vtech Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and Report & Order 22-84 located at https://docs.fcc.gov/public/attachments/DOC-389524A l .pdf Applicant: VTech Telecommunications Ltd. FCC ID: EW780-1502-00B To whom it may concern, Pursuant to FCC Report & Order 22-84 section IV. Interim Freeze Order, paragraphs 264, 265, and 266, as an author 远 d representative ofVTech Telecommunications Ltd ., I attest that the equipment for which we are seeking equipment authorization through certification is not prohibited from receiving an equipment authorization; and VTech Telecommunications Ltd. is not an entity identified on the Covered List or an affiliate or subsidiary of an entity identified on the Covered List, established pursuant to 4 7 CFR§1.50002 . I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the company and agree to immediately notify lntertek if there is any change in the status identified above. 三 Mr. Michael Tsui Approbation Supervisor VTech Telecommunications Ltd. Fonn: RFT-AMER-TCB-OP-19m Date: 16 January 2023 Revision: l Page 1 of 1
VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Sep. 27, 2017 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Terry Chan/ Koo Wai Ip/ Kenneth Wong/ Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor
VTech Telecommunications Ltd Jul 21, 2022 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-1502-00B Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor
INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (External) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (External) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (External)
BU LABEL VM5263-2SIZE: 21.5x14 mm LABEL SIZE: 24X14 mm 6.2mm A/V I.C.T.E. Model: VM5263 BU S/N: XXXXXXXXXXX UPC: 735078046116DiSa: xxxxxxxxxxxxx Model: VM5263-2 BU S/N: XXXXXXXXXXX UPC: DiSa: xxxxxxxxxxxxx LABEL VM5263SIZE: 21.5x14 mm Model: VM5263 BU S/N: XXXXXXXXXXX UPC: 735078046116DiSa: xxxxxxxxxxxxx ᆇփ˖$ULDOᆇᅨ ˖ ˖䴰㾱࣐8月ᒦ࣐лࡂ㓯˄ᮠᆇн⭘࣐8月˅ ᶑ⸱ቪረ˖aPP PPᆇᅨቪረ˖aPP PPᆇᅨоᶑ⸱ѻࡽⲴ䰤䐍ѪPPޜᐞPP A/V I.C.T.E. MANUFACTURED IN CHINAFCC ID: EW780-1502-00BIC: 1135B-80150200BHVIN: 35-201837BU www.vtechphones.com VTech Customer Service1-800-595-9511 A/V I.C.T.E. MANUFACTURED IN CHINAFCC ID: EW780-1502-00BIC: 1135B-80150200BHVIN: 35-201837BU www.vtechphones.com VTech Customer Service1-800-595-9511 735078048288
INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal) INTERTEK TESTING SERVICE Report No.: HK22110155 Equipment Photographs VM5263 BU (Internal)
INTERTEK TESTING SERVICE FCC ID: EW780-1502-00B MPE Analysis Report The Equipment-Under-Test (EUT) is a Video Monitor - Baby Unit. It has a microcontroller and 2.4GHz RF module. The EUT is powered by a 5VDC AC/DC adaptor. For Maximum Permissible Exposure (MPE) evaluation of the unit, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the 2.4GHz RF portion of the unit, the measured powers among all the measured channels were within its production tolerance. The antenna gain is 0 dBi = 1 (num gain) and its maximum source-based time-averaging duty factor is 100%. From these data and its operating configuration, the exposed power density at a distance (R) of 20 cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The EIRP radiated power = conducted power (with maximum tolerance) + antenna gain = 20 dBm + 0 dBi = 20 dBm (100 mW) The radiated (EIRP) source-based time-averaging output power = (100 * 1) mW = 100 mW The power density at 20 cm from the antenna = EIRP / 4 πR^2 = 0.02 mW cm-2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the Baby unit at least 20cm from nearby persons.”
