EW780-2986-01Video Baby Monitor - Parent Unit

Transmit frequencyBaby unit: 2412 - 2462 MHz Parent unit: 2412 - 2462 MHz Channels11 LCD5’’ Color LCD (IPS 1280x720 pixels) Nominal effective rangeMaximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use. Power requirementBaby unit power adapter: Output: 5V DC, 1.5A Parent unit power adapter: Output: 5V DC, 2A Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery Specifications are subject to change without notice. © 2023 VTech Communications, Inc. All rights reserved. 02/23. VC2105_US_QSG_V1 Technical specifications Disclaimer and Limitation of Liability VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product. Company: VTech Communications, Inc. Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United States Phone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada UL STD. 62368-1 CERTIFIED TO CSA STD. C22.2 NO.62368-1 CONFORMS TO Android TM and Google Play TM are trademarks of Google Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. Congratulations on purchasing your new VTech product. Before using this baby monitor, please read the Important safety instructions. For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com. In Canada, visit www.vtechcanada.com. VC2105 5” Smart Nursery Over-the-Crib Mount Monitor What does HD Video Monitor do? Quick start guide VTech 5” Smart Nursery Over-the-Crib Mount Monitor allows you to stay close to your baby when you are on the move or away. This monitor is Wi-Fi enabled, using your home wireless network to stream live video and audio through the 1080p baby unit and 5-inch color screen parent unit. It allows you to maintain a constant connection to your baby. You can also monitor from your smartphone or mobile tablet. VTech 5” Smart Wi-Fi 1080p Video Monitor uses MyVTech Baby Plus app to let you instantly see and hear what’s happening with your baby from anywhere in the world. The app can be downloaded from the App Store or the Google Play TM Store. Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. VC2105 For more support information S m The applied nameplate is located at the bottom of the baby unit’s base. When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Follow all warnings and instructions marked on the product. 2. Adult setup is required. 3. CAUTION: Do not install the baby unit at a height above 6.5 feet (2 meters). 4. This product is intended as an aid. It is not a substitute for responsible and proper adult supervision and should not be used as such. 5. This product is not intended for use as a medical monitor. 6. Do not use this product near water, for example, near to a bath, sink, swimming pool or shower. 7. CAUTION: Use only the battery provided. There may be a risk of explosion if a wrong type of battery is used for the parent unit. The battery cannot be subjected to high or low extreme temperature and low air pressure at high altitude during use, storage or transportation. Disposal of battery in fire or a hot oven, mechanically crushing or cutting the battery can result in an explosion. Leaving the battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid of gas. Battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. Dispose of used battery according to the information in The RBRC seal. 8. Use only the power adapters included with this product. Incorrect power adapter polarity or voltage can seriously damage the product. Power adapter information: Baby Unit Output: 5V DC 1.5A VTech Telecommunications Ltd. Model: VT07EUS05150 Parent Unit Output: 5V DC 2A VTech Telecommunications Ltd. Model: VT07EUS05200 Rechargeable battery information: 3.7V 5000mAh, 18.5Wh Lithium-ion battery Zhuhai Great Power Energy Co., Ltd. Model: GSP806090-5Ah-3.7V-1S1P 9. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under- the-table or cabinet outlet. 10. For pluggable equipment, the socket-outlet (power adapter) should be installed near the equipment and should be easily accessible. 11. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 12. Do not modify the power adapters or replace with other adapters, as this causes a hazardous situation. 13. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on or crimped. 14. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or electricity supply provider. 15. Do not overload wall outlets or use an extension cord. 16. Do not place this product on an unstable table, shelf, stand or other unstable surfaces. 17. This product should not be placed in any area where proper ventilation is not provided. Slots and openings in the back or bottom of this product are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat source. 18. Never push objects …

Text truncated - open the document above for the full version.

