EW780-9352-001.9GHz DECT Cordless Phone

 Abridged user’s manual TR1-2013/TR16-2013/TR17-2013/TR2-2013/ TR26-2013/TR27-2013 DECT 6.0 cordless telephone This Abridged user’s manual provides you with basic installation and use instructions. After reading this manual, you will learn how to: BC Install the telephone Install telephone base & charger Install handset battery 4 5 Set date and time Program common settings Set handset ringer volume Use common operations Directory Speed dial Caller ID 3 2  7 6 Set quiet mode 9 8 0 We recommend you refer to the full set of installation and operation instructions at www.vtechphones.com. For customer service, visit www.vtechphones.com or call 1 (800) 595-9511. Before using this VTech product, please read Important safety instructions on page 0 of this user’s manual. Answering system Use built-in answering system or voicemail? 2 The ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. T Compatible with Hearing Aid T-Coil TIA-1083 Register online to get an additional 3-month warranty! Go to www.vtechphones.com to register your product for enhanced warranty support and latest VTech product news. You can expand your telephone system by adding expansion handsets (TR02-2013/TR05-2013/TR06-2013/TR07-2013/TR08-2013, purchased separately). This telephone base supports up to five handsets. Handset ( for TR-203/TR6-203/TR7-203) (2 for TR2-203/TR26-203/TR27-203) Charger with power adapter ( for TR2-203/TR26-203/TR27-203) Telephone base Telephone line cord Telephone base power adapter • • • • • Battery compartment cover ( for TR-203/TR6-203/TR7-203) (2 for TR2-203/TR26-203/TR27-203) Battery ( for TR-203/TR6-203/TR7-203) (2 for TR2-203/TR26-203/TR27-203) Wall mount bracket Abridged user’s manual • • • • Parts checklist Your package contains:  Install telephone base & charger The telephone base is ready for tabletop use. If you want to change to wall mounting, see page 9 for details. DSL filter Click! Plug! Click! Plug! Plug! 3 Install handset battery 2 Charge for at least 30 minutes before initial settings. Charge for 11 hours before initial use.  2 3 Light on! ECO HANDSET 1 10:15PM 12/18 ECO ECO mode This power conserving technology reduces power consumption for optimal battery performance. The ECO mode activates automatically whenever the handset is synchronized with the telephone base. The handset shows ECO when the ECO mode activates. Use built-in answering system or voicemail? Your telephone has a built-in answering system which can be used without any service subscription. The telephone also supports voicemail feature which requires subscription from your telephone service provider. Contact your telephone service provider for details. 3 Record own announcement You can use the preset announcement to answer calls, or replace it with your own recorded announcement. Press MENU >> Press / to Answering Sys >> Press SELECT twice. Press 7 to start recording. After the tone, speak towards the handset microphone. Press 5 when done. 1. 2. 3. 4. To configure the built-in answering system Batter y P ack / Bloc -piles : (2.4V Ni-MH) WA RNING / A VERTISSEMENT : DO NO T BURN OR PUNC TURE BA T TERIES. NE PA S INCINÉRER OU PERCER LES PILES. Made in China / F abriqué en chine THIS SIDE UP / CE CÔ TÉ VERS LE HA UT CR1232 Plug! 4 You can save the voicemail number to 1 on each handset for easy access. Contact your telephone service provider for more information and assistance about using your voicemail service. To set voicemail number: Press MENU >> Press / to Settings >> Press SELECT. Press / to Voicemail # >> Press SELECT. Enter the voicemail number >> Press SELECT. While entering numbers, you can: Press DELETE to erase a digit. Press / to move the cursor to the left or right. Press and hold PAUSE to insert a dialing pause (a P appears). Press TONE to add ( appears) or QUIET# to add # ( appears). To retrieve voicemail messages: Press and hold 1. 1. 2. 3. • • • • Set number of rings You can set the answering system to answer an incoming call after 2, 3, 4, 5 or 6 rings; or toll saver. Press MENU >> Press / to Answering sys >> Press SELECT. Press / to Ans sys setup >> Press SELECT. Press / to # of rings >> Press SELECT. Press / to choose 6, 5, 4, 3, 2 or Toll saver >> Press SELECT. 1. 2. 3. 4. To use voicemail (requires service subscription) If you subscribe to caller ID service, the date and time are set automatically with each incoming call. You can also set the date and time manually. Press MENU >> Press / to Set date/time >> Press SELECT. Enter month (MM), date (DD) and year (YY) >> Press SELECT. Enter hour (HH) and minute (MM) >> Press / for AM/PM >> Press SELECT. 1. 2. 3. Set date and time 4 Set handset ringer volume You can adjust the ringer volume level, or turn the ringer off. Press MENU >> Press / to Ringers >> Press SELECT twice. Press / to sample each volume level >> Press SELECT. 1. 2. 5 5 The directory stores up to 50 entries which are shared by all system handsets. To add a directory entry: Enter the phone number >> Press MENU/SELECT twice. Enter the name >> Press SELECT. While entering names and numbers, you can: Press DELETE to backspace and erase a digit or character. Press / to move the cursor to the left or right. Press 0 to add a space (for entering names only). Press and hold PAUSE to insert a dialing pause (a P appears). Press TONE to add ( appears) or QUIET# to add # ( appears). To review and dial a directory entry: Press . Press / to browse to the desired directory; or use the dialing keys to start …

