EW780-5348-03Cordless Telephone Handset Transciever

39 Additional Information • In to event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the product, or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this product, some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. FCC, ACTA and IC Regulations This equipment complies with Parts 15 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired opera- tion of the device. A label is located on the underside of the Base Unit containing either the FCC registration number and Ringer Equivalence Number (REN) or the IC registration number and Load Number. You must, upon request, provide this information to your local telephone company. This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communications Inc CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377. For repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected. FCC Part 15 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful inter- ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular in- stallation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. FCC, ACTA and IC Regulations 40 Additional Information • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to com- ply with the FCC criteria. The handset has such a low power that it does not require testing. It may be safely held against the ear of the user. The base unit shall be installed & used such that parts of the user’s body other than the hands should be maintained at a comfortable distance of approximately 20 cm or more. FCC and ACTA Information If this equipment was approved for connection to the telephone network prior to July 23, 2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules. If the equipment was approved after that date, it complies with the Part 68 rules and with Technical Requirements for Connection of Equipment to the Telephone Network adopted by the Administrative Council for Terminal Attachments (ACTA). We are required to provide you with the following information. 1. Product identifier and REN information The label on the back or bottom of this equipment contains, among other things, an identifier indicating product approval and the Ringer Equivalence Number (REN). This information must be provided to your local telephone company upon request. For equipment approved prior to July 23, 2001, the product identifier is preceded by the phrase “FCC Reg No.” and the REN is listed separately. For equipment approved after that date, the product identifier is preceded by “US” and a colon (:), and the REN is encoded in the product identifier without a decimal point as the sixth and seventh characters following the colon. For example, the product identifier US:AAAEQ01B123XYZ would indicate an REN of 0.3. The REN is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. In most, but not all areas, the sum of all RENs should be five (5.0) or less. You may want to contact your local telephone company for more information. 2. Connection and use with the nationwide telephone network The plug and jack used to connect this equipment to the premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual. This equipment may not be used with Coin Telephone Lines or with FCC, ACTA and IC Regulations 41 Additional Information Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. 3. Repair ins…

Text truncated - open the document above for the full version.

1 When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool). 5. Do not place this product on an unstable cart, stand, or table. The prod- uct may fall, causing serious damage to the product. 6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it from overheating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. 9. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the appliance is subsequently used. 11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 12. Unplug this product from the wall outlet and contact VTECH under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, because improper adjustment of other controls may result in damage and will often require extensive work to restore the product to normal operation. E. If the product has been dropped and the cabinet has been damaged. F. If the product exhibits a distinct change in performance. 13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Important Safety Instructions 2 Important Safety Instructions If you have questions about this product, or if you're having difficulty with setup or operation, do not return your phone to the store. Call our Customer Support Center at 1-800-595-9511 In Canada, call 1-800-267-7377 STOP!! 14. Do not use this or any cordless telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS 3 Introduction This is an advanced cordless telephone, capable of supporting 2 Handsets. This manual is designed to familiarize you with this cordless telephone. We strongly recommend you read the manual before using your phone. 4 Parts Check List To purchase replacement battery cells, call VTech Communications, Inc. at 1-800- 595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267- 7377. Note : Use only VTech batteries P/N 80-5380-00-00 or equivalent AAA NiMH rechargeable batteries. 6. Belt Clip 7. Base Wall Mounting Bracket 8. Charger Wall Mounting Bracket 9. Owner’s Manual 10. Battery Cells 1. Base Unit 2. Handsets 3. Handset Charger 4. Base AC Power Adapter 5. Telephone Line Cord 5 1. Antenna 2. Earpiece 3. Volume Control 4. CID (Scroll Up) 5. On (Flash) 6. Dialing Keys (0-9, *, #) 7. Redial (Pause) The Handset Layout 8. Speakerphone 9. LCD Display 10. Select (Menu) 11. Phonebook(Scroll Down) 12. Headset jack (2.5mm) 13. Off (Clear) 14. Intercom 15. Mute (Delete) 6 1. In Use LED 2. Charging LED 3. Message Waiting LED 4. Page key 5. DC Connector 6. Telephone Jack The Base Unit Layout


 !!"#$%&%''%'$$ (((") *

   7 Connecting power to Base Unit/Handset Charger 1. Plug the AC power adapter into an electrical outlet, and the DC connector into the bottom of the Base Unit. Setup 2. Choose the location for your Handset Charger, and plug its power supply into an electrical outlet. Getting Started


