EW780-1410-00AAudio Baby Monitor - Baby Unit

Note • This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not be used as such. Test your baby monitor You may test the baby monitor before initial use, and at regular times thereafter. Caution • For hearing protection, make sure the parent unit is more than 6.5 feet (2 meters) away from the baby unit. If you hear any high-pitched noise, move the parent unit further until the noise stops. You can also press on the parent unit to lower or mute the noise. 1. Make sure your baby unit and parent unit are on. 2. Speak towards the microphone of the baby unit. You will hear the sound at the parent unit, and see the visual sound indicators light up. Note • When the POWER/LINK LED light flashes, move the parent unit closer to the baby unit (observe the minimum distance of 6.5 feet / 2 meters). You can also check if the baby monitor is connected to a live power socket and switched on. Tip • Increase the speaker volume of the parent unit if you cannot hear the sounds transmitted from the baby units. Positioning the baby monitor Caution • Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s crib or playpen. Note • To avoid interference from other electronic devices, place your baby monitor far away from devices such as wireless routers, microwaves, cell phones and computers. 1. Place the baby units more than 3 feet (1 meter) away from your baby. 2. Place the parent unit more than 6.5 feet (2 meters) away from the baby unit to avoid screeching noise. Caution • The default volume of your parent unit is Level 3, and the maximum volume is level 5. If you experience high-pitched screeching noise from your baby monitor while positioning: -Make sure your baby units and parent unit are more than 6.5 feet (2 meter) apart, OR -Turn down the volume of your parent unit. Operating range The operating range of the baby monitor is up to 1,500 feet (450 meters) outdoors or 160 feet (50 meters) indoors. The actual operating range may vary depending on the environmental conditions and other interferences such as walls, doors and other obstructions. Frequency control Crystal controlled PLL synthesizer Transmit frequency Baby unit: 902.7 MHz - 927.1 MHz Parent unit: 902.7 MHz - 927.1 MHz Channels 62 Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirements Baby unit adapter: Input: 100-120V AC 60Hz; Output: 6V DC @ 400mA Parent unit adapter: Input: 100-120V AC 60Hz; Output: 6V DC @ 400mA Parent unit battery: 2.4V NiMH battery Technical specifications Specifications are subject to change without notice. © 2022 VTech Communications, Inc. All rights reserved. 07/22. DM1111-X_CIB_V7 DM1111 DM1111-2 Enhanced Range Digital Audio Monitor Go to www.vtechphones.com to register your product for enhanced warranty support and the latest VTech product news. Congratulations on purchasing your new VTech product. Before using this product, please read Important safety instructions. This manual has all the feature operations and troubleshooting necessary to install and operate your new VTech product. Please review this manual thoroughly to ensure proper installation and operation of this innovative and feature-rich VTech product. For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com. What’s in the box Stra n gul at ion Haz ar d Ke e p this cor d o ut of r e ach o f ch il d ren. T h e cord n e eds t o be at l eas t t h ree fee t a w a y fr om t h e chil d at a ll t im e s . Do not use w i t h an e xtens io n cor d . Do n o t r e mo ve this t a g. É l o ig ne z ce c ord o n d e s enf a nt s . Le cordon d o i t se t r ou v e r à a u m o i n s tr oi s p ie d s d’ u n e nf a nt e t ce, en to ut temp s . N’ ut i li s ez p as d e ra l lon ge. N e r e t i r e z pa s c e t te é t i q u et te . M an t en ga est e c abl e f ue ra de l a alc a n ce de l o s ni ñ o s . E s t e cable d e b e e s tar p or lo me n o s t r es pi es f uera de l a a lcan c e del n i ñ o en t o do m omento . N o lo u s e con u n a ex t en s i ó n i n alámbri c a. N o qui t e es t a e ti quet a. Ri sq u e d’ ét r an gl em en t Ries go de e stra ng ula ció n Stra n gul at ion Haz ard Ke e p this cor d o ut of r e ach o f ch il dre n. T h e cord n e eds t o be at l e as t t h r ee fee t a w a y fr om t h e chil d at a ll t im e s . Do not use w i t h an e xtens io n co r d . Do n o t r e mo ve this t a g. É l o ig ne z ce c ord o n d e s enf a nt s . Le co rdon d o i t se t r ou v e r à au m o i n s tr oi s p ie d s d’ u n e nf a nt e t ce, en to ut temps . N’ ut i li s ez p as d e ra l lon ge . N e r et i r e z pa s c e t te é t i q u et te . M an t en ga e st e c able f ue ra de l a al c a n ce de l o s n i ño s . E s t e cable d e b e e s tar p or lo me n o s t r es pi es f uera de la a lcan c e del n i ñ o e n t o do m omento . N o lo u s e con u n a ext en s i ó n i n alámbri c a. N o qu i t e es t a e ti quet a. Ri sq u e d’ ét r an gl em en t Ries go de e s tra ng ula ción 1 set for DM1111 2 sets for DM1111-2 1 Connect the baby monitor 2 Before use >6.5ft (2m) Power on or off the baby unit • Press until the POWER light turns on. • Press until the POWER light turns off. Power on or off the parent unit • Press until the POWER / LINK light turns on. • Press until the POWER / LINK light turns off. Adjust parent unit speaker volume The speaker volume is preset to Level 3 on the parent unit. You can adjust to your preferred sound level. • Press to decrease the volume, and to increase the volume. Note • If you continue to press or when the volume reaches the minimum or maximum setting, the parent unit will beep twice. To mute the speaker volume • Press repeatedly until the volume reaches the minimum. Notes • When the parent unit is in mute, the visual sound indicator will still indicate the sound detected from the baby unit. …