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification July 3, 2013 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd July 3, 2013 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-9352-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd July 3, 2013 To whom it may concern, Label Location Justification FCC ID: EW780-9352-00 Request is hereby submitted by VTech Telecommunications Ltd. to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for handset will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9352-00 external photos - 1 of 2 HK13070171 Job Number HK13070171 Job Number INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9352-00 external photos - 2 of 2

TEL. LINE Model: TR1-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR1-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR16-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR17-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR2-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR26-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR27-2013 S/N: XXXXXXXXXXXXXXXXXXXX CORDLESS TELEPHONE VTECH TELECOMMUNICATIONS LTD. DC 6V 400mA COMPLIES WITH 47 CFR PART 68 Reg. No.: US:EW7W401B80-726900 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/RJ11W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE; AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. VTech Customer Service 1-800-595-9511 www.vtechphones.com VTECH TELECOMMUNICATIONS LTD. MANUFACTURED IN CHINA HAC FCC ID : EW780-9352-00 Use Only Supplied Adapter DC 6V 4H20 BB Model: TR02-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR02-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR05-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR06-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR07-2013 S/N: XXXXXXXXXXXXXXXXXXXX Model: TR08-2013 S/N: XXXXXXXXXXXXXXXXXXXX AC 6V Use Only Supplied Adapter CHARGER CORDLESS TELEPHONE AC 6V 300mA VTech Customer Service 1-800-595-9511 www.vtechphones.com 4H20 Accessory TRXY-2013 ENGRAVING FILE Model: TR1-2013SN:XXXXXXXXXXXX Model: TR1-2013 SN:XXXXXXXXXXXX Model: TR2-2013 SN:XXXXXXXXXXXX Model: TR26-2013 SN:XXXXXXXXXXXX Model: TR27-2013 SN:XXXXXXXXXXXX Model: TR02-2013 SN:XXXXXXXXXXXX Model: TR05-2013 SN:XXXXXXXXXXXX Model: TR06-2013 SN:XXXXXXXXXXXX Model: TR07-2013 SN:XXXXXXXXXXXX Model: TR08-2013 SN:XXXXXXXXXXXX Model: TR16-2013 SN:XXXXXXXXXXXX Model: TR17-2013 SN:XXXXXXXXXXXX CAUTION Use Only Supplied Battery or Battery BT262342 FCC ID: EW780-9352-00 HS SN LABEL 20X10mm SN LABEL 28X10mm CI BS

INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 1 of 9 Base Unit assembly Base Unit Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 2 of 9 Base Unit Main PCB comp side (View 2) Base Unit Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 3 of 9 Base Unit DAM front side Base Unit DAM rear side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 4 of 9 Base Unit Telephone Line and AC Jack front side Base Unit Telephone Line and AC Jack rear side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 5 of 9 Base Unit Antenna 1 Base Unit Antenna 2 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 6 of 9 Base Unit Oscillator PCB comp side (View 1) Base Unit Oscillator PCB comp side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 7 of 9 Handset assembly Handset Main PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 8 of 9 Handset Main PCB display side (View 1) Handset Main PCB display side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9352-00 internal photos - 9 of 9 Handset Main PCB display side (View 3) Handset Oscillator PCB comp side

