EW780-9677-004-Line Small Business System, Console with Cordless Handset
VTech Telecommunications Ltd
Click to zoom
Application Details
- Equipment Class
- PUE - Part 15 Unlicensed PCS portable Tx held to ear
- Date of Grant
- Mar 31, 2015
- Application Purpose
- Original Equipment
- Date of Application
- Mar 31, 2015
- Equipment Note
- 4-Line Small Business System, Console with Cordless Handset
- Frequency Range
- 1921.53600000 - 1928.44800000
- Company
- VTech Telecommunications Ltd
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
BC User’s manual CM18045 4-Line Small Business System Cordless Handset Go to www.vtechphones.com to register your product for enhanced warranty support and the latest VTech product news. Congratulations on your purchase of this VTech product. Before using this product, please read the Important safety information. This user’s manual provides you with the complete installation and setup instructions. For customer service or product information, visit our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada, please dial 1 (800) 267-7377. Model number: CM18045 Type: 4-Line Small Business System Cordless Handset Serial number: Purchase date: Place of purchase: Both the model and serial numbers of your VTech product can be found on the bottom of the charger. Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. T Compatible wi th Hearing Ai d T-Coil TIA-1083 Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. The ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. i This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Safety information • Read and understand all instructions in the user’s manual. Observe all markings on the product. • Avoid using a telephone during a thunderstorm. There may be a slight chance of electric shock from lightning. • Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain circumstances, a spark may be created when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of flammable or flame-supporting gases, unless there is adequate ventilation. A spark in such an environment could create a fire or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc. • Do not use this product near water, or when you are wet. For example, do not use it in a wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquid, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly. • Avoid placing the telephone system in places with extreme temperature, direct sunlight, or other electrical devices. Protect your phone from moisture, dust, corrosive liquids and fumes. • Install this product in a protected location where no one can trip over any line or power cords. Protect cords from damage or abrasion. • If this product does not operate normally, see the Troubleshooting section on pages 78-86. If you cannot solve the problem, or if the product is damaged, refer to the Limited warranty section on pages 96-98. Do not open this product except as directed in the user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks. • Replace backup battery only as described in the user’s manual. Do not burn or puncture batteries — they contain caustic chemicals. • This power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, an under-the-table or cabinet outlet. Important safety information ii • For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be easily accessible. Caution: • Use only the power adapter provided with this product. To obtain a replacement, visit our website at www.vtechphones.com, or call 1 (800) 595-9511. In Canada, dial 1 (800) 267-7377. • Use only the supplied rechargeable battery or replacement battery (model BT283342). To order a replacement battery, visit our website at www.vtechphones.com, or call 1 (800) 595-9511. In Canada, dial 1 (800) 267-7377. • To prevent risk of fire or battery explosion, replace with the correct battery type. Dispose of used batteries according to the instructions. Especially about cordless telephones • Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the console and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones. • Electrical power: The console of this cordless telephone must be connected to a working electrical outlet which is not controlled by a wall switch. Calls cannot be made from the handset if the console is unplugged, switched off or if the electrical power is interrupted. • Potential TV interference: Some cordless telephones operate at frequencies that may cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the console of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR wi…
Text truncated - open the document above for the full version.
