EW780-4177-B6SONY SPP-900 ANALOG 900 MHz CORDLESS TELEPHONE

VTech Telecommunications Ltd

Click to zoom

Application Details

Equipment Class: ETS - Part 15 Cordless Telephone System
Date of Grant: Jan 27, 1999
Application Purpose: Original Equipment
Date of Application: Dec 07, 1998
Equipment Note: SONY SPP-900 ANALOG 900 MHz CORDLESS TELEPHONE
Frequency Range: 923.10000000 - 927.75000000
Company: VTech Telecommunications Ltd
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

V TECH E NGINEERING C ANADA L TD . TITLEInternal Product Specification MODELSony SPP-900 - Analog 900MHz Cordless Telephone Reference: PRC 00BERevision: 2Page: 1 of 28 This document is proprietary to V TECH E NGINEERING C ANADA L TD . 15237.DOC Specifications are preliminary and are subject to change without notice Internal Product Specification for the Sony SPP-900 Analog 900MHz Cordless Telephone Revision History: RevisionDescriptionPageEffective Date DraftDraft Release.AllAug 10/98 0Incoporate comments from draft releaseAllAug 28/98 1Delete POTS mode and spare battery requirements. Delete one base LED. Add further details on keypad backlight. Modify channel plan. Add/change specification data. Change duration of PAGE tone. 4-6,21,22 10 9,14 26-28 23-29 10,15-17 Oct 13/98 2Update model number Revise specification data Further refinements to channel plan All 23-24 26-28 Nov 7/98 3Change all references of CPX-971 to SPP-900AllNov 9/98 All rights reserved. No part of this document may be reproduced, loaned, or transmitted in any form or by any means without authorization in accordance with V TECH policies and administrative procedures. This document remains the property of V TECH Engineering Canada Ltd., and must be returned upon request . Prepared ByMaria LiaoApproved ByGary Rogalski TitleProject ManagerTitleEngineering Manager V TECH E NGINEERING C ANADA L TD . TITLEInternal Product Specification MODELSony SPP-900 - Analog 900MHz Cordless Telephone Reference: PRC 00BERevision: 2Page: 2 of 28 This document is proprietary to V TECH E NGINEERING C ANADA L TD . 15237.DOC Specifications are preliminary and are subject to change without notice Contents 1Overview .......................................................................................................................... 4 1.1General Description...................................................................................................... 4 1.2Regulatory Standards................................................................................................... 4 1.3Preliminary Feature List................................................................................................ 4 1.3.1 Basic Features ........................................................................................................................... 4 1.3.2 Unique Features......................................................................................................................... 5 1.3.3 Features Not Provided ............................................................................................................... 5 1.4Cosmetic Styling........................................................................................................... 5 1.4.1 Base Unit Line Drawing.............................................................................................................. 6 1.4.2 Handset Line Drawing ................................................................................................................ 7 2Functional Layouts ......................................................................................................... 8 2.1Handset Functional Layout ........................................................................................... 8 2.1.1 Handset LED Indicators ............................................................................................................. 8 2.1.2 Handset Key Descriptions .......................................................................................................... 8 2.1.3 Keypad Illumination .................................................................................................................... 9 2.2Base Unit Functional Layout......................................................................................... 9 2.2.1 Base Unit LED Indicators ........................................................................................................... 9 2.2.2 Base Unit Key Descriptions...................................................................................................... 10 3Operating Modes........................................................................................................... 11 3.1STANDBY Mode ........................................................................................................ 11 3.2PHONE Mode............................................................................................................. 12 3.2.1 Dialling Methods....................................................................................................................... 12 3.2.2 Redial Buffer ............................................................................................................................ 12 3.2.3 Memory Dialling........................................................................................................................ 13 3.3PROGRAM Mode ....................................................................................................... 13 3.3.1 Speed Dial Programming ......................................................................................................... 14 3.3.2 Ringer Type Programming ....................................................................................................... 14 3.4RINGING Mode .......................................................................................................... 15 3.5PAGE Mode ............................................................................................................... 15 3.6PHONE/PAGE Mode.................................................................................................. 16 3.7PROGRAM/PAGE Mode ............................................................................................ 16 3.8PROGRAM/RINGING Mode....................................................................................... 17 4RF Link Operation...................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