 !!"#$%&%''%'$$ (((") *

   8 Installation of Battery Cells in Handset Setup Follow the steps below: 1. Place the new battery cells in the andset with the positive and negative poles aligned in the battery compart- ment. 2. Place the battery cover by sliding it upwards 3. If the new battery cells are not already charged, place the Handset in its Charger, and allow it to charge for 12 hours. After initial charge, a mainte- nance charge of 8 hours should be sufficient. Getting Started Charging of the Handset Battery Cells The Handset of your cordless telephone is powered by rechargeable battery cells. It charges automatically whenever the Handset is in its charger. You should charge the battery pack for 12 hours when you first receive your phone. You’ll know the battery pack needs charg- ing when: • The low battery message is displayed : • The Handset seems completely dead, the LCD is completely clear and does not activate when you pres…

Text truncated - open the document above for the full version.

1 When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool). 4. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. 5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. 6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it from overheating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. 9. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the appliance is subsequently used. 11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 12. Unplug this product from the wall outlet and contact VTECH under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, because improper adjustment of other controls may result in damage and will often require extensive work to restore the product to normal operation. E. If the product has been dropped and the cabinet has been damaged. F. If the product exhibits a distinct change in performance. Important Safety Instructions 2 13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 14. Do not use this or any cordless telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS Important Safety Instructions If you have questions about this product, or if you're having difficulty with setup or operation, do not return your phone to the store. Call our Customer Support Center at 1-800-595-9511 In Canada, call 1-800-267-7377 STOP!! 3 This is an advanced cordless telephone, capable of supporting 2 Handsets. This manual is designed to familiarize you with this cordless telephone. We strongly recommend you read the manual before using your phone. STOP!! If you have questions about this product, or if you’re having difficulty with setup or operation, do not return your phone to the store. Call our Customer Support Center at 1-800-595-9511 In Canada, call 1-800-267-7377 Introduction 4 1. Base Unit 2. Handset 3. Handset Charger 4. Base AC Power Adapter 5. Telephone Line Cord Parts Check List 6. Belt Clip 7. Base Wall Mounting Bracket 8. Charger Wall Mounting Bracket 9. Owner’s Manual 10. 6 AAA Cells To purchase replacement battery cells, call VTech Communications, Inc. at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377. Note: Use only VTech batteries P/N 80-5380-00-00 or equivalent AAA NiMH rechargeable batteries. 5 1. Antenna 2. Earpiece 3. Volume Control 4. CID 5. On (Flash) 6. Dialing Keys (0-9, *, #) 7. Redial (Pause) 8. Speakerphone The Handset Layout 9. LCD Display 10. Select (Menu) 11. Phonebook 12. Headset jack (2.5mm) 13. Off (Clear) 14. Intercom 15. Mute (Delete) 6 1. 2. 3. 4. 5. 6. 7. 8. The Base Unit Layout 9. 10. 11. 12. 13. 14. 15. 7 Connecting power to Base Unit/Handset Charger 1. Plug the AC power adapter into an electrical outlet, and the DC connector into the bottom of the Base Unit. Setup 2. Choose the location for your Handset Charger, and plug its power supply into an electrical outlet. Getting Started 8 Installation of Battery Cells in Handset Setup Follow the steps below: 1. Remove the battery cover by pressing on the indent and sliding downward. 2. Place the new battery cells in the Handset with the positive and negative poles aligned in the battery compartment. 3. Replace the battery cover by sliding it upwards. 4. If the new battery cells are not already charged, place the Handset in its Charger, and allow it to charge for 12 hours. After initial charge, a maintenance charge of 8 hours should be sufficient. Getting Started Charging of the Handset Battery Cells The Handset of your cordless telephone is powered by rechargeable battery cells. It charges automatically whenever the Hand- set is in its charger. You should charge the battery pack for 12 hours when you first receive your phone. You’ll know the battery pack needs charging when: • The low battery message is displayed : • The Handset seems completely dead, the LCD is completely clear and does not activate when you…

Text truncated - open the document above for the full version.

