FHO-J1936Decoration lamp with LED

IKEA of Sweden AB

Click to zoom

Application Details

Equipment Class: JAB - Part 15 Class B Digital Device
Date of Grant: Feb 17, 2020
Application Purpose: Original Equipment
Date of Application: Feb 17, 2020
Equipment Note: Decoration lamp with LED
Company: IKEA of Sweden AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

STRÅLA ENGLISH J1936 IMPORTANT SAFETY INSTRUCTIONS For indoor use only. Regularly check the cord, the transfor- mer and all other parts for damage. If any part is damaged the product should not be used. Important information! Keep these instructions for future use. CAUTION! The light source of this product is non-changeable light diodes (LED). Do not disassemble the product, as the light diodes can cause damage to the eyes. Do not immerse in water. Cleaning Use a damp cloth, never a strong cleaning agent. ENGLISH WARNING Deviation from the assembly instruc- tions may result in a risk of fire or electric shock. ENGLISH IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor applica- tions, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a qua- lified electrician for proper installation. This seasonal use product is not intended for permanent installation or use. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails. Do not let lamps rest on the supply cord or on any wire. Unplug the product when leaving the house, when retiring for the night, or if left unattended. This is an electric product - not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with or placed where small children can reach it. Do not use this product for other than its intended use. Do not hang ornaments or other objects from cord, wire, or light string. Do not close doors or windows on the product or extension cords as this may damage the wire insulation. Do not cover the product with cloth, paper or any material not part of the product when in use. Read and follow all instructions that are on the product or provided with the product. ENGLISH USE AND CARE INSTRUCTIONS When the product is placed on a live tree, the tree should be well maintai- ned and fresh. Do not place on live trees in which the needles are brown or break off easily. Keep the tree holder filled with water. If the product is placed on a tree, the tree should be well secured and stable. Before using or reusing, inspect product carefully. Discard any prod- ucts that have cut, damaged, or frayed wire insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire. When storing the product, carefully remove the product from wherever it is placed, including trees, branches, or bushes, to avoid any undue strain or stress on the product conductors, connections, and wires. When not in use, store neatly in a cool, dry location protected from sunlight. ENGLISH This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interfe- rence received, including interference that may cause undesired operation. WARNING Changes or modifications not express- ly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable pro- tection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accor- dance with the instructions, may cause harmful interference to radio commu- nications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. SAVE THESE INSTRUCTIONS FRANÇAIS J1936 CONSIGNES DE SÉCURITÉ IMPORTANTES Uniquement pour une utilisation en intérieur. Vérifier régulièrement que le câble, le transformateur et les autres parties ne sont pas endommagés. Si l’une de ces pièces est endommagée, ne pas utiliser le produit. Information importante. Conserver la notice pour tout utilisation ultérieure. MISE EN GARDE La source lumineuse du produit est composée de diodes (LED) qui ne se remplacent pas. Ne jamais démonter le produit, les diodes peuvent causer des blessures aux yeux. Ne jamais immerger dans de l’eau. Entretien Nettoyer à l’aide d’un chiffon humide, éviter les détergents puissants. FRANÇAIS ATTENTION Tout écart par rapport aux instructions d’assemblage peut entraîner un risque d’incendie ou de choc électri- que. FRANÇAIS CONSIGNES DE SÉCURITÉ IMPORTANTES Lors de l’utilisation de produits électriques, toujours respecter les consignes de sécurité, notamment les suivantes: LIRE ET RESPECTER TOUTES LES CONSIGNES DE SECURITE Ne pas utiliser les articles saisonniers à l’extérieur s’il n’est pas précisé qu’ils peuvent être utilisés à l’intérieur et à l’extérieur. Pour une utilisation à l’extérieur, le produit doit être branché à une protection de fuite à la terre. Si ce type de protection n’existe pas, faites appel à un électricien pour l’installer. Ce produit saisonnier n’est pas destiné à une installation fixe ou à une utilisation permanente. Ne doit pas être monté ou placé à proximité d’un radiateur à gaz ou électrique, d’une cheminé…

Text truncated - open the document above for the full version.

Cover Letter(s)

© Inter IKEA Systems B.V. 2014 Jan 15th, 2020 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-J1936 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Swedens to act as our Agent for the purpose of preparing application for FCC ID number FHO-J1936 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is Jan 15th 2020. The Limited Agency Agreement expires on July 15th, 2020, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This i s to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

Cover Letter(s)

© Inter IKEA Systems B.V. 2014 March 05, 2019 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-J1936 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

External Photos

1 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 2 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 3 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 4 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 5 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 6 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 7 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 8 (9) 1914304STO-001 (J1936 Stråla) 1914304STO-001 (J1936 Stråla) 9 (9) 1914304STO-001 (J1936 Stråla) Label location