Users Manual
Go to www.vtechphones.com to register your product for enhanced warranty support and the latest VTech product news. CM18445 4-Line Small Business System Main Console User’s manual $POHSBUVMBUJPOT POZPVSQVSDIBTFPGUIJT75FDIQSPEVDU#FGPSFVTJOHUIJT75FDIQSPEVDU QMFBTFSFBEUIF*NQPSUBOUTBGFUZJOGPSNBUJPO 5IJTVTFSmTNBOVBMQSPWJEFTZPVXJUIUIFDPNQMFUFJOTUBMMBUJPO TFUVQBOE PQFSBUJPOJOTUSVDUJPOT 'PSDVTUPNFSTFSWJDFPSQSPEVDUJOGPSNBUJPO WJTJUPVSXFCTJUFBU XXXWUFDIQIPOFTDPNPSDBMM *O$BOBEB QMFBTFEJBM .PEFMOVNCFS $. 5ZQF-JOF4NBMM#VTJOFTT4ZTUFN.BJO$POTPMF 4FSJBMOVNCFS 1VSDIBTFEBUF 1MBDFPGQVSDIBTF #PUIUIFNPEFMBOETFSJBMOVNCFSTPGZPVS75FDIQSPEVDUDBOCFGPVOEPOUIF CPUUPNPGUIFDPOTPMF 4BWFZPVSTBMFTSFDFJQUBOEPSJHJOBMQBDLBHJOHJODBTFJUJTOFDFTTBSZUPSFUVSO ZPVSUFMFQIPOFGPSXBSSBOUZTFSWJDF T Compatible with Hearing Aid T-Coil TIA-1083 5FMFQIPOFTJEFOUJGJFEXJUIUIJTMPHPIBWFSFEVDFEOPJTFBOEJOUFSGFSFODFXIFO VTFEXJUINPTU5DPJMFRVJQQFEIFBSJOHBJETBOEDPDIMFBSJNQMBOUT5IF5*" $PNQMJBOU-PHPJTBUSBEFNBSLPGUIF5FMFDPNNVOJDBUJPOT*OEVTUSZ"TTPDJBUJPO 6TFEVOEFSMJDFOTF J 5IJTTZNCPMJTUPBMFSUZPVUPJNQPSUBOUPQFSBUJOHPSTFSWJDJOHJOTUSVDUJPOTUIBUNBZBQQFBS JOUIJTVTFSmTNBOVBM"MXBZTGPMMPXCBTJDTBGFUZQSFDBVUJPOTXIFOVTJOHUIJTQSPEVDUUP SFEVDFUIFSJTLPGJOKVSZ GJSF PSFMFDUSJDTIPDL 4BGFUZJOGPSNBUJPO 3FBEBOEVOEFSTUBOEBMMJOTUSVDUJPOTJOUIFVTFSm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mTNBOVBM*GZPVDBOOPUTPMWFUIFQSPCMFN PSJGUIFQSPEVDUJTEBNBHFE SFGFSUP UIF-JNJUFEXBSSBOUZTFDUJPOPOQBHFT%POPUPQFOUIJTQSPEVDUFYDFQUBTEJSFDUFE JOZPVSVTFSm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p p p p p p p p p p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mTFWBMVBUJPOEJEOPUJEFOUJGZBOZSJTLUPCZTUBOEFSTXJUIQBDFNBLFSTGSPNPUIFSQFSTPOTVTJOH XJSFMFTTUFMFQIPOFT &TQFDJBMMZBCPVUUFMFQIPOFBOTXFSJOHTZTUFNT 5XPXBZSFDPSEJOH5IJTVOJUEPFTOPUTPVOEXBSOJOHCFFQTUPJOGPSNUIFPUIFSQBSUZUIBUUIFDBMMJT CFJOHSFDPSEFE5PFOTVSFUIBUZPVBSFJODPNQMJBODFXJUIBOZGFEFSBMPSTUBUFSFHVMBUJPOTSFHBSEJOH SFDPSEJOHBUFMFQIPOFDBMM ZPVTIPVMETUBSUUIFSFDPSEJOHQSPDFTTBOEUIFOJOGPSNUIFPUIFSQBSUZ UIBUZPVBSFSFDPSEJOHUIFDPOWFSTBUJPO 4"7&5)&4&*/4536$5*0/4 p …
Text truncated - open the document above for the full version.
Cover Letter(s)
VTech Telecommunications Ltd Feb 02, 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-9677-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information: Schematics Detailed Block diagrams Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor
Cover Letter(s)
VTech Telecommunications Ltd Feb 02, 2015 To whom it may concern, Label Location Justification FCC ID: EW780-9677-00 Request is hereby submitted by VTech Telecommunications Ltd. to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for handset will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches: Marketing the device without the battery installed, or Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, Michael Tsui Approbation Supervisor
External Photos
INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9677-00 IC: 1135B-80967700
ID Label/Location Info
CM18245 CM18045 10.50 20.50 17.60 22.00 IC: 1135B-80967700 FCC ID: EW780-9677-00 VTECH TELECOMMUNICATIONS LTD. DC 6V 100mA Use Only Supplied Adapter Text: engraved in recessed 0.3mm depth, text surface in high gloss Text: engraved in raised 0.3mm Text : Recessed 0.3mm High Gloss 4H20 CM18045 CM18045 SIZE:20X10MM Text: engraved in raised 0.3mm Text: engraved in raised 0.3mm Serial no. label 28x10mm Text : Recessed 0.3mm High Gloss Text : Recessed 0.3mm High Gloss Use only Supplied Adapter 4H20 Text: engraved in raised 0.3mm Text: engraved in raised 0.3mm CM18245 CM18445 CM18X45 ENGRAVING 14.50 47.00 28.50 10.50 BACKUP BATTERIES COMPARTMENT BACKUP BATTERIES COMPARTMENT Text: engraved in raised 0.3mm BT283342 BT266342 Serial no. label 28x10mm Text : Recessed 0.3mm High Gloss Use only Supplied Adapter Text: engraved in raised 0.3mm THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. COMPLIES WITH 47 CFR PART 68 REGISTRATION NO.: US: EW7KH01B80-967700 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/W, RJ14C/W DC 6V 800mA HAC MANUFACTURED IN CHINA IC: 1135B-80967700 VTECH TELECOMMUNICATIONS LTD. FCC ID: EW780-9677-00 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. COMPLIES WITH 47 CFR PART 68 REGISTRATION NO.: US: EW7KXNAN80-967800 DC 6V 600mA HAC MANUFACTURED IN CHINA IC: 1135B-80967800 VTECH TELECOMMUNICATIONS LTD. FCC ID: EW780-9678-00 4H20 CM18445 L4L3/4L2L1/2 VTech Customer Service 1-800-595-9511 www.vtechphones.com VTech Customer Service 1-800-595-9511 www.vtechphones.com VTech Customer Service 1-800-595-9511 www.vtechphones.com
Internal Photos
INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9677-00 IC: 1135B-80967700
RF Exposure Info
Report No.: 15011002HKG-001 Page 1 of 80 - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Specific Absorption Rate (SAR) Evaluation Report For 4-Line Small Business System Cordless Handset Unit Model Number: CM18045 Brand Name: VTech FCC ID: EW780-9677-00 Test Report: 15011002HKG-001 Date of Report: 13 March, 2015 Prepared for VTech Telecommunications Ltd. 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong Prepared and Checked by: Approved by: Chan Chun Foo, Bike Senior Lead Engineer Date: 13 March, 2015 Nip Ming Fung, Melvin Assistant Manager Date: 13 March, 2015 Report No.: 15011002HKG-001 Page 2 of 80 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1 Test Result Summary.................................................................................................. 3 2 General Information..................................................................................................... 4 3 Measurement System Description and Procedure ...................................................... 6 4 Tissue Verificaiton ..................................................................................................... 14 5 SAR Measurement System Verification .................................................................... 16 6 SAR Evaluation ......................................................................................................... 18 7 Test Insturments........................................................................................................ 24 8 Measurement Uncertainty ......................................................................................... 25 9 E-Field Probe and Dipole Antenna Calibration .......................................................... 25 10 References ............................................................................................................... 25 APPENDIX A – System Verification Data...................................................................... 26 APPENDIX B – SAR Evaluation Data ........................................................................... 28 APPENDIX C – E-Field Probe and Dipole Antenna Calibration .................................... 33 APPENDIX D – SAR Tissue Specification .................................................................... 79 APPENDIX E – SAR System Validation........................................................................ 80 Report No.: 15011002HKG-001 Page 3 of 80 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1. Test Result Summary The maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Highest Reported SAR Band Operating Mode TX Frequency (MHz) 1 g Head 1g Body-Worn 1.9GHz DECT Voice 1921.536 – 1928.448 0.053 W/kg 0.010 W/kg This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general population exposure limits specified in ANSI/IEEE C95.1. Applicant : VTech Telecommunications Ltd. Applicant Address : 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. Model : CM18045 Brand Name : VTech EUT Description : 4-Line Small Business System Cordless Handset Unit Exposure Category : General Population/Uncontrolled Exposure Test Device : Production Unit Date of Sample Received : 28 January, 2015 Date of Test : 10 February, 2015 Date of Report : 13 March, 2015 Place of Testing : Intertek Testing Services Hong Kong Workshop No. 3, G/F, World-wide Industrial Centre, 43-47 Shan Mei Street, Fotan Shatin, N.T., Hong Kong Temperature: +20 to 25°C Environmental Conidtions : Humidity 30 to 70% Test Specification : ANSI/IEEE C95.1: 1992 IEEE Std 1528: 2003 IEEE Std 1528a: 2005 FCC KDB Publication 447498 D01 v05r02 FCC KDB Publication 865664 D01 v01r03 FCC KDB Publication 865664 D02 v01r01 FCC KDB Publication 648474 D04 v01r02 Report No.: 15011002HKG-001 Page 4 of 80 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 2. General Information 2.1. Description of Equipment under test (EUT) *Note: 1. DECT has a TDD/TDMA frame structure with a complete frame of 10ms duration with 24 time slots. And under these 24 time slots, the first 12 slots are allocated for the transmission from base station to handsets, and the other 12 slots are for the transmission from handsets to base station. During a call, the handset of this produc…
Text truncated - open the document above for the full version.