• To keep this product working well and looking good, follow these guidelines: • Avoid placing it near heating appliances and devices that generate electrical noise (for example, motors or fluorescent lamps). • DO NOT expose it to direct sunlight or moisture. • Avoid dropping the product or treating it roughly. • Clean with a soft damp cloth. • DO NOT immerse the parent unit and the baby unit in water and do not clean under running water. • DO NOT use cleaning spray or liquid cleaners. • Make sure the parent unit and the baby unit are dry before you connect them to the mains again. When you are not going to use the video monitor for some time, store the parent unit, the baby unit and the power adapters in a cool, dry location. Below are the questions most frequently asked about the video monitor. Can I turn the parent unit display screen off but keep hearing sounds from the baby unit? Yes, press | LCD ON/OFF on the parent unit to turn off the screen. The parent unit display will also dim automatically after being inactive for some time. In both instances, you will still be able to hear all sounds from the baby unit. Press any key to turn the screen back on. Why is the baby unit not responding normally? Try the following (in the order listed) for a common cure: 1. Disconnect the power to the baby unit. 2. Wait a few minutes before connecting power back to the baby unit. 3. Reboot the parent unit. Why is my screen in black and white? The baby unit has a light sensor that measures ambient light. When the ambient light is dim, such as during night time or in a dark room, the baby unit activates its infrared LEDs, and displays the camera images in black and white night vision. Why does my baby unit show offline? Why is the connection lost every now and then? The baby unit may have lost connection to the Wi-Fi router. Check your network and router settings. Other electronic products may cause interference with your baby unit. Try installing your baby unit as far away from these electronic devices as possible. Why can’t I hear a sound/Why can’t I hear my baby crying? The parent unit speaker volume may be too low. Press on the parent unit to increase the volume. You may have set a low sound sensitivity level. Set the sound sensitivity to a higher level. For details, go to www.vtechphones.com for online help topics. Frequently asked questions General product care Storage La plaque signalétique appliquée est située au bas du socle de l’unité du bébé. Lorsque vous utilisez votre appareil, vous devriez toujours suivre certaines mesures de précaution de base afin de réduire les risques d’incendie, d’électrocution et de blessures corporelles, dont ceux qui suivent: 1. Observez toutes les instructions et mises en garde inscrites sur l’appareil. 2. L’installation par un adulte est requise. 3. MISE EN GARDE: N’installez pas l’unité du bébé à une hauteur supérieure à 2 mètres. 4. Ce produit a été conçu pour être un dispositif d’appoint seulement. Il n’est pas le remplacement d’une supervision responsable et adéquate par un adulte et ne devrait pas être utilisé comme telle. 5. Ce produit n’est pas conçu pour être utilisé en tant que moniteur médical. 6. N’utilisez pas cet appareil près de l’eau ni de toute autre source d’humidité, par exemple, près d’une baignoire, cuve à lessive, évier de cuisine, dans un sous-sol humide ni près d’une piscine, dans un soussol humide ou une douche. 7. MISE EN GARDE: N’utilisez que la pile fournie. Il peut y avoir un risque d’explosion si un mauvais type de pile est utilisé pour le dispositif apaisant. La pile ne peut pas être soumise a des températures extrêmes élevées ou basses et a une faible pression atmosphérique a haute altitude pendant son utilisation, son entreposage ou son transport. Le fait de jeter la pile dans au feu ou dans un four chaud, ou d’écraser ou de couper mécaniquement la pile peut entrainer une explosion. Le fait de laisser la pile dans un environnement a température extrêmement élevée peut entrainer une explosion ou une fuite de liquide ou de gaz inflammable. Une pile soumise a une pression d’air extrêmement basse peut provoquer une explosion ou une fuite de liquide ou de gaz inflammable. Mettez au rebut la pile usagée conformément aux informations figurant dans la section Le sceau RBRC. 8. N’utilisez que les adaptateurs inclus avec ce produit. L’utilisation d’un adaptateur dont la polarité ou la tension serait inadéquate risque d’endommager sérieusement le produit et mettre votre sécurité en péril. Informations sur les adaptateurs électriques : Sortie : 5 V CC 1,5A VTech Telecommunications Ltd. Modèle : VT07EUS05150 Sortie : 5 V CC 2A VTech Telecommunications Ltd. Modèle : VT07EUS05200 Informations sur les piles rechargeables : 3,7V 5000mAh, 18,5Wh Lithium-ion batterie Zhuhai Great Power Energy Co., Ltd. Modèle : GSP806090-5Ah-3.7V-1S1P 9. Lorsqu’ils sont branchés dans une prise de courant, les adaptateurs secteur ont été conçus pour être orientés correctement, soit à la verticale ou au plancher. Les broches n’ont pas été conçues pour supporter le poids du bloc d’alimentation et le maintenir en place si celuici est branché dans une prise au plafond, sous une table ou dans un meuble. 10. Pour les appareils raccordés, la prise de courant (de l’adaptateur secteur) doit être installée près de l’équipement et doit être facilement accessible. 11. Débranchez ce produit de la prise de courant avant de procéder au nettoyage. N’utilisez pas de nettoyants en aérosols. Utilisez un chiffon humide pour le nettoyer. 12. Ne coupez pas les cordons d’alimentation pour remplacer les fiches, car ceci peut présenter un danger potentiel. 13. Ne laissez aucun objet reposer ni appuyer sur le cordon d’alimentation. N’installez pas cet appareil dans un endroit où l’on risque d’écraser le cordon d’alimentation ou de le piétiner. 14. Ne faites fonctionner cet appareil qu’avec le type d’alimentation indiqué sur l’étiquette. Si vous ne connaissez pas le type d’alimentation que v…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 2 Date: 1/25/2023 Attention: Application Examiner Re: Certification designating a U.S. agent for serv ice of pr oce ss pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both VTech Communications, Inc. (“Agent”) and VTech Telecommunications Ltd. (“Applicant”) acknowledge con sent to obligations of each party pursuant to 47 CFR part §2.911(d) (7) of the FCC rules in regard to the agent for service of process. I Michael Tsui HEREBY CERTIFY THAT I am authorized to make the representations ab ove on behalf of the Applicant. I fur ther acknowle dge the requirement to maintain an agent exten ds for no less than one year after the termination of all marketing and importation or the c onclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC & Intertek if there is any change in the status identified abov e. Applicant Company Name : VTech Telecommunications Ltd. Contact Name : Michael Tsui Address : 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Rd, Tai Po, Hong Kong Telephone No : +852 2680 5398 Email : [email protected] Applicant FRN : 0015973951 Signature: ____________________________________ 17 February 2023 Date: ____________________________________ I Chris Conrad HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to all certification applications to the FCC submitted by above applicant and agree to immediately notify the FCC & Intertek if there is change in this representation. Agent Company Name : VTech Communications, Inc. Contact Name : Chris Conrad Address : 9020 SW Washington Square Road, Tigard OR 97223 Telephone No : +1(503) 596-1212 Email : [email protected] Agent FRN : 0033411265 For m: RFT-AMER-TCB-OP-19o Revision: 1 Page 2 of 2 Date: 1/25/2023 Signature: ____________________________________ 17 February 2023 Date: ____________________________________

