EW780-2529-00AVideo Baby Monitor

To keep this product working well and looking good, follow these guidelines: • Avoid placing it near heating appliances and devices that generate electrical noise (for example, motors or fluorescent lamps). • DO NOT expose it to direct sunlight or moisture. • Avoid dropping the product or treating it roughly. • Clean with a soft damp cloth. • DO NOT immerse the parent unit and the baby unit in water and do not clean them under running water. • DO NOT use cleaning spray or liquid cleaners. • Make sure the parent unit and the baby unit are dry before you connect them to the mains again. When you are not going to use the video monitor for some time, store the parent unit, the baby unit and the adapters in a cool, dry place. Below are the questions most frequently asked about the video monitor. Can I turn the parent unit display screen off but keep hearing sounds from the baby unit? Yes, press | LCD ON/OFF on the parent unit to turn off the screen. The parent unit display will also dim automatically after being inactive for some time. In both instances, you will still be able to hear all sounds from the baby unit. Press any key to turn the screen back on. Why is the baby unit not responding normally? Try the following (in the order listed) for a common cure: 1. Disconnect the power to the baby unit. 2. Wait a few minutes before connecting power back to the baby unit. 3. Reboot the parent unit. Why is my screen in black and white? The baby unit has a light sensor that measures ambient light. When the ambient light is dim, such as during night time or in a dark room, the baby unit activates its infrared LEDs, and displays the camera images in black and white night vision. Why does my baby unit show offline? Why is the connection lost every now and then? The baby unit may have lost connection to the Wi-Fi router. Check your network and router settings. Other electronic products may cause interference with your baby unit. Try installing your baby unit as far away from these electronic devices as possible. Why can’t I hear a sound/Why can’t I hear my baby crying? The parent unit speaker volume may be too low. Press on the parent unit to increase the volume. You may have set a low sound sensitivity level. Set the sound sensitivity to a higher level. For details, go to www.vtechphones.com for online help topics. Frequently asked questions General product care Storage mount the baby unit (optional) 1. Place the wall mount bracket on a wall and then use a pencil to mark two holes in parallel. Remove the wall mount bracket and drill two holes in the wall (7/32 inch drill bit). NOTESNOTE Notes • Check for reception strength and camera angle of the baby unit before drilling the holes. • The types of screws and plugs you need depend on the composition of the wall. You may need to purchase the screws and plugs separately to mount your baby units. 2. If you drill the holes into a stud, go to step 3. • If you drill the holes into an object other than a stud, insert the wall plugs into the holes. Tap gently on the ends with a hammer until the wall plugs are flush with the wall. 3. Align the wall mount bracket and screws with the holes in the wall as shown. Tighten the screw in the middle hole first, so that the wall mount bracket position is fixed. You can tighten the other screw in the top hole. 3. Insert the screws into the holes and tighten the screws until only 1/4 inch of the screws are exposed. 4. Place the baby unit on the wall mount bracket, and then slide it forward until it locks into place. Align the holes on the wall mount bracket with the screws on the wall, and slide the wall mount bracket down until it locks into place. 5. You can maximize your baby unit’s viewing angles by tilting the wall mount bracket. Hold the baby unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket. Tilt your baby unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the joint and secure the angle. OR 4. Place the baby unit on the wall mount bracket, and then slide it forward until it locks into place. Connect the power adapter to the baby unit and a power supply. 1 2 Need help? Use your smartphone or mobile device to access our online help. • Go to https://help.vtechphones.com/RM5766HD or https://help.vtechphones.com/RM5766-2HD; OR • Scan the QR code on the right. Launch the camera app or QR code scanner app on your smartphone or tablet. Hold the device’s camera up to the QR code and frame it. Tap the notification to be redirected to the online help page. -If the QR code is not clearly displayed, adjust your camera’s focus by moving your device closer or further away until the image is clear. If you would like to contact us, visit https://help.vtechphones.com/cs. You can also call our Customer Support at 1-844-848-8324 (1-844-84-VTECH) [in US] or 1-888-211-2005 [in Canada] for help. Test the sound level and position the baby monitor Basic operation S m For instructions and guides to make the best use of your baby monitor, and for the latest information and support, check out our online help topics and FAQs. The online help page will also be updated periodically to reflect product system updates. If you plan to install your baby unit in a designated location, and use your home Wi-Fi network to connect your video monitor, you need to test which of your selected monitoring areas within the house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your parent unit’s Wi-Fi signal indicator to assist in checking. Once you have identified the suitable location, you can install your baby unit. Adjust the distance between your baby unit and the Wi-Fi router if needed. • Surroundings and obstructing factors, such as distance, electrical appliances, and internal walls, may reduce Wi-Fi signal. test the location for the baby unit Talk to your baby via the baby unit 1. Press and hold th…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: VTech Telecommunications Ltd. FCC ID: EW780-2529-00A To whom it may concern, VTech Telecommunications Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] Mr. Michael Tsui Approbation Supervisor VTech Telecommunications Ltd. 25 January 2024