2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 42 TEST REPORT Report Number: 22110155HKG-001 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-247 Issue 2 Equipment FCC ID: EW780-1502-00B IC: 1135B-80150200B Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Assistant Supervisor Date: November 29, 2022 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22110155HKG-001 Page 2 of 42 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2021 Edition FCC ID: EW780-1502-00B FCC Model(s): VM5263 BU; VM5263-2 BU IC Specification Standard: RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 Amendment 2, February 2021 IC: 1135B-80150200B HVIN: 35-201837BU PMN: VM5263 BU, VM5263-2 BU VTech Model: VM5263 BU, VM5263-2 BU Type of EUT: Spread Spectrum Transmitter Description of EUT: Video Monitor - Baby Unit Serial Number: N/A Sample Receipt Date: November 04, 2022 Date of Test: November 17, 2022 Report Date: November 29, 2022 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-247 Issue 2 Certification. TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 22110155HKG-001 Page 3 of 42 TABLE OF CONTENTS 1.0 TEST RESULTS SUMMARY & STATEMENT OF COMPLIANCE ............................................ 4 1.1 Summary of Test Results ................................................................................................. 4 1.2 Statement of Compliance ................................................................................................ 4 2.0 GENERAL DESCRIPTION ................................................................................................ 5 2.1 Product Description......................................................................................................... 5 2.2 Test Methodology ........................................................................................................... 5 2.3 Test Facility ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ..................................................................................... 6 3.1 Justification ..................................................................................................................... 6 3.2 EUT Exercising Software .................................................................................................. 7 3.3 Details of EUT and Description of Accessories ................................................................. 8 3.4 Measurement Uncertainty .............................................................................................. 8 4.0 TEST RESULTS ............................................................................................................... 9 4.1 Maximum Conducted Output Power at Antenna Terminals ........................................... 9 4.2 Maximum 20 dB RF Bandwidth ..................................................................................... 12 4.3 Minimum Number of Hopping Frequencies .................................................................. 15 4.4 Minimum Hopping Channel Carrier Frequency Separation ........................................... 17 4.5 Average Channel Occupancy Time ................................................................................ 19 4.6 Out of Band Conducted Emissions ................................................................................ 21 4.7 Field Strength Calculation.............................................................................................. 27 4.8 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions ............... 28 4.8.1 Radiated Emission Configuration Photograph ............................................................ 29 4.8.2 Radiated Emission Data .............................................................................................. 29 4.8.3 Radiated Emission Test Setup ..................................................................................... 30 4.9 AC Power Line Conducted Emission .............................................................................. 35 4.9.1 AC Power Line Conducted Emission Configuration Photograph ................................. 35 4.9.2 AC Power Line Conducted Emission Data .........................................…
Text truncated - open the document above for the full version.
[VTECH] [2.4GHz Dipole Antenna] Model: VM5263 BU Antenna description: This dipole antenna is optimized and used in the Baby Unit in the baby monitor models. This antenna is directly soldered to the RF output in the main PCB. Ordering information: Model Number Description VM5263 BU 2.4GHz Dipole Antenna Specification: Operation Frequency Range 2405-2475 MHz Maximum Gain 0 dBi Type Dipole Operation bandwidth 70MHz Nominal Impedance ~50 ohms Connectors - Dimensions 120×2.7 mm Manufacturer Vtech Telecommunications Ltd Manufacturer address 23/F, Tai Ping Industrial Centre, Blk1, 57 Ting Kok Road, Tai Po, Hong Kong Model number ANT-VM5263-F-FH-1 [VTECH] [2.4GHz Dipole Antenna] Antenna pattern (2441MHz) (the frequency with maximum gain) Coordination: [VTECH] [2.4GHz Dipole Antenna] Physical Dimension: Figure 1 Physical dimension (mm)
INTERTEK TESTING SERVICE Report No: HK22040243 Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22040243 Configuration Photographs Worst-Case Radiated Emissions (Rear View) INTERTEK TESTING SERVICE Report No: HK22040243 Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22040243 Configuration Photographs Worst-Case Radiated Emissions (Rear View)
INTERTEK TESTING SERVICE Report No: HK22110155 i Configuration Photographs Worst-Case Line-Conducted Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22110155 ii Configuration Photographs Worst-Case Line-Conducted Emissions (Rear View) INTERTEK TESTING SERVICE Report No: HK22110155 iii Configuration Photographs Worst-Case Line-Conducted Emissions (Side View)