VTECH ENGINEERING CANADA LTD. TITLETheory of Operation MODELSony SPP-900 Analog 900MHz Cordless Telephone Reference: PRC 00AJRevision: 0Page: 1 of 27 This document is proprietary to VTECH ENGINEERING CANADA LTD.15238 Specifications are preliminary and are subject to change without notice Theory of Operation of the SONY SPP-900 Analog 900MHz Cordless Telephone Revision History: RevisionDescriptionPageEffective Date 0Initial ReleaseAllNov 10/98 All rights reserved. No part of this document may be reproduced, loaned, or transmitted in any form or by any means without authorization in accordance with V TECH policies and administrative procedures. This document remains the property of V TECH Engineering Canada Ltd., and must be returned upon request. Prepared ByMaria Liao TitleProject Manager VTECH ENGINEERING CANADA LTD. TITLETheory of Operation MODELSony SPP-900 Analog 900MHz Cordless Telephone Reference: PRC 00AJRevision: 0Page: 2 of 27 This document is proprietary to VTECH ENGINEERING CANADA LTD.15238 Specifications are preliminary and are subject to change without notice Contents 1 General................................................................................................................................... 3 1.1 Hardware ......................................................................................................................... 3 1.2 Overview.......................................................................................................................... 3 2 Baseband Module.................................................................................................................. 4 2.1 Telephone Line Interface ................................................................................................. 5 2.1.1 Line Protection and Filtering....................................................................................................... 5 2.1.2 Ring Detect................................................................................................................................. 6 2.1.3 Pulse Dialling or Off-Hook Switch .............................................................................................. 6 2.1.4 Speech Circuit ............................................................................................................................ 6 2.2 Power Management......................................................................................................... 7 2.2.1 Base Unit.................................................................................................................................... 7 2.2.2 Handset ...................................................................................................................................... 8 2.3 Audio Circuits .................................................................................................................. 9 2.3.1 Base Unit.................................................................................................................................... 9 2.3.2 Handset .................................................................................................................................... 11 2.4 MCU Circuits ................................................................................................................. 13 2.4.1 Base Unit.................................................................................................................................. 13 2.4.2 Handset .................................................................................................................................... 15 3 RF Module........................................................................................................................ 1718 3.1 Antenna Section ........................................................................................................ 2021 3.1.1 Antenna ................................................................................................................................ 2021 3.1.2 Duplexer ............................................................................................................................... 2021 3.1.3 Rx, Tx Bandpass Filters ....................................................................................................... 2021 3.2 Receive Section......................................................................................................... 2223 3.2.1 Rx Amplifier and SAW Filter ................................................................................................ 2223 3.2.2 Mixer, IF Amplifier, FM Demodulator ................................................................................... 2223 3.2.3 Rx VCO and LO Buffer......................................................................................................... 2324 3.2.4 Rx Synthesiser ..................................................................................................................... 2324 233.2.5 IF Filtering ........................................................................................................................ 2425 23 3.3 Transmit Section ............................................................................................... 2425 3.3.1 Tx Amplifiers ........................................................................................................................ 2425 3.3.2 Tx VCO ................................................................................................................................ 2425 3.3.3 Tx Synthesiser/PLL .............................................................................................................. 2425 VTECH ENGINEERING CANADA LTD. TITLETheory of Operation MODELSony SPP-900 Analog 900MHz Cordless Telephone Reference: PRC 00AJRevision: 0Page: 3 of 27 This document is proprietary to VTECH ENGINEERING CANADA LTD.15238 Specifications are preliminary and are subject …

Text truncated - open the document above for the full version.