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: VTech Telecommunications Ltd. FCC ID: EW780-2986-01 To whom it may concern, VTech Telecommunications Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] Mr. Michael Tsui Approbation Supervisor VTech Telecommunications Ltd. 13 April 2023

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Sep. 27, 2017 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Terry Chan/ Koo Wai Ip/ Kenneth Wong/ Jess Tang) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Mar 14, 2023 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-2986-01 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (External)

Label 28x32mm PU WIFI MAC: xxxxxxxxxxxx Model: VC2105 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2105 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2105 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2105 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2105 WIFI MAC: xxxxxxxxxxxx Model: VC2105 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2105 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2105 VC2105 PU&BU LBL50# PET SIZE: 56 x 62mm WIFI MAC: xxxxxxxxxxxx Model: VC2100 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2100 VC2100 BU LBL50# PET SIZE: 55 x 32mm WIFI MAC: xxxxxxxxxxxx Model: VC2110 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2110 VC2110 BU LBL50# PET SIZE: 55 x 32mm WIFI MAC: xxxxxxxxxxxx Model: VC2125 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2125 WIFI MAC: xxxxxxxxxxxx S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2125 BU S/N: XXXXXXXXXXX MANUFACTURED IN CHINAFCC ID: EW780-2986-00IC: 1135B-80298600HVIN: 35-400439BUA VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 1.5A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX VC2125 PU&BU LBL50# PET SIZE: 56 x 62mm WIFI MAC: xxxxxxxxxxxx S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC: xxxxxxxxxxxx Model: VC2605 PU S/N: XXXXXXXXXXX MANUFACTURED IN CHINA FCC ID: EW780-2986-01IC: 1135B-80298601HVIN: 35-400453PU VTech Customer Service 1-844-848-8324www.vtechphones.com 5V 2A A/V I.C.T.E. WIFI MAC : AABBCCDDEEFF S/N: XXXXXXXXXXXXXXXXXXXX Model: VC2605 PU VC2605 PU LBL50# PET SIZE: 55 x 32mm VC2810 BU LBL50# PET SIZE:

INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK23030024 Equipment Photographs (Internal)

