EW780-5735-01Cordless Telephone Handset Transceiver

www.vtechphones.comTABLE OF CONTENTS 1 Tabel of Contents Before You Begin . . . . . . . . . . . . . . . . . . . . 4 Parts Check List: . . . . . . . . . . . . . . . . . . . 4 Getting Started . . . . . . . . . . . . . . . . . . . . . 5 Installation . . . . . . . . . . . . . . . . . . . . . . . . 5 Choose Location . . . . . . . . . . . . . . . . . . . 5 Install Handset Battery . . . . . . . . . . . . . . . . 5 Connect Power and Telephone Line Cords. . . . . . 6 Wall Mounting. . . . . . . . . . . . . . . . . . . . . 7 Charge the Handset Battery . . . . . . . . . . . . . 8 Set Language Mode . . . . . . . . . . . . . . . . . 8 Check for Dial Tone. . . . . . . . . . . . . . . . . . 8 Set the Dial Mode. . . . . . . . . . . . . . . . . . . 8 Set Handset Date and Time. . . . . . . . . . . . . . 9 Handset Ringer Style/Battery Save. . . . . . . . . . 9 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . 10 Installation. . . . . . . . . . . . . . . . . . . . . . 10 Attach belt clip (optional). . . . . . . . . . . . . . . 10 Basic Operation. . . . . . . . . . . . . . . . . . . . 11 Telephone Operation. . . . . . . . . . . . . . . . . . 11 Handset Operation . . . . . . . . . . . . . . . . . 11 Base Operation . . . . . . . . . . . . . . . . . . . 12 Temporary Tone Dialing . . . . . . . . . . . . . . 13 Headset Jack . . . . . . . . . . . . . . . . . . . . 13 Operating Range . . . . . . . . . . . . . . . . . . 14 Message Waiting . . . . . . . . . . . . . . . . . . 15 Clear Message Waiting Alert . . . . . . . . . . . . 15 Display Screen Messages . . . . . . . . . . . . . 16 Speed Dial . . . . . . . . . . . . . . . . . . . . . . . 17 Store a Number/Name in Speed Dial . . . . . . . . 17 Edit a Speed Dial Number/Name . . . . . . . . . . 18 Delete a Speed Dial Number/Name. . . . . . . . . 19 Dial a Speed Dial Number . . . . . . . . . . . . . 19 Reassign Locations in Speed Dial . . . . . . . . . 19 Telephone Directory . . . . . . . . . . . . . . . . . . 20 Store a Number/Name in the Directory . . . . . . . 20 Edit a Number/Name in the Directory. . . . . . . . 20 Delete a Number/Name in the Directory . . . . . . 21 Move a Number/Name to Speed Dial . . . . . . . 22 Dial a Number from the Directory. . . . . . . . . . 22 Caller ID Operation. . . . . . . . . . . . . . . . . . . 23 About Call History (Caller ID) . . . . . . . . . . . . 24 Review Call History . . . . . . . . . . . . . . . . . 24 Delete Records from Call History . . . . . . . . . . 25 Dial a Displayed Number . . . . . . . . . . . . . . 25 Store a Call History Record in the Directory . . . . 25 Display Screen Messages . . . . . . . . . . . . . 26 Batteries . . . . . . . . . . . . . . . . . . . . . . . . 27 Battery Care and Maintenance . . . . . . . . . . . 27 TABLE OF CONTENTSwww.vtechphones.com 2 Replacing the Handset Battery . . . . . . . . . . . 27 Additional Information . . . . . . . . . . . . . . . . 28 Troubleshooting . . . . . . . . . . . . . . . . . . . . 28 Maintenance . . . . . . . . . . . . . . . . . . . . . . 35 Warranty Statement . . . . . . . . . . . . . . . . . . 35 Important Safety Instructions. . . . . . . . . . . . . . 37 FCC, ACTA and IC Regulations . . . . . . . . . . . . 38 The RBRC ® Seal. . . . . . . . . . . . . . . . . . . . 39 Technical Specifications . . . . . . . . . . . . . . . . 40 NEED HELP? This book has all the feature operation and troubleshooting you need to install and operate your new VTech phone. Please take the time to review thoroughly to ensure proper installation and the benefit of this VTech innovative and feature rich product. You can also visit our website at www.vtechphones.com for support, shopping, and everything new at VTech. In Canada, please visit www.vtechcanada.com. VTech toll free 1-800-595-9511 In Canada dial 1-800-267-7377 www.vtechphones.com 4 Before You Begin GETTING STARTED Enhanced 5.8GHz technology - dual band transmission combines the best of 5.8GHz and 900MHz technologies, providing enhanced performance over standard cordless telephones. 1. Handset 2. Base Unit 3. Battery 4. Belt Clip 5. Telephone Line Cord 6. Base Power Adaptor 7. Desk/Wall Mount Bracket 8. User’s Manual To purchase replacement batteries, visit us on the web at www.vtechphones.com or call VTech Communications, Inc. at 1-800-595-9511. In Canada, contact VTech Telecommunications Canada Ltd. at www.vtechcanada.com or 1-800-267-7377. Parts Check List: Handset Base Unit Desk/Wall Mount Bracket Base Power Adaptor Battery Belt Clip Telephone Line Cord User’s Manual • Important! Before using this telephone, you must read important safety instructions on page 47 . www.vtechphones.com 5 Getting Started GETTING STARTED Installation Choose Location For maximum performance of your cordless telephone system: 1. Choose a central location for your Base Unit. 2. Install your Base Unit and Extension Handsets away from electronic equipment, such as personal computers, television sets and microwave ovens. 3. In locations where there are multiple cordless telephones, separate base units as much as possible. 4. Install your telephone equipment away from heat sources and sunlight. 5. Avoid excessive moisture, dust or extreme cold. a) Remove battery compartment cover by pressing on the indentation and sliding downwards. b) Align the two holes in the plug with the socket pins, then snap the plug into place. c) Place the battery in the compartment with the wires in the lower right corner. d) Replace cover by sliding it up into place. e) Place the handset in its base when not in use to ensure maximum daily performance. • Use only the provided VTech b a t t e r y , o r equivalent. Install Handset Battery 1 2 www.vtechphones.com 6 GETTING STARTED Connect Power and Telephone Line Cords Installation Standard electrical outlet Connect the power cord. After charging the battery for at least 18 hours as instructed on page 5, connect the telephone line cord. Modular telephone jack www.vtechphones.com 7 GETTING STARTED Getting Started Installation Wall Mo…