Operational Description

Text truncated - open the document above for the full version.

Parts List/Tune Up Info

SONY CPX-971 - Pre-Prototype BOMOct 14/98 LevelVTN Part NumberPart DescriptionExtra DescriptionQtyReference PAREN T80-4222-00-00SONY CPX971,ADL-MKII-B,BLAC1 185-4222-02-00PACK ASSY,SONY CPX971,BLK1 .230-5132-00-00WALL-MNT,SONY971,BU,BLK,R,01 .246-4016-10-00PHONE CORD,BLK,6WX2CONT,7'L1 .246-4035-00-00PHONE CORD BLK 6WX2CONT,9"L1 185-4222-00-00PROD ASSY,SONY CPX971,HS,BL1 .250-4222-02-00PCBA,CPX971,HS,AUDIO,MAIN1 ..314-3400-60-24STD,BLK,1571,#30,40L,2T2T1 ..314-3400-62-24STD,RED,1571,30#,40L,2T2T1 ..314-3900-42-00STD WIRE,RED,UL,#26,90L,3T31 ..322-7200-00-07CAP,TRIM,20PF,100V,N4501C1 ..325-CRYSTAL,4MHZ,COMMUTEK1X1 ..330-5127-00-00SWITCH SONY971,HS,BLK,R.0,01 ..339-3404-00-00FOAM TAPE1 ..343-1052-00-33LED,GREEN,SML010MT0D1,D2,D3,D9 ..343-1065-00-00LED,DIFFUSE,RED,D3X5.21D5 ..347-1003-60-0 0ANTENNA1 ..350-PCBA,CPX971,HS,AUDIO SMD BD1 ...420-0039-01-00X'TR,CHIP,MMBT3906T,SOT23,RLTRANSISTOR,CHIP,MMBT3906T7Q12,Q13,Q14,Q16,Q18,Q19,Q2 ...420-0041-01-00X'TR,MMBT3904LT1,SOT-23,REELMMBT3904LT1,SOT-23,L PROF.REE4Q1,Q15,Q17,Q20 ...421-0001-01-00DIODE,SW,SOT23,SMD BAS161D6 ...421-1035-04-00DIODE,SW,SOT232D7,D8 ...421-1042-04-00DIODE,TVS,SOT23,SM12,SMD1D14 ...422-2105-30-33CAP,TANT,1UF,16V,10%1C102 ...422-2106-01-33CAP,TANT,10UF,6V,20%3C100,C119,C99 ...422-2225-21-33CAP,TANT,2.2UF,10V,+-20%3C113,C122,C126 ...422-3101-25-G6CAP,CER,100PF,50V,5%4C103,C137,C95,C97 ...422-3102-26-G5CAP,CER,1000PF,50V,+-10%3C118,C127,C139 ...422-3104-06-G5CAP,CER,0.1UF,16V,10%6C107,C108,C109,C121,C3,C40 ...422-3123-26-G5CAP,CER,0.012UF,50V,10%1C111 ...422-3182-26-G5CAP,CER,RL,1800P,50V,10%1C101 ...422-3220-25-G6CAP,CER,22PF,50V,+-5%3C140,C75,c91 ...422-3221-25-G6CAP,CER,RL,220PF,50V,5%2C104,C132 ...422-3222-26-G5CAP,CER,2200PF,50V,+-10%1C128 ...422-3223-16-G5CAP,CER,RL,22NF,25V,10%2C116,C2 ...422-3224-20-M3CAP,CER,SMD,0.22UF,16V,10%1C129 ...422-3330-25-G6CAP,CER,33PF,50V,5%2C105,C131 ...422-3470-25-G6CAP,CER,RL,47PF,50V,5%1C134 ...422-3472-26-G5CAP,CER,4700PF,50V,10%,RL,X1C112 ...422-3473-06-G5CAP,CER,RL,47NF,16V,10%5C110,C114,C123,C125,C138 ...422-3561-26-G5CAP,CER,560PF,50V,10%2C106,C130 ...422-3680-25-G6CAP,CER,RL,68PF,50V,5%1C124 ...422-3759-20-G6CAP,CER,7.5PF,50V,+-0.25PF1C93 ...423-0101-86-21RES,CR,SMD,REEL,100,1/16W,53R10,R71,R78 ...423-0102-86-21RES,CR,SMD,REEL,1K,1/16W,5%5R100,R11,R114,R122,R138 ...423-0103-86-21RES,CR,SMD,REEL,10K,1/16W,56R1,R106,R107,R115,R143,R98 ...423-0104-86-21RES,CR,SMD,REEL,100K,1/16W,6R134,R23,R36,R74,R75,R95 ...423-0105-86-21RES,CR,SMD,RL,1M OHM,1/16W,2R144,R146 ...423-0106-86-21RES,CF,SMD,RL,10M OHM,1/16W2R90,R96 ...423-0123-86-21RES,CER,SMD,RL,12K 1/16W,5%1R111 ...423-0150-86-21RES,SMD,RL,15R OHM,1/16W,5%1R139 ...423-0152-86-21RES,CR,SMD,REEL,1K5,1/16W,51R42 ...423-0153-86-21RES,CR,SMD,REEL,15K,1/16W,51R77 ...423-0154-86-21RES,SMD,RL,150K OHM,1/16W,53R129,R130,R131 ...423-0184-86-21RES,CR,0603,RL,180K,1/16W,54R108,R109,R110,R116 ...423-0222-86-21RES,CR,SMD,2.2K OHM,1/16W.52R102,R121 ...423-0224-86-21RES,CR,SMD,REEL 220K,1/16W5R105,R140,R24,R65,R81 ...423-0273-86-21RES,CR,SMD,REEL,27K,1/16W,51R4 ...423-0333-86-21RES,SMD,33K OHM,1/16W,5%3R124,R133,R94 ...423-0394-86-21RES,CF,SMD,RL,390K,1/16W,5%1R103 ...423-0471-86-21RES,CR,SMD,REEL,470,1/16W,51R142 ...423-0473-86-21RES,CR,SMD,REEL,47K,1/16W,57R141,R49,R63,R69,R70,R97,R99 ...423-0474-86-21RES,CF,SMD,RL,470K,1/16W,5%4R123,R125,R127,R82 ...423-0513-86-21RES,CR,SMD,REEL,51K,1/16W,51R128 ...423-0561-86-21RES,CR,SMD,560 OHM,1/16W,5%1R76 ...423-0564-86-21RES,CR,SMD,RL,560K,1/16W,5%2R147,R91 ...423-0624-86-21RES,CR,SMD,REEL,620K,1/16W,1R145 ...423-0682-86-21RES,CR,SMD,REEL,6.8K,1/16W,1R80 ...423-0823-86-21RES,CR,0603,REEL,82K,1/16W,2R112,R3 ...423-0824-86-21RES,SMD,REEL,820K,1/16W,5%2R135,R89 ...423-1003-G0-21RES,CR,SMD,RL,100K,1/16W,+-3R84,R86,R88 ...423-1473-G0-21RES,CR,SMD,RL,1/16W,147K,1%1R87 ...423-1823-G0-21RES,RL,182K,CR,SMD,1/16W,1%1R85 ...423-1913-G0-21RES,CR,SMD,RL,1/16W,191K,1%1R83 ...424-2103-10-05VR-TRIM TOP 10K +-25%2R113,R119 ...427-5210-13-05IC,COMPANDER,SSOP241U7 ...427-2026-03-01IC,LOW DROPOUT REGULATOR1U11 Page 1 of 5 SONY CPX-971 - Pre-Prototype BOMOct 14/98 ...427-3280-00-00IC MCU,OPT,MC68HSC705P6DW1U3 ...427-5015-09-01IC,QUAD OP AMP,CHIP,TAPE&RE1U5 ...435-4393-00-00PCB,CPX971,HS,AUDIO,R.01 .250-4222-00-00PCBA,CPX971,HS,RF,MAIN1 ..310-3013-00-00PTS DIA2X8,BH(+),ZN-CR PLT10 ..322-7200-00-07CAP,TRIM,20PF,100V,N4501C10 ..323-0000-81-14RES,CF,SMD,RL,0 OHM,1/8W,5%1R1 ..325-2212-00-39IFT,7MM,10.7MHZ,100PF,Q=601L2 ..325-3128-00-10FILTER,CER,10.7MHZ,230KHZ1F5 ..325-3321-00-10FILTER,CER,10.7MHZ,BW(150KH1F4 ..330-4808-00-00RF-SHIELD,FR HS ADLMK2A R.01 ..330-4809-00-00RF-SHIELD,REAR HS ADLMK2A R1 ..346-1177-00-00F-CABLE #28 3+40+3X10WAYS R1 ..350-PCBA,VT9111,HS,RF SMD BD1 ...420-1142-03-00X'TR,RF,NPN,SOT343,RL,BFP671Q2 ...420-3067-13-00X'TR,RF/NPN,SOT323,RL,2SC4083HFE 80-180,2SC4083T106P3Q1,Q3,Q8 ...421-1047-04-00DIODE,VRA,USC,SMD2-16P,1SV2143D1,D2,D3 ...422-3102-26-G5CAP,CER,1000PF,50V,+-10%SM,RL,X7R,GRM394C10,C21,C33,C38 ...422-3103-26-G5CAP,CER,0.01UF,50V,+-10%SM,RL,X7R,GRM394C11,C24,C29,C39 ...422-3104-06-G5CAP,CER,0.1UF,16V,10%SMD,0603,RL,X7R2C23,C28 ...422-3109-29-G6CAP,CER,1PF,50V,+-0.1PF1C67 ...422-3123-26-G5CAP,CER,0.012UF,50V,10%SMD,RL,X7R,06031C84 ...422-3129-29-G6CAP,CER,1P2,50V,+-0.1PF1C63 ...422-3151-25-G6CAP,CER,RL,150PF,50V,5%06035C26,C30,C65,C78,C79 ...422-3159-29-G6CAP,CER,1.5PF,50V,+-0.1PFSM,RL,COG,GRM394C15,C51,C60,C7 ...422-3189-29-G6CAP,CER,1.8PF,50V,+-0.1PFSM,RL,COG,GRM391C54 ...422-3249-29-G6CAP,CER,2P4,50V,+/-0.25P,COG1C1 ...422-3272-26-G5CAP,CER,2.7NF,50V,10%06031C89 ...422-3273-16-G5CAP,CER,SMD,27NF,25V,10%06031C76 ...422-CAP,CER,0.33UF,25V,10%SMD,RL,X7R,08051C83 ...422-3470-25-G6CAP,CER,RL,47PF,50V,5%060314C13,C14,C16,C19,C20,C31,C35,C36,C37,C57,C64,C8,C85,C9 ...422-3471-26-G5CAP,CER,470PF,50V,+-10%SM,RL,X7R,GRM391C77 ...422-3479-20-G6CAP,CER,4.7PF,50V,+-0.25PF9C12,C2,C58,C59,C6,C70,C71,C74,C82 ...422-3560-25-G6CAP,CER,56PF,50V,+-5%SM,RL,COG,GRM391C22 ...422-3569-20-G6CAP,CER,5.6PF,50V,+-0.25PFSM,RL,COG,GRM392…