33 SETTING UP YOUR ANSWERING SYSTEM Set outgoing Message (Your Greeting) Press MENU. Voice prompt will say “Set Outgoing Message”. Press any MAILBOX key to hear your greeting. To Erase your Outgoing Message Press MENU. Voice prompt will say “Set Outgoing Message”. Press any MAILBOX key to hear your greeting. Press ERASE while your greeting is playing. Voice prompt: ‘Outgoing message has been erased.’ Pre-recorded Outgoing Messages If you do not record your own Outgoing Message(s), your Answering System provides the following greetings: (With Announce Only set to OFF) ‘Hello! I’m unable to answer your call right now. Please leave your name, number and the message after the tone.’ (With Announce Only set to ON) ‘Hello! I’m unable to answer your call right now. Please call again. Thank you!’ HINT FOR RECORDING OUTGOING MESSAGES If you want to use the Mailbox feature of your answering system, instruct your caller to press 1, 2 or 3 before leaving a message. By doing this, the message will be stored in the corresponding mailbox. For example: “Howdy! We can’t come to the phone right now. To leave a message for Tex, press 1 now; to leave a message for Gomer, press 2 now; or, to leave a message for Fabio, press 3 now; or, just wait for the beep, and start talkin’. Thanks, pardner!” If your caller does not select a mailbox, the message will be recorded in Mailbox 1. Set Security Code A 2-digit security is required to access your answering system from a remote location. Press MENU until ‘Set Security Code’ or ‘Change remote access code’ prompt is heard. Press SELECT to hear the current setting. Press SELECT again to advance the setting by 1; or press and hold to advance in increments of 10. Press TIME/SET to confirm your setting. SET AUDIBLE MESSAGE ALERT MODE (preset to ON) This feature generates a beep tone at the Base every 10 seconds, alerting you to new messages. Answering System Operation At the Base Advanced Operation 34 To set AUDIBLE MESSAGE ALERT: Press MENU until ‘Set Audible Message Alert’ is heard. Pressing SELECT; the current setting will be announced. Press SELECT again to toggle the between ON & OFF. Press TIME/SET to confirm your setting. SET ANNOUNCE-ONLY MODE (preset to OFF) If you want your outgoing message to be heard by callers, but not take messages, set Announce Only to ON. However, if you want your callers to leave you messages, Announce Only must be set to OFF. To set ANNOUNCE-ONLY: Press MENU until: ‘Set Announce Only’ is heard. Pressing SELECT; the current setting will be announced. Press SELECT again to toggle between ON & OFF. Press TIME/SET to confirm your selection. SET CALL SCREENING MODE (preset to ON) Call Screening lets you listen to the incoming message at the Base, as the caller leaves it. To set CALL SCREENING: Press MENU until: ‘Set Call-Screening’ is heard. Pressing SELECT; the current setting will be announced. Press SELECT again to toggle the between ON & OFF. Press TIME/SET to confirm your selection. SET BASE RINGER MODE (preset to ON) The Base Unit has its own ringer, which operates independently of the Handset ringer. To set the BASE RINGER: Press MENU until: ‘Set Base Ringer’ is heard. Pressing SELECT; the current setting will be announced. Press SELECT again to toggle between ON & OFF. Press TIME/SET to confirm your selection. SET NUMBER OF RINGS The Answering System has 4 ‘rings-to-answer’ settings: 2 rings The incoming call is answered after 2 rings. 4 rings The incoming call is answered after 4 rings. 6 rings The incoming call is answered after 6 rings. Toll Saver The incoming call is answered after 2 rings only if there are new messages/memos present in memory; otherwise, the call is answered after 4 rings. Thus, if Toll Saver is active, and your system rings 3 times when you call, you can hang-up to avoid any long distance charges. To set NUMBER OF RINGS: Press MENU: ‘Set Number of Rings’ is heard. Pressing SELECT; the current setting will be announced. Press SELECT again to select 2, 4, 6 & Toll Saver. Press TIME/SET to confirm your selection. Answering System Operation At the Base Advanced Operation 35 LEAVING A MESSAGE (Announce Only set to OFF) If your caller presses 1, 2 or 3 as instructed by your outgoing greeting, he will hear ‘Mailbox _, Now Recording’, followed by a beep. If no mailbox is chosen, the message will be stored in Mailbox 1. If, after recording has begun, the caller does not speak, or hangs up, the recording will terminate in approximately 6 seconds. The maximum length of each message or memo is 4 minutes. The maximum storage capacity of old & new messages / and memos is 99. Total capacity from all sources (Greetings, Messages and Memos) is approximately 15 minutes. RECORDING A MEMO Press REC/MEMO at the Base. You will hear ‘Please select mailbox’. Press the desired Mailbox key. You will hear ‘Now recording’. Speak towards the Base Unit. During recording, the Message Window will count the recording time in seconds. If it exceeds 99 seconds, it will flash [99]. Press any Mailbox key when finished. PLAYING MESSAGES & MEMOS During IDLE mode, press MAILBOX x (x=1, 2 or 3). You will hear ‘Mailbox X. You have XX new messages and XX old messages.’ (if there are new messages) or ‘Mailbox X. You have XX old messages.’ (if there are only old messages) or ‘Mailbox X. You have no messages.’ (if there are no messages). Next, the system will play the messages in mailbox 1, 2 or 3. If there are old and new messages, only new ones are played back. If there are only old messages, all of them are played back. Each message is preceded by a date-time stamp. NOTE: If the system has less than 5 minutes recording time remaining, it will announce the remaining recording time to alert the user after all messages has been played. For example, if the system has less than 3 minutes of storage, it will announce: ‘Remaining recording time is 2 minutes’. ERASE (ALL OLD MESSAGES & MEMOS) During IDLE mode, press ERASE. You will hear ‘Please select mailbox’,…

