EW780-9354-001.9GHz DECT SIP Cordless Phone

Quick Start GuideVSP600DECT SIP Cordless Base Station with Cordless Handset 2 Important Safety Information This symbol is to alert you to important operating or servicing instructions that may appear on the product or in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of        Important Safety InstructionsWhen using your telephone equipment, basic safety precautions should always be                     1.                2. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS). 3. Read and understand all instructions.4. Follow all warnings and instructions marked on the product.5. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 6. Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet basement or shower. 7. Do not place this product on an unstable table, shelf, stand or other unstable surfaces. 8. Slots and openings in the back or bottom of the base station and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided. 9. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied at the premises, consult your dealer or local power company. 10. Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on. 3 11. Never push objects of any kind into this product through the slots in the base station or handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product. 12. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the base station                       voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. 13. !   "           14. Unplug this product from the wall outlet and refer servicing to an authorized  "          A. When the power supply cord or plug is damaged or frayed.B. If liquid has been spilled onto the product.# $              D. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operation instructions. Improper adjustment of other controls may             "      %  technician to restore the product to normal operation.E. If the product has been dropped and the telephone base and/or handset has been damaged.& $             15. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning. 16. Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain circumstances, a spark may be created when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing      '  ' *           "    +     "              - "               adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc. 4 17. :                           mode. 18.                      "   '  mount position. The prongs are not designed to hold the plug in place if it is          * *      19. Use only the power cord indicated in this manual.20. In wall mounting position, make sure to mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone base down on both mounting studs until it locks into place. Refer to the full installation instructions in the User Guide. 21. #+<$:= >                  handset receiver. SAVE THESE INSTRUCTIONS 5 ComplianceFCC part 15This device complies with Part 15 of the FCC rules. Operation is subject to the       ?@J   "            ?KJ this device must accept any interference received, including interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the                    L   M #       …

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification November 20, 2013 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd. do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd November 20, 2013 To whom it may concern, Label Location Justification FCC ID: EW780-9354-00 Request is hereby submitted by VTech Telecommunications Ltd. to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for handset will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd November 20, 2013 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-9354-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd. and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

Model : XXXXXX Serial No. Label size:20x10mm Model : VSP601 Serial no. labelSize:20x10mmonly for SB8601 DC 6V Label VSP601 / VSP600 Charge btm VSP601 / VSP600 HS rear VSP600 BS BTM VSP600 BS side PC sheet engraved in raised 0.3mm Labelsize: 15.6*21.5 mm Advanced American TelephonesDC 6V 300 mA BC 4H20 Accessory MAC / SN LabelSize: 29*22 mm Use onlySupplied Adapter RESET Model : VSP601 Model : VSP600 PC sheet Use Only Supplied Adapter IC: 1135B-80935400 FCC ID: EW780-9354-00 MAC: XXXXXXXXXXXX Model: VSP600 SN: XXXXXXXXXXX FCC ID: EW780-9354-00HAC 4H20 IC: 1135B-80935400 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE; AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. Label (permanently affixedon product ) VSP740 Engraving Charge HS Model : VSP740 Serial No. Label size:20x10mm Model : VS740 Serial no. label Size:20x10mm only for SB8601 DC 6V Label engraved in raised 0.3mm Advanced American Telephones DC 6V 300 mA BC 4H20 Accessory Model : VSP740 Use Only Supplied Adapter Label Label size: 15.6*21.5 mm IC: 1135B-80935400 FCC ID: EW780-9354-00

INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 1 of 8 Base Unit assembly (View 1) Base Unit assembly (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 2 of 8 Base Unit Main PCB comp side with 2 antennas Base Unit Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 3 of 8 Base Unit Key PCB comp side Base Unit key PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 4 of 8 Base Unit Oscillator PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 5 of 8 Handset assembly (view 1) Handset assembly (view 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 6 of 8 Handset Main PCB c omp side (View 1) Handset Main PCB comp side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 7 of 8 Han dset Main Keypad side Handset Oscillator PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9354-00 IC: 1135B-80935400 internal photos - 8 of 8 Han dset Oscillator PCB solder side

