FHO-J2033Lighting chain for outdoor use with LED

STRÅLA English J2033 IMPORTANT SAFETY INSTRUCTIONS FOR INDOOR & OUTDOOR USE! Regularly check the cord, the transformer and all other parts for damage. If any part is damaged the product should not be used. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall be replaced. Important information! Keep these instructions for future use. CAUTION! The light source of this product is non-changeable light diodes (LED). ̈Do not disassemble the product, as the light diodes can cause damage to the eyes. Do not immerse in water English CAUTION! Strangulation hazard. Hang out of reach of young children. English IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation. This seasonal use product is not intended for permanent installation or use. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails. Do not let lamps rest on the supply cord or on any wire. Unplug the product when leaving the house, when retiring for the night, or if left unattended. This is an electric product - not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with or placed where small children can reach it. Do not use this product for other than its intended use. Do not hang ornaments or other objects from cord, wire, or light string. Do not close doors or windows on the product or extension cords as this may damage the wire insulation. Do not cover the product with cloth, paper or any material not part of the product when in use. Read and follow all instructions that are on the product or provided with the product. English USE AND CARE INSTRUCTIONS Before using or reusing, inspect product carefully. Discard any products that have cut, damaged, or frayed wire insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire. When storing the product, carefully remove the product from wherever it is placed, including trees, branches, or bushes, to avoid any undue strain or stress on the product conductors, connections, and wires. When not in use, store neatly in a cool, dry location protected from sunlight. English This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. English WARNING Deviation from the assembly instructions may result in a risk of fire or electric shock. SAVE THESE INSTRUCTIONS Français J2033 INSTRUCTIONS DE SECURITE IMPORTANTES POUR UNE UTILISATION À L’INTÉRIEUR ET À L’EXTÉRIEUR ! Vérifier régulièrement le câble, le transformateur et toutes les pièces pour vous assurer qu'ils ne sont pas endommagés. Ne pas utiliser le produit si une pièce est endommagée. La source lumineuse de ce luminaire n’est pas remplaçable ; lorsque la source lumineuse atteint sa fin de vie, le luminaire entier doit être remplacé. Information importante. A conserver pour pouvoir s'y reporter ultérieure- ment. ATTENTION! La source lumineuse de ce produit se compose de diodes électro- luminescentes non remplaçables (LED). Ne pas démonter le produit car les diodes électroluminescentes peuvent abîmer les yeux. Ne pas plonger dans l’eau. Français ATTENTION! Risque d'étranglement. Accrocher hors de portée des jeunes enfants. Français CONSIGNES DE SÉCURITÉ IMPORTANTES Lors de l'utilisation de produits électriques, toujours respecter les consignes de sécurité, notamment les suivantes: LIRE ET RESPECTER TOUTES LES CONSIGNES DE SECURITE Ne pas utiliser les articles saisonniers à l'extérieur s'il n'est pas précisé qu'ils peuvent être utilisés à l'intérieur et à l'extérieur. Pour une utilisation à l'extérieur, le produit doit être branché à une protection de fuite à la terre. Si ce type d'équipement n'est pas inclus, contacter un électricien pour qu'il approuve l'installation. Ce produit saisonnier n'est pas destiné à une installation fixe ou à une utilisation permanente. Ne doit pas être monté ou placé à proximité d'un radiateur à gaz ou électrique, d'une cheminée, d'une bougie ou autre source de chaleur similaire. Ne pas fixer les f…

Text truncated - open the document above for the full version.

© Inter IKEA Systems B.V. 2014 Dec 30, 2020 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-J2033 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Swedens to act as our Agent for the purpose of preparing application for FCC ID number FHO-J2033 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is Dec 30th 2020. The Limited Agency Agreement expires on May 30th, 2021, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This is to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

© Inter IKEA Systems B.V. 2014 March 05, 2019 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-J2033 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

J2033 STRALA STRÅLA LED lghtng chain 24 star flashing/outdoor gld-col External & Internal photos: Driver (ICPSL24-2-IL-1) details :

J2033 STRALA STRÅLA LED lghtng chain 24 star flashing/outdoor gld-col External & Internal photos: Driver (ICPSL24-2-IL-1) details :