Text truncated - open the document above for the full version.

www.vtechphones.comTABLE OF CONTENTS 1 Table of Contents GETTING STARTED. . . . . . . . . . . . . . . . . . . 4 Before You Begin . . . . . . . . . . . . . . . . . . . . . 4 Parts Check List: . . . . . . . . . . . . . . . . . . . 4 Installation . . . . . . . . . . . . . . . . . . . . . . . . 5 Choose Location . . . . . . . . . . . . . . . . . . . 5 Install Handset Battery . . . . . . . . . . . . . . . . 5 Connect Power and Telephone Line Cords . . . . . . 6 Wall Mounting. . . . . . . . . . . . . . . . . . . . . 7 Charge the Handset Battery . . . . . . . . . . . . . 8 Set Language Mode . . . . . . . . . . . . . . . . . 8 Check for Dial Tone . . . . . . . . . . . . . . . . . . 8 Set the Dial Mode. . . . . . . . . . . . . . . . . . . 8 Set Handset Date and Time. . . . . . . . . . . . . . 9 Handset Ringer Style/Battery Save. . . . . . . . . . 9 Attach belt clip (optional). . . . . . . . . . . . . . . .10 BASIC OPERATION . . . . . . . . . . . . . . . . . . 11 Telephone Operation . . . . . . . . . . . . . . . . . . 11 Handset Operation . . . . . . . . . . . . . . . . . .11 Base Operation . . . . . . . . . . . . . . . . . . . .12 Temporary Tone Dialing. . . . . . . . . . . . . . . .12 Message Waiting . . . . . . . . . . . . . . . . . . .12 Clear Message Waiting Alert . . . . . . . . . . . . .13 Call Forward. . . . . . . . . . . . . . . . . . . . . .13 Headset Jack . . . . . . . . . . . . . . . . . . . . .14 Operating Range . . . . . . . . . . . . . . . . . . .14 Display Screen Messages. . . . . . . . . . . . . . .15 Speed Dialing. . . . . . . . . . . . . . . . . . . . . . 16 Store a Number/Name in Speed Dial . . . . . . . . .16 Edit a Number/Name Stored in Speed Dial. . . . . .17 Delete a Number/Name Stored in Speed Dial . . . .18 Dial a Speed Dial Number . . . . . . . . . . . . . .18 Reassign Locations in Speed Dial . . . . . . . . . .18 Telephone Directory . . . . . . . . . . . . . . . . . . 19 Store a Number/Name in the Directory . . . . . . . .19 Edit a Number/Name Stored in the Directory . . . . .19 Delete a Number/Name Stored in the Directory . . .20 Move a Number/Name to the Speed Dial Memory . .21 Dial a Number from the Directory. . . . . . . . . . .21 Caller ID Operation . . . . . . . . . . . . . . . . . . . 22 About Call History (Caller ID) . . . . . . . . . . . . .23 Review Call History . . . . . . . . . . . . . . . . . .23 Delete Records from Call History . . . . . . . . . . .24 Dial a Displayed Number . . . . . . . . . . . . . . .24 Store a Call History Record in the Directory . . . . .24 Display Screen Messages. . . . . . . . . . . . . . .25 Answering System Operation At the Base . . . . . . . 