EW780-2015-00DECT 6.0 Cordless Telephone - Base Unit

Specifications are subject to change without notice.© 2020 VTech Communications, Inc.All rights reserved. 04/20. DS6821-X_QSG_V1.0Document order number: 96-013017-010-100 Technical specifications Frequency control Crystal controlled PLL synthesizer Transmit frequency Handset: 1921.536-1928.448 MHzTelephone base: 1921.536-1928.448 MHz Channels DECT channel: 5 Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirement Handset: 2.4 VDC, AAA x 2, Ni-MH batteryTelephone base: 6V DC @ 400mACharger: 6V DC @ 400mA Memory Phonebook: 1000 memory locations; up to 30 digits and 15 characters Caller ID log: 50 memory locations; up to 24 digits and 15 characters Call block: 1000 entries Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. Quick start guide DS6821 DS6821-2 DS6821-3 DS6821-4 DS6821-17 DS6821-27 DS6821-37 DS6821-47 DECT 6.0 Cordless telephone with BLUETOOTH® wireless technology PhonebookThe phonebook can store up to 1000 entries, which are shared by all handsets. Each entry may consist of a telephone number up to 30 digits, and a name up to 15 characters.Add a phonebook entry Review phonebook entries Delete a phonebook entry When your desired phonebook entry display: Caller IDIf you subscribe to caller ID service, information about each caller appears after the first or second ring.The caller ID log stores up to 50 entries. Each entry has up to 24 digits for the phone number and 15 characters for the name.Review caller ID log entries Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. T Compatible with Hearing Aid T-Coil TIA -1083 The ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. Volume Press  - OR - Put the handset in the telephone base or charger End a home call Answer a home call Make a home call 1  Press   - OR - 2   Enter the phone number. ECO Handset 10:15p M 12/25 595-9511_ ECO Enter number 595-9511_ ECO Enter name ECO Mike Smith ECO ECO Handset 10:15p M 12/25 Mike Smith 800-595-9511 ECO Mike Smith 800-595-9511 ECO Delete entry ? ECO ECO Handset 10:15p M 12/25 Dial a caller ID log entry When your desired caller ID entry displays on the handset screen:  Press   - OR - - OR - Save a caller ID log entry to the phonebook Delete a caller ID log entry When your desired caller ID entry displays on the handset screen: When your desired caller ID entry displays on the handset screen: Press  ECO Mike Smith 595-9511 NEW 09:05p M 12/25 ECO Mike Smith 595-9511 NEW 09:05p M 12/25 ECO Mike Smith 595-9511 NEW 09:05p M 12/25 >To Phonebook ECO Enter number 800-595-9511_ ECO Mike Smiths_ ECO Important safety instructionsWhen using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following:1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or a swimming pool, nor in a wet basement or shower. 5. Do not place this product on an unstable table, shelf, stand or other unstable surfaces. 6. Avoid placing the telephone system in places with extreme temperature, direct sunlight, or other electrical devices. Protect your phone from moisture, dust, corrosive liquids and fumes. 7. Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided. 8. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home or office, consult your dealer or local power company. 9. Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on. 10. Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product. 11. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the telephone base or handset other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 12. Do not overload wall outlets and extension cords.13. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: • When the power supply cord or plug is damaged or frayed.• If liquid has been spilled onto the product.• If the product has been exposed to rain or water.• If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operation instructions. Improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation. • If the pro…

Text truncated - open the document above for the full version.

