EW7DVD15
VTech Telecommunications Ltd
Click to zoom
Application Details
- Equipment Class
- DSC - Part 15 Security/Remote Control Transmitter
- Date of Grant
- Oct 10, 2000
- Application Purpose
- Original Equipment
- Date of Application
- Jul 15, 2000
- Frequency Range
- 384.00000000 - 384.00000000
- Company
- VTech Telecommunications Ltd
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Block Diagram
Remote.sch-1 - Thu Jun 15 18:27:31 2000
Block Diagram
ACI2000-F002A / EA98201 / August 22, 2000FCC ID: EW7DVD15ss Video Output Block diagram for Duty Cycle calculation EUT Bi-log-Antenna Pre-amplifier Spectrum analyzer Storage oscilloscope
Cover Letter(s)
Safety & Compliance Consulting 29 Sweetman Lane West Milford, NJ 07480-2932 Tel/Fax (973) 728-5141 July 16, 2000 ACI2000-F002 731 Confirmation Number: EA98201 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Subject:Original Application for Remote Control Transmitter (DSC) Periodic Remote Control Transmitter / FCC ID: EW7DVD15 Gentlemen: Enclosed find VTech Communications Ltd.βs Application for Equipment Authorization dated June 19, 2000. This device is in compliance with FCC Part 15, Subpart C and in accordance with Section 15.231. The subject device is a periodic remote control transmitter that will operate within the 384~386 MHz frequency band. This device provides remote control to its associated digital satellite receiver with built-in DVD player, which is being separately being submitted for Certification as TV Interface Device under FCC ID: EW7DVD01. The attached test report for periodic transmitter was tested in accordance with ANSI C63.4-1992 for intentional radiator. Should you have any questions or comments, please contact the undersigned. Thank you for your attention and cooperation in this matter. Sincerely yours, Richard Mullen Group Manager Safety & Compliance Consulting
Cover Letter(s)
Safety & Compliance Consulting 29 Sweetman Lane West Milford, NJ 07480-2932 Tel/Fax (973) 728-5141 August 22, 2000 ACI2000-F002A Attn:Katie Hawkins / FCC-OET Re:FCC ID: EW7DVD15 Applicant:VTech Communications Ltd. Correspondence Ref No:15680 731 Confirmation Number:EA98201 Date of FCC E-Mail:08/18/00 Type Product:Periodic Remote Control Transmitter Dear Katie Hawki ns: 1. The test setup used to determine the calculation for duty cycle followed ANSI C63.4-1992, Appendix I4 and (10). The test instruments used were bi-log antenna, pre-amplifier, spectrum analyzer and storage oscilloscope. Attached find timing block diagram for test setup. 2. The duty cycly was calculated by averaging the sum of the pulse widths over one complete pulse train. The duty cycle = 2/10.5=0.19, the correction factor = 20*log (duty cycly) =20*log (2/10.5)=- 14.40(dB). 3. The resolution bandwidth used in the past provided bandwidth plot was set at 10KHz. Please advise if you have any further questions or comments. Thank you for your attention and cooperation in this mater. Sincerely yours, Richard Mullen Group Manager Safety & Compliance Consulting Tel/Fax: (973) 728-5141 Email: [email protected]
Cover Letter(s)
Safety & Compliance Consulting 29 Sweetman Lane West Milford, NJ 07480-2932 Tel/Fax (973) 728-5141 Amended: September 7, 2000 ACI2000-F002C Attn:Katie Hawkins / FCC-OET Re:FCC ID: EW7DVD15 Applicant:VTech Communications Ltd. Correspondence Ref No:15945 731 Confirmation Number:EA98201 Date of FCC E-Mail:09/06/00 Type Product:Periodic Remote Control Transmitter Dear Katie Hawki ns: Today I am filing the requested whole pulse train spectrum analyzer plot that was taken with span set to zero with sweep at worst case 100 msec. From this plot, we understand sum of the pulse width is 0.8*6+0.5*3+0.8*5+0.5*5+0.8*2+0.5*3+0.8*5+0.5*2 to equal 20.9 msec and the length of the period is 100 msec. As such, the duty cycle is calculated to be 20.9/100 = 0.21. Please advise if this provided plot and explanation is sufficient or should we retest? Thanks you for your continued cooperation in this mater. Sincerely yours, Richard Mullen Group Manager Safety & Compliance Consulting Tel/Fax: (973) 728-5141 Email: [email protected]
External Photos
! "" # $%%%& & ! "" # $%%%& !! " !! ' ! "" # $%%%& # !! ( ! "" # $%%%&
External Photos
!"###$% !"###$% !"###$% !"###$% !"###$% !"###$% !"###$% !" #
ID Label/Location Info
NOTES: 1. ALL DIMENSIONS ARE IN MILLIMETERS, UNLESS OTHERWISE SPECIFIED. 2. PLACE ARTWORK AT LOCATION SHOWN. 3. COLOR OF PRINTING TO BE LIGHT GRAY, PMS 427. 4. MATERIAL: POLYCARBONATE .010" THICK, BLACK LIGHT SATIN TEXTURE WITH PERMANENT PRESSURE SENSITIVE BACKING. UL/CSA APPROVED. 5. COVER ADHESIVE WITH PROTECTIVE BACKING TITLE SCALE 1:1 SIZE DWG. NO A SHEET 1 of 1 REV AA ART/LBL BOT CASE DIG RMTE 1.5 UHF CHINA (w/oLOGO) 123479515-AA APPROVALS DATE UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MM. DRAWN CHECKED REVISIONS ECOITEM MASTER DESCRIPTION REVDATEBY TOLERANCES: 0.000 +/- .125 0.00 +/- .25 0.0 +/- .4 0. +/- .7 HOLE DIA: +/- .075 ANGLES: +/- .5 5130123479515-AA INITIAL RELEASE AA 6-1-99 KMH K. HOWER 6-1-99 21.0 24.0 Scale: 100% Use this image to create label Scale: 200% Use this image to create label THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES OPERATIONS SUBJECT TO THE FOLLOWING TWO CONDITIONS (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. 103392 Patent Pending FCC ID EW7DVD15 MADE IN CHINA THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES OPERATIONS SUBJECT TO THE FOLLOWING TWO CONDITIONS (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. 103392 Patent Pending FCC ID EW7DVD15 MADE IN CHINA THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES OPERATIONS SUBJECT TO THE FOLLOWING TWO CONDITIONS (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. 103392 Patent Pending FCC ID EW7DVD15 MADE IN CHINA ! "" # $%%%&
