1 STRÅLA 2AA-2257264-1 English J2024 IMPORTANT SAFETY INSTRUCTIONS For indoor use only. This product is not intended for children due to the content of electrical components. IKEA recommends that only adults should handle the recharging. Regularly examine for damage of cord, plug, enclosure and other parts. In the event of such damage, the product must not be used with the charger. Only to be supplied at SELV. Important information! Save this instruction! Technical specification: Inside battery Ni-MH rechargeable, 2x1.2V, 1000mAh, AA. DO NOT USE NON-RECHARGEABLE BATTERIES. Cleaning Use a damp cloth, avoid strong detergents. English CAUTION This is an electric product - not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with or placed where small children can reach it. Do not use this product for other than its intended use. Do not hang ornaments or other objects from cord, wire, or light string. Do not close doors or windows on the product or extension cords as this may damage the wire insulation. Do not cover the product with cloth, paper or any material not part of the product when in use. Read and follow all instructions that are on the product or provided with the product. 3 English This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. SAVE THESE INSTRUCTIONS 4AA-2257264-1 Français J2024 CONSIGNES DE SÉCURITÉ IMPORTANTES Pour une utilisation en intérieur uniquement. Ce produit ne convient pas aux enfants car il contient des composants électriques. IKEA recommande que seul un adulte procède au chargement. Vérifier régulièrement l'état du câble, de la prise et du boîtier et des autres parties du produit. Si une partie est endommagée, ne pas utiliser le produit avec le chargeur. Utiliser uniquement en très basse tension de sécurité (TBTS). Informations importantes à conserver ! Caractéristiques techniques: batterie Ni-MH rechargeable incluse, 2x1,2V, 1000mAh, AA. NE PAS UTILISER DE BATTERIES NON RECHARGEABLES. Entretien Utiliser un chiffon humide, éviter les détergents puissants. Français ATTENTION Ceci est un produit électrique, pas un jouet. Pour réduire le risque d'incendie, de blessure ou de décharge électrique, ne pas laisser un enfant jouer avec le produit. Le placer hors de portée des enfants. Utiliser ce produit uniquement pour ce à quoi il est destiné. Ne pas suspendre d'objets ou de décorations sur le fil, le câble ou la guirlande. Ne pas coincer le produit ou des rallonges dans des portes ou fenêtres pour éviter d'endommager l'isolation du câble. Ne pas recouvrir le produit de tissu, de papier ou autre matériau ne faisant pas partie du produit. Lire attentivement et suivre toutes les instructions apposées sur le produit ou fournies avec celui-ci. 5 Français Cet appareil est conforme à la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes: 1. Cet appareil ne doit pas provoquer de brouillage préjudiciable et 2. il doit accepter tout brouillage reçu, y compris le brouillage pouvant entraîner un mauvais fonctionnement. ATTENTION: Tout changement apporté à cet appareil non expressément approuvé par la partie responsable de la conformité est susceptible d'annuler le droit de l'utilisateur à se servir de cet équipement. Note: Cet équipement a été testé et déclaré conforme aux limites imposées aux appareils numériques de la classe B, en vertu de la partie 15 des règles de la FCC. Ces limites sont conçues pour assurer une protection suffisante contre les interférences nuisibles dans les installations résidentielles. Cet équipement génère, utilise et peut dégager de l'énergie de radiofréquence et, s'il n'est pas installé et utilisé conformément aux instructions du fabricant, provoquer un brouillage préjudiciable aux communications radio. Il n'existe toutefois aucune garantie qu'un équipement particulier ne sera pas victime de brouillage. Si cet équipement entraîne un brouillage préjudiciable à la réception des émissions radio ou de télévision, identifiable en mettant le terminal hors puis sous tension, il est recommandé à l'utilisateur de tenter de résoudre ce problème au moyen d'une ou plusieurs des mesures suivantes: - Orienter l'antenne réceptrice différemment ou la changer de place. - Augmenter la distance séparant l'équipement du récepteur. - Connecter l’appareil à une prise sur un circuit différent de celui auquel est branché le récepteur. - Obtenir de l'aide auprès du revendeur ou d'un technicien radio/TV expérimenté. CONSERVER CES MESURES DE SÉCURITÉ 6AA-2257264-1 Esp…

Text truncated - open the document above for the full version.

© Inter IKEA Systems B.V. 2014 JAN 10, 2021 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-J2024 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Swedens to act as our Agent for the purpose of preparing application for FCC ID number FHO-J2024 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is JAN 06 2021. The Limited Agency Agreement expires on JUNE 10 , 2021, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This i s to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

© Inter IKEA Systems B.V. 2014 March 05, 2019 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-J2024 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

J2024 STRÅLA LED tbl deco bear with gift External & Internal photos: Driver (YH-U-040-0120D) details : J2024 Stråla label position

Type No. J2024 Made in China 22217 Stråla TYP J2024 NA Version 1 Conforms to: UL Std 588 Certified to: CSA Std C22.2 No. 37 CAN CAN ICES-005 (B) / NMB-005 (B) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Sup. No. FCC ID: FHO-J2024 4VDC, Max. 1.5W 4002352 EP5014716

J2024 STRÅLA LED tbl deco bear with gift External & Internal photos: Driver (YH-U-040-0120D) details : J2024 Stråla label position