Specifications are subject to change without notice.© 2020 VTech Communications, Inc.All rights reserved. 03/20. VS112-X_QSG_V1.0Document order number: 96-013088-010-100 Technical specifications Frequency control Crystal controlled PLL synthesizer Transmit frequency Handset: 1921.536-1928.448 MHzTelephone base: 1921.536-1928.448 MHz Channels DECT channel: 5 Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirement Handset: 2.4 VDC, AAA x 2, Ni-MH batteryTelephone base: 6V DC @ 400mACharger: 6V DC @ 400mA Memory Phonebook: 1000 memory locations; up to 30 digits and 15 characters Caller ID log: 50 memory locations; up to 24 digits and 15 characters Call block: 1000 entries Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. Quick start guide VS112 VS112-2 VS112-3 VS112-4 VS112-17 VS112-27 VS112-37 VS112-47 DECT 6.0 Cordless Answering System with Smart Call Blocker PhonebookThe phonebook can store up to 1000 entries, which are shared by all handsets. Each entry may consist of a telephone number up to 30 digits, and a name up to 15 characters.Add a phonebook entry Review phonebook entries Delete a phonebook entry When your desired phonebook entry display: Caller IDIf you subscribe to caller ID service, information about each caller appears after the first or second ring.The caller ID log stores up to 50 entries. Each entry has up to 24 digits for the phone number and 15 characters for the name.Review caller ID log entries Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. T Compatible with Hearing Aid T-Coil TIA -1083 The ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. Disclaimer and Limitation of LiabilityVTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product.Company: VTech Communications, Inc.Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United StatesPhone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada Volume Press  - OR - Put the handset in the telephone base or charger End a home call Answer a home call Make a home call 1  Press   - OR - 2   Enter the phone number. ECO Handset 10:15p M 12/25 595-9511_ ECO Enter number 595-9511_ ECO Enter name ECO Mike Smith ECO ECO Handset 10:15p M 12/25 Mike Smith 800-595-9511 ECO Mike Smith 800-595-9511 ECO Delete entry ? ECO ECO Handset 10:15p M 12/25 Mike Smith 595-9511 ECO Dial a caller ID log entry When your desired caller ID entry displays on the handset screen:  Press   - OR - - OR - Save a caller ID log entry to the phonebook Delete a caller ID log entry When your desired caller ID entry displays on the handset screen: When your desired caller ID entry displays on the handset screen: Press  ECO Mike Smith 595-9511 NEW 09:05p M 12/25 ECO Mike Smith 595-9511 NEW 09:05p M 12/25 ECO Mike Smith 595-9511 NEW 09:05p M 12/25 >To Phonebook ECO Edit number 800-595-9511_ ECO Edit name Mike Smiths_ ECO Important safety instructionsWhen using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following:1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or a swimming pool, nor in a wet basement or shower. 5. Do not place this product on an unstable table, shelf, stand or other unstable surfaces. 6. Avoid placing the telephone system in places with extreme temperature, direct sunlight, or other electrical devices. Protect your phone from moisture, dust, corrosive liquids and fumes. 7. Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided. 8. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home or office, consult your dealer or local power company. 9. Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on. 10. Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product. 11. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the telephone base or handset other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 12. Do not overload wall outlets and extension cords.13. Unplug this product from the wall outlet and refer servicing to an authorized servi…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification Mar. 19, 2020 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Limited do hereby authorize Intertek Testing Services (Mr. Terry Chan/ Kenneth Wong/ Ms. Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Mar. 19. 2020 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-2015-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd 31 March, 2020 To whom it may concern, Declarations FCC ID: EW780-2015-00 IC: 1135B-80201500 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit 1 Switch-off companion device NA 2 On hook by companion device B 3 Switch-off device NA 4 On hook on device side NA 5 Remove power from device A 6 Remove power from companion device B A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. 5. M L of base unit declared by manufacturer are 30dBm. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES External Photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES External Photos FCC ID: EW780-2015-00 IC: 1135B-80201500