Schematics
Remote.sch-1 - Thu Jun 15 18:27:31 2000
Test Report
VTech Communi cati ons Ltd. FCC ID: 1.51DBS 16 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 Prepared For : VTech Communications Ltd. 23/F, Taiping Industrial Centre, Block 1, 57 Tingkok Road, Taipo, N.T., Hong Kong Prepared By : AUDIX Technology (Shanghai) Co., Ltd. 3 F., 34 Bldg., 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China Tel : (+8621) 64955500 Report No. :ACI-F00026 Date of Test :June 28-30 Date of Report :June 30, 2000 Application for Certification On behalf of VTech Communications Ltd. UHF/IR Remote Controller Model No.: 1.51DBS FCC ID: EW7DVD15 VTech Communi cati ons Ltd. FCC ID: 1.51DBS 17 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TABLE OF CONTENTS Page 1 GENERAL INFORMATION ........................................................................................................ 19 1.1 Description of Equipment Under Test ...................................................................................... 19 1.2 Description of Test Facility ...................................................................................................... 19 1.3 Measurement Uncertainty......................................................................................................... 19 2 RADIATED EMISSION TEST..................................................................................................... 20 2.1 Test Equipment ......................................................................................................................... 20 2.2 Block Diagram of Test Setup.................................................................................................... 20 2.3 Limit.......................................................................................................................................... 21 2.4 Test Configuration .................................................................................................................... 22 2.5 Operating Condition of EUT .................................................................................................... 22 2.6 Test Procedure .......................................................................................................................... 22 2.7 Test Results............................................................................................................................... 23 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST.......................................................... 24 3.1 Test Equipment ......................................................................................................................... 24 3.2 Block Diagram of Test Setup.................................................................................................... 24 3.3 Limit.......................................................................................................................................... 25 3.4 Test Configuration .................................................................................................................... 25 3.5 Operating Condition of EUT .................................................................................................... 25 3.6 Test Procedure .......................................................................................................................... 25 3.7 Test Result ................................................................................................................................ 26 4 BANDWIDTH MEASUREMENT ................................................................................................ 29 4.1 Test Equipment ......................................................................................................................... 29 4.2 Bandwidth Limit ....................................................................................................................... 29 4.3 Test Results............................................................................................................................... 29 5 PHOTOGRAPHS............................................................. ERROR! BOOKMARK NOT DEFINED. 5.1 Radiated Emission Test............................................................. Error! Bookmark not defined. 5.2 Fundamental And Spurious Emissions Test ............................. Error! Bookmark not defined. 5.3 Bandwidth Measurement .......................................................... Error! Bookmark not defined. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 18 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TEST REPORT FOR FCC CERTIFICATION Applicant : VTech Communications Ltd. Manufacturer : VTech Communications Ltd. EUT Description :UHF/IR Remote Controller (A) Model No.: 1.51DBS (B) Serial No.: ACI-20000525002 (C) Power Supply: DC 6V With Battery Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C, SECTION 15.231 OCTOBER 1998 AND FCC/ANSI C63.4:1992 The device described above is tested by AUDIX Technology (Shanghai) Co., Ltd. To determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits. The measurement results are contained in this test report and AUDIX Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of AUDIX Technology (Shanghai) Co., Ltd. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 19 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description:UHF/IR Remote Controller Periodic 384 MHz TX for use with Digital Satellite Receiver With DVD Player (TVID) under FCC ID: EW7DVD01. Type of EUT:! Production " Pre-product " Prβ¦
Text truncated - open the document above for the full version.
