vtech GEMINI vtech GEMINI Display and keypad Display and symbols The handset display provides easy to understand information on the current status of your telephone. The 4-line display (with backlight illumination) is capable of showing several graphical symbols and text lines. The meaning of the symbols shown in the upper part of the display is as follows: ............ This antenna symbol is permanently lit if a radio connection between handset and base station exists. A blinking symbol shows that the handset is almost outside of the range of the corresponding base station. .......... You have pressed the talk key. ......... Indicates that the handset is logged on to base station A, B, C or D. Upon delivery the handset is logged on to base station A. Refer to page 48 for more information on selecting another base station. .......... The keypad has been locked („key lock“). .......... One or more new SMS 1 text message have been received. ........ The ring tone has been switched off („do not disturb“). Incoming calls are signalled by a short beep. ........... The microphone is switched off („mute“). ........ Indicates charge status of the battery (refer to page Error! Bookmark not defined. for more information). Name and number of the handset. You can operate up to 5 handsets on the same base station. This allows you to make internal calls between handsets free of charge! • 1 Ask your service provider about the availability and any charges for this service. Handset front view Handset keypad The following illustrations represent the keys on the handset keypad. For each key a short description is provided. ... Softkeys (left and right) which corresponding to different functions as displayed on the screen. The navigation keys have different functions: ⇒ While in a standby: open the redial list. ⇒ While in a menu: scroll up or down. ⇒ During a call: change the volume. This C (cancel)-key has different functions: ⇒ While in a menu: press to quit the (sub) menu ⇒ Press for 2 seconds to return to the standby mode. ⇒ During a call: press to switch off the microphone (mute). Open the phonebook. Talk key. Corresponds to “lift/replace receiver” on a conventional telephone. Handsfree / speakerphone: switch the loudspeaker on/off. When the loudspeaker is on, this key is illuminated. Message key. This key blinks when one or more new messages have been received. Press this key to open the message list. Display with backlight Cancel key Phonebook key Talk key Microphone VIP phonebook Soft key Navigation keys EARPIECE ( ADDITIONAL LOUDSPEAKER IS LOCATED AT THE Message key (illuminated) Soft key R-key Hands-free key (illuminated) INTERN 1 17.01 20:53 Number pad vtech GEMINI .. Numerical keys for entering telephone numbers as well as text. • When pressing the 1-key for approx. 2 seconds (long-press), the network mailbox number is dialled directly. • In dialling mode, when pressing the 0-key for approx. 2 seconds (long-press), a dialling pause is inserted between digits Asterisk (or star) key to enter the “asterisk” symbol. Pressing this key and holding it for approx. 2 seconds switches the ring tone on/off. While editing names or writing text, pressing this key switches between uppercase and lowercase characters. Hash (or pound) key to enter the “hash” symbol. Pressing this key and holding it for approx. 2 seconds locks/unlocks the keypad. Open the VIP phonebook. R – or Flash key. Base station front view The vtech GEMINI base station is equipped with a multi-functional paging key used for finding (paging) the handset(s) (see below) and registering handsets on to the base station (refer to page 11). Finding the handset (paging) You can easily find a (misplaced) handset by pressing the paging key on the base station. All handsets which are logged on to this base station will start ringing for 60 seconds enabling you to quickly find the handset(s) again. Stop the ring tone on the handset by pressing the talk key . Note A handset will not start ringing if the handset is not registered to the base station. For more information how to register the handset to the base station refer to page 11. The handset will not ring if switched off or the batteries are flat. Paging key Charging cradle for the handse t Making the first call Switching the handset on/off After placing the handset in the base station (and completing the initial charging of the batteries) the handset is automatically switched on and ready for operation. Switching on the handset If the handset happens to be off, you can switch it on again by pressing the talk key . Switching off the handset You may switch off the handset in order to prolong the duration of the rechargeable batteries. Follow this procedure: Open the menu by pressing the «Menu» softkey. Select the menu entry Switch off HS and press the «OK» softkey. The display shows: Switch off HS? Press the «OK» softkey to switch off the handset. Note The handset does not respond to paging from the base station nor to incoming calls when it is switched off! Registering (Log on) the handset The handset is initially already registered to the base station. In this case both the and symbols should be visible in the display. If for whatever reason the handset is no longer registered to the base station, the display will show Please Log-on ! . In this case follow the registration procedure as described on page 47. Note With this vtech GEMINI you can operate up to 5 handset on the same base station. This allows internal calls between handsets (registered to the same base station) free of charge! Switching the key lock on/off When carrying the handset with you, you may want to switch on the key lock. This prevents any calls be made unintentionally since all key functions are disabled. Pressing the key for approx. 2 seconds will lock/unlock the keypad. When the keys are locked, the display shows Key lock on ! as well as the symbol. Note • Even when the key lock is on, you can answer any incoming call simply …

Text truncated - open the document above for the full version.

