User’s manual SB8735 IP Phone Congratulations on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. Model number: SB8735 Type: IP Phone Serial number: Purchase date: Place of purchase: Both the model and serial numbers of your AT&T product can be found on the bottom of the phone. Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. © 2013 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. T Compatible with Hearing Aid T-Coil TIA-1083 Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Handset with coiled cord installed User's manual Phone Phone power adapter Ethernet cable Quick start guide Wall mount bracket User’s manual SB8735 IP Phone Quide start guide SB8735 IP Phone Replacement directory card 1 Navigation keys While in menus, press or to scroll through the menus, highlight items or change settings. Press to enter the selected item, or press to return to the previous menu. While entering names or numbers, press or to move the cursor to the left or right. • • MENU Press to enter the menu.• SELECT While in the menu, press to select an item or save an entry or setting. • MESSAGE Press to enter the message menu. • MESSAGE WAITING indicator Flashes when there are new messages in the private mailbox. • Liquid cystral display Provides information and controls for using the phone. • Soft keys Four keys that produce different actions depending on the LCD labels • Getting started Quick reference guide CANCEL While in a menu, press to cancel an operation and exit the menu display. • DIRECTORY Press to view directory information. • CALL HISTORY Press to view caller ID information. • Getting started Quick reference guide 2 REDIAL Press to view the last 10 numbers dialed. • TRANSFER Press to transfer a call to an extension. • MUTE During a call, press to mute the microphone. • p/VOLUME/q During a call, press to adjust the listening volume. During message playback, press to adjust the playback volume. Press to adjust the ringer volume when in idle mode. • • • FLASH During a call, press to answer an incoming call when you receive a call waiting alert . • DND Press to enter do-not- disturb mode. • HEADSET When a corded headset is connected to the phone, press to make, answer or hang up a call. • CONFERENCE Press to add another extension or outside line to an existing cal. • HOLD Press to place an outside call on hold . • LOWER When assigning or dialing a one-touch number, press to switch to the lower location (the second 16 locations) of a programmable key. • Programmable keys Provide access to various call functions, which are determined by your system administrator. • SPEAKER Press to turn on the speakerphone. Press again to turn it off. • MIC 3 This section assumes that your network infrastructure is established and that the SIP PBX service has been ordered and configured for your location. Install the phone close to a router or network switch. If you are not using PoE, install the phone near a power outlet not controlled by a wall switch. The phone can be placed on a flat surface or vertically mounted on the wall. Avoid placing the phone too close to: Communication devices such as television sets, VCRs, or other cordless telephones. Excessive heat sources. Noise sources such as a window with traffic outside, motors, microwave ovens, refrigerators, or fluorescent lighting. Excessive dust sources such as a workshop or garage. Excessive moisture. Extremely low temperature. Mechanical vibration or shock such as on top of a washing machine or work bench. NOTE: The Deskset shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. • • • • • • • Getting started Installation  Getting started Phone installation Make sure you plug in the Ethernet cable before powering up the phone. Plug the end of the coiled handset cord into the Use onlySupplied Adapte r L4 L3/ 4 L 2 L1/ 2 5. 1 MS2085 Engraving:MS2015 Engraving: Use onlySupplied Adapte r jack on the left side of the telephone. 1. Lift the kickstand as the arrow indicates below to release it from the groove. There are seven pairs of grooves designed to hold the phone at different angles for optimum visibility. 2. Getting started Phone installation 5 Getting started Phone installation Plug one end of the Ethernet cable into the Ethernet jack at the back of the phone, and plug the other end of the Ethernet cable into the router. (Continued on next page) . Snap the kickstand into the desired grooves until it locks into place. 3. 6 Getting started Phone installation Router Plug the large end of the phone power adapter into an electrical outlet not controlled by a wall switch. (If PoE cannot be provided through Ethernet cable.) Plug one end of the Ethernet cable into the Ethernet jack at the back of the phone. Plug the other end of the Ethernet cable into the router connecting to your console. Route the Ethernet cable and power cord through these slots. Plug the small end of the phone power adapter into the power jack at the back of the phone. (…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification March 25, 2013 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Senior Electronic Engineer

VTech Telecommunications Ltd March 25, 2013 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-8519-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Senior Electronic Engineer

INTERTEK TESTING SERVICES External Photos FCC ID: EW780-8519-00 IC: 1135B-80851900 external photos - 1 of 2 HK13030545 Job Number HK13030545 Job Number INTERTEK TESTING SERVICES External Photos FCC ID: EW780-8519-00 IC: 1135B-80851900 external photos - 2 of 2 HK13030545 Job Number

SB8735 Engraving Text: engraved in raised 0.3mm Advanced American Telephones FCC ID: EW780-8519-00 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. DC 5.1V 1.7A HAC MANUFACTURED IN CHINA IC: 1135B-80851900 4H20 Use only Supplied Adapter Text : Recessed 0.3mm High Gloss LABEL Text: engraved in raised 0.3mm SN/Mac label PoE Class 3 Model: SB8735

INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 1 of 9 Deskset assembly (View 1) Deskset assembly (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 2 of 9 Deskset Main PCB comp side Deskset Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 3 of 9 Deskset Antenna 1 Deskset Antenna 2 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 4 of 9 Deskset Keypad and Display front side (View 1) Deskset Keypad and Display front side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 5 of 9 Deskset Keypad and Display rear side ( View 1) Deskset Keypad and Display rear side (View 2 ) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 6 of 9 Deskset, Logic Gate front side Deskset,Logic Gate rear side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 7 of 9 Deskset On-Off Hook front side Deskset On-Off Hook rear side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 8 of 9 Deskset Page Key front side Deskset Page Key rear side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-8519-00 IC: 1135B-80851900 internal photos - 9 of 9 Deskset Oscillator PCB comp side

INTERTEK TESTING SERVICES FCC ID: EW780-8519-00 RF exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. The setup and equipment setting were made in accordance with ANSI C63.17. The antenna of EUT transmitter was replaced by a coaxial cable. The impendence matching of connection, cable loss and external RF attenuator are taken into account. The EUT was arranged to communicate via a fixed carrier frequency between its transmitter and a companion device. The transmission was configured in burst mode with pseudo-random data as typical as normal operation. For the 1.9GHz DECT Transmission of tested model: SB8735, the measured powers among all the measured channels were within its production tolerance: +16 dBm (Minimum) and +21 dBm (Maximum). The antenna gain of SB8735 is 2 dBi = 1.58 (num gain) and its maximum source-based time-averaging duty factor is 8.3% (2/24 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 21 dBm = 125.9 mW The Conducted Power source-based time-averaging output power = (125.9 * 0.083) mW = 10.45 mW The power density at 20cm = 10.45 *1.58/ 4πR 2 = 0.0033 mW cm -2 In frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As simultaneous transmission MPE test exclusion is applied and the measured power density at 20cm from all the standalone transmissions is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.” EUT Spectrum Analyzer Companion Device Directional Coupler

Report Number :13030545HKG-001 Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13030545HKG-001 Page 1 of 63 FCC ID: EW780-8519-00 IC: 1135B-808519000 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION VTech Telecommunications Ltd.: VTech Telecommunications Ltd. Applicant Address: 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, N.T., Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2011 Edition and 77 FR 43013, July 23, 2012 FCC ID: EW780-8519-00 FCC Model(s): SB8735 IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 1135B-80851900 IC Model(s): SB8735 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz DECT SIP Cordless Deskset with Caller ID, Speakerphone and Corded Handset Serial Number: N/A Sample Receipt Date: January 16, 2013 Date of Test: March 18 – 21, 2013 Report Date: May 09, 2013 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13030545HKG-001 Page 2 of 63 FCC ID: EW780-8519-00 IC: 1135B-808519000 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 Test Results Summary & Statement of Compliance.............................................. 5 1.1 Summary of Test Results ....................................................................................... 5 1.2 Statement of Compliance ....................................................................................... 6 2.0 General Description................................................................................................. 8 2.1 Product Description ................................................................................................. 8 2.2 Technical Description .............................................................................................. 8 2.3 Test Methodology.................................................................................................... 8 2.4 Test Facility............................................................................................................. 8 3.0 System Test Configuration.................................................................................... 10 3.1 Justification ........................................................................................................... 10 3.2 Conducted Emission Test Configuration ................................................................ 12 3.3 Conducted Monitoring and Operational Test Configuration .................................... 12 3.4 EUT Exercising Software....................................................................................... 12 3.5 Details of EUT and Description of Accessories...................................................... 13 3.6 Measurement Uncertainty ..................................................................................... 13 4.0 Measurement Results............................................................................................ 15 4.1 Antenna Requirement........................................................................................... 15 4.2 Digital Modulation Techniques............................................................................... 15 4.3 Emission Bandwidth.............................................................................................. 16 4.4 Directional Gain of the Antenna ............................................................................. 19 4.5 Peak Transmit Power ............................................................................................ 20 4.6 Power Spectral Density ......................................................................................... 23 4.7 Automatic Discontinuation of Transmission............................................................ 26 4.8 Unwanted Emission Inside the Sub-Band .............................................................. 27 4.9 Emissions Outside the Sub-Band .......................................................................... 31 4.9.1 Radiated Emissions Configuration Photographs ................................................. 32 4.9.2 Radiated Emissions Data ................................................................................... 32 4.9.3 Field Strength Calculation................................................................................... 36 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements ................ 37 4.10 AC Power Line Conducted Emissions ................................................................. 38 4.10.1 AC Power Line Conducted Emissions Configuration Photographs .................... 39 4.10.2 AC Power Line Conducted Emissions Data ...................................................... 39 4.11 Radio Frequency Radiation Exposure.................................................................. 42 4.12 Frame Repetition …

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd January 23, 2013 To whom it may concern, Declarations FCC ID: EW780-8519-00 IC:1135B- 80851900 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the headset unit will act as the initiating device, which will initiate the establishment of the duplex connection. 4. For FCC, Upper Monitoring Threshold of deskset declared by manufacturer are -61.2 dBm. 5. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Deskset Reaction of Headset 1 Switch-off companion device B NA 2 On hook by companion device B C 3 Remove power from companion device B A 4 Switch-off device NA C 5 On hook device B C 6 Remove power from device A C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Senior Electronics Engineer

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-8915-00 IC: 1135B-80891500 config photos (radiated emission - deskset) - 1 of 1 Radiated Emission - Deskset Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Cordless Headset On-Line + PC On-Line FCC ID: EW780-8519-00 IC: 1135B-80851900 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Cordless Headset On-Line + PC On-Line FCC ID: EW780-8519-00 IC: 1135B-80851900 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