Report No.: 13070777HKG-001 Page 1 of 89 - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Specific Absorption Rate (SAR) Evaluation Report For DECT 6.0 Cordless Telephone Handset Unit Model Number: VSP600 Brand Name: vtech FCC ID: EW780-9354-00 Test Report: 13070777HKG-001 Date of Report: 21 January, 2014 Prepared for VTech Telecommunications Ltd. 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong Prepared and Checked by: Approved by: Chan Chun Foo, Bike Senior Lead Engineer Date: 21 January, 2014 Nip Ming Fung, Melvin Assistant Manager Date: 21 January, 2014 Report No.: 13070777HKG-001 Page 2 of 89 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1 Test Result Summary.................................................................................................. 3 2 General Information..................................................................................................... 4 3 Measurement System Description and Procedure ...................................................... 7 4 Tissue Verificaiton ..................................................................................................... 15 5 SAR Measurement System Verification .................................................................... 17 6 SAR Evaluation ......................................................................................................... 19 7 Test Insturments........................................................................................................ 25 8 Measurement Uncertainty .......................................................................................... 26 9 E-Field Probe and Dipole Antenna Calibration ........................................................... 26 10 References ............................................................................................................... 26 APPENDIX A – System Verification Data...................................................................... 27 APPENDIX B – SAR Evaluation Data ........................................................................... 29 APPENDIX C – E-Field Probe and Dipole Antenna Calibration .................................... 66 APPENDIX D – SAR Tissue Specification .................................................................... 88 APPENDIX E – SAR System Validation........................................................................ 89 Report No.: 13070777HKG-001 Page 3 of 89 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1. Test Result Summary The maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Highest Reported SAR Band Operating Mode TX Frequency (MHz) 1 g Head 1g Body-Worn 1.9GHz DECT Voice 1921.536 – 1928.448 0.009 W/kg 0.010 W/kg This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general population exposure limits specified in ANSI/IEEE C95.1. Applicant : VTech Telecommunications Ltd. Applicant Address : 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. Model : VSP600 Brand Name : vtech EUT Description : DECT 6.0 Cordless Telephone Handset Unit Exposure Category : General Population/Uncontrolled Exposure Test Device : Production Unit Date of Sample Received : 29 November, 2013 Date of Test : 12 December, 2013 – 13 December, 2013 Date of Report : 21 January, 2014 Place of Testing : Intertek Testing Services Hong Kong 5/F, Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong Temperature: +20 to 25°C Environmental Conidtions : Humidity 30 to 70% Test Specification : ANSI/IEEE C95.1: 1992 IEEE Std 1528: 2003 IEEE Std 1528a: 2005 FCC KDB Publication 447498 D01 v05r01 FCC KDB Publication 865664 D01 v01r02 FCC KDB Publication 865664 D02 v01r01 FCC KDB Publication 648474 D04 v01r02 Report No.: 13070777HKG-001 Page 4 of 89 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 2. General Information 2.1. Description of Equipment under test (EUT) *Note: 1. DECT has a TDD/TDMA frame structure with a complete frame of 10ms duration with 24 time slots. And under these 24 time slots, the first 12 slots are allocated for the transmission from base station to handsets, and the other 12 slots are for the transmission from handsets to base station. During a call, the handset of this product will use one of 24 time slots t…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page of 3 1 Left Cheek Left Tilt INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page of 3 2 Right Cheek Right Tilt INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page of 3 3 Back 0mm separation

INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 1 of 6 EUT Photo Figure 1 – Handset Unit front view Figure 2 – Handset Unit back view INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 2 of 6 Figure 3 – 2.4V 550mAh Ni-MH Corun rechargeable battery front view Figure 4 – 2.4V 550mAh Ni-MH Corun rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 3 of 6 Figure 5 – 2.4V 550mAh Ni-MH Coslight rechargeable battery front view Figure 6 – 2.4V 550mAh Ni-MH Coslight rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 4 of 6 Figure 7 – 2.4V 550mAh Ni-MH GP rechargeable battery front view Figure 8 – 2.4V 550mAh Ni-MH GP rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 5 of 6 Figure 9 – 2.4V 750mAh Ni-MH Coslight rechargeable battery front view Figure 10 – 2.4V 750mAh Ni-MH Coslight rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9354-00 Page 6 of 6 Figure 11 – 2.4V 750mAh Ni-MH GP rechargeable battery front view Figure 12 – 2.4V 750mAh Ni-MH GP rechargeable battery back view

Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13051483HKG-001 Page 1 of 77 FCC ID: EW780-9354-00 IC: 1135B-80935400 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2012 Edition FCC ID: EW780-9354-00 FCC Model(s): VSP600, VSP601, VSP740 IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 1135B-80935400 IC Model(s): VSP600, VSP601, VSP740 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz DECT SIP Cordless Base Station with Cordless Handset Serial Number: N/A Sample Receipt Date: May 28, 2013 Date of Test: June 11, 2013 - February 21, 2014 Report Date: March 25, 2014 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13051483HKG-001 Page 2 of 77 FCC ID: EW780-9354-00 IC: 1135B-80935400 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 Test Results Summary & Statement of Compliance.............................................. 5 1.1 Summary of Test Results ....................................................................................... 5 1.2 Statement of Compliance ....................................................................................... 7 2.0 General Description................................................................................................. 9 2.1 Product Description ................................................................................................. 9 2.2 Technical Description .............................................................................................. 9 2.3 Test Methodology.................................................................................................... 9 2.4 Test Facility........................................................................................................... 10 3.0 System Test Configuration.................................................................................... 12 3.1 Justification ........................................................................................................... 12 3.2 Conducted Emission Test Configuration ................................................................ 14 3.3 Conducted Monitoring and Operational Test Configuration .................................... 14 3.4 EUT Exercising Software....................................................................................... 14 3.5 Details of EUT and Description of Accessories...................................................... 15 3.6 Measurement Uncertainty ..................................................................................... 15 4.0 Measurement Results............................................................................................ 17 4.1 Antenna Requirement........................................................................................... 17 4.2 Digital Modulation Techniques............................................................................... 17 4.3 Emission Bandwidth.............................................................................................. 18 4.4 Directional Gain of the Antenna ............................................................................. 22 4.5 Peak Transmit Power ............................................................................................ 23 4.6 Power Spectral Density ......................................................................................... 27 4.7 Automatic Discontinuation of Transmission............................................................ 31 4.8 Unwanted Emission Inside the Sub-Band .............................................................. 32 4.9 Emissions Outside the Sub-Band .......................................................................... 38 4.9.1 Radiated Emissions Configuration Photographs ................................................. 39 4.9.2 Radiated Emissions Data ................................................................................... 39 4.9.3 Field Strength Calculation................................................................................... 46 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements ................ 47 4.10 AC Power Line Conducted Emissions ................................................................. 48 4.10.1 AC Power Line Conducted Emissions Configuration Photographs .................... 49 4.10.2 AC Power Line Conducted Emissions Data ...................................................... 49 4.11 Frame Repetition Stability .................................................................................. 52 4.12 Frame Period and Jitter ..............................................…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd Date: June 6, 2013 To whom it may concern, Declarations FCC ID: EW780-9354-00 IC: 1135B-80935400 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the Handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset 1 Switch-off companion device NA NA 2 On Hook by companion device B NA 3 Remove power from companion device B A 4 Switch-off device NA NA 5 On Hook on device side NA C 6 Remove power from device A C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable 5. For FCC, Upper Monitoring Threshold of base unit and handset declared by manufacturer are -60.8dBm and -61dBm respectively. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9354-00 IC: 1135B-80935400 config photos (radiated emission - base unit) - 1 of 2 Radiated Emission - Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9354-00 IC: 1135B-80935400 config photos (radiated emission - handset) - 2 of 2 Radiated Emission - Handset Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9354-00 IC: 1135B-80935400 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9354-00 IC: 1135B-80935400 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