RF Exposure Info
INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 1 of 6 EUT Photo Figure 1 – Handset Unit front view Figure 2 – Handset Unit back view INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 2 of 6 Fi gure 3 – 2.4V 400mAh Ni-MH Wewin rechargeable battery front view Figure 4 – 2.4V 400mAh Ni-MH Wewin rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 3 of 6 Fi gure 5 – 2.4V 400mAh Ni-MH Corun rechargeable battery front view Figure 6 – 2.4V 400mAh Ni-MH Corun rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 4 of 6 Fi gure 7 – 2.4V 400mAh Ni-MH GPI rechargeable battery front view Figure 8 – 2.4V 400mAh Ni-MH GPI rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 5 of 6 F igure 9 – 2.4V 400mAh Ni-MH Coslight rechargeable battery front view Figure 10 – 2.4V 400mAh Ni-MH Coslight rechargeable battery back view INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page 6 of 6 Fi gure 11 – 2.4V 400mAh Ni-MH Sanik rechargeable battery front view Figure 12 – 2.4V 400mAh Ni-MH Sanik rechargeable battery back view
RF Exposure Info
INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page of 2 1 Left Cheek Left Tilt INTERTEK TESTING SERVICES FCC ID: EW780-9677-00 Page of 2 2 Right Cheek Right T ilt
Test Report
- Intertek’s standard Terms and Conditions can be obtained at our website: http://www.intertek.com/terms/. - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: 15010867HKG-002 Application For Original Grant of 47 CFR Part 15 Certification New Family of RSS-213 Issue 2 Equipment Certification Unlicensed Personal Communication Service Devices/ 2 GHz License-exempt Personal Communications Service Devices FCC ID: EW780-9677-00 IC: 1135B-80967700 Prepared and Checked by: Approved by: Leung Chiu Kuen, Stanley Nip Ming Fung, Melvin Engineer Assistant Manager March 20, 2015 INTERTEK TESTING SERVICES Test Report Number: 15010867HKG-002 Page 1 of 82 FCC ID: EW780-9677-00 IC: 1135B-80967700 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2013 Edition FCC ID: EW780-9677-00 FCC Model(s): CM18445, CM18045 IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 1135B-80967700 IC Model(s): CM18445, CM18045 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 4-Line Small Business System, Console with Cordless Handset Serial Number: N/A Sample Receipt Date: January 26, 2015 Date of Test: January 30, 2015 to February 04, 2015 Report Date: March 20, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: 15010867HKG-002 Page 2 of 82 FCC ID: EW780-9677-00 IC: 1135B-80967700 Table of Contents 1.0 Test Results Summary & Statement of Compliance............................................... 5 1.1 Summary of Test Results......................................................................................... 5 1.2 Statement of Compliance......................................................................................... 7 2.0 General Description................................................................................................... 9 2.1 Product Description ................................................................................................... 9 2.2 Technical Description ................................................................................................ 9 2.3 Test Methodology...................................................................................................... 9 2.4 Test Facility ...............................................................................................................9 3.0 System Test Configuration...................................................................................... 11 3.1 Justification ............................................................................................................. 11 3.2 Conducted Emission Test Configuration ................................................................. 12 3.3 Conducted Monitoring and Operational Test Configuration ..................................... 12 3.4 EUT Exercising Software ........................................................................................ 12 3.5 Details of EUT and Description of Accessories ....................................................... 13 3.6 Measurement Uncertainty ....................................................................................... 13 4.0 Measurement Results.............................................................................................. 15 4.1 Antenna Requirement ............................................................................................. 15 4.2 Digital Modulation Techniques ................................................................................ 15 4.3 Emission Bandwidth.............................................................................…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Michael Tsui(Approbation Supervisor)
Technical Contact
Intertek Testing Services Hong Kong Ltd.Melvin Nip
[email protected](852) 2173 8888
Flat D, 5/F., Garment Centre · Kowloon · Hong Kong
Non-Technical Contact
Intertek Testing Services Hong Kong Ltd.Melvin Nip
[email protected](852) 2173 8888
Test Firm
Intertek Testing Services Hong Kong Ltd.Billy Chow
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15D | 1.92 GHz - 1.93 GHz | 93.00 mW |
