Congratulations on purchasing your new VTech product. Before using this baby monitor, please read the Important safety instructions . RM5756HD 3.)% 5” Smart Wi-Fi 1080p Video Monitor What does HD Video Monitor do? VTech 5” Smart Wi-Fi 1080p Video Monitor allows you to stay close to your baby when you are on the move or away. This monitor is Wi-Fi enabled, using your home wireless network to stream live video and audio through the 1080p baby unit and 5-inch colour screen parent unit. It allows you to maintain a constant connection to your baby. You can also monitor from your smartphone or mobile tablet.VTech 5” Smart Wi-Fi 1080p Video Monitor uses MyVTech Baby Pro app to let you instantly see and hear what’s happening with your baby from anywhere in the world. The app can be downloaded from the App Store or the Google Play TM Store. Transmit frequency Baby unit: 2412 - 24  2 MHz
Parent unit: 2412 - 24  2 MHz Channels 1  LCD 5’’ Colour LCD (IPS 1280x720 pixels) Nominal effective range Actual operating range may vary according to environmental conditions at the time of use. Power requirement Baby unit power adapter: Output: 5V DC, 1000mA. Parent unit power adapter: Output: 5V DC, 2A.Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery Specifications are subject to change without notice.© 2022 VTech Communications, Inc.All rights reserved. 05/22. RM5756HD_US_QSG_V2 5FDIOJDBM
TQFDJGJDBUJPOT %JTDMBJNFS
BOE
-JNJUBUJPO
PG
-JBCJMJUZ VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product.Company: VTech Communications, Inc.Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United StatesPhone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada UL STD. 62368-1 CERTIFIED TO CSA STD. C22.2 NO.62368-1CONFORMS TO Android TM and Google Play TM are trademarks of Google Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of Cisco in the U.S. and other countri es and is used under license. Quick start guide

0WFSWJFX


8IBUłT
JO
UIF
CPY

$POOFDU
DIBSHF
BOE
QPXFS
PO
UIF
CBCZ
NPOJUPS x 2 x 2 Quick start guide Your baby monitor package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

1BSFOU
VOJU
JDPOT For mobile access:MyVTech Baby Pro mobile app Network Wi-Fi Wi-Fi router 2.4GHz 802.11 b/g/n Internet connection 1.5 Mbps @ 720p or 2.5 Mbps @1080p uploadbandwidth per baby unit Requirements Baby unit overview 1 Light sensor 2 Camera lens 3 Infrared LEDs • Allow you to see clearly in a dark environment. 4 Microphone 5 Night Light 6 Night Light Control Key • Go to Night Light section to learn more. 7 ON/OFF switch• Power it on or off. 8 LED indicator• Red is steadily on when the baby unit is connecting to the parent unit in direct mode. • Green is steadily on when the baby unit is connected in Wi-Fi router mode. • Red flashes slowly during video streaming in direct mode. • Green flashes slowly during video streaming in Wi-Fi router mode. 9 Speaker 10 Temperature sensor 11 PAIR• Press and hold for three seconds to enter pairing mode. • Reset the baby unit to factory default. 1. Press and hold PAIR key until you hear a beep sound. 2. Release the PAIR key, and then press the PAIR key again five times until you hear another beep sound. 3. The baby unit will sound another beep when the reset completes. Then, thebaby unit will reboot. 12 Power jack 13 Wall mount slots 4 6 35 2 1 78 9 10 1112 13 Connect the baby monitor • The rechargeable battery in the parent unit is built-in. • Use only the power adapters supplied with this product. • Make sure the parent unit and the baby unit are not connected to the switch controlled electric outlets. • Connect the power adapters in a vertical or floor mount position only. The adapter prongs are not designed to hold the weight of the parent unit and the baby unit, so do not connect them to any ceilin g, under-the-table, or cabinet outlets. Otherwise, the adapter may not properly connect to the outlets. • Make sure the parent unit, the baby unit and the power adapter cords are out of reach of children. Charge the parent unit battery before use The parent unit runs on rechargeable battery or AC power. To continuously monitor your baby, keep the parent unit connected to AC power. • Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the parent unit battery is fully charged, the battery icon becomes solid . • The standby time varies depending on your actual use. After the parent unit is fully charged, press Power until the welcome screen appears. The battery icon indicates the battery status (see the following table). #BUUFSZ
JOEJDBUPST #BUUFSZ
TUBUVT "DUJPO The screen displays and . The LED light flashes. The battery has very little charge and may be used for only a short time. Charge without interruption (about 30 minutes). The battery icon becomes solid . The battery is fully charged. To keep the battery charged, connect it to AC power when in use. 1 set for RM5756HD
2 sets for 3.)% Slide the switch to ON to power on your baby unit. • After powering up, the baby unit status LED will turn on and then turn off after a short time. • The status LED is set to off by default. If you want to keep the LED on, press MENU , then go to > Status LED and turn it on. NOTE: Camera lens and surface may get warm during normal operation. WARM Parent unit overview 1 LINK LED light • On when the parent unit is linked to the baby unit. • Flashes when the link to the baby unit is lost. 2 LED light • On when the parent unit is connected to AC power, and the battery is charging. • Flashes when the parent unit batt…
