Complete user’s manual BL102/BL102-2/BL102-3/ BL102-4/BL102-5 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting Congratulations on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information section on pages 2-2 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. This telephone meets the California Energy Commission regulations for energy consumption. Your telephone is set up to comply with the energy-conserving standards right out of the box. No further action is necessary. This telephone system is compatible with certain AT&T DECT 6.0 cordless headsets. Visit www.telephones.att.com/headsets for a list of compatible cordless headsets. Model number: BL102 (one handset) BL102-2 (two handsets) BL102-3 (three handsets) BL102-4 (four handsets) BL102-5 (five handsets) Type: DECT 6.0 cordless telephone/answering system with caller ID/call waiting Serial number: ________________________________________________________ Purchase date: ________________________________________________________ Place of purchase: _____________________________________________________________ Both the model and serial numbers of your AT&T product can be found on the bottom of the telephone base. Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. © 2020 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. ­ ̧¿ ̧ûÂÁ ̧Ƽ· ̧ÁǼè ̧·ʼǻÇ»¼Æ¿ÂºÂ» ́É ̧Å ̧·È¶ ̧·ÁÂ¼Æ ̧ ́Á·¼ÁÇ ̧Ź ̧Å ̧Á¶ ̧Ê» ̧Á used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest ̧Á ̧źÌ ̧ﶼ ̧Á¶ÌºÈ¼· ̧¿¼Á ̧Æ Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Telephone line cord Power adapter for telephone base Wall-mount bracket Quick start guideSmart call μ¿Â¶¾ ̧Å¿ ̧ ́ë ̧Ç Telephone base Battery for cordless handset (1 for BL102) (2 for BL102-2) (3 for BL102-3) (4 for BL102-4) (5 for BL102-5) Cordless handset (1 for BL102) (2 for BL102-2) (3 for BL102-3) (4 for BL102-4) (5 for BL102-5) Charger for cordless handset with power adapter installed (1 for BL102-2) (2 for BL102-3) (3 for BL102-4) (4 for BL102-5) Battery compartment cover (1 for BL102) (2 for BL102-2) (3 for BL102-3) (4 for BL102-4) (5 for BL102-5) Quick start guide BL102/BL102-2/BL102-3/ BL102-4/BL102-5 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting THIS SIDE UP / CE CÔTÉ VERS LE HAUT Battery Pack / Bloc-piles :BT183342/BT283342 (2.4V 400mAh Ni-MH)WARNING / AVERTISSEMENT :DO NOT BURN OR PUNCTURE BATTERIES.NE PAS INCINÉRER OU PERCER LES PILES.Made in China / Fabriqué en chine CR1535 Complete user’s manual BL102/BL102-2/BL102-3/ BL102-4/BL102-5 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting Table of contents Getting started Quick reference guide - handset ......... 1 Quick reference guide - telephone base ...................................................................3 Installation ......................................................... 4 Telephone base and charger installation ....................................................5 Telephone base installation ..............5 Charger installation ................................5 Battery installation and charging ...... 6 Installation options ...................................... 8 Tabletop to wall-mount installation ................................................ 8 Wall-mount to tabletop installation ................................................ 9 Telephone settings Handset settings ......................................... 10 Ringer volume .......................................... 11 Ringer tone ................................................. 11 Set date/time ...........................................12 LCD language ............................................13 Caller ID announce ................................13 Set speed dial voicemail number ..................................................... 14 Voicemail (visual message waiting) indicator ................................15 Clear voicemail indicator ..................15 Rename handset ................................... 16 Key tone ...................................................... 16 Use caller ID to automatically set date and time ................................17 Home area code .....................................17 Dial mode ................................................... 18 Web address ............................................. 18 QUIET mode .............................................. 18 Telephone operation Handset operation ..................................... 19 Making a call ............................................. 19 On hook dialing (predialing) .......... 19 Answering a call ..................................... 19 Ending a call .............................................. 19 šÈÇÂÂæ ........................................................ 19 Temporary ringer silencing ............ 19 Speakerphone .........................................20 Last number redial ...............................20 Equalizer .......................................................21 Options while on calls ...........…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification Mar. 24, 2020 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Kenneth Wong/ Ms. Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Mar. 24. 2020 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-2062-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd 31 March, 2020 To whom it may concern, Declarations FCC ID: EW780-2062-00 IC: 1135B-80206201 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Handset Unit 1 Switch-off companion device NA 2 On hook by companion device NA 3 Switch-off device NA 4 On hook on device side C 5 Remove power from device C 6 Remove power from companion device A A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. 5. M L of handset declared by manufacturer are 30dBm. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor