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both VTech Communications, Inc. (“Agent”) and VTech Telecommunications Ltd. (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I Michael Tsui HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC & Intertek if there is any change in the status identified above. Applicant Company Name : VTech Telecommunications Ltd. Contact Name : Michael Tsui Address : 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Rd, Tai Po, Hong Kong Telephone No : +852 2680 5398 Email : [email protected] Applicant FRN : 0015973951 Signature: ____________________________________ 17 February 2023 Date: ____________________________________ I Chris Conrad HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to all certification applications to the FCC submitted by above applicant and agree to immediately notify the FCC & Intertek if there is change in this representation. Agent Company Name : VTech Communications, Inc. Contact Name : Chris Conrad Address : 9020 SW Washington Square Road, Tigard OR 97223 Telephone No : +1(503) 596-1212 Email : [email protected] Agent FRN : 0033411265 Signature: ____________________________________ 17 February 2023 Date: ____________________________________

Fo rm: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: VTech Telecommunications Ltd. FCC ID: EW780-1410-00A To whom it may concern, VTech Telecommunications Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] Mr. Michael Tsui Approbation Supervisor VTech Telecommunications Ltd. 17 February 2023

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Sep. 27, 2017 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Terry Chan/ Koo Wai Ip/ Kenneth Wong/ Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Sep 20, 2021 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-1410-00A Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (External)

BU LABEL Size: 24 x 21 mm R=0.5 MM Model: DM1111 BU S/N: XXXXXXXXXXX Model: DM1111-2 BU S/N: XXXXXXXXXXX Model: DM1111 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINA www.vtechphones.com VTech Customer Service 1-800-595-9511 Use only Supplied Adapter FCC ID: EW780-1410-00A IC: 1135B-80141000A HVIN: 35-201975BU MANUFACTURED IN CHINA www.vtechphones.com VTech Customer Service 1-800-595-9511 Use only Supplied Adapter FCC ID: EW780-1410-00A IC: 1135B-80141000A HVIN: 35-201975BU MANUFACTURED IN CHINA www.vtechphones.com VTech Customer Service 1-800-595-9511 Use only Supplied Adapter FCC ID: EW780-1410-00A IC: 1135B-80141000A HVIN: 35-201975BU A/V I.C.T.E. A/V I.C.T.E.A/V I.C.T.E.

INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK22080027 Equipment Photographs (Internal)

INTERTEK TESTING SERVICES RF exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498 D01 v06. For the 915MHz portion of the tested model, the measured EIRP power was within its production tolerance. The antenna gain is 0 dBi = 1.00 (num gain) and its maximum source- based time-averaging duty factor is 100%. From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The EIRP Power = 20 dBm = 100 mW The EIRP Power source-based time-averaging output power = (100 * 1) mW = 100 mW The power density at 20cm = 100 / 4πR 2 = 0.02 mW cm -2 In the frequency range of 902-928MHz, the MPE limit is 0.6 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the unit at least 20cm from nearby persons.”