Test report No. 2102813STO-101 Page 2 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Revision History Test report no. Release no. Date of issue Description 2026179STO-102 1 December 22, 2020 2102813STO-101 2 March 22, 2021 Update of test report 2026179STO-102 with editorial correction of the LED-driver type name, page 7 Test report No. 2102813STO-101 Page 3 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Terms, definition and abbreviations The following terms, definitions and abbreviations may be used throughout the report. Term/definition/abbreviation Meaning AAN Asymmetrical Artificial Network AC Alternating Current AE Associated Equipment AM Amplitude Modulation AMN Artificial Mains Network AV Average BW Bandwidth CAV CISPR Average CDN Coupling/Decoupling Network CM Common Mode CMAD Common Mode Absorption Device DC Direct Current DM Differential Mode EM Electromagnetic EMC Electromagnetic Compatibility ESD Electrostatic Discharge EUT Equipment Under Test F Fail FM Frequency Modulation FAR Fully Anechoic Room Highest fundamental frequency generated or used within the EUT, or highest frequency at which it operates H Horizontal HCP Horizontal Coupling Plane I ref Reference Current ISN Impedance Stabilizing Network MU Measurement Uncertainty N/A Not Applicable P Pass PE Protective Earth PK Peak Pol. Polarisation PWHC Partial Weighted Harmonic Current QP / QPK Quasi-Peak RF Radio Frequency RGP Reference Ground Plane RH Relative Humidity RMS Root Mean Square Rx Receiver / Receiving SAC Semi-Anechoic Chamber THC Total Harmonic Current Tx Transmitter / Transmitting V Vertical VCP Vertical Coupling Plane Test report No. 2102813STO-101 Page 4 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 CONTENTS Page 1. Client Information ............................................................................................................... 5 2. Equipment under test (EUT) ............................................................................................... 5 2.1 Identification of the EUT ........................................................................................... 5 2.2 Test set up and EUT photos .................................................................................... 6 2.3 Additional information about the EUT ...................................................................... 7 2.4 Peripheral equipment ............................................................................................... 7 3. Test Specifications ............................................................................................................. 8 3.1 Additions, deviations and exclusions from standards and accreditation ................. 8 3.2 Test site .................................................................................................................... 8 3.3 Mode of operation during the test ............................................................................ 8 4. Test Summary .................................................................................................................... 9 5. Conducted continuous disturbances ................................................................................ 10 5.1 Test results, AC Power input port, Class B ............................................................ 11 5.2 Test equipment ...................................................................................................... 12 6. Radiated rf Emission in the frequency-range 30 MHz – 1 GHz ....................................... 13 6.1 Test results, 30 – 1000 MHz, FCC, Class B .......................................................... 15 6.2 Test equipment ...................................................................................................... 16 Test report No. 2102813STO-101 Page 5 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 1. CLIENT INFORMATION The EUT has been tested by request of Company IKEA of Sweden AB Name of contact Jianqiu Chen 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT Equipment: Lighting chain for outdoor use with LED Type/Model: J2033 Stråla Brand name: IKEA S/N: - Manufacturer: IKEA of Sweden AB Box 702 343 81 Älmhult Sweden Installation class: ☐ I ☐ II ☒ III ☐ N/A Highest clock frequency, : < 108 MHz Software version: - Hardware version: - Mounting position: (during normal use) ☐ Table-top ☐ Floor-standing ☐ Wall/ceiling ☐ Hand-held ☒ Other: FCC ID: FHO-J2033 Input ratings Voltage [V] Freq. [Hz] Current [A] Power [W] Coupling ☒ AC 100 - 120 50/60 0.04 2 L1 L2 L3 N PE ☒ ☐ ☐ ☒ ☐ ☒ DC 24 1.5 V+ V- PE ☒ ☒ ☐ ☐ Battery V+ V- PE ☐ ☐ ☐ ☐ Other: Supplementary information: Auxiliary equipment, LED driver Test report No. 2102813STO-101 Page 6 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 Photo/copy of marking/rating plate(s) 2.2 Test set up and EUT photos Test set up and EUT photos are enclosed in Annex 1 No 2102813STO-102 to this test report. Test report No. 2102813STO-101 Page 7 (16) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Version 2.01 2.3 Additional information about the EUT The EUT is a lighting chain for outdoor use with LED, supplied by a LED-driver. The EUT can operate with fading-switching light. The EUT was tested in a table-top configuration The EUT has the following ports: Port type Port name Shielded AC I/O ☒ AC power input AC-mains (LED driver) ☐ ☐ AC power output ☐ DC I/O ☒ DC power input DC-cable ☐ ☐ DC power output ☐ Signal/control I/O ☐ Telecom/network ☐ ☐ Signal/control ☐ Supplementary information: The EUT ports were connected according to the following: Port name Cable type Connected to AC -mains L-N LED-driver DC-cable Two line Luminaire 2.4 P…

Text truncated - open the document above for the full version.

Test report no. 2102813STO-102 Annex 1 Page 1 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se ANNEX 1 Photos of EUT EUT Test report no. 2102813STO-102 Annex 1 Page 2 (2) Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden www.intertek.se Photos of test setup Test setup for conducted emission 150 kHz – 30 MHz Test set up radiated emission 30 MHz – 1 GHz