Test Report
VTech Communi cati ons Ltd. FCC ID: 1.51DBS 18 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 Prepared For : VTech Communications Ltd. 23/F, Taiping Industrial Centre, Block 1, 57 Tingkok Road, Taipo, N.T., Hong Kong Prepared By : AUDIX Technology (Shanghai) Co., Ltd. 3 F., 34 Bldg., 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China Tel : (+8621) 64955500 Report No. :ACI-F00026 Date of Test :June 28-30 Date of Report :June 30, 2000 Application for Certification On behalf of VTech Communications Ltd. UHF/IR Remote Controller Model No.: 1.51DBS FCC ID: EW7DVD15 VTech Communi cati ons Ltd. FCC ID: 1.51DBS 19 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TABLE OF CONTENTS Page 1 GENERAL INFORMATION ........................................................................................................ 21 1.1 Description of Equipment Under Test ...................................................................................... 21 1.2 Description of Test Facility ...................................................................................................... 21 1.3 Measurement Uncertainty......................................................................................................... 21 2 RADIATED EMISSION TEST..................................................................................................... 22 2.1 Test Equipment ......................................................................................................................... 22 2.2 Block Diagram of Test Setup.................................................................................................... 22 2.3 Limit.......................................................................................................................................... 23 2.4 Test Configuration .................................................................................................................... 24 2.5 Operating Condition of EUT .................................................................................................... 24 2.6 Test Procedure .......................................................................................................................... 24 2.7 Test Results............................................................................................................................... 25 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST.......................................................... 26 3.1 Test Equipment ......................................................................................................................... 26 3.2 Block Diagram of Test Setup.................................................................................................... 26 3.3 Limit.......................................................................................................................................... 27 3.4 Test Configuration .................................................................................................................... 27 3.5 Operating Condition of EUT .................................................................................................... 27 3.6 Test Procedure .......................................................................................................................... 27 3.7 Test Result ................................................................................................................................ 28 4 BANDWIDTH MEASUREMENT ................................................................................................ 32 4.1 Test Equipment ......................................................................................................................... 32 4.2 Bandwidth Limit ....................................................................................................................... 32 4.3 Test Results............................................................................................................................... 32 5 PHOTOGRAPHS............................................................. ERROR! BOOKMARK NOT DEFINED. 5.1 Radiated Emission Test............................................................. Error! Bookmark not defined. 5.2 Fundamental And Spurious Emissions Test ............................. Error! Bookmark not defined. 5.3 Bandwidth Measurement .......................................................... Error! Bookmark not defined. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 20 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TEST REPORT FOR FCC CERTIFICATION Applicant : VTech Communications Ltd. Manufacturer : VTech Communications Ltd. EUT Description :UHF/IR Remote Controller (A) Model No.: 1.51DBS (B) Serial No.: ACI-20000525002 (C) Power Supply: DC 6V With Battery Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C OCTOBER 1998 AND FCC/ANSI C63.4:1992 The device described above is tested by AUDIX Technology (Shanghai) Co., Ltd. To determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits. The measurement results are contained in this test report and AUDIX Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of AUDIX Technology (Shanghai) Co., Ltd. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 21 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description:UHF/IR Remote Controller Type of EUT:! Production " Pre-product " Pro-type Model Number: 1.51DBS Serial No.: ACI-20000525002 FCC ID:EW7DVD15 Applicant :VTech Communications Ltd. 23/F, Taipingβ¦
Text truncated - open the document above for the full version.