2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 38 TEST REPORT Report Number: 22080027HKG-001 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-247 Issue 2 Equipment FCC ID: EW780-1410-00A IC: 1135B-80141000A Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Assistant Supervisor Date: October 10, 2022 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22080027HKG-001 Page 2 of 38 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. Manufacturer Name: VTech (Dongguan) Telecommunications Limited. Manufacturer Address: VTech Science Park, Xia Ling Bei Management Zone, Liaobu, Dongguan, Guangdong, China. FCC Specification Standard: FCC Part 15, October 1, 2021 Edition FCC ID: EW780-1410-00A FCC Model(s): DM1111 BU, DM1111-2 BU IC Specification Standard: RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 Amendment 2, February 2021 IC: 1135B-80141000A HVIN: 35-201975BU VTech Model(s): DM1111 BU, DM1111-2 BU PMN: DM1111 BU, DM1111-2 BU Type of EUT: Spread Spectrum Transmitter Description of EUT: Audio Baby Monitor - Baby Unit Sample Receipt Date: August 01, 2022 Date of Test: August 01, 2022 to September 23, 2022 Report Date: October 10, 2022 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-247 Issue 2 Certification. TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22080027HKG-001 Page 3 of 38 TABLE OF CONTENTS 1.0 TEST RESULTS SUMMARY & STATEMENT OF COMPLIANCE ............................................ 4 1.1 Summary of Test Results ................................................................................................. 4 1.2 Statement of Compliance ................................................................................................ 4 2.0 GENERAL DESCRIPTION ................................................................................................ 5 2.1 Product Description......................................................................................................... 5 2.2 Test Methodology ........................................................................................................... 5 2.3 Test Facility ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ..................................................................................... 6 3.1 Justification ..................................................................................................................... 6 3.2 EUT Exercising Software .................................................................................................. 7 3.3 Details of EUT and Description of Accessories ................................................................. 8 3.4 Measurement Uncertainty .............................................................................................. 8 4.0 TEST RESULTS ............................................................................................................... 9 4.1 Maximum Conducted Output Power at Antenna Terminals ........................................... 9 4.2 Maximum 20 dB RF Bandwidth ..................................................................................... 12 4.3 Minimum Number of Hopping Frequencies .................................................................. 15 4.4 Minimum Hopping Channel Carrier Frequency Separation ........................................... 17 4.5 Average Channel Occupancy Time ................................................................................ 19 4.6 Out of Band Conducted Emissions ................................................................................ 21 4.7 Field Strength Calculation.............................................................................................. 26 4.8 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions ............... 27 4.8.1 Radiated Emission Configuration Photograph ............................................................ 28 4.8.2 Radiated Emission Data .............................................................................................. 28 4.8.3 Radiated Emission Test Setup ..................................................................................... 29 4.9 AC Power Line Conducted Emission .............................................................................. 34 4.9.1 AC …

Text truncated - open the document above for the full version.

[VTECH DM1111] [900MHz wire Antenna] Model: DM1111 Device: BU Coordination: Antenna Description: This monopole antenna is optimized and used in the Baby Unit of DM1111. This antenna is directly soldered to the RF output on the main PCB. Model Number Description DM1111 BU 900MHz Monopole Antenna Antenna Specification: Item Specification Operating Frequency 902MHz - 928MHz Maximum Gain 0 dBi Antenna Type Monopole antenna Operation Bandwidth 26MHz Nominal Impedance ~50 Ohm Connectors NA Dimensions See details below Manufacturer Vtech Telecommunications Ltd Manufacturer Address 23/F, Tai Ping Industrial Centre, Blk1, 57 Ting Kok Road, Tai Po, Hong Kong Model Number ANT-DM1111BU-P-SU2-1 [VTECH DM1111] [900MHz wire Antenna] Antenna Pattern (915.1MHz): Max antenna gain is 0dBi. Antenna Dimensions:
