INTERTEK TESTING SERVICE FCC ID: EW780-1502-00A MPE Analysis Report The Equipment-Under-Test (EUT) is a Video Monitor - Baby Unit. It has a microcontroller and 2.4GHz RF module. The EUT is powered by a 5VDC AC/DC adaptor. For Maximum Permissible Exposure (MPE) evaluation of the unit, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498 D01 v06. For the Bluetooth portion of the unit, the measured powers among all the measured channels were within its production tolerance. The maximum source-based time-averaging duty factor is 100%. From these data and its operating configuration, the exposed power density at a distance (R) of 20 cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The EIRP radiated power = conducted power (with maximum tolerance) + antenna gain = 20 dBm + 0 dBi = 20 dBm (100 mW) The radiated (EIRP) source-based time-averaging output power = (100 * 1) mW = 100 mW The power density at 20 cm from the antenna = EIRP / 4 πR^2 = 0.02 mW cm-2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the unit at least 20cm from nearby persons.”

2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 42 TEST REPORT Report Number: 22060653HKG-001 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-247 Issue 2 Equipment FCC ID: EW780-1502-00A IC: 1135B-80150200A Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Assistant Supervisor Date: August 02, 2022 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22060653HKG-001 Page 2 of 42 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2020 Edition FCC ID: EW780-1502-00A FCC Model(s): VM5263 BU VM5263-2 BU IC Specification Standard: RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 Amendment 2, February 2021 IC: 1135B-80150200A HVIN: 35-201942BUA PMN: VM5263 BU, VM5263-2 BU VTech Model: VM5263 BU, VM5263-2 BU Type of EUT: Spread Spectrum Transmitter Description of EUT: Video Monitor - Baby Unit Serial Number: N/A Sample Receipt Date: June 13, 2022 Date of Test: June 13, 2022 to June 28, 2022 Report Date: August 02, 2022 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-247 Issue 2 Certification. TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22060653HKG-001 Page 3 of 42 TABLE OF CONTENTS 1.0 TEST RESULTS SUMMARY & STATEMENT OF COMPLIANCE ............................................ 4 1.1 Summary of Test Results ................................................................................................. 4 1.2 Statement of Compliance ................................................................................................ 4 2.0 GENERAL DESCRIPTION ................................................................................................ 5 2.1 Product Description......................................................................................................... 5 2.2 Test Methodology ........................................................................................................... 5 2.3 Test Facility ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ..................................................................................... 6 3.1 Justification ..................................................................................................................... 6 3.2 EUT Exercising Software .................................................................................................. 7 3.3 Details of EUT and Description of Accessories ................................................................. 8 3.4 Measurement Uncertainty .............................................................................................. 8 4.0 TEST RESULTS ............................................................................................................... 9 4.1 Maximum Conducted Output Power at Antenna Terminals ........................................... 9 4.2 Maximum 20 dB RF Bandwidth ..................................................................................... 12 4.3 Minimum Number of Hopping Frequencies .................................................................. 15 4.4 Minimum Hopping Channel Carrier Frequency Separation ........................................... 17 4.5 Average Channel Occupancy Time ................................................................................ 19 4.6 Out of Band Conducted Emissions ................................................................................ 21 4.7 Field Strength Calculation.............................................................................................. 27 4.8 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions ............... 28 4.8.1 Radiated Emission Configuration Photograph ............................................................ 29 4.8.2 Radiated Emission Data .............................................................................................. 29 4.8.3 Radiated Emission Test Setup ..................................................................................... 30 4.9 AC Power Line Conducted Emission .............................................................................. 35 4.9.1 AC Power Line Conducted Emission Configuration Photograph ................................. 35 4.9.2 AC Power Line Conducted Emission Data ....................................…

Text truncated - open the document above for the full version.

[VTECH] [2.4GHz Dipole Antenna] Model: VM5263 BU Antenna description: This dipole antenna is optimized and used in the Baby Unit in the baby monitor models. This antenna is directly soldered to the RF output in the main PCB. Ordering information: Model Number Description VM5263 BU 2.4GHz Dipole Antenna Specification: Operation Frequency Range 2405-2475 MHz Maximum Gain 0 dBi Type Dipole Operation bandwidth 70MHz Nominal Impedance ~50 ohms Connectors - Dimensions 120×2.7 mm Manufacturer Vtech Telecommunications Ltd Manufacturer address 23/F, Tai Ping Industrial Centre, Blk1, 57 Ting Kok Road, Tai Po, Hong Kong Model number ANT-VM5263-F-FH-1 [VTECH] [2.4GHz Dipole Antenna] Antenna pattern (2441MHz) (the frequency with maximum gain) Coordination: [VTECH] [2.4GHz Dipole Antenna] Physical Dimension: Figure 1 Physical dimension (mm)