Test Report
VTech Communi cati ons Ltd. FCC ID: 1.51DBS 18 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 Prepared For : VTech Communications Ltd. 23/F, Taiping Industrial Centre, Block 1, 57 Tingkok Road, Taipo, N.T., Hong Kong Prepared By : AUDIX Technology (Shanghai) Co., Ltd. 3 F., 34 Bldg., 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China Tel : (+8621) 64955500 Report No. :ACI-F00026 Date of Test :June 28-30 Date of Report :June 30, 2000 Application for Certification On behalf of VTech Communications Ltd. UHF/IR Remote Controller Model No.: 1.51DBS FCC ID: EW7DVD15 VTech Communi cati ons Ltd. FCC ID: 1.51DBS 19 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TABLE OF CONTENTS Page 1 GENERAL INFORMATION ........................................................................................................ 21 1.1 Description of Equipment Under Test ...................................................................................... 21 1.2 Description of Test Facility ...................................................................................................... 21 1.3 Measurement Uncertainty......................................................................................................... 21 2 RADIATED EMISSION TEST..................................................................................................... 22 2.1 Test Equipment ......................................................................................................................... 22 2.2 Block Diagram of Test Setup.................................................................................................... 22 2.3 Limit.......................................................................................................................................... 23 2.4 Test Configuration .................................................................................................................... 24 2.5 Operating Condition of EUT .................................................................................................... 24 2.6 Test Procedure .......................................................................................................................... 24 2.7 Test Results............................................................................................................................... 25 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST.......................................................... 26 3.1 Test Equipment ......................................................................................................................... 26 3.2 Block Diagram of Test Setup.................................................................................................... 26 3.3 Limit.......................................................................................................................................... 27 3.4 Test Configuration .................................................................................................................... 27 3.5 Operating Condition of EUT .................................................................................................... 27 3.6 Test Procedure .......................................................................................................................... 27 3.7 Test Result ................................................................................................................................ 28 4 BANDWIDTH MEASUREMENT ................................................................................................ 32 4.1 Test Equipment ......................................................................................................................... 32 4.2 Bandwidth Limit ....................................................................................................................... 32 4.3 Test Results............................................................................................................................... 32 5 PHOTOGRAPHS............................................................. ERROR! BOOKMARK NOT DEFINED. 5.1 Radiated Emission Test............................................................. Error! Bookmark not defined. 5.2 Fundamental And Spurious Emissions Test ............................. Error! Bookmark not defined. 5.3 Bandwidth Measurement .......................................................... Error! Bookmark not defined. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 20 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 TEST REPORT FOR FCC CERTIFICATION Applicant : VTech Communications Ltd. Manufacturer : VTech Communications Ltd. EUT Description :UHF/IR Remote Controller (A) Model No.: 1.51DBS (B) Serial No.: ACI-20000525002 (C) Power Supply: DC 6V With Battery Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C OCTOBER 1998 AND FCC/ANSI C63.4:1992 The device described above is tested by AUDIX Technology (Shanghai) Co., Ltd. To determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits. The measurement results are contained in this test report and AUDIX Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of AUDIX Technology (Shanghai) Co., Ltd. VTech Communi cati ons Ltd. FCC ID: 1.51DBS 21 AUDIX TECHNOLOGY (Shanghai) Co., Ltd. Report No.ACI-F00026 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description:UHF/IR Remote Controller Type of EUT:! Production " Pre-product " Pro-type Model Number: 1.51DBS Serial No.: ACI-20000525002 FCC ID:EW7DVD15 Applicant :VTech Communications Ltd. 23/F, Taipingβ¦
Text truncated - open the document above for the full version.
Test Report
VTech Communications Ltd.FCC ID: EW7DVD15 26 AUDIX Technology (Shanghai) Co., Ltd. Report No. ACI-F00026 3.7 Test Results < PASS > The frequency and amplitude of the highest AC radiated emissions relative to the limit is reported. All the emissions not reported below are too low against the FCC limit. EUT:UHF/IR Remote ControllerTemperature : 21 Model No.:1.51DBSHumidity:53% Test Mode: (Attitude) Transmitting mode (Side)Date of Test :June 28, 2000 Polarization Frequency (MHz) Antenna Factor (dB/m) Cable Loss (dB) Preamp Factor (dB) Correction Factor (dB) Meter Reading dB( ΞΌ V) Emission Level dB( ΞΌ V/m) Limits dB( ΞΌ V/m) Margin (dB) 385.99016.346.6225.89-14.4083.5366.2079.0012.80 766.23022.3410.10 26.60-14.4041.1532.5959.0029.35Horizontal 1536.14025.905.8026.70-14.4044.5035.1054.0026.84 385.99016.346.6225.89-14.4091.2773.9479.005.06 766.23022.3410.10 26.60-14.4040.5031.9459.0030.00Vertical 1536.14025.905.8026.70-14.4041.5032.1054.0029.84 Note 1. All readings are peak values Note 2. Emission Leave = Antenna Factor + Cable Loss + Meter Reading β Preamp Factor + Correction Factor Note 3. Correction factor is calculated by averaging the sum of the pluse widths over one complete pluse train. Correction Factor = 20lg (2/10.5) = -14.40 (dB) TEST ENGINEER:_________________ (STEVEN LEE)
