EW780-5595-00Vtech 5871

1 Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water (for example, near a bath tub, kitchen sink or swimming pool). 5. Do not place this product on an unstable surface such as a table, shelf or stand. The product may fall, causing serious damage. 6. Slots and openings in the back or bottom of the Base Unit and Handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. Nor should this product should not be placed in any area where proper ventilation is not provided. 7. This product should be operated only from the type of power source indicated on the packaging. If you are not sure of the type of power supply in your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not install this product where the cord may have anyone walking on it. 9. Never push objects of any kind into this product through slots in the Base or Handset as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Avoid spilling liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the Base or Handset other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 12. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled onto the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation. E. If the product has been dropped and the Base and/or Handset has been damaged. 2 F. If the product exhibits a distinct change in performance. 13. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. 15. Only put the Handset of your telephone next to your ear when it is in normal talk mode. Important Safety Instructions WARNING: To insure your safety from possible electric shock, only use the enclosed VTech Audio Patch Cable to record custom ring tones. Do NOT leave the Audio Patch Cable attached to the Handset while charging in its cradle. 3 Your i 5871 is an advanced cordless telephone that operates in the 5.8GHz fre- quency range. Your i 5871 is capable of supporting up to a maximum of 8 Handsets. Using additional Handsets, up to 2 people can be conferenced on a call (2 Handsets), or two extensions can be conferenced on a call, while two other extensions can be talking internally, using the Intercom feature. This manual is designed to familiarize you with the i 5871 cordless telephone. We strongly recommend you read the manual before using your phone. To order additional system Handsets (model number i 5808), battery cells or headsets, call VTech Communications, Inc. at 1-800-595-9511. In Canada, call 1-800-267-7377. Introduction 4 Parts Check List 1. Base Unit 2. Handset 3. Telephone Line Cord 4. Belt Clip 5. User’s Manual 6. Quick Start Guide 7. Battery Pack 8. USB Cable 9. Audio Patch Cable 10. Image Editor Software (CD-ROM) 11. Base AC Power Adapter To purchase replacement battery cells, call VTech Communications, Inc. at 1-800- 595-9511. In Canada, call VTech Telecommunication Canada Ltd. at 1-800-267-7377. Note: Use only VTech batteries (part number 80-5461-00-00) or equivalent AA NiMH re- chargeable batteries. Base Unit Handset Telephone Line Cord Belt Clip User’s Manual Quick Start Guide Battery Pack USB CableAudio Patch Cable Image Editor Software (CD-ROM) Base AC Power Adapter 5 The Handset Layout 1. Earpiece 2. Headset Jack and Audio Patch Cable Jack (2.5mm) 3. Soft/Select Key 4. On/Flash Key 5. Dialing Keys (0-9, *, #) 6.Speakerphone Key 7.LCD Display 8.Navigation Key 9.Volume Keys 10. Off/Cancel Key 11. Microphone 6 The Base Unit Layout 1. Volume Keys 2. Charging LED 3. Repeat/Slow 4. Skip/Quick 5. Delete 6. Record 7. Change 8. Antenna 9. Time/Set 10. Menu 11. Mailbox Keys (Play/Stop) 12. In Use LED 13. Page 14. On/Off 15. Spare Battery Drawer 16. Spare Battery Release Button 17. Telephone Jack 18. DC Connector Jack 7 Getting Started Setup Connecting Power to Base Unit Plug the AC power adapter into an electrical outlet, and the DC connector into the bottom of the Base Unit. Installation and Charge of Battery Cells in Handset 1. Remove the battery cover and place the new battery cells in the Handset with the positive and negative poles aligned in the battery compartment. 2. Replace the battery cover by sliding it upwards. 3. If the new battery cells are not already charged, place the Handset in its Charger or Base Unit, and allow it to charge for at least 12 hours. After initial charge, a maintenance charge of 8 hours shoul…

Text truncated - open the document above for the full version.