TEST REPORT 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 41 SPECIFIC ABSORPTION RATE (SAR) EVALUATION REPORT Report No.: 23030024HKG-008 For Video Monitor - Parent Unit Model Number: VC2105 PU, VC2125 PU, VC2605 PU Brand Name: vtech FCC ID: EW780-2986-01 Prepared for VTech Telecommunications Ltd. 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. PREPARED AND CHECKED BY: APPROVED BY: Signed On File Lee King Kai, Thomas Assistant Engineer Date: May 24, 2023 Wong Kwok Yeung, Kenneth Assistant Manager Date: May 24, 2023 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 23030024HKG-008 Page 2 of 41 TABLE OF CONTENTS 1 Test Result Summary ................................................................................................................. 3 2 General Information .................................................................................................................. 4 3 SAR Measurement System Description .................................................................................... 8 4 Tissue Verificaiton ................................................................................................................... 16 5 SAR Measurement System Verification .................................................................................. 19 6 SAR Evaluation ......................................................................................................................... 21 7 Test Equipment List ................................................................................................................. 35 8 Measurement Uncertainty ...................................................................................................... 36 9 E-Field Probe and Dipole Antenna Calibration ....................................................................... 36 APPENDIX A – System Check Data .............................................................................................. 37 APPENDIX B – SAR Evaluation Data ............................................................................................ 38 APPENDIX C – E-Field Probe and Dipole Antenna Calibration ................................................... 40 APPENDIX D – Sar System Validation ......................................................................................... 41 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 23030024HKG-008 Page 3 of 41 1. TEST RESULT SUMMARY The maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Band Operating Mode TX Frequency (MHz) Highest Reported SAR In-front-of mouth Body 2.4GHz WiFi Data 2412 – 2462 0.066W/kg 0.198W/kg This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general population exposure limits specified in ANSI/IEEE C95.1. Applicant: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. Model: VC2105 PU, VC2125 PU, VC2605 PU Brand Name: vtech Serial Number: N/A FCC ID: EW780-2986-01 Test Device: Production Unit EUT Exercising Software Tera Terms Version 4.57 Exposure Category: General Population/Uncontrolled Exposure Date of Test: May 24, 2023 Place of Testing: Workshop No. 3, G/F., World-Wide Industrial Centre, 43-47 Shan Mei Street, Fo Tan, Sha Tin, N.T., Hong Kong SAR, China. Environmental Conditions: Temperature: +18 to 25°C Humidity 25 to 75% Test Specification: ANSI/IEEE C95.1 IEEE Std 1528: 2013 FCC KDB Publication 447498 D01 v06 FCC KDB Publication 865664 D01 v01r04 FCC KDB Publication 865664 D02 v01r02 FCC KDB Publication 248227 D01 V02r02 TEST REPORT VTech Telecommunications Ltd. Intertek Report No: 23030024HKG-008 Page 4 of 41 2. GENERAL INFORMATION 2.1. Description of Equipment Under Test (EUT) Manufacturer: VTech (Dongguan) Telecommunications Limited. Manufacturer Address: VTech Science Park, Xia Ling Bei Management Zone, Liaobu, Dongguan, Guangdong, China. Device dimension (L x W): 157 (mm) x 77 (mm) Device Thickness: 17 (mm) Antenna Gain: 0 dBi Operating Configuration(s) / Mode: In-front-of mouth (Data) Body (Data) TX Frequency (MHz): 2412 MHz to 2472 MHz (802.11b, g, n (HT20)) Duty Cycle*: 100% H/W Version: N/A S/W Version: N/A Battery Type: 3.7VDC (1 x 3.7V 5000mAh Li-ion rechargeable Battery) Body-worn Accessories: N/A Remark: The models VC2125 PU, VC2605 PU are the same as the model VC2105 PU in hardware aspect. The difference in model number serves as marketing strategy as declared by client. The difference in model number represents different color and model number as declared by client. *Note: 1. Worst case was selected to …

Text truncated - open the document above for the full version.

[VTECH] [2.4GHz Antenna] Model: RM7868 PU Antenna description: This dipole antenna is optimized and used in the Parent in the baby monitor models. This antenna is directly soldered to the RF output in the main PCB. Ordering information: Model Description RM7868 PU 2.4GHz Dipole Antenna Specification: Operation Frequency Range 2412-2472 MHz Maximum Gain 2 dBi Type Dipole Operation bandwidth 60MHz Nominal Impedance ~50 ohms Connectors - Dimensions 84mm x 14 mm Manufacturer Vtech Telecommunications Ltd Manufacturer address 23/F, Tai Ping Industrial Centre, Blk1, 57 Ting Kok Road, Tai Po, Hong Kong Model number ANT-RM7868-P-WI-1 [VTECH] [2.4GHz Antenna] Antenna pattern (2436MHz) (the frequency with maximum gain) XY plane (gain theta) Coordination: [VTECH] [2.4GHz Antenna] Physical Dimension: Figure 1 Physical dimension (mm)

TEST REPORT 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is…
