F92SW350Wall Control

5 5 4 4 3 3 2 2 1 1 DD CC BB AA Antenna (1) Address is embedded into U1 EPROM (1) Key Select PB1 Lights PB2 Select PB3 INC PB4 DEC PB5 FAN PB6 FLOW PB7 SLEEP PB8 SECURITY Key Assignments PB9 Learn BLACK BLACK -- Emerson SW-350 Wall Switch Mission Microsystems, Inc 5942 Edinger Ave. Suite 113 Huntington Beach, CA 92649 714-841-1986 FAX: 841-1036 email: [email protected] B 11Wednesday, May 16, 2001 Title SizeDocument NumberRev Date:Sheetof R5 10K C2 30pF C1 30pF Q1 MPSH-10 R10 100 OHM PB5 C10 1000pF PB6 C112 pF NPO PB8 C12 6 pf NPO PB7 R3 10K R8 47 OHM R2 470 OHM U1 Z86E04 5 14 7 6 11 12 13 4 3 2 1 18 17 16 15 10 9 8 Vcc Gnd Xtal1 Xtal2 P00 P01 P02 P27 P26 P25 P24 P23 P22 P21 P20 P33 P32 P31 SW1 POWER SW Y2 417.5 MHZ SAW F1 250v 6 A LD1RED LD2 GRN D1 P6000 D4 1N4148 C5 0.01 AC1 1 LD6 R9 300K PB1 LD5 PB2 AC2 1 LD4 PB4D51N4148 C4 0.01 LD3 PB3 D6 1N4148 D7 1N4148 R1 470 OHM C9 0.01 R4 10K PB9 Learn Y1 4.0 MHZ C9 1000pF BT151X SCR DZ1 BV2 R6 100 ohm D6 1N4004 + C6 470uF/16v R7 220 OHM DZ2 5v1 +C7 220uF/10V C8 0.01

FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 16 FCC PART 15, SUBPART C TEST METHOD: ANSI C63.4-1992 for FAN CONTROLLER MODEL: SW350 Prepared for EMERSON ELECTRIC COMPANY 8400 PERSHALL ROAD HAZELWOOD, MISSOURI 63042 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JUNE 5, 2000 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 13 23 2 58 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. Description of Test Configuration 8 4.1 Description of Test Configuration - EMI 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. Test Procedures 13 7.1 Conducted Emissions Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.3 Bandwidth of the Fundamental 15 8. CONCLUSIONS 16 FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Modifications to the EUT B Additional Models Covered Under This Report C Diagrams, Charts and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors D Data Sheets E Laboratory Recognitions LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: Fan Controller Model: SW350 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Customer: Emerson Electric Company 8400 Pershall Road Hazlewood, Missouri 63042 Test Date: May 24, 2001 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart C, Sections 15.205, 15.207, 15.209, and 15.231 Test Procedure: ANSI C63.4: 1992 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 450 kHz - 30 MHz Complies with the CFR Title 47, Part 15 Subpart C, section 15.207 using the limits of section 15.207 (b) 2 Radiated RF Emissions, 10 kHz - 4500 MHz Complies with the CFR Title 47, Part 15 Subpart C, sections 15.205, 15.209, and 15.231 FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Fan Controller Model: SW350. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by CFR Title 47, Part 15, Subpart C, sections 15.205, 15.207, 15.209, and 15.231. FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 16 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST) . 2.3 Cognizant Personnel Emerson Electric Company Craig Johnson Engineer Compatible Electronics Inc. Kyle Fujimoto Test Engineer Michael Christensen Test Engineer 2.4 Date Test Sample was Received The test sample was received on May 24, 2001. 2.5 Disposition of the Test Sample The test sample was returned to Emerson Electric Company on May 25, 2001. 2.6 Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. RF Radio Frequency EMI Electromagnetic Interference EUT Equipment Under Test P/N Part Number S/N Serial Number HP Hewlett Packard ITE Information Technology Equipment CML Corrected Meter Limit LISN Line Impedance Stabilization Network CFR Code of Federal Regulations FCC ID: F92SW350 Report Number: B10524D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 7 of 16 3. APPLICABLE DOCUMENTS The following documents are referenced or used in the preparation of this EMI Test Report. SPEC TITLE CFR Title 47, Subpart…