26 Audible Indicators . . . . . . . . . . . . . . . . . . .26 Setting the clock. . . . . . . . . . . . . . . . . . . .26 About Announcements . . . . . . . . . . . . . . . .26 Record Your Announcement . . . . . . . . . . . . .27 To review your announcement at any time: . . . . . .27 To delete your announcement: . . . . . . . . . . . .27 Setting up your answering system . . . . . . . . . .28 Feature summary . . . . . . . . . . . . . . . . . . .28 Listen to, Save & Delete Messages. . . . . . . . . .29 Call Screening/Intercept. . . . . . . . . . . . . . . .30 Record a Memo. . . . . . . . . . . . . . . . . . . .30 Window display . . . . . . . . . . . . . . . . . . . .31 Answering System Operation - Remote Access . . . . 32 Connect with the Answering System . . . . . . . . .32 TABLE OF CONTENTSwww.vtechphones.com 2 Voice Menu . . . . . . . . . . . . . . . . . . . . . .32 Remote Access Commands . . . . . . . . . . . . .32 Batteries . . . . . . . . . . . . . . . . . . . . . . . . 34 Battery Care and Maintenance . . . . . . . . . . . .34 Replacing the Handset Battery . . . . . . . . . . . .34 ADDITIONAL INFO . . . . . . . . . . . . . . . . . . .35 Troubleshooting. . . . . . . . . . . . . . . . . . . . . 35 Maintenance . . . . . . . . . . . . . . . . . . . . . . 42 Warranty Statement. . . . . . . . . . . . . . . . . . . 42 Important Safety Instructions . . . . . . . . . . . . . . 44 FCC, ACTA and IC Regulation . . . . . . . . . . . . . 45 The RBRC ® Seal . . . . . . . . . . . . . . . . . . . . 46 Technical Specifications . . . . . . . . . . . . . . . . 47 Index . . . . . . . . . . . . . . . . . . . . . . . . . . 48 NEED HELP? This book has all the feature operation and troubleshooting you need to install and operate your new VTech phone. Please take the time to review thoroughly to ensure proper installation and the benefit of this VTech innovative and feature rich product. You can also visit our website at www.vtechphones.com for support, shopping, and everything new at VTech. In Canada, please visit www.vtechcanada.com. VTech toll free 1-800-595-9511 In Canada dial 1-800-267-7377 www.vtechphones.com 4 Before You Begin GETTING STARTED Enhanced 5.8GHz Technology - Dual band transmission combines the best of 5.8GHz and 900MHz technologies, providing enhanced performance over standard cordless telephones. 1. Base Unit 2. Handsets (2) 3. Charger 4. Charger Power Adaptor 5. Telephone Line Cord 6. Desk/Wall Mount Bracket 7. Belt Clips (2) 8. Base Power Adaptor 9. Batteries (2) 10. User’s Manual To purchase replacement batteries, visit us on the web at www.vtechphones.com or call VTech Communications, Inc. at 1-800-595-9511. In Canada, contact VTech Telecommunications Canada Ltd. at www.vtechcanada.com or 1-800-267-7377. Parts Check List: Base Unit Handsets (2) Charger Batteries (2) Belt Clips (2) Charger Power Adaptor Telephone Line Cord Base Power Adaptor Desk/Wall Mount Bracket User’s Manual • Important! Before using this telephone, you must read important safety instructions on page 47. www.vtechphones.com 5 GETTING STARTED Getting Started Installation Choose Location For maximum performance of your cordless telephone system: 1. Choose a central location for your Base Unit. 2. Install your Base Unit and Extension Handsets away from electronic equipment, such as personal computers, television sets and mic…

