FCC ID: FGOWS-T4W RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the followi ng table shall be used to evaluat e the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission form ula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. mW = 10^( dBm/10) 11.2 Measurement Result WIFI Channel Freq. (MHz) modulation conducted power (mW) conducted power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2412 802.11b 40.27 16.05 16.5±1 17.5 1.58 0.2033 1 2437 802.11b 44.36 16.47 16.5±1 17.5 1.58 0.2239 1 2462 802.11b 51.05 17.08 16.5±1 17.5 1.58 0.2577 1 2412 802.11g 38.02 15.8 16.0±1 17 1.58 0.1919 1 2437 802.11g 40.27 16.05 16.0±1 17 1.58 0.2033 1 2462 802.11g 38.19 15.82 16.0±1 17 1.58 0.1928 1 2412 802.11n H20 40.55 16.08 16.0±1 17 1.58 0.2047 1 2437 802.11n H20 41.59 16.19 16.0±1 17 1.58 0.2099 1 2462 802.11n H20 38.90 15.9 16.0±1 17 1.58 0.1964 1 2422 802.11n H40 44.06 16.44 16.0±1 17 1.58 0.2224 1 2437 802.11n H40 41.88 16.22 16.0±1 17 1.58 0.2114 1 2452 802.11n H40 44.87 16.52 16.0±1 17 1.58 0.2265 1

TRF No.: FCC 15.247/A Page 1 of 60 Report No.: ES141126212E Ver.1.0 FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For Wireless digital scanner MODEL No.: WS-T4W, JET-DBG011-WIFI, JET-DBG011-WIFI-H, WS-T4, WS-T4-H, WS-T4W-H, WS-T3, WS-T3-H, WS-T3W, WS-T3W-H FCC ID: FGOWS-T4W Trade Mark: , REPORT NO.: ES141126212E ISSUE DATE: February 8, 2015 Prepared for JETION INTERNATIONAL LIMITED Room 501, No.894, North TianHe Road, GuangZhou510630, China. Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC 15.247/A Page 2 of 60 Report No.: ES141126212E Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................... 4 3 SUMMARY OF TEST RESULT ................................................................................................................ 5 4 TEST METHODOLOGY ........................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED ............................................................................................. 6 4.3 DESCRIPTION OF TEST MODES .................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS ..................................................................................................... 8 5.1 FACILITIES ....................................................................................................................................... 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................ 8 6 TEST SYSTEM UNCERTAINTY .............................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 7.1 RADIO FREQUENCY TEST SETUP 1 ............................................................................................ 10 7.2 RADIO FREQUENCY TEST SETUP 2 ............................................................................................ 10 7.3 CONDUCTED EMISSION TEST SETUP ........................................................................................ 11 7.4 SUPPORT EQUIPMENT ................................................................................................................. 11 8 TEST REQUIREMENTS ......................................................................................................................... 12 8.1 DTS (6DB) BANDWIDTH ................................................................................................................ 12 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ...................................................................... 19 8.3 MAXIMUM POWER SPECTRAL DENSITY .................................................................................... 20 8.4 UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS ............................... 27 8.5 RADIATED SPURIOUS EMISSION ................................................................................................ 32 8.6 CONDUCTED EMISSION TEST ..................................................................................................... 57 8.7 ANTENNA APPLICATION ............................................................................................................... 60 procedures given in ANSI C63.4 (2014) and the energy emitted by the sample EUT tested as described in TRF No.: FCC 15.247/A Page 3 of 60 Report No.: ES141126212E Ver.1.0 1 TEST RESULT CERTIFICATION Applicant: JETION INTERNATIONAL LIMITED Manufacturer: JETION INTERNATIONAL LIMITED EUT Description: Wireless digital scanner Model Number: WS-T4W, JET-DBG011-WIFI, JET-DBG011-WIFI-H, WS-T4, WS-T4-H, WS-T4W-H, WS-T3, WS-T3-H, WS-T3W, WS-T3W-H (Note: all the model numbers are identical in circuitry and electrical, mechanical and physical construction, PCB layout, External dimension; the only differences are the model no., and the colour of appearance. for trading purpose. We take WS-T4W to test.) File Number: ES141126212E Date of Test: November 27, 2014 to February 8, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test : December 15, 2014 to December 27, 2014 Prepared by : Jack Li /Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.: FCC 15.247/A Page 4 of 60 Report No.: ES141126212E Ver.1.0 2 EUT TECHNICAL DESCRIPTION Characteristics Description IEEE 802.11 WLAN Mode Supported: 802.11b(20MHz channel bandwidth) 802.11g(20MHz channel bandwidth) 802.11n(20MHz channel bandwidth) 802.11n(40MHz channel bandwidth) Data Rate: 802.11 b:1,2,5.5,11Mbps; 802.11 g:6,9,12,18,24,36,48,54Mbps; 802.11n(HT20):MCS0-MCS7; 802.11n(HT40):MCS0-MCS7; Modulation: DSSS with DBPSK/DQPSK/CCK for 802.11b; OFDM with BPSK/QPSK/16QAM/64QAM for 802.11g/n; Operating Frequency Range: 2412-2462MHz for 802.11b/g; 2412-2462MHz for 802.11n(HT20); 2422-2452MHz for 802.11n(HT40); Number of Channels: 11 channels for 802.11b/g; 11 channels for 802.11n(HT2…
