EW780-2522-01Video Monitor - Parent Unit

Touch and learn! Touch and learn! LF930HD LF930-2HD 7” High Definition7” High Definition Pan & Tilt MonitorPan & Tilt Monitor Need help? Visit leapfrog.com/support Parent Guide This guide contains important information. Please keep it for future reference. Read our complete warranty policy online at leapfrog.com/warranty. Visit our website leapfrog.com leapfrog.com for more information about products, downloads, resources and more. Scan the QR code to enter the Online Manual: Or go to www.leapfrog.zendesk.com UL STD. 62368-1 CERTIFIED TO CSA STD. C22.2 NO.62368-1 CONFORMS TO Important Safety Instructions The applied nameplate is located at the bottom of the Baby Unit’s base. When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Follow all warnings and instructions marked on the product. 2. Adult setup is required. 3. CAUTION: Do not install the Baby Unit at a height above 2 meters. 4. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will continue working properly for any given period of time. Further, this is not a medical device and should not be used as such. This product is intended to assist you in supervising your baby. 5. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet basement or shower. 6. CAUTION: Use only the battery provided. There may be a risk of explosion if a wrong type of battery is used for the Parent Viewer. The battery cannot be subjected to high or low extreme temperature and low air pressure at high altitude during use, storage or transportation. Disposal of battery into fire or a hot oven, or mechanically crushing or cutting or the battery can result in an explosion. Leaving the battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid of gas. Battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. Dispose of used battery according to the information in The RBRC seal. 7. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the product. Power adapter information: Baby Unit output: Output: 5V DC 1.5A; VTech Telecommunications Ltd.; Model: VT07EUS05150 Parent Viewer output: Output: 5V DC 2A; VTech Telecommunications Ltd.; Model: VT07EUS05200 Rechargeable battery information: Zhuhai Great Power Energy Co., Ltd.; Lithium battery, 3.7V 5000mAh; Model: GSP806090-5Ah-3.7V-1S1P 8. The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under- the-table or cabinet outlet. 9. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible. 10. Unplug this product from the wall outlet before cleaning. 11. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation. 12. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on or crimped. 13. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or local power company. 14. Do not overload wall outlets or use an extension cord. 15. Do not place this product on an unstable table, shelf, stand or other unstable surfaces. 16. This product should not be placed in any area where proper ventilation is not provided. Slots and openings in the back or bottom of this product are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. 17. Never push objects of any kind into this product through the slots because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product. 18. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the product other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 19. You should test the sound reception every time you turn on the units or move one of the components. 20. Periodically examine all components for damage. 21. There is a very low risk of privacy loss when using certain electronic devices, such as baby monitors, cordless telephones, etc. To protect your privacy, make sure the product has never been used before purchase, reset the baby monitor periodically by powering off and then powering on the units, and power off the baby monitor if you will not use it for some time. 22. Children should be supervised to ensure that they do not play with the product. 23. The product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. SAVE THESE INSTRUCTIONS Cautions 1. Use and store the product at a temperature between 32 o F (0 o C) and 104 o F (40 o C). 2. Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source. 3. Batteries should not be exposed to excessive heat such as bright…
