high-pitched screeching noise from your baby monitor while positioning: -Make sure your baby units and parent unit are more than 3 feet (1 meter) apart, OR -Turn down the volume of your parent unit. Operating range The operating range of the baby monitor is up to 1000 feet (300 meters) outdoors. The actual operating range may vary depending on the environmental conditions and other interferences such as walls, doors and other obstructions. Power on or off the baby unit • Slide the ON/OFF switch to ON to turn on the baby unit. The POWER LED light turns on. • Slide the ON/OFF switch to OFF to turn off the baby unit. The POWER LED light turns off. Power on or off the parent unit • Slide the ON/OFF switch to ON to turn on the parent unit. The screen and the POWER LED light turns on. • Slide the ON/OFF switch to OFF to turn off the parent unit. The screen and the POWER LED light turns off. Adjust speaker volume For parent unit: • Press VOL /VOL on the parent unit to adjust the speaker volume. Note • The parent unit will be muted automatically when the parent unit is talking to the baby unit. When it is muted, appears on the screen. For baby unit: The baby unit speaker volume determines the lullaby volume and talkback volume transmitted from parent unit. The volume can be adjusted in the parent unit. 1. Press when the parent unit is idle. 2. Press or to choose , then press or . 3. Press or to choose . 4. Press or to choose the volume level of the baby unit, then press to confirm. Adjust LCD brightness You can change the brightness of the parent unit screen from Level 1 to Level 5. The LCD brightness is preset to Level 3. 1. Press when the parent unit is idle. 2. Press or to choose , then press or . 3. Press or to choose the desired level of brightness, then press to confirm your selection. Monitoring mode * for VM320-2 only Every time the parent unit is turned on, it displays a baby unit in SINGLE-CAM mode. If there are more two baby units in your system, you can also monitor your baby in PATROL mode. SINGLE-CAMThe screen displays image of a single baby unit in full screen. PATROL A single cam view that transitions to a different baby unit every 10 seconds. To switch from SINGLE-CAM to PATROL mode: 1. Press when the parent unit is idle. 2. Press or to choose , then press or to open the submenu. 3. Press or to select to enter PATROL mode to alternately view the image from one baby unit to the next one in every 10 seconds. To switch from PATROL to SINGLE-CAM mode: 1. Press when the parent unit is idle. 2. Press or to choose , then press or to open the submenu. 3. Press or to select a camera number to enter SINGLE-CAM mode. Note • If one or more paired baby units are powered off or disconnected during patrolling, the parent unit will keep searching until its power has run out or a baby unit is connected once again. 1Pair hole • Your baby units and parent unit provided are already paired. 2POWER LED light • On when the baby unit is turned on and is paired to the parent unit. • Flashes when the baby unit is not being viewed; or when the link to the parent unit is lost. 3Microphone 4Camera 5Infrared LEDs 6Light sensor 7 ON/OFF switch • Slide to turn on or off the baby unit. 8Speaker 9Power jack 10Wall mount holes NOTESNOTE • The rechargeable battery is pre-installed in your parent unit. • Use only the power adapters supplied with this product. • Make sure the baby monitor is not connected to a switch controlled electric outlet. • Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not designed to hold the weight of baby monitor, so do not connect them to any ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets. • Make sure the parent unit, the baby unit and the power adapter cords are out of reach of children. Connect the baby monitor Charge the parent unit battery When you have connected and turned on the parent unit, the battery will be charged automatically. The battery icon indicates the battery status (see the following table). NOTESNOTE Notes • The parent unit battery is fully charged after 11 hou…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd Add: 23/F Tai Ping Ind Center Block 1 57 Ting Kok Rd Tai Po NT, Hong Kong Telephone: (852)2680 5398 Fax: (852)2680 5252 E-mail: [email protected] QA-FR-170-B FCC Authorization Date: 2020/08/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, VTech Telecommunications Ltd, the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Add: 23/F Tai Ping Ind Center Block 1 57 Ting Kok Rd Tai Po NT, Hong Kong Telephone: (852)2680 5398 Fax: (852)2680 5252 E-mail: [email protected] FCC Confidential Authorization Date: 2020/08/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: EW780-1385-00 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, VTech Telecommunications Ltd hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Aug. 05, 2020 To whom it may concern, Multiple Models Confirmation Letter-BU I, the undersigned, hereby confirm that the family models are listed in the following table. These models are identical as follows: Electronics/electrical designs, including software & firmware Construction design/Physical design/Enclosure PCB layout (Others, please specify) The only differences between these models are the follows for marketing purpose: Color Cosmetic details Trade name Model Number (Others, please specify) Model VM2X51-ab BU is identical to model VM320-ab BU except for model designation and appearance. Model VM3X52-ab BU is identical to mode VM2X51-ab BU except for model designation and adaptor Suffix (“a, b, x”) represents Color code Packing configuration Others, please specify) x=any alphanumeric character is presenting different type packaging. a=any alphanumeric character or blank is presenting number of baby unit. b = any alphanumeric character or blank is presenting color of enclosure. For the product subject to authorization under FCC Declaration of Conformity: In addition, it is to confirm that all the below information 1) the U.S. responsible party, 2) FCC label artworks and location, 3) FCC required statement in the user manual are the same but different in the following model numbers only: Item No. New model Model Number Trade Name Remarks 1 YES VM2251 BU vtech 1 baby unit 2 YES VM2251-2 BU vtech 2 baby unit 3 YES VM2x51-ab BU vtech a baby unit 4 YES VM3252 BU vtech 1 baby unit 5 YES VM3252-2 BU vtech 2 baby unit 6 YES VM3X52-ab BU vtech a baby unit 7 YES VM320 BU vtech 1 baby unit 8 YES VM320-2 BU vtech 2 baby unit 9 YES VM320-ab BU vtech a baby unit All above model's FCC ID is EW780-1385-00, IC is 1135B-80138500. The sample being submitted to Bay Area Compliance Labs Corp.(Shenzhen) for conformity assessment is VM320 BU (test model) of the above list. Regards, Michael Tsui Approbation Supervisor