Text: engraved in raised 0.3mm CORDLESS TELEPHONE DC 6V 400mA VTech Customer Service 1-800-595-9511 www.vtechphones.com Text : Recessed 0.3mm High Gloss Text : Recessed 0.3mm High Gloss Model: DS6821SN: XXXXXXXXXXXX CAUTION Use Only Supplied Battery or Battery BT262342 FCC ID: EW780-2015-00 IC: 1135B-80201501 HVIN: 35-201326HS Model: DS6821 SN: XXXXXXXXXXXX Model: DS6801 SN: XXXXXXXXXXXX Model: DS6821-2 SN: XXXXXXXXXXXX Model: DS6821-3 SN: XXXXXXXXXXXX SN Label 20X10 mm Model: DS6801-07 SN: XXXXXXXXXXXX Model: VS112 SN: XXXXXXXXXXXX Model: VS112-0 SN: XXXXXXXXXXXX Model: VS112-2 SN: XXXXXXXXXXXX Model: VS112-3 SN: XXXXXXXXXXXX Model: VS112-4 SN: XXXXXXXXXXXX Model: VS112-17 SN: XXXXXXXXXXXX Model: VS112-27 SN: XXXXXXXXXXXX Model: VS112-37 SN: XXXXXXXXXXXX Model: VS112-47 SN: XXXXXXXXXXXX Model: DS6821-4 SN: XXXXXXXXXXXX Model: DS6821-17 SN: XXXXXXXXXXXX Model: DS6821-27 SN: XXXXXXXXXXXX Model: DS6821-37 SN: XXXXXXXXXXXX Model: DS6821-47 SN: XXXXXXXXXXXX Model: VS112-07 SN: XXXXXXXXXXXX Use Only Supplied Adapter 6V Model: DS6821 S/N: XXXXXXXXXXXXXXXXXXXX SN Label 28X10 mm Model: DS6821 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-2 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-4 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-17 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-27 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-37 S/N: XXXXXXXXXXXXXXXXXXXX Model: DS6821-47 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-2 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-4 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-17 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-27 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-37 S/N: XXXXXXXXXXXXXXXXXXXX Model: VS112-47 S/N: XXXXXXXXXXXXXXXXXXXX I.T.E. RINGER EQUIVALENCE: 0.1A HAC USOC JACK: RJ11C/RJ11W FCC ID : EW780-2015-00 IC: 1135B-80201500 COMPLIES WITH 47 CFR PART 68 Reg. No.: US: EW7W401A80-201500 HVIN:35-201325BS DC 6V 400mA DS6821-x & VS112-x ENGRAVING FILE 4H20 Accessory I.T.E. 6V

INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-2015-00 IC: 1135B-80201500

INTERTEK TESTING SERVICES FCC ID: EW780-2015-00 RF exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the 1.9GHz DECT Transmission of tested model: DS6821, the measured powers among all the measured channels were within its production tolerance: +16 dBm (Minimum) and +21 dBm (Maximum). The antenna gain of DS6821 is 0 dBi = 1.00 (num gain) and its maximum source-based time-averaging duty factor is 25.0% (6/24 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 21 dBm = 125.9 mW The Conducted Power source-based time-averaging output power = (125.9 * 0.250) mW = 31.47 mW The power density at 20cm = 31.47 *1.00/ 4πR 2 = 0.0063 mW cm -2 For the 2.4GHz Bluetooth Transmission of tested model: DS6821, the measured powers among all the measured channels were within its production tolerance: -6 dBm (Minimum) and +4 dBm (Maximum). The antenna gain of DS6821 is 0 dBi = 1.00 (num gain) and its maximum source-based time-averaging duty factor is 83.3% (5/6 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 4 dBm = 2.5 mW The Conducted Power source-based time-averaging output power = (2.5 * 0.833) mW = 2.09 mW The power density at 20cm = 2.09 *1.00/ 4πR 2 = 0.0004 mW cm -2 INTERTEK TESTING SERVICES FCC ID: EW780-2015-00 RF exposure - 1 of 1 Per KDB 447498 D01 v06, simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on calculated or measured field strengths or power density, is ≤ 1.0. The MPE ratio for DECT Transmission can be calculated as follow: = The power density at 20cm / MPE limit = 0.0063 mW cm -2 / 1.0 mW cm -2 = 0.0063 The MPE ratio for Bluetooth Transmission can be calculated as follow: = The power density at 20cm / MPE limit = 0.0004 mW cm -2 / 1.0 mW cm -2 = 0.0004 The sum of the MPE ratios for all simultaneous transmitting antennas = 0.0063 + 0.0004 = 0.0067 As the sum of MPE ratios for all simultaneous transmitting antennas is ≤ 1.0, simultaneous transmission MPE test exclusion will be applied. Conclusion In frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As simultaneous transmission MPE test exclusion is applied and the measured power density at 20cm from all the standalone transmissions is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.”

