EW780-5654-00Cordless Telephone Base

1 Important Safety Instructions When using your telephone equipment, basic safety precautions should al- ways be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the power outlet and broadband connection be- fore cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool). 5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage. 6. Slots and openings on the base and handset are provided for ventilation. To protect it from overheating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. 9. Never push objects of any kind into this product through the slots in the base or handset as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the appliance is subsequently used. 11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 12. Unplug this product from the wall outlet and contact VTech under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instruc tions. Adjust only those controls that are covered by the operating in structions, because improper adjustment of other controls may result in damage and will often require extensive work to restore the product to normal operation. 2 Important Safety Instructions BEFORE USING YOUR IP 8100-2 SYSTEM, CAREFULLY PEEL OFF THE PROTECTIVE FILM COVERING THE DISPLAYS. E. If the product has been dropped and the handset and/or base unit has been damaged. F. If the product exhibits a distinct change in performance. 13. Avoid using a telephone (other than cordless) during an electrical storm. There may be a remote risk of electric shock from lightning. 14. Do not use this or any cordless telephone to report a gas leak in the vicinity of the leak. 15. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. SAVE THESE INSTRUCTIONS Add new handsets to make your phone more versatile Your telephone can accommodate up to four cordless handsets. You can add new handsets (Model IP 811, sold separately) at any time. You can register a maximum of four handsets. 3 Parts Check List NOTE: USE ONLY VTech Battery 80-5808-00-00 or VTech Replacement 89-1324-00-00. 6. Charger Wall Mounting Bracket (2) 7. Belt Clips (2) 8. User Documentation CD 9. Quick Start Guide 10. Batteries (2) 1. Base Unit 2. Handsets (2) 3. Handset Chargers (2) 4. Ethernet Cable 5. Base Power Adapter Base Unit Handset x 2 Base AC Adapter Handset Charger x 2 Ethernet Cable Belt Clip x 2 User Docu- mentation CD Quick Start Guide Charger Wall Mounting Bracket x 2 Battery x 2 The IP 8100-2 is an advanced Broadband cordless telephone set, capable of supporting four handsets. This manual is designed to familiarize you with this Broadband cordless tele- phone. We strongly recommend you read the manual before using your phone. 4 1. Antenna 2. Earpiece 3. Volume Control 4. CID (Scroll Down) 5. On (Flash) 6. Voicemail 7. Dialing Keys (0-9, *, #) 8. Redial (Pause) The Handset Layout 9. Speakerphone 10. LCD Display 11. Select (Menu) 12. Phonebook (Scroll Up) 13. Headset Jack (2.5mm) 14. Off (Clear) 15. Intercom 16. Mute (Delete) 16 12 13 5 The Base Unit Layout
       1. Message Waiting LED 2. Page key 3. In Use LED 4. Service Status LED 5. LAN Port 6. WAN Port 7. DC Connector Jack 8. Telephone Adapter Reset Switch 6 Getting Started Setup Charging of the Handset Battery Pack The handset of your cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever handset is in its charger. You should charge the batteries for 10-12 hours when you first receive your phone. You will know the battery pack needs charg- ing when: • The low battery message is displayed: •The handset seems completely dead, the LCD is completely clear and does not activate when you press the keys. NOTE: While in PLACE IN CHARGER (low battery) mode, the keypad sounds, backlighting and speakerphone features will not work. When the battery has been charged, the features will return to their normal function. IMPORTANT: 1. Do not dispose of the battery pack in a fire, it might explode. 2. Do not open or mutilate the battery pack. Toxic substances may be re- leased, causing harm to eyes or skin. 3. Exercise care in handling batteries in order to prevent an accidental short of the charge contacts, potentially causing the batteries to overheat. Installation of Battery Pack in Handset Follow the steps below: 1. Re…

Text truncated - open the document above for the full version.

30 Additional Information FCC and IC Regulations This equipment complies with Parts 15 of the Federal Communications Commis- sion (FCC) rules for the United States. It also complies with regulations RSS210 of Industry and Science Canada. Operation is subject to the following two con- ditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired op- eration of the device. FCC Part 15 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tele- vision reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset has such a low power that it does not require testing. It may be safely held against the ear of the user. The base unit shall be installed & used such that parts of the user’s body other than the hands should be maintained at a comfortable distance of approximately 20 cm or more. IC (Industry Canada) This telephone is registered for use in Canada. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equip- 31 Additional Information FCC and IC Regulations ment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of services in some situations. Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecom- munications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connec- tions of the power utility, telephone lines and internal metallic water pipe sys- tem, if present, are connected together. This precaution may be particularly im- portant in rural areas. Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electrical inspection authority, or electrician, as appropriate. Your cordless phone is designed to operate at the maximum power allowed by the FCC and IC. This means your handset and base unit can communicate only over a certain distance - which will depend on the location of the base unit and handset, weather, and the construction and layout of your home or office.