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Sep. 27, 2017 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Terry Chan/ Koo Wai Ip/ Kenneth Wong/ Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Oct 16, 2023 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-2529-00A Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (External) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (External) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (External) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (External) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (External)

RM5766-XHD UNIT LABEL BU Label 34.6x16.6mm HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5766HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5766HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5766-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. RM5866HD Label size: 105X42mm BU LABELGB LABEL Model: RM5866HD BT MAC: XXXXXXXXXXX S/N: XXXXXXXXXXX S/N: 11 digits, the serial no. is made in VTT barcode system. DiSa: Download from system UPC/DiSa: Font size : Arial ,5 pt. 1.字体：Arial 2.字符UPC：&Disa：需要加粗并加下划线（数字不用加粗） 3.条码尺寸：55~60mm*8mm 4.字符尺寸：55~60mm*2mm 5.字符与条码之前的间距为1mm 6.公差+/- 0.5mm UPC: 7- 3507805309 -1 DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX 55~60mm 1mm 8mm 55~60mm Disa Barcode notes: UPC: 7- 3507805309 -1 DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX UPC: 7- 3507805309 -1 DiSa: xxxxxxxxxxxxx HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5866HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. RM5866-2HD Label size: 94.6x50.2 mm BU LABELGB LABEL Model: RM5866-2HD BT MAC: XXXXXXXXXXX BT MAC: XXXXXXXXXXX S/N: XXXXXXXXXXX S/N: 11 digits, the serial no. is made in VTT barcode system. DiSa: Download from system UPC/DiSa: Font size : Arial ,5 pt. 1.字体：Arial 2.字符UPC：&Disa：需要加粗并加下划线（数字不用加粗） 3.条码尺寸：55~60mm*8mm 4.字符尺寸：55~60mm*2mm 5.字符与条码之前的间距为1mm 6.公差+/- 0.5mm DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX 55~60mm 1mm 8mm 55~60mm Disa Barcode notes: DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX DiSa: xxxxxxxxxxxxx HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5866-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. DiSa: xxxxxxxxxxxxx HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM5866-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. RM7766-XHD UNIT LABEL BU Label 34.6x16.6mm HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM7766HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM7766HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. HVIN: 35-400515BU V2 HVIN: 35-400515BU MANUFACTURED IN CHINA FCC ID: EW780-2529-00A IC: 1135B-80252900A V2 WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx Model: RM7766-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. BU LABELGB LABEL Model: RM7866HD BT MAC: XXXXXXXXXXXXXX S/N: XXXXXXXXXXX DiSa: xxxxxxxxxxxxx S/N: 11 digits, the serial no. is made in VTT barcode system. DiSa: Download from system UPC/DiSa: Font size : Arial ,5 pt. 1.字体：Arial 2.字符UPC：&Disa：需要加粗并加下划线（数字不用加粗） 3.条码尺寸：55~60mm*8mm 4.字符尺寸：55~60mm*2mm 5.字符与条码之前的间距为1mm 6.公差+/- 0.5mm UPC: 7- 3507805370 -1 DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX 55~60mm 8mm 55~60mm Disa Barcode notes: UPC: 7- 3507805370 -1 DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX MANUFACTURED IN CHINA WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx FCC ID: EW780-2529-00A IC: 1135B-80252900A UPC: 7- 3507805370 -1 Model: RM7866HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. RM7866HD Label size: 89.6X42mm BU LABELGB LABEL Model: RM7866-2HD BT MAC: XXXXXXXXXXXXXX BT MAC: XXXXXXXXXXXXXX S/N: XXXXXXXXXXX S/N: 11 digits, the serial no. is made in VTT barcode system. DiSa: Download from system UPC/DiSa: Font size : Arial ,5 pt. 1.字体：Arial 2.字符UPC：&Disa：需要加粗并加下划线（数字不用加粗） 3.条码尺寸：55~60mm*8mm 4.字符尺寸：55~60mm*2mm 5.字符与条码之前的间距为1mm 6.公差+/- 0.5mm UPC: x-xxxxxxxxx-x DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX 55~60mm 8mm 55~60mm Disa Barcode notes: UPC: x-xxxxxxxxxx-x DiSa: xxxxxxxxxxxxxxx DiSa Barcode S/N: XXXXXXXXXXX RM7866-2HD Label size: 89.6X50.2mm HVIN: 35-400515BU V2 DiSa: xxxxxxxxxxxxx MANUFACTURED IN CHINA WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx FCC ID: EW780-2529-00A IC: 1135B-80252900A UPC: x- xxxxxxxxxx -x Model: RM7866-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E. HVIN: 35-400515BU V2 DiSa: xxxxxxxxxxxxx MANUFACTURED IN CHINA WIFI MAC: xxxxxxxxxxxxxx BT MAC: xxxxxxxxxxxxxx FCC ID: EW780-2529-00A IC: 1135B-80252900A UPC: x- xxxxxxxxxx -x Model: RM7866-2HD BU S/N: XXXXXXXXXXX A/V I.C.T.E.

INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal) INTERTEK TESTING SERVICES FCC ID: EW780-2529-00A IC: 1135B-80252900A Equipment Photographs (Internal)

INTERTEK TESTING SERVICE FCC ID: EW780-2529-00A MPE Analysis Report The Equipment-Under-Test (EUT) is a Video Monitor - Baby Unit. It has a microcontroller and 2.4GHz RF module. The EUT is powered by a 5V DC AC/DC adaptor. For Maximum Permissible Exposure (MPE) evaluation of the unit, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in K DB447498 D04 V01. For the 2.4GHz RF portion of the unit, the measured powers among all the measured channels were within its production tolerance. The antenna gain is 0 dBi = 1 (num gain) and its maximum source-based time-averaging duty factor is 100%. From these data and its operating configuration, the exposed power density at a distance (R) of 20 cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: BLE portion Antenna Type: Internal, integral A ntenna Gain: 0dBi Nominal rated power: 7.6dBm Range of Peak Conducted Power: 3dBm to 8dBm WiFi portion The WiFi portion was tested in according with the following power output and in actual application the below limit shall not be exceeded. Operating Mode Range of Peak Conducted Power 802.11b 9dBm to 22dBm 802.11g 9dBm to 22dBm 802.11n (HT20) Nominal Radiated Field Strength 13.9dBm 11.5dBm 10.6dBm 9dBm to 22dBm An internal, integral antenna has been used. Antenna Gain: 0dBi FHSS portion Antenna Type: Internal, integral Antenna Gain: 0dBi Nominal power: 16.01dBm Range of Peak Conducted Power: 13dB m to 17dBm INTERTEK TESTING SERVICE FCC ID: EW780-2529-00A For Maximum Permissible Exposure (MPE) evaluation of the EUT, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled M PE limit in OET Bulletin 65. 1) For the BLE portion, maximum power was 8 dBm. And the maximum source-based time- averaging duty factor is 100%. From these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET B ulletin 65 as follow: The radiated power = 8dBm + 0 dBi = 8dBm (6.3 mW) The radiated (EIRP) source-based time-averaging output power = (6.3 * 1) mW = 6.3 mW The power density at 20 cm from the antenna = EIRP / 4πR^2 = 0.001253 mW cm-2 2) For the WiFi portion, maximum power was 22 dBm. And the maximum source-based time- averaging duty factor is 100%. From these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The radiated power = 22dBm + 0dBi = 22 dBm (158.5 mW) The radiated (EIRP) source-based time-averaging output power = (158.5 * 1) mW = 158.5 mW The power density at 20 cm from the antenna = EIRP / 4πR^2 = 0.031533 mW cm-2 3) For the FHSS portion, maximum power was 17 dBm. And the maximum source-based time- averaging duty factor is 100%. Fr om these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The radiated power = 17dBm + 0dBi = 17dBm (50.1 mW) The radiated (EIRP) source-based time-averaging output power = (50.1* 1) mW = 50.1 mW The power density at 20 cm from the antenna = EIRP / 4πR^2 = 0.009967 mW cm-2 INTERTEK TESTING SERVICE FCC ID: EW780-2529-00A In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the Internet Music System at least 20cm from nearby persons.” In addition, for this product with multiple transmitter and antenna (BLE portion, WiFi portion and FHSS portion), the requirement of Simultaneous Transmission evaluation has also been considered and has complied with the following conditions of the worse case; MPE1 /Limit1 + MPE2/Limit2 + MPE3/Limit3 ≤ 1 Thus, 0.001253 / 1 + 0.031533 / 1 + 0.009967 / 1 = 0.042753 BLE portion WiFi portion FHSS portion It is concluded that no Simultaneous Transmission evaluation is required.