Text truncated - open the document above for the full version.

Test Report

Master: ktlPT15BR Date: October 8, 1998 KTL Test Report:8R00987 Applicant:VTECH Engineering Canada Ltd. 200-7671 Alderbridge Way Richmond, B.C. V6X 1Z9 Equipment Under Test:Sony SPP-900 (E.U.T.)Analog 900 MHz Cordless Telephone In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: _____________________________________ W. Waterhouse, RF Engineering Lab Manager Date:_____________________________________ Total Number of Pages:30 KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 2 of 30 TABLE OF CONTENTS Section 1. Summary of Test Results General Summary of Tests Section 2. Equipment Under Test (E.U.T.) Equipment Details Description of E.U.T. Modifications Incorporated in E.U.T. Theory of Operation Justification Exercise Program Section 3. Equipment Configuration Equipment Configuration List Inter-connection Cables Configuration of the Equipment Under Test (E.U.T.) Block Diagram Section 4. Receiver Antenna Conducted Emissions Test Conditions Test Results Receiver Antenna Conducted Plots Section 5. Radiated Emissions Test Conditions Test Results Test Data-Radiated Emissions Radiated Photographs Radiated Emissions Plots Section 6. Powerline Conducted Emissions Test Conditions Test Results Powerline Conducted Photographs Powerline Conducted Plots KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 3 of 30 TABLE OF CONTENTS, continued Section 7. Sample Calculations Conducted Emissions Radiated Emissions Section 8. Block Diagrams Conducted Emissions Radiated Emissions Section 9. Test Equipment List Equipment List - Powerline Conducted Emissions Equipment List - Radiated Emissions KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 4 of 30 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. Abstract: Name Of TestPara. No.Results Antenna Conducted Emissions15.111Not Applicable Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Complies THIS REPORT APPLIES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. None NVLAP Lab Code: 100351-0 It is recommended that the margin of compliance be improved to allow for manufacturing tolerances. TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist TECHNICAL REVIEW: ____________________________ DATE: ___________________ Tom Tidwell, Wireless Group Manager KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 5 of 30 Section 2.Equipment Under Test (E.U.T.) Manufacturer:VTECH Engineering Canada Ltd. Model No.:Sony SPP-900, MK2A and MK2B Serial No.:None Class IINewProductionPre-ProductionEquipment Code Permissive ChangeSubmissionUnitUnit Equipment Details Base Handset Frequency Range:923.10 – 927.75 MHz902.3 – 906.65 MHz Number of Channels:3030 Operating Frequency(ies) of Sample:923.10, 925.05 MHz905.00, 905.15 MHz Crystal Frequency(ies):Not ApplicableNot Applicable Primary Power Requirement:9 Vdc via 120 VAC, 60 Hz (AC Adapter) 3.6 Vdc (NICD Battery) Bandwidth and Emission Designator:165KF1D165KF1D Intermediate Frequency(ies):10.7 MHz10.7 MHz KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 6 of 30 Description of E.U.T. The E.U.T. is a 30 channel analog cordless telephone. Modifications Incorporated in E.U.T. The EUT has not been modified from what is described by the brand name and unique type identification stated above. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 7 of 30 Theory of Operation The Sony SPP-900 is a basic analog cordless telephone. It has 30-channel operation which is operator controllable. It is intended to be compatible with most types of central office equipment in Canada, the United States and South America. KTL OttawaFCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 8R00987 EQUIPMENT: Sony SPP-900 Analog 900 MHz Cordless Telephone Page 8 of 30 Justification The E.U.T. was configured for testing as per typical installation. Position and bundling of cables were investigated to establish maximum amplitude of emissions. The following combinations were investigated to establish worst case configuration: BASE: 3-Orthagonal Orientations (1) Lying flat on the table, antenna pointing up. (2) Lying flat on the table, antenna pointing straight back. (3) Vertically mounted, antenna pointing up. HANDSET: 3-Orthagonal Orientations (1) Lying flat on its back. (2) Vertical (3) Lying on its side. Exercise Program The E.U.T. exercise program used during radiated and conducted testing was designed to exercise the various system components in a manner similar to typical use. Exercise mode: (1) Off hook, loaded telephone line, carrier enabled. KTL…