April 13, 2005 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Canada Inc, 203 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with VTech Engineering Canada, 200-7671 Alderbridge Way, Richmond B.C., Canada V6X 1Z9. Dated this 13th Day of April 20 05 Agency agreement expiration date: October 31, 2005 By: Joseph Poon Signature Printed Title: Regulatory Compliance Manager On behalf of : VTech Engineering Canada Ltd. Telephone: (604) 273-5131

April 13, 2005 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: EW780-5654-00 (Base) Product Name: VTech IP8100-2 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents (list no# 1 to 5) be held confidential: (1) Theory of Operation (2) Wireless System Description (3) Schematics (4) Block Diagrams (5) Parts List (BOM) We also request that the FCC mark the below documents (list no# 6 to 8) as "Temporary Confidential" as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Vtech temporary confidentiality prior to product launch. (6) External Photos (7) Internal Photos (8) Users Manual These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 13th Day of April 2 0 05 By: Joseph Poon Signature Printed Title: Regulatory Compliance Manager On behalf of : VTech Engineering Canada Ltd. Telephone: (604) 273-5131

Vtech IP8100-2 Cosmetic Vtech IP8100-2 Base Cosmetic Vtech IP8100-2 Base Cosmetic - Ethernet Ports Vtech IP8100-2 Base Cosmetic - Bottom Vtech IP811 Handset & Charger Cosmetic

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 27.36 (dBm) Maximum peak output power at antenna input terminal: 544.5026528 (mW) Antenna gain(typical): 3 (dBi) Maximum antenna gain: 1.995262315 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5744.736 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.216138 (mW/cm^2) Maximum allowable antenna gain: 9.652698554 (dBi) Margin of Compliance: 6.652698554 2 4 R PG S π =

Master: PT15C-FHT Date: February 7, 2002 Test Report: 5W37404 Issue 2 Applicant: VTech Engineering Canada Ltd. Suite 200 – 7671 Alderbridge Way Richmond, B.C., Canada V6X 1Z9 Equipment Under Test: Vtech Ip 8100-2 (EUT) 5.8GHz FHSS Base Unit FCC ID: In Accordance With: FCC Part 15.247, Subpart C FHSS System and Digitally Modulated Radiators 5725-5850MHz Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, General Manager Date: 22 April 2005 Total Number of Pages: 33 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 2 of 33 Table of Contents Section 1. Summary of Test Results ...................................................................................3 Section 2. General Equipment Specification......................................................................5 Section 3. Powerline Conducted Emissions........................................................................6 Section 4. 20 dB Bandwidth...............................................................................................10 Section 6. Number of Hopping Channels .........................................................................14 Section 7. Minimum Channel Separation ........................................................................17 Section 8. Peak Output Power...........................................................................................18 Section 9. Spurious Emissions ...........................................................................................21 Section 10. Block Diagrams ..................................................................................................32 Section 11. Test Equipment List ..........................................................................................33 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 3 of 33 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C. Radiated tests were conducted is accordance with ANSI C63.4-2001. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: Glen Westwell, Wireless Specialist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 4 of 33 Summary Of Test Data Name Of Test Para. No. Result Powerline Conducted Emissions 15.207(a) Complies 20 dB Bandwidth 15.247(a)(1)(ii) Complies Number of Hopping Channels 15.247(a)(1)(ii) Complies Occupancy Time 15.247(a)(1)(ii) Complies Minimum Channel Separation 15.247(a)(1) Complies Peak Output Power 15.247(b)(1) Complies Spurious Emissions 15.247(d) Complies Test Conditions: Indoor Temperature: 23°C Humidity: 42% Outdoor Temperature: -12°C Humidity: 30% Test Set Up Diagram Input source=110Vac EUT Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 5 of 33 Section 2. General Equipment Specification Manufacturer: Vtech Engineering Model No.: Ip 8100-2 Serial No.: 2881 Date Received In Laboratory: 20 Jan 2005 Band of Operation: 5725-5850MHz Operating Frequency of EUT: 5744.736-5825.952MHz Peak Output Power (Rated): 27.0dBm Modulation: GFSK Antenna Gain: 3dBi Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 6 of 33 Section 3. Powerline Conducted Emissions Para. No.: 15.207(a) Test Performed By: Glen Westwell Date of Test: 20 Jan. 2005 Test Results: Complies. General These tests were conducted using measurement procedures of ANSI C63.4-2001. The equipment was tested for conducted emissions from 0.15MHz to 30MHz using a 50 microhenry line impedance stabilization network (L.I.S.N.) as described in ANSI C63.4-2001. Peripheral equipment was also operated through a 50 microhenry L.I.S.N. Limits For Conducted Disturbance At The Mains Ports: Paragraph No. 15.107 for Class B Limits dB(μV) Frequency Range MHz Quasi-Peak Average 0.15 to 0.50 66 to 56 56 to 46 0.5 to 5 56 46 5 to 30 60 50 Notes 1. The lower limit shall apply at the transition frequency. 2. The limit decreases linearly with the logarithm of the frequency in the range 0.15 to 0.50MHz. Measurement Data: See attached graph(s). Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 7 of 33 Set-up Photo Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 8 of 33 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 9 of 33 Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 Issue 2 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 10 of 33 Section 4. 20 dB Bandwidth Para. No.: 15.247(a)…

Text truncated - open the document above for the full version.

Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 7 of 34 Set-up Photo Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 26 of 34 Set-up Photo Nemko Canada Inc. FCC PART 15, SUBPART C FREQUENCY HOPPING TRANSMITTERS PROJECT NO.:5W37404 EQUIPMENT: Vtech Ip 8100-2, Base Unit Page 27 of 34