FCC, ACTA and IC Regulations • In to event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the product, or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this product, some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. FCC, ACTA and IC Regulations This equipment complies with Parts 15 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. A label is located on the underside of the Base Unit containing either the FCC registration number and Ringer Equivalence Number (REN) or the IC registration number and Load Number. You must, upon request, provide this information to your local telephone company. This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communications Inc CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267- 7377. For repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected. FCC Part 15 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset has such a low power that it does not require testing. It may be safely held against the ear of the user. The base unit shall be installed & used such that parts of the user’s body other than the hands should be maintained at a comfortable distance of approximately 20 cm or more. FCC and ACTA Information If this equipment was approved for connection to the telephone network prior to July 23, 2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules. If the equipment was approved after that date, it complies with the Part 68 rules and with Technical Requirements for Connection of Equipment to the Telephone Network adopted by the Administrative Council for Terminal Attachments (ACTA). We are required to provide you with the following information. 1. Product identifier and REN information The label on the back or bottom of this equipment contains, among other things, an identifier indicating product approval and the Ringer Equivalence Number (REN). This information must be provided to your local telephone company upon request. For equipment approved prior to July 23, 2001, the product identifier is preceded by the phrase “FCC Reg No.” and the REN is listed separately. For equipment approved after that date, the product

External photos FCC ID: EW780-5316-00 External photos FCC ID: EW780-5316-00

Internal photos FCC ID: EW780-5316-00 Base assembly Base Main PCB comp side Internal photos FCC ID: EW780-5316-00 Base Main PCB solder side Base Oscillator PCB comp side (View 1) Internal photos FCC ID: EW780-5316-00 Base Oscillator PCB comp side (View 2) Base Oscillator PCB comp side (View 3) Internal photos FCC ID: EW780-5316-00 Handset assembly Handset Main PCB comp side Internal photos FCC ID: EW780-5316-00 Handset Main PCB display side Handset Oscillator PCB comp side (View 1) Internal photos FCC ID: EW780-5316-00 Handset Oscillator PCB comp side (View 2) Handset Oscillator PCB comp side (View 3)

Vtech Telecommunications Ltd. 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, N.T., Hong Kong Tel: (852)2680-1000 Date: 13 September, 2004 Fax: (852)2680-1468 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, Maryland 21046 USA Declaration on Security Code Dear Sir/Madam, The model “GEMINI” (FCC ID: EW780-5316-00) use 40-bit of security code. It is randomly pre-fixed in the factory. Best Regards, Wilson P.S. Cheung Senior Electronic Engineer R&D Department Vtech Telecommunications Ltd.

FCC, ACTA and IC Regulations • In to event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the product, or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this product, some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. FCC, ACTA and IC Regulations This equipment complies with Parts 15 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. A label is located on the underside of the Base Unit containing either the FCC registration number and Ringer Equivalence Number (REN) or the IC registration number and Load Number. You must, upon request, provide this information to your local telephone company. This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communications Inc CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267- 7377. For repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected. FCC Part 15 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset has such a low power that it does not require testing. It may be safely held against the ear of the user. The base unit shall be installed & used such that parts of the user’s body other than the hands should be maintained at a comfortable distance of approximately 20 cm or more. FCC and ACTA Information If this equipment was approved for connection to the telephone network prior to July 23, 2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules. If the equipment was approved after that date, it complies with the Part 68 rules and with Technical Requirements for Connection of Equipment to the Telephone Network adopted by the Administrative Council for Terminal Attachments (ACTA). We are required to provide you with the following information. 1. Product identifier and REN information The label on the back or bottom of this equipment contains, among other things, an identifier indicating product approval and the Ringer Equivalence Number (REN). This information must be provided to your local telephone company upon request. For equipment approved prior to July 23, 2001, the product identifier is preceded by the phrase “FCC Reg No.” and the REN is listed separately. For equipment approved after that date, the product Intertek Testing Services FCC ID: EW780-5316-00 Date: January 20, 2005 For SAR evaluation of the handset, refer to FCC OET Laboratory Division – Mobile and Portable Device RF Exposure Equipment Authorization Procedures on March 18, 2004. Potable transmitter with output power less than 50-100mW, operating frequency less than or equal to 3GHz and, the distance between antenna and person’s body within 2.5cm can be certified by FCC without SAR evaluation. For the tested model of GEMINI, the measured peak conducted power was 296.48mW. The conducted source-based time averaged output power = (296.48 * 0.03853) mW = 11.42mW The maximum field strength (FS) was 116.8dBμV/m at 2479.680MHz. The distance (D) between the antenna and the equipment under test (EUT) was 3 meters. From these data, the EIRP can be calculated by: EIRP = (FS*D) 2 / 30 = 143.59mW The radiated source-based time averaged output power = (143.59 * 0.03853) mW = 5.53mW Based on the above calculation, it is concluded that the handset can be certified by FCC without the SAR evaluation.