Text truncated - open the document above for the full version.

www.vtechphones.com 38 ADDITIONAL INFO FCC, ACTA and IC Regulation FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The base unit shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip. FCC Part 68 and ACTA This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request. The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual. The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your local telephone company. This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty. If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned. If this product is equipped with a corded or cordless handset, it is hearing aid compatible. If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please: www.vtechphones.com 39 Additional Information ADDITIONAL INFO FCC, ACTA and IC Regulations * Remain on the line and briefly explain the reason for the call before hanging up. * Perform such activities in off-peak hours, such as early morning or late evening. Industry Canada This equipment complies with regulations RSS210 and CS-03 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The term ‘’IC: ‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met. The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five. The RBRC ® Seal The RBRC ® Seal on the nicke…

Text truncated - open the document above for the full version.

July 7, 2005 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Declaration on security code Dear Sir/Madam, FCC ID: EW780-5735-00 (Base) EW780-5735-01 (Handset) Vtech ia5823 and Vtech ia5854 cordless telephones use 20-bit of security code, randomly pre-fixed in the factory. Best Regards, Joseph Poon Regulatory Compliance Manager Vtech Telecommunications Canada Ltd.

July 7, 2005 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: EW780-5735-00 (Base) EW780-5735-01 (Handset) Product Name: Vtech ia5823 & Vtech ia5854 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents (list no# 1 to 4) be held confidential: (1) Theory of Operation (2) Schematics (3) Block Diagrams (4) Parts List (BOM) We also request that the FCC mark the below documents (list no# 5 to 7) as "Temporary Confidential" as outlined in Public Notice DA 04-1705, dated June 15, 2004. This provision will give Vtech temporary confidentiality prior to product launch. (5) External Photos (6) Internal Photos (7) Users Manual These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 7th Day of July 2 0 05 By: Joseph Poon Signature Printed Title: Regulatory Compliance Manager On behalf of : VTech Telecommunications Canada Ltd. Telephone: (604) 273-5131

July 7, 2005 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Canada Inc, 203 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with VTech Telecommunications Canada Ltd., 200-7671 Alderbridge Way, Richmond B.C., Canada V6X 1Z9. Dated this 7th Day of July 20 05 Agency agreement expiration date: December 31, 2005 By: Joseph Poon Signature Printed Title: Regulatory Compliance Manager On behalf of : VTech Telecommunications Canada Ltd. Telephone: (604) 273-5131

VTech ia5823 Cosmetic VTech ia5845 Cosmetic

VTech ia5854 Cosmetic Photo VTech ia5864 Cosmetic Photo



  !"#$%$&&$&##'''!() *##+& $%&,+&
     *##+& $%&,+&

  - *,%$&,+&$
     -       .,- /% 0     * *,.#1%$&,+&  02
 *#1 3 4*3##53##
    #&--      13- 0     *#6
     -  - 7 6
    -
8   0 -
-      1      0   model#: ia5874

VTech ia5823_ia5845_ia5854_ia5864_ia5874 Handset PCB VTech ia5823_ia5845_ia5854_ia5864_ia5874 Handset PCB VTech ia5823_ia5845_ia5854_ia5864_ia5874 Handset PCB