1 When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water (for example, near a bath tub, sink or swimming pool). 5. Do not place this product on an unstable surface such as a table, shelf, or stand. The product may fall, causing serious damage. 6. Slots and openings in the back or bottom of the Base Unit and Handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not install this product where the cord may have anyone walking on it. 9. Never push objects of any kind into this product through slots in the Base or Handset as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the Base or Handset other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 12. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: A . When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled onto the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation. E. If the product has been dropped and the Base and/or Handset has beendamaged. F. If the product exhibits a distinct change in performance. Important Safety Instructions 2 Important Safety Instructions 13. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. 15. Only put the Handset of your telephone next to your ear when it is in normal talk mode. WARNING: To insure your safety from possible electric shock, only use the enclosed VTech Audio Patch Cable to record custom ring tones. Do NOT leave the Audio Patch Cable attached to the Handset while charging in its cradle. 3 The i 5858 is an advanced cordless telephone that operates in the 5.8GHz frequency range. Your i 5858 is capable of supporting up to a maximum of 8 Handsets. Using additional Handsets, up to three people can be conferenced on a call (2 Handsets and the Base Speakerphone), or two extensions can be conferenced on a call, while two other extensions can be talking internally, using the Intercom feature. This manual is designed to familiarize you with the i 5858 cordless telephone. We strongly recommend you read the manual before using your phone. To order additional system Handsets (model number i 5808), battery cells or Introduction headsets, call VTech Communications, Inc. at 1-800-595-9511. In Canada, call 1-800- 267-7377. 4 To purchase replacement battery cells, call VTech Communications, Inc. at 1-800-595-9511. In Canada, call VTech Telecommunication Canada Ltd. at 1-800-267-7377. NOTE: Use only VTech batteries P/N 80-5461-00-00 or equivalent AA NiMH rechargeable batteries. Parts Check List 1. Base Unit 2. Handset 3. Base AC Power Adapter 4. Telephone Line Cord 5. Quick Start Guide 6. Belt Clip 7. User’s Manual 8. Audio Patch Cord 9. Battery Cells 10. Image Editor Software (CD-Rom) 11. USB Cable Base Unit Handset Base AC Power Adapter Telephone Line Cord Quick Start Guide Belt Clip User’s Manual Audio Patch Cord Image Editor Software (CD- Rom) USB Cable Battery pack 5 The Handset Layout 1. Earpiece 2. USB Cable Jack 3. Headset Jack and Audio Patch Cable Jack (2.5mm) 4. On/Flash Key 5. Dialing Keys (0-9, *, #) 6. Speakerphone Key 7. LCD Display 8. Select Key 9. Softkey 10. Volume Keys 11. Off/Cancel Key 12. Microphone




 6 1. Charging LED 2. LCD Display 3. Message LED 4. Speakerphone 5. Softkeys 6. Flash 7. Intercom The Base Unit Layout 8. Volume Key 9. Dialing Keys (0-9, * , #) 10. Clear 11. Antenna 12. Telephone Jack 13. DC Connector Jack 14. Spare Battery Drawer






 7 Getting Started Connecting Power to Base Unit Plug the AC power adapter into an electrical outlet, and the DC connector into the bottom of the Base Unit. Setup Getting Started To AC outlet 8 Getting Started Installation and Charge of Battery Cells in Handset The original Handset that is shipped with your i 5858 system will be automatically registered to the Base. This Handset is HANDSET 1. As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3, etc. Whenever a charged Handset battery pack is installed, the Handset will automat…

Text truncated - open the document above for the full version.

51 Additional Information FCC, ACTA and IC Regulations FCC and ACTA Information If this equipment was approved for connection to the telephone network prior to July 23, 2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules. If the equipment was approved after that date, it complies with the Part 68 rules and with Technical Requirements for Connection of Equipment to the Telephone Network adopted by the Administrative Council for Terminal Attachments (ACTA). We are required to provide you with the following information. This equipment complies with Parts 15 of the Federal Communications Commission (FCC) rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry and Science Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. A label is located on the underside of the base unit containing either the FCC registration number and Ringer Equivalence Number (REN) or the IC registration number and Load Number. You must, upon request, provide this information to your local telephone company. This equipment is compatible with inductively coupled hearing aids. Should you experience trouble with this telephone equipment, please contact: VTech Communications Inc. CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377 for repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected. FCC Part 15 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet or on a circuit different from that to which he receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset has such a low power that it does not require testing. It may be safely held against the ear of the user. The base unit shall be installed & used such that parts of the user’s body other than the hands should be maintained at a comfortable distance of approximately 20 cm or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip. 52 Additional Information FCC, ACTA and IC Regulations 1. Product identifier and REN information The label on the back or bottom of this equipment contains, among other things, an identifier indicating product approval and the Ringer Equivalence Number (REN). This information must be provided to your local telephone company upon request. For equipment approved prior to July 23, 2001, the product identifier is preceded by the phrase “FCC Reg No.” and the REN is listed separately. For equipment approved after that date, the product identifier is preceded by “US” and a colon (:), and the REN is encoded in the product identifier without a decimal point as the sixth and seventh characters following the colon. For example, the product identifier US:AAAEQ03T123XYZ would indicate an REN of 0.3. The REN is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your local telephone company. 2. Connection and use with the nationwide telephone network The plug and jack used to connect this equipment to the premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in this user’s manual. This equipment may not be used with Coin Telephone Lines or with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. 3. Repair instructions If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty. 4. Rights of the telephone company If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue y…

Text truncated - open the document above for the full version.

