Complete user’s manual CL83215/CL83315/CL83415/ CL83465/CL83565 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting Congratulations on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information section on pages 123-118 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. This telephone meets the California Energy Commission regulations for energy consumption. Your telephone is set up to comply with the energy- conserving standards right out of the box. No further action is necessary. This telephone system is compatible with certain AT&T DECT 6.0 cordless headsets. Visit www.telephones.att.com/accessories for a list of compatible cordless headsets and speakerphones. Model number: CL83215 (two handsets) CL83315 (three handsets) CL83415/CL83465 (four handsets) CL83565 (five handsets) Type: DECT 6.0 cordless telephone/answering system with caller ID/call waiting Serial number: Purchase date: Place of purchase: Both the model and serial numbers of your AT&T product can be found on the bottom of the telephone base. Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. © 2015 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines. Parts checklist Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Cordless handset (2 for CL83215) (3 for CL83315) (4 for CL83415/CL83465) (5 for CL83565) Charger for cordless handset with power adapter installed (1 for CL83215) (2 for CL83315) (3 for CL83415/CL83465) (4 for CL83565) Battery compartment cover (2 for CL83215) (3 for CL83315) (4 for CL83415/CL83465) (5 for CL83565) Telephone line cord Power adapter for telephone base Telephone baseBattery for cordless handset (2 for CL83215) (3 for CL83315) (4 for CL83415/CL83465) (5 for CL83565) Abridged User’s manual Quick start guide Caution: Use only the power adapter provided with this product. To obtain a replacement, visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. Telephone base installation This quick start guide provides you with basic instructions only. For more complete instructions, refer to your Abridged user’s manual provided in the package, or see the online Complete user’s manual at www.telephones.att.com/manuals. Quick start guide CL83215/CL83315/CL83415/CL83465/CL83565 Raise the antenna. Plug the power cord and the telephone line cord into the jacks. Plug one end of the telephone line cord into a telephone jack or a DSL filter. Charger installation Plug the power adapter into a power outlet not controlled by a wall switch. Complete user’s manual CL83215/CL83315/CL83415/ CL83465/CL83565 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting Plug the large end of the power adapter into a power outlet not controlled by a wall switch. Route the power adapter cord through this slot. If you have DSL high-speed Internet service, a DSL filter (not included) is required. Route the telephone line cord through this slot. Wall-mount bracket Complete user’s manual CL83215/CL83315/CL83415/ CL83465/CL83565 DECT 6.0 cordless telephone/ answering system with caller ID/call waiting Table of contents Getting started Quick reference guide - handset ........ 1 Quick reference guide - telephone base ...................................... 4 Installation ..................................................... 7 Telephone base and charger installation ............................................... 8 Telephone base installation ............ 8 Charger installation ............................. 8 Battery installation and charging ....... 9 Battery backup mode ............................ 11 To activate the mode ...................... 11 Operation ............................................... 11 Installation options ................................. 12 Tabletop to wall-mount installation.......................................... 12 Wall-mount to tabletop installation.......................................... 13 Telephone settings Handset settings ...................................... 14 Ringer volume ..................................... 15 Ringer tone ........................................... 15 Set date/time ...................................... 16 LCD language ...................................... 17 Caller ID announce ........................... 18 Set speed dial voicemail number ................................................. 19 Voicemail (visual message waiting) indicator ............................ 19 Clear voicemail indication ........... 20 Rename handset ............................. 21 Key tone ................................................. 21 Use caller ID to automatically set date and time ........................... 22 Home area code ................................. 22 Dial mode .............................................. 23 Web address ........................................ 23 QUIET mode ................…

Text truncated - open the document above for the full version.

