FRWCVC-151VHF ATC Communication Transceiver

APPLICATION REVISIONS REV D NEXT ASSEMBLY FINAL ASSEMBLY REV DESCRIPTION DATE APPROVED APPROVED A Initial Release per DCN W3749 6-18-04 V Wallace J Markham SH 1 B Revised per DCN W3905 12-23-04 V Wallace J Markham C Revised per DCN W4435 4-30-04 V Wallace J Markham D Revised per DCN W4917 12-21-05 V Wallace Bob Evans DWG. NO. 150-047012 THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF WULFSBERG ELECTRONICS, A CHELTON GROUP COMPANY, NEITHER RECEIPT NOR POSSESSION THEREOF CONFERS ANY RIGHT TO REPRODUCE OR USE, OR DISCLOSE, IN WHOLE OR IN PART, ANY SUCH INFORMATION WITHOUT WRITTEN AUTHORIZATION FROM WULFSBERG ELECTRONICS APPROVALS DATE DRAWN C Gregory 6-18-04 CHECKED H Schnieder 6-18-04 PILOT'S GUIDE, AVIONICS SYSTEMS, FLITELINE ™ ENGINEER J Markham 6-18-04 ISSUED V Wallace 6-18-04 SIZE A CAGE CODE 1B7G3 DWG NO. 150-047012 REV D Typed signatures indicate approval. Handwritten signature approval of this document is on file at Wulfsberg Electronics, Prescott, Arizona. SCALE: NONE DO NOT SCALE DRAWING This page intentionally left blank. FLITELINE AVIONICS SYSTEM PILOT’S GUIDE Page 2 Publication No. 150-047012 Dec 2005 Rev. D Table of Contents INTRODUCTION .................................................................................................................................................... 4 FLITELINE VHF COMMUNICATION SYSTEM (FLITECOMM)............................................................................ 5 GENERAL DESCRIPTION CVC-151.......................................................................................................................... 5 GENERAL DESCRIPTION CVC-152.......................................................................................................................... 5 CVC-152 DISPLAY (SERIES III AND FLITELINE INTERFACE – FAILURE INDICATION) .................................................. 12 OPERATING THE CVC-152 ................................................................................................................................... 13 VHF COM SYSTEM BLOCK DIAGRAM (TYPICAL).................................................................................................... 16 FLITELINE VHF NAVIGATION SYSTEM (FLITENAV AND FLITEDME) .......................................................... 17 GENERAL DESCRIPTION CVN-251........................................................................................................................17 GENERAL DESCRIPTION CDM-451 ....................................................................................................................... 17 GENERAL DESCRIPTION CVN-252........................................................................................................................18 LIMITATIONS........................................................................................................................................................ 18 CVN-252 CONTROLS (SERIES III AND FLITELINE INTERFACE) ................................................................................ 20 CVN-252 CONTROLS (SERIES III AND FLITELINE INTERFACE - FAILURE INDICATION) ............................................... 24 CVN-252 CONTROLS (SERIES III AND FLITELINE INTERFACE - DME HOLD OPERATION) ......................................... 25 CVN-252 CONTROLS (ARINC 410 INTERFACE) .................................................................................................... 26 CVN-252 CONTROLS (ARINC 410 INTERFACE - DME HOLD OPERATION) ............................................................. 27 OPERATING THE CVN-252 ................................................................................................................................... 28 GENERAL DESCRIPTION SD-442 ..........................................................................................................................30 VHF NAV SYSTEM BLOCK DIAGRAM (TYPICAL)..................................................................................................... 33 FLITELINE AUTOMATIC DIRECTION FINDER (ADF) ......................................................................................34 GENERAL DESCRIPTION....................................................................................................................................... 34 CDF-552 CONTROLS (SERIES III AND FLITELINE INTERFACE) ................................................................................ 36 CDF-552 CONTROLS (SERIES III AND FLITELINE INTERFACE – FAILURE INDICATION) .............................................. 42 CDF-552 CONTROLS (BCD INTERFACE)............................................................................................................... 43 OPERATING THE CDF-552 ................................................................................................................................... 45 ADF SYSTEM BLOCK DIAGRAM (TYPICAL) ............................................................................................................. 47 FLITELINE DUAL VHF COM AND VHF NAV CONTROL DISPLAY SYSTEM ................................................. 48 GENERAL DESCRIPTION....................................................................................................................................... 48 LIMITATIONS........................................................................................................................................................ 48 CCN-955 CONTROLS.......................................................................................................................................... 49 CCN-955 CONTROLS.......................................................................................................................................... 50 OPERATING THE CCN-955 ................................................................................................................................... 51 FLITELINE AVIONICS SYSTEM PILOT’S GUIDE Publication No. 150-047012 Pag…