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2741 1693 Website: www.hk.intertek-etlsemko.com VTech Telecommunications Ltd. Application For Certification 2.4GHz Digital Modulation Cordless Phone with Caller ID (FCC ID: EW780-5316-00) 04167831 TL/Ann Choy February 1, 2005 INTERTEK TESTING SERVICE FCC ID: EW780-5316-00 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: Summary of Tests EXHIBIT 2 : General Description EXHIBIT 3 : System Test Configuration EXHIBIT 4 : Measurement Results EXHIBIT 5 : Equipment Photographs EXHIBIT 6 : Product Labelling EXHIBIT 7 : Technical Specifications EXHIBIT 8 : Instruction Manual EXHIBIT 9 : Security Code Information EXHIBIT 10 : Confidentiality Request INTERTEK TESTING SERVICES FCC ID: EW780-5316-00 i MEASUREMENT/TECHNICAL REPORT VTech Telecommunications Ltd.- MODEL: GEMINI FCC ID: EW780-5316-00 This report concerns (check one) Original Grant X Class II Change Equipment Type: DSS-Part 15 Spread Spectrum Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12- 08-03 Edition] provision. Report prepared by: Tommy Leung Intertek Testing Services 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8538 Fax: 852-2741-1693 INTERTEK TESTING SERVICES FCC ID: EW780-5316-00 ii Table of Contents 1.0 Summary of test results ....................................................................................2 2.0 General Description .................................................................................................. 4 2.1 Product Description ................................................................................................. 4 2.2 Related Submittal(s) Grants..................................................................................... 5 2.3 Test Methodology.................................................................................................... 5 2.4 Test Facility ............................................................................................................. 5 3.0 System Test Configuration ...................................................................................... 7 3.1 Justification..............................................................................................................7 3.2 EUT Exercising Software ......................................................................................... 7 3.3 Support Equipment List and Description................................................................... 8 3.4 Equipment Modification............................................................................................ 9 4.0 Measurement Results............................................................................................ 11 4.1 Maximum Conducted Output Power at Antenna Terminals ..................................... 11 4.2 Minimum 6dB RF Bandwidth.................................................................................. 13 4.3 Maximum Power Density ............................................................................................ 15 4.4 Out of Band Conducted Emissions ............................................................................. 17 4.5 Out of Band Radiated Emissions............................................................................ 18 4.6 Transmitter Radiated Emissions in Restricted Bands.............................................. 18 4.7 Field Strength Calculation ...................................................................................... 19 4.8 Radiated Emission Configuration Photograph - Base Unit ......................................... 20 4.9 Radiated Emission Data - Base Unit....................................................................... 21 4.10 Radiated Emission Configuration Photograph - Handset ................................... 25 4.11 Radiated Emission Data - Handset Unit ............................................................. 26 4.12 AC Line Conducted Emission............................................................................... 30 4.13 Line Conducted Configuration Photograph - Base Unit ......................................... 31 4.14 Line Conducted Emission Configuration Data....................................................... 32 4.15 Radiated Emission from Digital Section of Transceiver............................................ 33 4.16 Transmitter Duty Cycle Calculation and Measurements ........................................ 36 5.0 Equipment Photographs ........................................................................................ 38 6.0 Product Labelling ................................................................................................... 40 7.0 Technical Specifications ........................................................................................ 42 8.0 Instruction Manual ...................................................................................................... 44 9.0 Security Code Information.......................................................................................... 46 10.0 Confidential…

Text truncated - open the document above for the full version.

The Worst Case Configuration Photographs FCC ID: EW780-5316-00 Radiated Emission – Base Front View Rear View The Worst Case Configuration Photographs FCC ID: EW780-5316-00 Radiated Emission – Handset Front View Rear View The Worst Case Configuration Photographs FCC ID: EW780-5316-00 Conducted Emission Front View Rear View The Worst Case Configuration Photographs FCC ID: EW780-5316-00 Conducted Emission Side View
