FHO-J2020Decoration lamp with LED

1 STRÅLA 2AA-2258895-2 English J2020 IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation. This seasonal use product is not intended for permanent installation or use. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails. Do not let lamps rest on the supply cord or on any wire. Unplug the product when leaving the house, when retiring for the night, or if left unattended. This is an electric product - not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with or placed where small children can reach it. Do not use this product for other than its intended use. Do not hang ornaments or other objects from cord, wire, or light string. Do not close doors or windows on the product or extension cords as this may damage the wire insulation. Do not cover the product with cloth, paper or any material not part of the product when in use. Read and follow all instructions that are on the product or provided with the product. 3 English USE AND CARE INSTRUCTIONS Before using or reusing, inspect product carefully. Discard any products that have cut, damaged, or frayed wire insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire. When storing the product, carefully remove the product from wherever it is placed, including trees, branches, or bushes, to avoid any undue strain or stress on the product conductors, connections, and wires. When not in use, store neatly in a cool, dry location protected from sunlight. English This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. 4AA-2258895-2 English CAUTION Risk of fire. How to replace the lamp: Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord. Unscrew lamp counter clock-wise. CAUTION Risk of fire. This product does not contain lamp shunts in order to allow the product to operate if one lamp burns out. Do not replace lamps with other than the spare lamps provided with this product. English WARNING Deviation from the assembly instructions may result in a risk of fire or electric shock. SAVE THESE INSTRUCTIONS 5 Français J2020 CONSIGNES DE SÉCURITÉ IMPORTANTES Lors de l’utilisation de produits électriques, toujours respecter les consignes de sécurité, notamment les suivantes: LIRE ET RESPECTER TOUTES LES CONSIGNES DE SECURITE Ne pas utiliser les articles saisonniers à l’extérieur s’il n’est pas précisé qu’ils peuvent être utilisés à l’intérieur et à l’extérieur. Pour une utilisation à l’extérieur, le produit doit être branché à une protection de fuite à la terre. Si ce type d’équipement n’est pas inclus, contacter un électricien pour qu’il approuve l’installation. Ce produit saisonnier n’est pas destiné à une installation fixe ou à une utilisation permanente. Ne doit pas être monté ou placé à proximité d’un radiateur à gaz ou électrique, d’une cheminée, d’une bougie ou autre source de chaleur similaire. Ne pas fixer les fils électriques avec des agrafes ou des clous. Les ampoules ne doivent pas reposer contre un câble d’alimentation ou autre câble. Débrancher le produit lorsque vous quittez le domicile, lorsque vous allez vous coucher ou laissez le produit est sans surveillance. Ceci est un produit électrique, pas un jouet. Pour réduire le risque d’incendie, ne pas laisser un enfant jouer avec le produit et placez-le hors de la portée des enfants. Utiliser ce produit uniquement pour ce à quoi il est destiné. Ne pas suspendre des objets, décoratifs ou autres, sur le fil, le câble ou la guirlande. Ne pas coincer le produit ou des rallonges dans des portes ou fenêtres pour éviter d’endommager l’isolation du câble. Ne pas recouvrir le produit de tissu, de papier ou autre matériau ne faisant pas partie du produit. Lire attentivement et suivre toutes les instructions apposées sur le produit ou fournies avec celui-ci. 6AA-2258895-2 Français NOTICE D’UTILISATION ET D’ENTRETIEN Vérifier soigneusement le produit avant la première utilisation ou avant de le réutil…

Text truncated - open the document above for the full version.

© Inter IKEA Systems B.V. 2014 Dec 10, 2020 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-J2020 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Swedens to act as our Agent for the purpose of preparing application for FCC ID number FHO-J2020 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is Dec 10th 2020. The Limited Agency Agreement expires on May 10th, 2020, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This i s to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

© Inter IKEA Systems B.V. 2014 March 05, 2019 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-J2020 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

J2020 STRÅLA LED 5-arm cndlbr black External & Internal photos: Driver (KMV-040-030-NA-3) details :

J2020 STRÅLA LED 5-arm cndlbr black External & Internal photos: Driver (KMV-040-030-NA-3) details :