User’s manual CL80115 DECT 6.0 expansion handset for use with AT&T models CL82115/CL82215/CL82315/ CL82415/CL82465/CL82515/ CL83215/CL83315/CL83365/ CL83415/CL83465/CL83565/ CL84115/CL84215/CL84265/ CL84365 Congratulations on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information section on pages 23-25 of this manual. For complete instructions, please refer to the manual provided with your CL82115/CL82215/CL82315/ CL82415/CL82465/CL82515/CL83215/CL83315/CL83365/CL83415/ CL83465/CL83565/CL84115/CL84215/CL84265/CL84365 telephone. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. This telephone meets the California Energy Commission regulations for energy consumption. Your telephone is set up to comply with the energy-conserving standards right out of the box. No further action is necessary. Model number: CL80115 Type: DECT 6.0 expansion handset Serial number: Purchase date: Place of purchase: Both the model and serial numbers of your AT&T product can be found on the bottom of the telephone base. Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service. © 2015 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to supply this product with an ENERGY STAR® qualified power adapter meeting the latest energy efficiency guidelines. T Compatible with Hearing Aid T-Coil TIA-1083 Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license. Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Battery for cordless handset Cordless handset Charger for cordless handset with power adapter installed Battery compartment cover User’s manual User’s manual CL80115 DECT 6.0 expansion handset for use with AT&T models CL82115/CL82215/CL82315/ CL82415/CL82465/CL82515/ CL83215/CL83315/CL83365/ CL83415/CL83465/CL83565/ CL84115/CL84215/CL84265/ CL84365 Parts checklist User’s manual CL80115 DECT 6.0 expansion handset for use with AT&T models CL82115/CL82215/CL82315/CL82415/CL82465/ CL82515/CL83215/CL83315/CL83365/CL83415/ CL83465/CL83565/CL84115/CL84215/CL84265/ CL84365 Table of contents Getting started Installation ...................................................................................................................1 Quick reference guide ...........................................................................................2 Charger installation .................................................................................................5 Battery installation and charging .....................................................................6 Registration and deregistration Adding and registering handsets .....................................................................9 Deregistering handsets ......................................................................................12 Appendix Troubleshooting .....................................................................................................14 Maintenance.............................................................................................................22 Important safety information ..........................................................................23 Safety information.............................................................................................23 Especially about cordless telephones .....................................................24 Precautions for users of implanted cardiac pacemakers ..............25 Pacemaker patients ..........................................................................................25 ECO mode .............................................................................................................25 Especially about telephone answering systems ................................25 For C-UL compliance ...........................................................................................26 Mesures de sécurité importantes ..............................................................26 FCC Part 68 and ACTA........................................................................................30 FCC Part 15 ..............................................................................................................32 California Energy Commission battery charging testing instructions ...33 Limited warranty ....................................................................................................34 Technical specifications .....................................................................................37 DECT 6.0 digital technology .........................................................................37 Telephone operating range ..........................................................................37 Redefining long range coverage and clarity ........................................37 HD audio ................................................................................................................37 Simulated full-duplex handset speakerphone ....................................37 Getting started 1 See pages 6-8 for easy instructions. You must install and charge the battery before using the telephone. STOP! Installation Your product may be shipped with a protective sticker covering the handset display - remove it before use. For customer service or product information, vi…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification December 22, 2014 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd December 22, 2014 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: EW780-9870-00 Request is hereby submitted by VTech Telecommunications Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd . and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9870-00 IC: 1135B-80987000 external photos - 1 of 2 Job Number HK14120782 Job Number HK14120782 INTERTEK TESTING SERVICES External Photos FCC ID: EW780-9870-00 IC: 1135B-80987000 external photos - 2 of 2

CL83XX5 Engraving CL83XX5 BS EngravingCL83XX5 CH Engraving CL801X5 Accessory HS Engraving CL83XX5 HS Engraving Advanced American Telephones DC 6V 100mA Customer Service 1-800-222-3111 www.telephones.att.com Model: CL83215SN: XXXXXXXXXXX Model: CL83215 SN: XXXXXXXXXXX Model: CL80115 SN: XXXXXXXXXXX Model: CL80115 SN: XXXXXXXXXXX Model: CL83315 SN: XXXXXXXXXXX Model: CL83415 SN: XXXXXXXXXXX Model: CL83465 SN: XXXXXXXXXXX Model: CL83365 SN: XXXXXXXXXXX Model: CL83565 SN: XXXXXXXXXXX COMPLIES WITH 47 CFR PART 68 DC 6V 600mA HAC REGISTRATION NO.: US: EW7W410B80-987000 RINGER EQUIVALENCE: 1.0B USOC JACK: RJ11C/W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE; AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. Advanced American Telephones MANUFACTURED IN CHINA FCC ID: EW780-9870-00 IC: 1135B-80987000 4H20 Model: CL83215 S/N: XXXXXXXXXXX Model: CL83215 S/N: XXXXXXXXXXX Model: CL83315 S/N: XXXXXXXXXXX Model: CL83415 S/N: XXXXXXXXXXX Model: CL83365 S/N: XXXXXXXXXXX Model: CL83465 S/N: XXXXXXXXXXX Model: CL83565 S/N: XXXXXXXXXXX Use Only Supplied Adapter SN. label for models (28x10mm) PN:92-007224-000-100 CAUTION Use Only Supplied Battery or Battery BT183342 FCC ID: EW780-9870-00 IC: 1135B-80987000 The red serial number and barcode will be printed in VTT SN. label for models (20x10mm) PN:92-026208-000-100 The red serial number and barcode will be printed in VTT SN. label for models (20x10mm) PN:92-004378-001-100 The red serial number and barcode will be printed in VTT CAUTION Use Only Supplied Battery or Battery BT183342 FCC ID: EW780-9870-00 IC: 1135B-80987000 DC 6V Use Only Supplied Adapter

INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 1 of 9 Base Unit assembly (View 1) Base Unit Antenna 1 INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 2 of 9 Base Unit assembly (Vie w 2) and Antenna 0 Base Unit Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 3 of 9 Bas e Unit Main PCB comp side (View 2) Base Unit Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 4 of 9 Bas e Unit Key PCB comp side (view 1) Base Unit Key PCB comp side (view 2) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 5 of 9 Bas e Unit Key PCB solder side Base Unit – Handset Locator PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 6 of 9 Base Unit – Handset Locator PCB comp side Base Unit – DECT Oscillator PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 7 of 9 Han dset assembly Handset Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 8 of 9 Handset Main PCB c omp side (View 2) Handset Main PCB display side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: EW780-9870-00 IC: 1135B-80987000 internal photos - 9 of 9 Han dset Main PCB display side (View 2) Handset DECT Oscillator PCB comp side

INTERTEK TESTING SERVICES FCC ID: EW780-9870-00 RF exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the 1.9GHz Base Unit of tested model: CL83215, the measured powers among all the measured channels were within its production tolerance: +20 dBm (Minimum) and +21 dBm (Maximum).The antenna gain of CL83215 is 2 dBi = 1.58 (num gain) and its maximum source-base d time-averaging duty factor is 25.0% (6/24 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 21 dBm = 125.9 mW The Conducted Power source-based time-averaging output power = (125.9 * 0.250) mW = 31.47 mW The power density at 20cm = 31.47 *1.58/ 4R 2 = 0.0099 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or near by persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.”

- Intertek's standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: 14120782HKG-001 Application For Original Grant of 47 CFR Part 15 Certification New Family of RSS-213 Issue 2 Equipment Certification Unlicensed Personal Communication Service Devices/ 2 GHz License-exempt Personal Communications Service Devices FCC ID: EW780-9870-00 IC: 1135B-80987000 Test Engineer: Approved by: Signed on File Leung Chiu Kuen, Stanley Nip Ming Fung, Melvin Engineer Assistant Manager February 12, 2015 INTERTEK TESTING SERVICES Test Report Number: 14120782HKG-001 Page 1 of 82 FCC ID: EW780-9870-00 IC: 1135B-80987000 GENERAL INFORMATION Applicant Name: VTech Telecommunications Ltd. Applicant Address: 23/F., Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2013 Edition FCC ID: EW780-9870-00 FCC Model(s): CL83215, CL83315, CL83415, CL83465, CL83565, CL83XY5, CL80115, CL801Y5 IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 1135B-80987000 IC Model(s): CL83215, CL83315, CL83415, CL80115 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz DECT Cordless Phone with Caller ID, Speakerphone, Answering Machine Serial Number: N/A Sample Receipt Date: December 19, 2014 Date of Test: January 09-30, 2015 Report Date: February 12, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: 14120782HKG-001 Page 2 of 82 FCC ID: EW780-9870-00 IC: 1135B-80987000 Table of Contents 1.0 Test Results Summary & Statement of Compliance.............................................. 5 1.1 Summary of Test Results ....................................................................................... 5 1.2 Statement of Compliance ....................................................................................... 7 2.0 General Description................................................................................................. 9 2.1 Product Description ................................................................................................. 9 2.2 Technical Description ............................................................................................ 10 2.3 Test Methodology.................................................................................................. 10 2.4 Test Facility........................................................................................................... 10 3.0 System Test Configuration.................................................................................... 12 3.1 Justification ........................................................................................................... 12 3.2 Conducted Emission Test Configuration ................................................................ 13 3.3 Conducted Monitoring and Operational Test Configuration .................................... 13 3.4 EUT Exercising Software....................................................................................... 13 3.5 Details of EUT and Description of Accessories...................................................... 14 3.6 Measurement Uncertainty ..................................................................................... 14 4.0 Measurement Results............................................................................................ 16 4.1 Antenna Requirement........................................................................................... 16 4.2 Digital Modulation Techniques............................................................................... 16 4.3 Emission Bandwidth.............................................................................................. 17 4.4 Directional Gain of the Antenna ............................................................................. 21 4.5 Peak Transmit Power ............................................................................................ 22 4.6 Power Spectral Density ......................................................................................... 26 4.7 Automatic Discontinuation of Transmission............................................................ 30 4.8 Unwanted Emission Inside the Sub-Band .............................................................. 31 4.9 Emissions Outside the Sub-Band .......................................................................... 37 4.9.1 Radiated Emissions Configuration Photographs ................................................. 38 4.9.2 Radiated Emissions Data ...............................................................................…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd December 22, 2014 To whom it may concern, Declarations FCC ID: EW780-9870-00 IC: 1135B-80987000 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset Unit 1 Switch-off companion device NA NA 2 On hook by companion device B NA 3 Switch-off device NA NA 4 On hook on device side NA C 5 Remove power from device A C 6 Remove power from companion device B A A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. 5. For FCC, M L of base unit and handset declared by manufacturer are 30dBm. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9870-00 IC: 1135B-80987000 config photos (radiated emission - base unit) - 1 of 1 Radiated Emission – Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-9870-00 IC: 1135B-80987000 config photos (radiated emission - handset unit) - 1 of 1 Radiated Emission - Handset Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9870-00 IC: 1135B-80987000 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: EW780-9870-00 IC: 1135B-80987000 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