Test report No. 2024534STO-101 Page 2 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Revision History Test report no. Release no. Date of issue Description 2024534STO-101 1 December 17, 2020 Test report No. 2024534STO-101 Page 3 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Terms, definition and abbreviations The following terms, definitions and abbreviations may be used throughout the report. Term/definition/abbreviation Meaning AAN Asymmetrical Artificial Network AC Alternating Current AE Associated Equipment AM Amplitude Modulation AMN Artificial Mains Network AV Average BW Bandwidth CAV CISPR Average CDN Coupling/Decoupling Network CM Common Mode CMAD Common Mode Absorption Device DC Direct Current DM Differential Mode EM Electromagnetic EMC Electromagnetic Compatibility ESD Electrostatic Discharge EUT Equipment Under Test F Fail FM Frequency Modulation FAR Fully Anechoic Room 푭 푿 Highest fundamental frequency generated or used within the EUT, or highest frequency at which it operates H Horizontal HCP Horizontal Coupling Plane I ref Reference Current ISN Impedance Stabilizing Network MU Measurement Uncertainty N/A Not Applicable P Pass PE Protective Earth PK Peak Pol. Polarisation PWHC Partial Weighted Harmonic Current QP / QPK Quasi-Peak RF Radio Frequency RGP Reference Ground Plane RH Relative Humidity RMS Root Mean Square Rx Receiver / Receiving SAC Semi-Anechoic Chamber THC Total Harmonic Current Tx Transmitter / Transmitting V Vertical VCP Vertical Coupling Plane Test report No. 2024534STO-101 Page 4 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 CONTENTS Page 1. Client Information ............................................................................................................... 5 2. Equipment under test (EUT) ............................................................................................... 5 2.1 Identification of the EUT ........................................................................................... 5 2.2 Test set up and EUT photos .................................................................................... 6 2.3 Additional information about the EUT ...................................................................... 7 2.4 Peripheral equipment ............................................................................................... 7 3. Test Specifications ............................................................................................................. 8 3.1 Additions, deviations and exclusions from standards and accreditation ................. 8 3.2 Test site .................................................................................................................... 8 3.3 Mode of operation during the test ............................................................................ 8 4. Test Summary .................................................................................................................... 9 5. Conducted continuous disturbances ................................................................................ 10 5.1 Test results, AC Power input port, Class B, Operating mode 1 ............................. 11 5.2 Test equipment ...................................................................................................... 12 6. Radiated rf Emission in the frequency-range 30 MHz – 1 GHz ....................................... 13 6.1 Test results, 30 – 1000 MHz, FCC, Class B, Operating mode 1 ........................... 15 6.2 Test results, 30 – 1000 MHz, FCC, Class B, Operating mode 2 ........................... 16 6.3 Test equipment ...................................................................................................... 17 Test report No. 2024534STO-101 Page 5 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 1. CLIENT INFORMATION The EUT has been tested by request of Company IKEA of Sweden AB Name of contact Jianqiu Chen 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT Equipment: Decoration lamp with LED Type/Model: J2024 Stråla Brand name: IKEA S/N: - Manufacturer: IKEA of Sweden AB Box 702 343 81 Älmhult Sweden Installation class: ☐ I ☒ II (LED driver) ☒ III (Luminaire) ☐ N/A Highest clock frequency, 퐹 푋 : < 108 MHz Software version: - Hardware version: - Mounting position: (during normal use) ☒ Table-top ☐ Floor-standing ☐ Wall/ceiling ☐ Hand-held ☐ Other: Supplementary information: FCC ID: FHO-J2024 Input ratings Voltage [V] Freq. [Hz] Current [A] Power [W] Coupling ☒ AC (LED-driver) 100-120 50/60 L1 L2 L3 N PE ☒ ☐ ☐ ☒ ☐ ☐ DC V+ V- PE ☐ ☐ ☐ ☒ Battery (Luminaire) 4 1.5 V+ V- PE ☒ ☒ ☐ ☐ Other: Test report No. 2024534STO-101 Page 6 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Photo/copy of marking/rating plate(s) 2.2 Test set up and EUT photos Test set up and EUT photos are enclosed in Annex 1 No 2024534STO-102 to this test report. Test report No. 2024534STO-101 Page 7 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 2.3 Additional information about the EUT The EUT was supplied by two AA rechargeable batteries. The LED driver: YH-U-040-0120D was used to charge the batteries. The EUT was tested in a table-top configuration. 2.4 Peripheral equipment Peripheral equipment is equipment needed for correct operation of the EUT, but not included as part of the testing and evaluation of the EUT. Equipment Manufacturer Type/Model S/N LED-driver IKEA YH-U-040-0120D - Test report No. 2024534STO-101 Page 8 (17) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 3. TEST SPECIFICATIONS 3.1 Additions, deviations and exclusions from standards and accreditation No additions, devi…

Text truncated - open the document above for the full version.

Test report no. 2024534STO-102 Annex 1 Page 1 (3) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se ANNEX 1 Photos of EUT EUT Test report no. 2024534STO-102 Annex 1 Page 2 (3) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Photos of test setup Test setup for conducted emission 150 kHz – 30 MHz Test report no. 2024534STO-102 Annex 1 Page 3 (3) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Test set up radiated emission 30 MHz – 1 GHz, battery operated
