EW780-9148-001.9GHz Digital Modulation Cordless Phone (BU)

1 CS6758-3/CS6759 DECT 6.0 Cordless telephone Introduction To protect our environment and conserve natural resources, this Abridged user’s manual provides you with the basic installation and use instructions. A limited set of features are described in abbreviated form. Please refer to the online Complete user’s manual for a full set of installation and operation instructions at www.vtechphones.com. Before using this VTech product, please read Important safety instructions on page 5 of this user’s manual. Abridged user’s manual The ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. Register online to get an additional 3-month warranty! Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. T Compatible with Hearing Aid T-Coil TIA-1083 2 Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Handset charger and charger adapter (2 for CS6758-3) Tel e p h o n e b a s e Handset (1 for CS6759) (3 for CS6758-3) Tel e p h o n e b a s e power adapter Battery compartment cover (1 for CS6759) (3 for CS6758-3) Battery (1 for CS6759) (3 for CS6758-3) Telephone line cord Abridged user’s manual Quick start guide Quick start guideAbridged user’s manual Use only the power adapter and battery supplied with this product. To order a replacement, visit our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com or call 1 (800) 267-7377. • Handset charger Telephone base power adapter Electrical outlet not controlled by a wall switch Charger adapter Te l e p h o n e wall jack CAUTION: If you subscribe to telephone service from a cable company or a VoIP service provider, contact your cable/VoIP service provider for more information. Telephone base and handset charger installation TEL. LINE Use Only Supplied Adapter DC 6V Telephone base Telephone line cord A DSL filter (not included) is required if you have DSL high-speed Internet service. The DSL filter must be plugged into the telephone wall jack. 3 IMPORTANT: Check for a dial tone by pressing . If you hear a dial tone, the installation is successful. If you do not hear a dial tone: Make sure the installation procedures described above are properly done. It may be a wiring problem. If you have changed your telephone service to digital service from a cable company or a VoIP service provider, the telephone line may need to be rewired to allow all existing telephone jacks to work. Contact your cable/VolP service provider for more information. • • Handset battery installation Install the battery as shown below. Plug the battery connector securely into the socket. 1.Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment. 2. Slide the battery compartment cover towards the center of the handset until it clicks into place. 3.Place the handset in the telephone base or charger to charge. 4. CHARGE light remains on when charging. Battery indicatorsBattery statusAction The screen is blank, or shows Put in charger and flashes. The battery has no charge or very little charge. The handset cannot be used. Charge without interruption (at least 30 minutes). The screen shows Low battery and flashes. The battery has enough charge to be used for a short time. Charge without interruption (at least 30 minutes). The screen shows HANDSET X. The battery is charged.To keep the battery charged, place it in the handset charger when not in use. Handset battery charging Once you have installed the battery, the screen indicates the battery status. For best performance, keep the handset in the handset charger when not in use. The battery is fully charged after 11 hours of continuous charging. 4 Tabletop to wall mount installation The telephone comes ready for tabletop use. Follow the steps below to mount your telephone on a wall. Plug the power adapter and the telephone line cord to the base through the space between the wall mount bracket and the base. 4. Push to open the wall mount bracket as the arrows indicated below. 2. Unplug the power adapter and telephone line from the wall outlets. and the telephone base. 1. Press the wall mount bracket onto the telephone base until it clicks into place. Plug the power adapter and telephone line into the wall outlets. Align the holes on the wall mount bracket with the standard wall mounting plate and slide the telephone down until it locks securely. Bundle the telephone line cord and power adapter cord neatly with twist ties. 5. TEL. LINE Use Only Supplied Adapter DC 6V Swivel the wall mount bracket down.3. Using the menu Press MENU when the telephone base/handset is not in use. Press or until the screen displays the desired feature menu. Press SELECT to enter that menu. • To return to the previous menu, press CANCEL. To return to idle mode, press and hold CANCEL. 1. 2. • 5 Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet basement or shower. Do not place th…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd. Letter of Agency for FCC Certification 9 th , August, 2012 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd. do hereby authorize Intertek Testing Services (Mr. Ken Sit/Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Samson Man Approbation Supervisor

VTech Telecommunications Ltd. 9 th , August, 2012 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780- 9148-00 Reque st is here by submitted by VTech Telecommunications Ltd. to withhold perma nently from public review certain portions of the a pplication for equipment certification for the refe renced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In partic ular, the following sections of the application are to be kept permane ntly confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd. and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantag es in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Samson Man Approbation Supervisor

INTERTEK TESTING SERVICES External Photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 external photos - 1 of 4 HK12100866 Job Number HK12100866 Job Number INTERTEK TESTING SERVICES External Photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 external photos - 2 of 4 HK12100866 Job Number INTERTEK TESTING SERVICES External Photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 external photos - 3 of 4 HK12100866 Job Number HK12100866 Job Number INTERTEK TESTING SERVICES External Photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 external photos - 4 of 4 HK12100866 Job Number

CS6759-X/CS6859-X ENGRAVING FFILE CS6759-X ENGRAVING FFILE CS6859-X ENGRAVING FFILE VTech Customer Service 1-800-595-9511 www.vtechphones.com COMPLIES WITH 47 CFR PART 68 HAC Reg. No.: US: EW7W401B80-914800 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/RJ11W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. CORDLESS TELEPHONE DC 6V 400mA VTECH TELECOMMUNICATIONS LTD.MANUFACTURED IN CHINA 4H20 FCC ID: EW780-9148-00 IC: 1135B-80914800 Model: CS6759SN:XXXXXXXXXXXX Model: CS6759-2 SN:XXXXXXXXXXXX Model: CS6759 SN:XXXXXXXXXXXX Model: CS6758-3 SN:XXXXXXXXXXXX Model: CS6859 SN:XXXXXXXXXXXX Model: CS6859-2 SN:XXXXXXXXXXXX Model: CS6859-3 SN:XXXXXXXXXXXX Model: CS6859-4 SN:XXXXXXXXXXXX Model: CS6858-3 SN:XXXXXXXXXXXX HS SN LABEL 20X10mm CAUTION Use Only Supplied Battery or Battery BT283342 FCC ID: EW780-9066-00IC: 1135B-80914800 CHARGER AC 6V Use Only Supplied Adapter CORDLESS TELEPHONE AC 6V 300mA VTech Customer Service 1-800-595-9511 www.vtechphones.com 4H20 Accessory Model: CS6758-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6759 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6758-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6759-2 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-2 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6858-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-4 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6759-2 S/N: XXXXXXXXXXXXXXXXXXXX SN LABEL 28X10mm Model: CS6859 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-2 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6858-3 S/N: XXXXXXXXXXXXXXXXXXXX Model: CS6859-4 S/N: XXXXXXXXXXXXXXXXXXXX TEL. LINE Use Only Supplied Adapter DC 6V TEL. LINE Use Only Supplied Adapter DC 6V VTech Customer Service 1-800-595-9511 www.vtechphones.com COMPLIES WITH 47 CFR PART 68 HAC Reg. No.: US: EW7W401B80-914800 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/RJ11W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. CORDLESS TELEPHONE DC 6V 400mA VTECH TELECOMMUNICATIONS LTD.MANUFACTURED IN CHINA 4H20 FCC ID: EW780-9148-00 IC: 1135B-80914800

INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 1 of 11 Base Unit assembly Base Unit Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 2 of 11 Base Unit Main PCB comp side (View 2) Base Unit Main PCB solder side (View 1) INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 3 of 11 Base Unit Main PCB solder side (View 2) Base Unit LED front side INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 4 of 11 Base Unit LED rear side Base Unit Antenna front side INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 5 of 11 Base Unit Antenna rear side Base Unit Keyboard front side INTERTEK TESTING SERVICES Internal photos – Model: CS6758-3 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 6 of 11 Base Unit Keyboard rear side Base Unit RF Module INTERTEK TESTING SERVICES Internal photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 7 of 11 Base Unit assembly Base Unit Main PCB comp side INTERTEK TESTING SERVICES Internal photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 8 of 11 Base Unit Main PCB solder side Base Unit LED front side INTERTEK TESTING SERVICES Internal photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 9 of 11 Base Unit LED rear side Base Unit Antenna front side INTERTEK TESTING SERVICES Internal photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 10 of 11 Base Unit Antenna rear side Base Unit Keyboard front side INTERTEK TESTING SERVICES Internal photos – Model: CS6859 FCC ID: EW780-9148-00 IC: 1135B-80914800 internal photos - 11 of 11 Base Unit Keyboard rear side Base Unit RF Module

INTERTEK TESTING SERVICES FCC ID: EW780-9148-00 RF exposure info- 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65. For the base unit of tested model of CS6758-3, the maximum field strength measured (FS) was 112.4 dBV/m. The distance (D) between the antenna and the equipment under test (EUT) was 3 meters. And the maximum source-based time- averaging duty factor in four-handsets operation is 20.8%. From these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The radiated power = (FS*D) 2 / 30 = 52.13 mW The radiated (EIRP) source-based time-averaging output power = (52.13 * 0.208) mW = 10.84 mW The power density at 20 cm from the antenna = EIRP / 4R 2 = 0.0022 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.”

Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: HK12100866-1 Page 1 of 65 FCC ID: EW780-9148-00 IC: 1135B-80914800 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, N.T., Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2011 Edition and 77 FR 43013, July 23, 2012 FCC ID: EW780-9148-00 FCC Model(s): CS6758-3, CS6759, CS6759-2, CS675Z- XY, CS6858-3, CS6859, CS6859-2, CS6859-3, CS6859-4, CS685Z-XY IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 1135B-80914800 IC Model(s): CS6758-3, CS6759, CS6759-2, CS6858- 3, CS6859, CS6859-2, CS6859-3, CS6859-4 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz Digital Modulation Cordless Phone with Caller ID, Speakerphone, Digital Answering Machine - Base Unit Serial Number: N/A Sample Receipt Date: October 30, 2012 Date of Test: November 05 - 08, 2012 Report Date: November 22, 2012 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: HK12100866-1 Page 2 of 65 FCC ID: EW780-9148-00 IC: 1135B-80914800 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 Test Results Summary & Statement of Compliance............................................... 5 1.1 Summary of Test Results......................................................................................... 5 1.2 Statement of Compliance......................................................................................... 7 2.0 General Description................................................................................................... 9 2.1 Product Description ................................................................................................... 9 2.2 Technical Description ................................................................................................ 9 2.3 Test Methodology.................................................................................................... 10 2.4 Test Facility ............................................................................................................. 10 3.0 System Test Configuration...................................................................................... 12 3.1 Justification ............................................................................................................. 12 3.2 Conducted Emission Test Configuration ................................................................. 14 3.3 Conducted Monitoring and Operational Test Configuration ..................................... 14 3.4 EUT Exercising Software ........................................................................................ 14 3.5 Details of EUT and Description of Accessories ....................................................... 15 3.6 Measurement Uncertainty ....................................................................................... 15 4.0 Measurement Results.............................................................................................. 17 4.1 Antenna Requirement ............................................................................................. 17 4.2 Digital Modulation Techniques ................................................................................ 17 4.3 Emission Bandwidth................................................................................................ 18 4.4 Directional Gain of the Antenna............................................................................... 21 4.5 Peak Transmit Power .............................................................................................. 22 4.6 Power Spectral Density ........................................................................................... 25 4.7 Automatic Discontinuation of Transmission ............................................................. 28 4.8 Unwanted Emission Inside the Sub-Band ............................................................... 29 4.9 Emissions Outside the Sub-Band............................................................................ 33 4.9.1 Radiated Emissions Configuration Photographs .................................................. 34 4.9.2 Radiated Emissions Data ..................................................................................... 34 4.9.3 Field Strength Calculation .................................................................................... 38 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements................. 39 4.10 AC Power Line Conducted Emissions ................................................................... 40 4.10.1 AC Power Line Conducted Emissions Configuration Photographs..................... 41 4.10.2 AC Power Line Conducted Emissions Da…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd Date: November 7, 2012 To whom it may concern, Declarations FCC ID: EW780-9148-00 IC: 1135B-80914800 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the Handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. For FCC, Base Unit, its Upper Monitoring Threshold declared by manufacturer: -60 dBm 5. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset 1 Switch-off companion device NA NA 2 On Hook by companion device B C 3 Switch-off device NA NA 4 On Hook on device side B C 5 Remove power from device A C 6 Remove power from companion device B A A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. N A – Not applicable If you have questions or need further information, please contact the undersigned. Regards, Name: Samson Man Title: Approbation Supervisor

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9148-00 IC: 1135B-80914800 config photos (radiated emission - base unit) - 1 of 1 Radiated Emission - Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk (DECT) FCC ID: EW780-9148-00 IC: 1135B-80914800 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk (DECT) FCC ID: EW780-9148-00 IC: 1135B-80914800 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
