EW780-9896-01Digital Audio Baby Monitor - Parent Unit

Adjust the sound sensitivity of the baby unit You can choose to hear sounds from the baby unit all the time, or to hear sounds that exceed a certain level. You can use the parent unit to adjust the microphone sensitivity of your baby unit. The higher the sensitivity level, the more sensitive the baby unit is in detecting sounds for transmitting to the parent unit. The sound sensitivity is preset to Level 5. Sound sensitivity table for reference DisplaySensitivity Description High sensitivity level The parent unit speaker is constantly on, and you will hear all sounds (including background noises) from your baby’s room. Medium high sensitivity level The parent unit speaker turns on for soft babbling and louder sounds from your baby. It remains quiet when your baby sleeps soundly. Medium sensitivity level The parent unit speaker turns on for loud babbling and louder sounds from your baby. It remains quiet when your baby makes soft sounds. Medium low sensitivity level The parent unit speaker turns on for crying and louder sounds from your baby. It remains quiet when your baby makes soft sounds. Low sensitivity level The parent unit speaker turns on for loud crying or screeching sounds from your baby. It remains quiet when your baby makes soft sounds. Press menu when the parent unit is not in use. Press select. Press volume + or volume - to choose the sensitivity level. Press select to confirm your selection. 1. 2. 3. 4. BC Baby unit overview 1 Projector When it is on, it projects some image patterns to the user environment. • 2 Microphone 3 Control key panel power on Press to power on. Press and hold to power off. page Press to start or stop paging parent unit. volume + Press to increase the listening volume or lullaby volume. volume - Press to decrease the listening volume or lullaby volume. Press to turn on or off the projector and lullaby. • • • • • • 4 Magnetic base 5 Speaker 6 Temperature sensor 7 Power jack Parent unit overview 1 sensor alerts Press to turn on or off the sensor alert system. • 2 Microphone 3 Visual sound indicator The visual sound indicator has two functions. One is to show the sound level detected by the baby unit. The other one is to show the volume level during speaker volume setting. Sound level detected by the baby unit One to three green lights indicate a moderate sound level detected by the baby unit. Additional red lights indicate a higher sound level detected by the baby unit (e.g. baby crying loudly). Speaker volume level One to three green lights indicate Level 1 to Level 3 of the speaker volume setting. Additional red lights indicate Level 4 to Level 5 of the speaker volume setting. • • • • 4 LCD panel 5menu Press to enter the settings menu while idle. • Baby Monitor Overview 6Control key panel select While in a menu, press to choose an item, or save a setting. back While in a menu, press to return to the previous screen. volume + Press to increase the speaker volume. While in a menu, press to scroll up. volume - Press to decrease the speaker volume. While in a menu, press to scroll down. • • • • • • 7 Battery level indicator Light on when the parent unit is connected to AC power. Light flashes when the parent unit battery is low and needs charging. Light off when the parent unit battery is fully charged, or when not connect to AC power and with no battery installed . • • • 8 (On/off) Press to power on. Press and hold to power off. • • 9talk Press and hold to talk to the baby unit; release to stop talking. While in a menu, press to return to idle screen. • • 10 Power jack 11 Speaker 12 Belt clip 13 Battery compartment cover What’s in the box Power on or off the baby unit Press power on to turn on the baby unit. The power on lights up. Press and hold power on again to power off the baby unit. The power on turns off. Power on or off the parent unit Press to power on the parent unit. The screen turns on. Press and hold again to power off the parent unit. The screen turns off. NOTE The parent unit powers on automatically once it is connected to AC power or battery installed. The baby unit also powers on automatically once connected to AC power. Adjust the speaker volume for baby unit Press volume + or volume - on the baby unit at any time. Adjust the speaker volume for parent unit You can adjust the speaker volume from VOLUME 1 toto VOLUME 5, or turn it off. The speaker volume is preset to VOLUME 3. Press volume + or volume - when the parent unit is not in use. When the speaker volume is set to off, the screen displays . • • • • • • • Using the baby monitor Press volume + or volume - to choose On or Off. Press select to confirm your selection. The screen displays Saved and you hear a confirmation tone. NOTES Each time you set the vibration alert to ON, the parent unit vibrates briefly after you press select. We recommend you not to turn on the vibration alert and the lullaby at the same time, as the lullaby will trigger the vibration alert frequently. The vibration alert setting on each parent unit is independent. Projector You can turn on or off the baby unit projector. Press menu when the parent unit is not in use. Press volume + or volume - to choose Project, then press select. Press volume + or volume - to choose On or Off. Press select to confirm your selection. The screen displays Saved and you hear a confirmation tone. LCD language You can select a language (English, French or Spanish) to be used in all screen displays. The language is preset to English. Press menu when the parent unit is not in use. Press volume + or volume - to choose Language, then press select. Press volume + or volume - to choose English, Français or Español. Press select to confirm your selection. The screen displays Saved and you hear a confirmation tone. NOTE The language setting on each parent unit is independent. Temperature You can change the settings for the temperature’s range, alerts, format. Set the temperature range You can set the desired minimum and maximum room temper…

Text truncated - open the document above for the full version.

VTech Telecommunications Ltd Appendix B1 Letter of Agency for FCC Certification Oct 06, 2015 To whom it may concern, Letter of Agency I, an officer of VTech Telecommunications Ltd do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Oct 06, 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification-PU FCC ID: EW780-9896-01 Request is hereby submitted by VTech Telecommunications Ltd to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and VTech Telecommunications Ltd reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of VTech Telecommunications Ltd and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor

VTech Telecommunications Ltd Oct 06, 2015 To whom it may concern, Declarations-PU FCC ID: EW780-9896-01 IC: 1135B-80989601 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the Parent unit will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Parent unit 1 Switch-off companion device A 2 On hook by companion device NA 3 Remove power from companion device A 4 Switch-off device C 5 On hook device NA 6 Remove power from device C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. 5. M L of baby unit and Parent unit declared by manufacturer are 30dBm. If you have questions or need further information, please contact the undersigned. Regards, Michael Tsui Approbation Supervisor