Text truncated - open the document above for the full version.

Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680041 Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 3 Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 1 of 4 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680041 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0680041 d) Client: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 e) Identification: CVC-151 FCC ID: FRWCVC-151 Description: Aviation Control Unit (SN: E0001) f) EUT Condition: Not required unless specified in individual tests. g) Report Date: August 15, 2006 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Hoosamuddin S. Bandukwala, Lab Director n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 2 of 4 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680041 Identification of the Equipment Under Test (EUT) Name and Address of Applicant: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 Manufacturer: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 FCC ID: FRWCVC-151 Model Number: CVC-151 Description: Aviation Control Unit (SN: E0001) Type of Emission: 16K0F3E Frequency Range, MHz: 118.0 to 151.975 Power Rating, Watts: 22.4 Switchable Variable x N/A Modulation: AMPS TDMA CDMA X OTHER Antenna: Helical Monopole Whip X Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBi) and RF Power set to highest nominal power across all channels. Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 3 of 4 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680041 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-2003 Draft, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 4 of 4 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680041 Name of Test: R.F. Radiation Exposure FCC Rules: 1.1307, 1.1310, 1.1311, 2.1091 Description, EUT: See page 2 of Test Report 0.3-1.234 MHz: Limit [mW/cm 2 ] = 100 1.34-30 MHz: Limit [mW/cm 2 ] = (180/f 2 ) 30-300 MHz: Limit [mW/cm 2 ] = 0.2 Limits: Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 300-1500 MHz Limit [mW/cm 2 ] = f/1500 1500-100,000 MHz: Limit [mW/cm 2 ] = 1.0 Test Frequencies, MHz 118 Power, Conducted, W = 22.4 Antenna Gain = 0 dB Antenna Model N/A Power [W EIRP] = P [conducted] x G [antenna] = 22.4 Limit [mW/cm2] = 0.2 Limit [W/m2] = 10 x Limit [mW/cm2] = 2.0 Calculations R [m] = [P [W EIRP] / (4π x Limit [W/m2] )] 1/2 = 0.944

6400 Wilkinson Drive Prescott, AZ 86301-6164 USA Phone 1-928-708-1550 Fax 1-928-541-7627 www.Wulfsberg.com Wulfsberg Electronics Cobham Avionics & Surveillance September 14, 2006 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Wulfsberg Electronics Equipment: CVC-151 FCC ID: FRWCVC-151 FCC Rules: 87 Gentlemen: On behalf of Wulfsberg Electronics, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, for approval of the referenced equipment. I trust all is in order. Should you need any further information, kindly contact me at the following: Office 928-708-1548 Main 928-708-1550 e-mail [email protected] Respectfully submitted, Vern D. Wallace Certification Manager

6400 Wilkinson Drive Prescott, AZ 86301-6164 USA Phone 1-928-708-1550 Fax 1-928-541-7627 www.Wulfsberg.com Wulfsberg Electronics Cobham Avionics & Surveillance Date: July 27, 2006 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Attn: Authorization and Evaluation Division PER: 47 CFR 0.457 and 0.459 RE: FRWCVC-151 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application as listed below, i.e. Active Devices Alignment Block Diagrams Parts Lists Schematics Theory of Operation These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Vern D. Wallace Product Certification Manager Wulfsberg Electronics