Report No.: 13070173HKG-001 Page 1 of 80 - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Specific Absorption Rate (SAR) Evaluation Report For 1.9GHz DECT 6.0 Cordless Phone Model Number: TR2-2013 Brand Name: vtech FCC ID: EW780-9352-00 Test Report: 13070173HKG-001 Date of Report: 24 July, 2013 Prepared for VTech Telecommunications Ltd. 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong Prepared and Checked by: Approved by: Chan Chun Foo, Bike Senior Lead Engineer Date: 24 July, 2013 Nip Ming Fung, Melvin Assistant Manager Date: 24 July, 2013 2349 Report No.: 13070173HKG-001 Page 2 of 80 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 General Information.............................................................................................. 3 2.0 Measurement System Description and Procedure ............................................... 6 3.0 Tissue Verification .............................................................................................. 14 4.0 SAR Measurement System Verification ............................................................. 15 5.0 SAR Evaluation .................................................................................................. 17 6.0 Test Instruments ................................................................................................ 22 7.0 Measurement Uncertainty .................................................................................. 23 8.0 E-Field Probe and 1900 Dipole Antenna Calibration.......................................... 23 9.0 References ......................................................................................................... 23 APPENDIX A - System Verification Data .................................................................. 29 APPENDIX B - SAR Evaluation Data ....................................................................... 25 APPENDIX C - E-Field Probe and 1900MHz Dipole Antenna Calibration Data ....... 33 APPENDIX D - SAR Tissue Specification ................................................................ 79 APPENDIX E - SAR System Validation.................................................................... 80 Report No.: 13070173HKG-001 Page 3 of 80 - Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1.0 General information 1.1 Test Result Summary Applicant : VTech Telecommunications Ltd. Applicant Address : 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong Model : TR2-2013 Brand Name : vtech EUT Description : 1.9GHz DECT 6.0 Cordless Phone Exposure Category : General Population/Uncontrolled Exposure Test Device : Production Unit Date of Sample Received : 04 July, 2013 Date of Test: : 09 July, 2013 – 10 July, 2013 Date of Report: : 24 July, 2013 Place of Testing : Intertek Testing Services Hong Kong 5/F Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong Environmental Conidtions: : Temperature: +20 to 25°C Humidity: 30 to 70% Test Specification : ANSI/IEEE C95.1: 1992 IEEE Std 1528: 2003 IEEE Std 1528a: 2005 FCC KDB Publication 447498 D01 v05r01 FCC KDB Publication 865664 D01 v01r01 FCC KDB Publication 865664 D02 v01r01 FCC KDB Publication 648474 D04 v01r01 The maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Highest Reported SAR Band Operating Mode TX Frequency (MHz) 1 g Head 1g Body-Worn 1.9GHz DECT Voice 1921.536 – 1928.448 0.060 W/kg N/A This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general population exposure limits specified in ANSI/IEEE C95.1. Report No.: 13070173HKG-001 Page 4 of 80 - Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1.2 Description of Equipment under test (EUT) EUT Description : 1.9GHz DECT 6.0 Cordless Phone Model : TR2-2013 Brand Name : vtech FCC ID : EW780-9352-00 Serial Number : N/A Manufacturer : VTech (Dongguan) Telecommunications Limited Manufacturer Address : VTech Science Park, Xia Ling Bei Management Zone, Liaobu, Dongguan, Guangdong, China Device dimension (L x W) : 165 (mm) x 45 (mm) Device thickness : 25 (mm) Operating Configuration(s) / mode : Held to head (Voice call) RF Exposure Condition(s) : Head Device Category : Portable Device Tx Frequency : 1921.536 – 1928.448 MHz (UPCS) Duty Cycle : 1/24 Battery Type : 1 x 2.4V 300mAh Ni-MH rechargeable batt…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Left Cheek Left Tilt INTERTEK TESTING SERVICES Right Cheek Right Tilt

INTERTEK TESTING SERVICES Page 1 of 6 EU T Photo Figure 1 - Handset front view Figure 2 - Handset back view INTERTEK TESTING SERVICES Page 2 of 6 Figure 3 – 2.4VDC 300mAh WEWIN battery front view Figure 4 – 2.4VDC 300mAh WEWIN battery back view INTERTEK TESTING SERVICES Page 3 of 6 Figure 5 – 2.4VDC 300mAh CORUN battery front view Figure 6 – 2.4VDC 300mAh CORUN battery back view INTERTEK TESTING SERVICES Page 4 of 6 Figure 7 – 2.4VDC 300mAh Coslight batter y front view Figure 8 – 2.4VDC 300mAh Coslight battery bac k view INTERTEK TESTING SERVICES Page 5 of 6 Figure 9 – 2.4VDC 300mAh Sanik battery front view Figure 10 – 2.4VDC 300mAh Sanik battery back view INTERTEK TESTING SERVICES Page 6 of 6 Figure 11 – 2.4VDC 300mAh GP I battery front view Figure 12 – 2.4VDC 300mAh GPI battery back view

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: 13070171HKG-001 Application For Original Grant of 47 CFR Part 15 Certification Unlicensed Personal Communication Service Devices FCC ID: EW780-9352-00 Prepared and Checked by: Approved by: Lau Chin Yu, Benny Nip Ming Fung, Melvin Lead Engineer Assistant Manager September 3, 2013 INTERTEK TESTING SERVICES Test Report Number: 13070171HKG-001 Page 1 of 68 FCC ID: EW780-9352-00 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2011 Edition and 77 FR 43013, July 23, 2012 FCC ID: EW780-9352-00 FCC Model(s): TR1-2013, TR16-2013, TR17-2013, TR2- 2013, TR26-2013, TR27-2013, TRXY- 2013; TR02-2013, TR05-2013, TR06- 2013, TR07-2013, TR08-2013, TR0Y- 2013 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz Digital Modulation Cordless Phone with Caller ID and Digital Answering Machine Serial Number: N/A Sample Receipt Date: July 4, 2013 Date of Test: July 15, 2013 to August 27, 2013 Report Date: September 3, 2013 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: 13070171HKG-001 Page 2 of 68 FCC ID: EW780-9352-00 Table of Contents 1.0 Test Results Summary & Statement of Compliance......................................... 5 1.1 Summary of Test Results .................................................................................. 5 1.2 Statement of Compliance .................................................................................. 6 2.0 General Description............................................................................................ 8 2.1 Product Description ............................................................................................ 8 2.2 Technical Description ......................................................................................... 8 2.3 Test Methodology............................................................................................... 9 2.4 Test Facility........................................................................................................ 9 3.0 System Test Configuration............................................................................... 11 3.1 Justification ...................................................................................................... 11 3.2 Conducted Emission Test Configuration ........................................................... 12 3.3 Conducted Monitoring and Operational Test Configuration ............................... 12 3.4 EUT Exercising Software.................................................................................. 12 3.5 Details of EUT and Description of Accessories................................................. 13 3.6 Measurement Uncertainty ................................................................................ 13 4.0 Measurement Results....................................................................................... 15 4.1 Antenna Requirement...................................................................................... 15 4.2 Digital Modulation Techniques.......................................................................... 15 4.3 Emission Bandwidth......................................................................................... 16 4.4 Directional Gain of the Antenna ........................................................................ 19 4.5 Peak Transmit Power ....................................................................................... 20 4.6 Power Spectral Density .................................................................................... 23 4.7 Automatic Discontinuation of Transmission....................................................... 26 4.8 Unwanted Emission Inside the Sub-Band ......................................................... 27 4.9 Emissions Outside the Sub-Band ..................................................................... 30 4.9.1 Radiated Emissions Configuration Photographs ............................................ 31 4.9.2 Radiated Emissions Data .............................................................................. 31 4.9.3 Field Strength Calculation.............................................................................. 38 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements ........... 39 4.10 AC Power Line Conducted Emissions ............................................................ 40 4.10.1 AC Power Line Conducted Emissions Configuration Photographs ............... 41 4.10.2 AC Power Line Conducted Emissions Data .........…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd July 3, 2013 To whom it may concern, Declarations FCC ID: EW780-9352-00 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset Unit 1 Switch-off companion device NA NA 2 On hook by companion device B NA 3 Remove power from companion device B A 4 Switch-off device NA NA 5 On hook device NA C 6 Remove power from device A C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. 5. For FCC, upper monitoring threshold of base unit and handset declared by manufacturer are -60.7dBm and -60.5dBm respectively. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9352-00 config photos (radiated emission - base unit) - 1 of 1 Radiated Emission - Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9352-00 config photos (radiated emission - handset) - 1 of 1 Radiated Emission – Handset Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9352-00 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9352-00 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