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 1 of 12 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS VM320 BU Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 2 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 3 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 4 of 12 VM3252 BU Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 5 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 6 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 7 of 12 Adapter 1 (VT05EUS06040) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 8 of 12 Adapter 1 Label (VT05EUS06040) Adapter 2 (S003GU0600040) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 9 of 12 Adapter 2 Label (S003GU0600040) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 10 of 12 Adapter 3 (VT05EUS06050) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 11 of 12 Adapter 3 Label (VT05EUS06050) Adapter 4 (S003GU0600050) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 12 of 12 Adapter 4 Label (S003GU0600050)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 1 of 9 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS VM320 BU Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 2 of 9 Antenna Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 3 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 4 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 5 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 6 of 9 VM3252 BU Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 7 of 9 Antenna Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 8 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200622003-RF Page 9 of 9

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200622003-00A FCC Part 15.247 Page 11 of 49 FCC §15.247 (i) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG  S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Frequency (MHz) Antenna Gain Tune Up Conducted Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm) (mW) 2405-2475 0 1 18.0 63.10 20 0.013 1.0 Note: To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Pass

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 TEST REPORT For VTech Telecommunications Ltd 23/F Tai Ping Ind Center Block 1 57 Ting Kok Rd Tai Po NT, Hong Kong FCC ID: EW780-1385-00 Report Type: Original Report Product Type: Video Baby Monitor Re port Number: RSZ200622003-00A Re port Date: 2020-08-26 Reviewed B y: Jimmy Xiao RF Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200622003-00A FCC Part 15.247 Page 2 of 49 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 SPECIAL ACCESSORIES ................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 7 EXTERNAL I/O CABLE .................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC §15.247 (i) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................................ 11 APPLICABLE STANDARD ............................................................................................................................................ 11 RESULT ...................................................................................................................................................................... 11 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 12 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ....................................................................................................................................... 13 TEST PROCEDURE .............................................................................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Adapter 1 (VT05EUS06040) Conducted Emissions - Front View Conducted Emissions - Side View Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz) Adapter 2 (S003GU0600040) Conducted Emissions - Front View Conducted Emissions - Side View Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz) Adapter 3 (VT05EUS06050) Conducted Emissions - Front View Conducted Emissions - Side View Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz) Adapter 4 (S003GU0600050) Conducted Emissions - Front View Conducted Emissions - Side View Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz)