2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 56 TEST REPORT Report Number: 20010232HKG-001 Application For Original Grant of 47 CFR Part 15 Certification Single New of RSS-213 Issue 3 Equipment Certification Unlicensed Personal Communication Service Devices/ 2 GHz License-exempt Personal Communications Service Devices (Base Unit) FCC ID: EW780-2015-00 IC: 1135B-80201500 Prepared and Checked by: Approved by: Signed On File Leung Chiu Kuen, Stanley Engineer Tang Kwan Mo, Jess Lead Engineer Date: April 02, 2020 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 20010232HKG-001.doc Page 2 of 56 GENERAL INFORMATION Grantee: VTech Telecommunications Ltd. Grantee Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2018 Edition FCC ID: EW780-2015-00 FCC Model(s): DS6821, DS6821-2, DS6821-3, DS6821-4, DS6821-17, DS6821-27, DS6821-37, DS6821-47, DS682Z-XY, VS112, VS112-2, VS112-3, VS112-4, VS112-17, VS112-27, VS112-37, VS112-47, VS112-ab IC Specification Standard: RSS-213 Issue 3, March 2015 RSS-Gen Issue 5, April 2018 IC: 1135B-80201500 HVIN: 35-201325BS VTech Model(s): VS112-1S, VS112-2S, VS112-3S, VS112-4S, VS112-1W, VS112- 2W, VS112-3W, VS112-4W PMN: VS112-1S/VS112-2S/VS112-3S/VS112-4S/VS112-1W/VS112- 2W/VS112-3W/VS112-4W Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: DECT 6.0 Cordless Telephone - Base Unit Serial Number: N/A Sample Receipt Date: January 09, 2020 Date of Test: January 13 - March 25, 2020 Report Date: April 02, 2020 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-213 Issue 3 Certification. TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 20010232HKG-001.doc Page 3 of 56 TABLE OF CONTENTS 1.0 TEST RESULTS SUMMARY & STATEMENT OF COMPLIANCE ............................................ 5 1.1 Summary of Test Results ................................................................................................ 5 1.2 Statement of Compliance .............................................................................................. 6 2.0 GENERAL DESCRIPTION ................................................................................................ 7 2.1 Product Description......................................................................................................... 7 2.2 Technical Description ...................................................................................................... 7 2.3 Test Methodology ........................................................................................................... 7 2.4 Test Facility ..................................................................................................................... 7 3.0 SYSTEM TEST CONFIGURATION .................................................................................... 8 3.1 Justification ..................................................................................................................... 8 3.2 Radiated Emission Test Setup ......................................................................................... 9 3.3 AC Line Conducted Emission Test Setup ........................................................................ 10 3.4 Conducted Emission Test Configuration ........................................................................ 11 3.5 Conducted Monitoring and Operational Test Configuration ......................................... 11 3.6 EUT Exercising Software ................................................................................................ 11 3.7 Details of EUT and Description of Accessories ............................................................... 12 3.8 Measurement Uncertainty ............................................................................................ 12 4.0 MEASUREMENT RESULTS ........................................................................................... 13 4.1 Antenna Requirement ................................................................................................... 13 4.2 Digital Modulation Techniques...................................................................................... 13 4.3 Emission Bandwidth ...................................................................................................... 14 4.4 Directional Gain of the Antenna .................................................................................... 16 4.5 Peak Transmit Power ................................................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 Radiated Emission - Dect Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 Radiated Emission - Bluetooth Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 AC Conducted Emission - Dect Front View Side View 1 INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 AC Conducted Emission Side View 2 INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 AC Conducted Emission - Bluetooth Front View Side View 1 INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: EW780-2015-00 IC: 1135B-80201500 AC Conducted Emission Side View 2