Text truncated - open the document above for the full version.

October 8, 2003 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: Base: EW780-5348-02 Handset: EW780-5348-03 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: (1) Theory of Operation (2) Wireless System Description (3) Schematics (4) Block Diagrams (5) Part Lists The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Joseph Poon Regulatory Compliance Manager

VTech 5825/5850 Handset Cosmetic VTech 5825/5850 Handset Cosmetic


           !

 "##$$ %#$$ &#'(%(()*   +  ,-#'%&.-'#&   ((&%'-#%&.-## ",%$$ (/%$$ )  012) 3 2  2 42 42  52 6) 7          !


  +  ,-#'%&.-'#&   ((&%'-#%&.-##

VTech Engineering Canada Ltd. 200 – 7671 Alderbridge Way, Richmond, B.C. Canada V6X 1Z9 Tel: (604) 273-5131 Fax: (604) 276-9137 Radio Frequency Exposure Information For VTech 5825 / 5850 Cordless Handset Handset (Tx: 2.4GHz; Rx: 5.8GHz) Readings from test report : (1) Max. Output Power = 78.7 mW (19 dBm) (2) Duty cycle – 917us / 10ms = 9.17% (measured in single slot transmission) Under the worst environment with interference, dual slot diversity gives the max. duty cycle on the handset Tx (ie. 9.17% x2 or 18.34%) Hence, taking the max. power output & max. duty cycle, the average effective output power is : 78.7 mW x 18.34% = 14.4 mW Conclusion : The average effective output power is much lower than the 50mW level (Supplement C, Table 1) which starts to require SAR testing. Hence, there is no RF exposure concerns on handset.

Master: PT15C-FHT Date: February 7, 2002 Test Report: 3W07491 Applicant: VTech Engineering Canada Ltd. Suite 200 – 7671 Alderbridge Way Richmond, B.C., Canada V6X 1Z9 Equipment Under Test: 5825 & 5850 (EUT) In Accordance With: FCC Part 15, Subpart C Frequency Hopping Transmitters Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Glen Westwell, Wireless Technologist Date: 29 October 2003 Total Number of Pages: 47 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:3W07491 EQUIPMENT: 5825 & 5850 Page 2 of 47 Table of Contents Section 1. Summary of Test Results .................................................................................. 3 Section 2. General Equipment Specification..................................................................... 5 Section 3. Powerline Conducted Emissions....................................................................... 6 Section 4. Channel Separation ......................................................................................... 11 Section 5. Number of Hopping Channels ........................................................................ 13 Section 6. Time of Occupancy .......................................................................................... 19 Section 7. Occupied Bandwidth ....................................................................................... 23 Section 8. Peak Power Output.......................................................................................... 30 Section 9. Spurious Emissions (Radiated)........................................................................ 32 Section 10. Block Diagrams ................................................................................................. 46 Section 11. Test Equipment List ......................................................................................... 47 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:3W07491 EQUIPMENT: 5825 & 5850 Page 3 of 47 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.247 for Frequency Hopping Spread Spectrum devices. Radiated tests were conducted is accordance with ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: _______________________________ DATE: 23 October 2003 Kevin Carr, EMC/EMI/Wireless Specialist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:3W07491 EQUIPMENT: 5825 & 5850 Page 4 of 47 Summary Of Test Data Name Of Test Para. No. Result Powerline Conducted Emissions 15.207(a) Complies Channel Separation 15.247(a)(1) Complies Time of Occupancy 15.247(a)(1)(iii) Complies 20 dB Occupied Bandwidth 15.247(a)(1) Complies Number of Hopping Channels 15.247(a)(1)(iii) Complies Peak Powe…