Test Report: 5W47733 Applicant: VTech Telecommunications Canada Ltd. Suite 200 – 7671 Alderbridge Way Richmond, B.C., V6X 1Z9 Canada Equipment Under Test: ia5823 – Basic 5.8 GHz Analogue Cordless Phone with CID ia5854 – 5.8 GHz Analogue Cordless Phone with CID and Answering Machine In Accordance With: FCC Part 15, Subpart C, 15.249 Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, General Manager Date: 14 July 2005 Total Number of Pages: 34 Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 2 of 34 Table Of Contents Section 1. Summary Of Test Results ...................................................................................3 Section 2. Summary Of Test Data .......................................................................................4 Section 3. General Equipment Specification ......................................................................5 Section 4. Powerline Conducted Emissions ........................................................................7 Section 5. Radiated Emissions ...........................................................................................12 Section 6. Block Diagrams..................................................................................................33 Section 7. Test Equipment List ..........................................................................................34 Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 3 of 34 Section 1. Summary Of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15.249. All tests were conducted using measurement procedure ANSI C63.4-2003. Radiated Emissions were made on an open area test site. A description of the test facility is on file with the FCC. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: ______________________________ DATE: 14 July 2005 Roman Kuleba, Wireless Specialist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 4 of 34 Section 2. Summary Of Test Data Summary Of Test Data Name Of Test Para. No. Result Power line Conducted Emissions 15.207(a) Complies Radiated Emissions 15.249 Complies Test Conditions: Indoor Temperature: 24°C Humidity: 50% Outdoor Temperature: 27°C Humidity: 60% Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 5 of 34 Section 3. General Equipment Specification Manufacturer: VTech Telecommunications Canada Ltd. Model No.: ia5823 ia5854 Serial No.: Handset unit: PA 05/05 487 Base unit: PA 05/05 480 Date Received In Laboratory: June 27, 2005 Nemko Identification No.: Handset unit: Item No. 1 Base unit: Item No. 3 Frequency Range: Handset unit: 5863.80 – 5872.50 MHz Base unit: 912.75 – 917.10 MHz Number of Channels: 30 Modulation: Voice: FM (Deviation: 30 kHz) Data: FSK at 1000 bps Power Source: Base: 120 VAC / 60 Hz to 9 VDC Adapter Handset : 3.6 VDC Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 6 of 34 Theory of Operation The ia5823/ia5854 is the second generation of the VTech Analog 5.8GHz hybrid cordless telephone. It consists of a mobile handset and a fixed base unit. The base and Handset RF module are used as a RF combo to provide a full duplex wireless links between the handsets and base unit. This is accomplished by setting up two simultaneous communications links between the handset and base RF Modules. The RF receiver and transmitter circuitries essentially provide a link between the microphone and speaker in the handset to telephone line connected to the base. The RF link between the Handset and the Base occurs in two frequency bands. The upper end of the 5.8 GHz band is used for the RF carrier of the audio signal from the handset microphone to the base station. The transmitting frequencies from the handset to the base: 5863.80 MHz to 5872.50 MHz.. The 900 MHz band is used for the RF carrier of the audio signal from the base to the handset’s speaker. The transmitting frequencies from the base to the handset: 912.75 MHz to 917.10 MHz. The voice signals wideband frequency modulate (FM) the RF carriers and the data packets use frequency shift keying (FSK) to modulate the RF carriers. There are two types of bases, first is the basic 5.8 GHz Analogue Cordless Phone with CID ia5823 (C Model) and the second is the 5.8GHz Analogue Cordless Phone with CID and Answering Machine ia5854 (Ci Base Model). Both models use the same type of handset. The Base RF module used on the ia5823 is the same as the RF module used on the ia5854. Nemko Canada Inc. FCC PART 15, SUBPART C, 15.249 PROJECT NO.: 5W47733 EQUIPMENT: VTech ia5823 & ia5854 5.8 GHz Analogue Cordless Phone with CID Page 7 of 34 Section 4. Powerline Conducted Emissions Para. No.: 15.207 (a) Test Performed By: Roman Kuleba Date of Test: July 5, 2005 Test Result…

Text truncated - open the document above for the full version.

Conducted Disturbance at Mains Detailed Setup Photos Radiated Emissions Test Setup Photos Base Unit Radiated Emissions Test Setup Photos Handset Unit
