Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. Congratulations on purchasing your new VTech product. Before using this baby monitor, please read the Important safety instructions . For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com. In Canada, visit www.vtechcanada.com . Frequency Baby unit: 2412 - 2462 MHz Channels 11 LCD 7’’ Color LCD (IPS 1280x800 pixels) Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirement Baby unit power adapter: Output: 5V DC, 1000mA. Parent unit power adapter: Output: 5V DC, 2A.Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery Specifications are subject to change without notice.© 2022 VTech Communications, Inc.All rights reserved. 05/22. RM7766-XHD_QSG_V1 7HFKQLFDOVSHFLơFDWLRQV Android TM and Google Play TM are trademarks of Google Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of Cisco in the U.S. and other countri es and is used under license. UL STD. 62368-1 CERTIFIED TO CSA STD. C22.2 NO.62368-1CONFORMS TO RM7868HD RM7868-2HD 7” Touch Screen Wi-Fi 1080p Pan & Tilt Monitor What does HD Video Monitor do? Disclaimer and Limitation of Liability VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product.Company: VTech Communications, Inc.Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United StatesPhone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada Quick start guide RM7868HD RM7868-2HD For more support information S m VTech 7” Touch Screen Wi-Fi 1080p Pan & Tilt Monitor allows you to stay close to your baby when you are on the move or away. This monitor is Wi-Fi enabled, using your home wireless network to stream live video and audio through the 1080p baby unit and 7-inch color screen parent unit. It allows you to maintain a constant connection to your baby. You can also monitor from your smartphone and mobile tablet.VTech 7” Touch Screen Wi-Fi 1080p Pan & Tilt Monitor uses MyVTech Baby Pro app to let you instantly see and hear what’s happening with your baby from anywhere in the world. The app can be downloaded from the App Store or the Google Play TM Store. Direct mode The parent unit and the baby unit of your video monitor connect to each others in Direct mode by default, which allows you to stream live video right out of the box. Direct mode connection lets you stream live video from parent unit only. • You may experience reduced signal strength if your parent unit and baby unit are far apart, or there are obstructing factors, such as internal walls, between them. Move the parent unit closer to the baby unit to improve the signal strength. Wi-Fi Router mode To stream live video with better connection, you can also set up your monitor in Router mode connection. Router mode uses your home Wi-Fi network to connect the video monitor. It supports streaming live video through the parent unit and MyVTech Baby Pro app.Download and install the MyVTech Baby Pro mobile app to stream remotely. With the mobile app, your Wi-Fi router (not included) serves as a communicating channel between your baby unit and mobile device, allowing you to monitor and control your baby unit wherever you are. For details, see Download app for mobile access section in this quick start guide. Auto mode With Auto mode connection, the parent unit will automatically select the most reliable connection mode ( Direct or Wi-Fi ) when connecting to the baby unit(s). Mobile app access will not be interrupted in Auto mode . • When both parent unit and app are viewing the camera simultaneously, the video quality will be optimised to deliver the best possible viewing result. Overview What’s in the box Connect, charge and power on the baby monitor Protect your privacy and online security x 2 x 2 Quick start guide Your baby monitor package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. How the system works VTech cares about your privacy and peace of mind. T hat’s why we’ve put together a list of industry-rec ommended best practices to help keep your wireless connection pri vate and your devices protected when online. We rec ommend you carefully review and consider complying with the fo llowing tips. Ensure your wireless connection is secure. • Before installing a device, ensure your router’s wireless signal is encrypted by selecting the “WPA2-PSK with AES” setting in your router’s wireless security menu. Change default settings. • Change your wireless router’s default wireless network name (SSID) to something unique. • Change default passwords to unique, strong passwords. A strong password: - Is at least 10 characters long.- Is complex.- Does not contain dictionary words or personal information.- Contains a mix of uppercase letters, lowercase letters, special characters and numbers. Keep your devices up to date. • Download security patches from manufacturers as soon as they become available. This will ensure you always have the latest security updates. • If the feature is available, enable automatic updates for future releases. Disable Universal Plug and Play (UPnP) on your router. • UPnP enabled on a router can limit the effectiveness of your firewall by allowing other network devices to open inbound ports without any intervention or approval from you. A virus or other malware program could use this function to compromise security for the entire network. For more information on wireless connections and protecting your data, please review the following re…