November 1, 2004 Federal Communications Commission 7435 Oakland Mills Road, Columbia, Maryland 21046 USA Authority to Act as Agent to Federal Communications Commissions FCC ID: EW780-5595-00 On our behalf, I appoint Nemko Canada Inc, 203 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with VTech Engineering Canada, 200-7671 Alderbridge Way, Richmond B.C., Canada V6X 1Z9. Dated this 1st Day of November 20 04 Agency agreement expiration date: March 30, 2005 By: Joseph Poon Signature Printed Title: Regulatory Compliance Manager On behalf of : VTech Engineering Canada Ltd. Telephone: (604) 273-5131

November 1, 2004 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Confidentiality Request regarding application for certification with FCC ID: EW780-5595-00 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, Vtech hereby request confidential treatment of information accompanying this application as outlined below: Please mark the below information (list no# 1 to 3) as "Confidential". (1) Theory of Operation and Block Diagrams (2) Schematics (3) Parts Lists The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. We are also requesting that the FCC mark the below information (list no# 4 to 6) as "Temporary Confidential" as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Vtech temporary confidentiality prior to product launch. (4) External Photos (5) Internal Photos (6) User's Manual The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you need any further information, please contact me. Thanks. Sincerely, Joseph Poon Regulatory Compliance Manager

December 9, 2004 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Addition of Model 5858 in application filing -- FCC ID: EW780-5595-00 Due to mistake made in the model number of the original application filed in November 2004, revised exhibits & additional exhibits are uploaded. The filing will now include both family models VTech 5858 & 5871. VTech 5858 : 5.8GHz digital cordless telephone with Base dialing keypad. VTech 5871 : same as above except the base is equipped with an digital answering machine. The base dialing keypad is removed. The handset is identical as VTech 5858. They both share the identical RF module & a majority of other baseband circuitry. See schematic diagrams for reference. Although there are some confusion on the model no. appears on the SAR & EMC reports, the testing are valid & were done on the same set of VTech 5858 sample unit. 1) Handset SAR report – the handset tested is from VTech 5858. The report is named as VTech 5871. Since both handsets are identical, the report is applicable to VTech 5858 & 5871. 2) EMC report – the report was revised to reflect the correct model no. VTech 5858. 3) Digital emission testing was done on VTech 5871. The report can be available on request. Should you need any further information, please contact me. Thanks. Sincerely, Joseph Poon Regulatory Compliance Manager

December 16, 2004 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Confidentiality Request regarding application for certification with FCC ID: EW780-5595-00 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, Vtech hereby request confidential treatment of information accompanying this application as outlined below: Please mark the below information (list no# 1 to 5) as "Confidential". (1) Theory of Operation (2) Schematics (3) Parts Lists (4) Wireless System Description (5) Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. We are also requesting that the FCC mark the below information (list no# 6 to 8) as "Temporary Confidential" as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Vtech temporary confidentiality prior to product launch. (6) External Photos (7) Internal Photos (8) User's Manual The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you need any further information, please contact me. Thanks. Sincerely, Joseph Poon Regulatory Compliance Manager

Page 1 of 3 Mr W. Leung VTech Telecommunications Ltd Date: 14 th December 2004 REF: EW780-5595-00 CRN: 28167 Dear Mr. Leung, Please find attached details and responses to the relevant questions received from the FCC. If you have any questions please let me know. Thanks, Stuart Nicol. Please provide details of the scanning procedure such as step size and distance from phantom surface. Area scan dimensions along with the distance from the phantom surface are included within the test report(s) data under the phantom data section. The distance from the probe to the phantom surface is recorded in section 4.1 isotropic E-Field probe as (sensor offset+2.44mm) =5mm. The area scan is recorded as 280mm by 200mm maximum scan area, but is reduced to 130 by 80mm after the peak SAR location has been identified. APREL Laboratories use a 4mm step resolution for “zoom” scan processes in all directions due to the axial isotropic response error for the E-020 probe being around 0.05dB. It has been found that this process allows FDTD derived target validation numbers to be achieved. Please provide details justifying the developed target values. Presented below are numerical references derived from homogeneous compositions based on the FCC values for epsilon and sigma, along with the values for epsilon and sigma used for experimental tissues used by APREL Laboratories, and complex heterogeneous (anatomical models). All numerical problems were executed using Remcom XFDTD. The data presented above shows that a complex anatomical model based on MRI/VH data at a resolution of 0.3mm yields significantly lower SAR values. It should be noted that these values are closer to the physical biological phenomenon. Deviations of SAR when comparing the FCC data for epsilon and sigma against the APREL tissue values for epsilon and sigma show that the deviation is within tolerance which is significantly lower than allowable deviations of 30%. It can also be shown that the tissues used by APREL Laboratories yield conservative SAR, and prove that a conservative mandate has been met. Tissue Type Epsilon Sigma Frequency 1g SAR 10g SAR Peak SAR APREL 43 5.75 5200 MHz 58.8 17.7 240.2 FCC 49 5.3 5200 MHz 55.7 15.5 210.3 Anatomical - - 5200 MHz 34.1 11.38 - APREL 48.2 6 5800 MHz 57.9 16.6 295.3 FCC 48.2 6 5800 MHz 55.8 15.2 230.1 Anatomical - - 5800 MHz 33.0 11.1 - Page 2 of 3 Papers along with presentations have been submitted to IEC 62209 for consideration and use in the development of the part 2 standard. APREL Laboratories shall also present relevant papers to IEEE at symposiums next year. Please justify body worn test position as shown on page 23 of 41. The device hanging off the phantom is unusual. Initial scans were executed over the complete area of the device to identify the location for the hotspot and to determine the distribution of the SAR in X and Y. This exercise allows APREL Laboratories to create a smaller scanning area and thus reduce test time for the exercise. Included below is a series of images showing the device setup used for the larger area scan used to determine the reduction scan ratio. Maximum Area Scan Back of Device Maximum Area Scan Front of Device Page 3 of 3 Please provide a body worn position scan of the entire device. A complete series of area scans were run on both the front and back configurations and it was found that the SAR was lower than that reported in the SAR test report following the reduced area scan parameters. The maximum SAR values recorded are listed below. Back of Device SAR 1g=0.14 SAR Peak=0.32 Front of Device SAR 1g=0.06 SAR Peak=0.17 As the SAR results were close to the noise floor level the plots were not included in the original report.