Test report No. 2024497STO-104 Page 2 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 Revision History Test report no. Release no. Date of issue Description 2024497STO-104 1 December 22, 2020 Test report No. 2024497STO-104 Page 3 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 Terms, definition and abbreviations The following terms, definitions and abbreviations may be used throughout the report. Term/definition/abbreviation Meaning AAN Asymmetrical Artificial Network AC Alternating Current AE Associated Equipment AM Amplitude Modulation AMN Artificial Mains Network AV Average BW Bandwidth CAV CISPR Average CDN Coupling/Decoupling Network CM Common Mode CMAD Common Mode Absorption Device DC Direct Current DM Differential Mode EM Electromagnetic EMC Electromagnetic Compatibility ESD Electrostatic Discharge EUT Equipment Under Test F Fail FM Frequency Modulation FAR Fully Anechoic Room Highest fundamental frequency generated or used within the EUT, or highest frequency at which it operates H Horizontal HCP Horizontal Coupling Plane I ref Reference Current ISN Impedance Stabilizing Network MU Measurement Uncertainty N/A Not Applicable P Pass PE Protective Earth PK Peak Pol. Polarisation PWHC Partial Weighted Harmonic Current QP / QPK Quasi-Peak RF Radio Frequency RGP Reference Ground Plane RH Relative Humidity RMS Root Mean Square Rx Receiver / Receiving SAC Semi-Anechoic Chamber THC Total Harmonic Current Tx Transmitter / Transmitting V Vertical VCP Vertical Coupling Plane Test report No. 2024497STO-104 Page 4 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 CONTENTS Page 1. Client Information ............................................................................................................... 5 2. Equipment under test (EUT) ............................................................................................... 5 2.1 Identification of the EUT ........................................................................................... 5 2.2 Additional information about the EUT ...................................................................... 7 3. Test Specifications ............................................................................................................. 8 3.1 Additions, deviations and exclusions from standards and accreditation ................. 8 3.2 Test site .................................................................................................................... 8 3.3 Mode of operation during the test ............................................................................ 8 4. Test Summary .................................................................................................................... 9 5. Conducted continuous disturbances ................................................................................ 10 5.1 Test results, AC Power input port, Class B, Mode1 ............................................... 11 5.2 Test results, AC Power input port, Class B, Mode1 ............................................... 12 5.3 Test equipment ...................................................................................................... 13 6. Radiated rf Emission in the frequency-range 30 MHz – 1 GHz ....................................... 14 6.1 Test results, 30 – 1000 MHz, Class B, Mode 1...................................................... 16 6.2 Test results, 30 – 1000 MHz, Class B, Mode 2...................................................... 17 6.3 Test equipment ...................................................................................................... 18 Test report No. 2024497STO-104 Page 5 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 1. CLIENT INFORMATION The EUT has been tested by request of Company IKEA of Sweden AB Name of contact Jianqiu Chen Client observer - 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT Equipment: Decoration lamp with LED Type/Model: J2020 Stråla Brand name: IKEA S/N: - Manufacturer: IKEA of Sweden AB Box 702 SE-343 81 Älmhult Sweden Installation class: ☐ I ☐ II ☒ III ☐ N/A Highest clock frequency, : <108 MHz Transmitting freq.: - Software version: - Hardware version: - Mounting position: (during normal use) ☒ Table-top ☐ Floor-standing ☐ Wall/ceiling ☐ Hand-held ☐ Other: Input ratings Voltage [V] Freq. [Hz] Current [A] Power [W] Coupling ☒ AC* 100-120 50/60 0.09 L1 L2 L3 N PE ☒ ☐ ☐ ☒ ☐ ☒ DC 4 0,2 V+ V- PE ☒ ☒ ☐ ☐ Battery V+ V- PE ☐ ☐ ☐ ☐ Other: Supplementary information: * Auxiliary LED-driver Test report No. 2024497STO-104 Page 6 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 Photo/copy of marking/rating plate(s) Test report No. 2024497STO-104 Page 7 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 2.2 Additional information about the EUT The EUT consists of the following units: Unit Type Description Decoration lamp with LED J2020 Stråla - LED driver KMV-040-030-NA-3 Auxiliary equipment, needed for correct operation, but not EUT. The EUT has the following ports: Port type Port name Shielded AC I/O ☒ AC power input ☐ ☐ AC power output ☐ DC I/O ☒ DC power input ☐ ☐ DC power output ☐ Signal/control I/O ☐ Telecom/network ☐ ☐ Signal/control ☐ Supplementary information: The EUT ports were connected according to the following: Port name Cable type Connected to AC Plug-in LED driver DC Two-core Lamp Test report No. 2024497STO-104 Page 8 (18) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 3.02 3. TEST SPECIFICATIONS 3.1 Additions, deviations and exclusions from standards and accreditation No additions, deviations or exclusions have been made from standards and accreditation…

Text truncated - open the document above for the full version.

Test report no. 2024497STO-104 Annex 1 Page 1 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se ANNEX 1 Photos of EUT EUT Test report no. 2024497STO-104 Annex 1 Page 2 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Photos of test setup Test setup for conducted emission 150 kHz – 30 MHz Test set up radiated emission 30 MHz – 1 GHz