ID Label/Location Info

Label location

Internal Photos

Test Report

Test report No. 1915151STO-001, Ed. 1 Page 2 (4) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.00 Revision History Edition Date Description Changes 1 2019-10-10 First release Test report No. 1915151STO-001, Ed. 1 Page 3 (4) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.00 Reference type/model Test report no. 1817142STO-001, Ed. 2 Test performed by: Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista Sweden Standards: FCC 47 CFR Part 15: 2015, Subpart B ICES-005 Issue 4: Lightning Equipment, Class B ICES-005 Issue 5: Lightning Equipment, Class B Equipment: Decoration lamp with LED Type / model: J1829 Stråla Brand name: IKEA Manufacturer: IKEA of Sweden AB Box 702 SE-343 81 Älmhult Sweden Rating 4 V DC, 2.2 W Class III Highest clock frequency: < 108 MHz Transmitting frequency: - Opinions and interpretation This test report covers alternative types, presumed to have the same EMC-characteristics as the above tested reference type. According to the manufacturer, the alternative type is identical to the tested type except for the following difference:  Changed LED:s.  The resistances R1 and R2 are changed from 4.7 Ω to 4.3 Ω.  Santa claus lamp shade. The differences are considered not to imply different EMC-characteristics when compared to the tested type. Therefore, this type is not tested, but considered to have the same EMC-characteristics as the tested type. Test report No. 1915151STO-001, Ed. 1 Page 4 (4) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.00 Rating plate J1936 Stråla Test set up and EUT photos Test set up and EUT photos are enclosed in Annex 1 to this test report.

Test Report

Report No. 2010264STO-101 Page 2 (14) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.02 Revision History Report No Date Description Changes 1817142STO-001, Ed. 1 2018-12-13 First release 1817142STO-001, Ed. 2 2019-08-23 Second release The report was updated according to order number 1914417. Standard issue ICES-005 Issue 5 is added as there are no differences compared to ICES-005 Issue 4 that affect the tests performed. Clause 2.4 Opinions and interpretations added. 2010264STO-101 2020-02-04 Third release Pictures of EUT moved to Annex 2010264STO-102 Report No. 2010264STO-101 Page 3 (14) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.02 CONTENTS Page 1. Client Information ............................................................................................................... 4 2. Equipment under test (EUT) ............................................................................................... 4 2.1 Identification of the EUT ........................................................................................... 4 2.2 Test set up and EUT photos .................................................................................... 4 2.3 Additional information about the EUT ...................................................................... 5 2.4 Opinions and interpretations .................................................................................... 5 3. Test Specifications ............................................................................................................. 6 3.1 Standards ................................................................................................................. 6 3.2 Additions, deviations and exclusions from standards and accreditation ................. 6 3.3 Test site .................................................................................................................... 6 3.4 Mode of operation during the test ............................................................................ 6 3.5 Compliance .............................................................................................................. 7 4. Test Summary .................................................................................................................... 8 5. Conducted continuous disturbances .................................................................................. 9 5.1 Operating environment ............................................................................................. 9 5.2 Test setup and test procedure ................................................................................. 9 5.3 Measurement uncertainty ......................................................................................... 9 5.4 Test results, AC Power input port, Class B ............................................................ 10 5.5 Test equipment ...................................................................................................... 11 6. Radiated rf Emission in the frequency-range 30 MHz – 1 GHz ....................................... 12 6.1 Operating environment ........................................................................................... 12 6.2 Test setup and test procedure ............................................................................... 12 6.3 Test conditions ....................................................................................................... 12 6.4 Measurement uncertainty ....................................................................................... 12 6.5 Test results, 30 – 1000 MHz, FCC, Class B .......................................................... 13 6.6 Test equipment ...................................................................................................... 14 Report No. 2010264STO-101 Page 4 (14) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.02 1. CLIENT INFORMATION The EUT has been tested by request of Company IKEA of Sweden AB Box 702 343 81 Älmhult SVERIGE Name of contact Jianqiu Chen 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT Equipment Decoration lamp with LED Type/Model J1829 Stråla Brand name IKEA Serial Number - Manufacturer IKEA of Sweden AB Rating 4 V DC, 2.2 W Class III Highest clock frequency - Software version - Rating plate 2.2 Test set up and EUT photos Test set up and EUT photos are enclosed in Annex 1 to this test report. Report No. 2010264STO-101 Page 5 (14) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.02 2.3 Additional information about the EUT The EUT was tested in a tabletop standing configuration. 2.4 Opinions and interpretations The change of standard from ICES-005 Issue 4 to ICES-005 Issue 5 does not affect the measurements performed in this report. The tests performed according to ICES-005 Issue 4 fulfils the requirements of ICES-005 Issue 5. Report No. 2010264STO-101 Page 6 (14) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.02 3. TEST SPECIFICATIONS 3.1 Standards Requirements: FCC 47 CFR Part 15: Radio frequency device, Subpart B: Unintentional radiators. ICES-005 Issue 4: Lighting Equipment. ICES-005 Issue 5: Lighting Equipment. Test methods: ANSI C63.4: 2014: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 3.2 Additions, deviations and exclusions from standards and accreditation No additions, deviations or exclusions have been made from standards and accreditation. 3.3 Test site Measurements were performed at: Intertek Semko AB. Torshamnsgatan 43, P.O. Box 1103 SE-164 22 Kista Intertek Semko AB is a FCC listed test site with site registration number 90913 Intertek Semko AB is a FCC accredited conform…

Text truncated - open the document above for the full version.

Test Setup Photos

Report no. 2010264STO-102 Page 1 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se ANNEX 1 Photos of EUT EUT Report no. 2010264STO-102 Page 2 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Photos of test setup Test setup for conducted emission 150 kHz – 30 MHz Test set up radiated emission 30 MHz – 1 GHz