VTech 5871 Cosmetic AT&T 5871 Base Cosmetic - Front AT&T 5871 Base Cosmetic - Back

VTech 5871 Handset Cosmetic - Front VTech 5871 Handset Cosmetic - Back

VTech 5871 Base PCB VTech 5871 Base PCB VTech 5871 Base PCB VTech 5871 Base PCB VTech 5871 Base PCB VTech 5871 Base PCB

Vtech 5871 Handset PCB Vtech 5871 Handset PCB Vtech 5871 Handset PCB

VTech 5858 (Handset + Base) Cosmetic AT&T 5858 Base Cosmetic - Front AT&T 5858 Base Cosmetic - Back VTech 5858 Base PCB VTech 5858 Base PCB VTech 5858 Base PCB VTech 5858 Base PCB VTech 5858 Base PCB VTech 5858 Base PCB

VTech 5858 Handset Cosmetic - Front VTech 5858 Handset Cosmetic - Back Vtech 5858 Handset PCB Vtech 5858 Handset PCB Vtech 5858 Handset PCB

VTech 5871 Cosmetic AT&T 5871 Base Cosmetic - Front AT&T 5871 Base Cosmetic - Back Vtech 5871 Base PCB Vtech 5871 Base PCB Vtech 5871 Base PCB Vtech 5871 Base PCB Vtech 5871 Base PCB

Consulting ● Research ● Certification Testing ● SAR Tools and Training ● Since 1981 51 Spectrum Way Nepean, Ontario Canada K2R 1E6 © 2004 APREL Laboratories Tel: (613) 820-2730 Fax: (613) 820-4161 [email protected] www.aprel.com This report shall not be reproduced, except in full, without written approval of APREL Laboratories Project number: VTCB-Handset-5071 FCC ID: EW780-5595-00 AL-065 Page 1 of 54 Applicant Name: V-Tech Telecommunications Ltd Applicant Address: VTech Telecommunications Ltd, 23/F Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, N.T. Hong Kong FCC ID: EW780-5595-00 Test/Analysis Date: 15 October 2004 Project Number: VTCB-Handset Phoenix-5071 DUT Type Cordless Telephone Model Number VTech 5871 Handset Agency Series Number Not Applicable Project Name VTech 5.8GHz Freq. Hopping Spread Spectrum Cordless Telephone Received Status Pre Production Model DUT Serial Number 4W3055 Experimental/Compliance Compliance Head Analysis Tx Frequency 5744.736 MHz – 5825.952 MHz Max Tx Power 21.6 dB NOTE: The Tx Power could not be measured directly. Power was measured using an air interface setup and relative power was recorded. A letter of attestation was received from VTech providing the actual maximum power. Conservative Averaged SAR (RF Exposure) 0.09 W/Kg SAM Left Touch Position We the undersigned of APREL Laboratories, located at 51 Spectrum Way, Ottawa, Ontario, Canada, K2R-1E6, on the date indicated attest that the Device Under Test as detailed within this test report has been tested and found to be compliant with the Uncontrolled Environment RF exposure rules and regulations as defined by the methodologies, procedures, and standards as described in this document. ConsultingłResearchłCertification TestingłSAR Tools and TrainingłSince 1981 51 Spectrum Way Nepean, Ontario Canada K2R 1E6 © 2004 APREL Labo…

Text truncated - open the document above for the full version.