6400 Wilkinson Drive Prescott, AZ 86301-6164 USA Phone 1-928-708-1550 Fax 1-928-541-7627 www.Wulfsberg.com Wulfsberg Electronics Cobham Avionics & Surveillance September 14, 2006 FAA Headquarters Spectrum Policy and Management ASR1 800 Independence Ave. SW Washington, DC 20591 Gentlemen: We will be manufacturing an aircraft ATC radio that operates in the band of 108.000 MHz to 137.000 MHz and we are filing a certification application with the FCC. The equipment is TSO’d under TSO-C169. Description of Equipment: The VHF communications transceiver is manufactured for aircraft installation and is a remote mounted transceiver. The transceiver provides voice communications between the aircraft and ground facilities over a frequency range of 118.000 MHz to 136.975 MHz. The extended frequency range units provide voice communications from 118.000 MHz to 151.975 MHz. The transceiver is designed to operate in systems with 25 kHz and/or 8.33 kHz channel spacing. Manufacturer’s Identification: CVC-151 VHF Communications Transceiver Antenna Characteristics: While no specific antenna is specified; the antenna must have an Ohm characteristic input impedance and be able to handle 25 Watts. Receive and transmit signals horizontally polarized in the 118-136 MHz band (118-152 MHz antenna required for extended range units), operable with 50-ohm co-axial RF cable. VSWR = 3 : 1 maximum. Rated Output Power: 20 Watts Emission Type and Characteristics: 6K00A3E – 6kHz occupied bandwidth Double Sideband – Single Channel Analog – Telephony 6K00A9W – 6kHz occupied bandwidth Double sideband – Single Channel Analog/Digital Telephony/Data. 5K00A3E – 5kHz occupied bandwidth AM Double Sideband – Single Channel Analog Telephony. Frequencies of operation: 6400 Wilkinson Drive Prescott, AZ 86301-6164 USA Phone 1-928-708-1550 Fax 1-928-541-7627 www.Wulfsberg.com Wulfsberg Electronics Cobham Avionics & Surveillance The range of frequencies is 118-152 MHz settable at the control head. Channels of operation for 8.33 kHz and 25 kHz spacing mode are the standard channels as allowed by TSO-C169 with FAA approved extended range beyond 137 MHz. Essential Receiver Characteristics: Receiver Sensitivity 20μV max. For 6 dB (S+N)/N Noise Level 30 dB min (S+N)/N for 100 μv Selectivity 6 dB max. at ± 10 kHz 60 dB min at ±25 kHz If the FAA objects to the equipment authorization it is understood that the FAA will mail its objection showing that the equipment is incompatible with the National Airspace System to: Office of Engineering and Technology Laboratory Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia, MD 21046 TSO coordination is being handled through the FAA LA ACO in Long Beach, CA. Please consider this letter as our notification to apply for FCC equipment authorization per CFR 87.147 (d). Best regards, Vern D. Wallace Manager of Product Certification Wulfsberg Electronics A Cobham Avionics & Surveillance Group Company 6400 Wilkinson Dr. Prescott, AZ 86301 Ph: 928-708-1548 Fax: 928-708-1511

Page 1 of 8 CVC-151 External Photos Page 2 of 8 CVC-151 External Photos Proposed FCC Label

Page 2 of 8 CVC-151 External Photos Proposed FCC Label

Page 3 of 8 CVC-151 Internal Photos Page 4 of 8 CVC-151 Circuit Board Photos 310-048117-01 Digital Receiver Board Top Side Top Side without Shields Top Side with Shields Page 5 of 8 CVC-151 Circuit Board Photos 310-048117-01 Digital Receiver Board Bottom Side Bottom Side without Shield Bottom Side with Shield Page 6 of 8 CVC-151 Circuit Board Photos 310-048118-01 Power Amplifier Board Top Side Top Side without Shield Top Side with Shield Page 7 of 8 CVC-151 Circuit Board Photos 310-048118-01 Power Amplifier Board Bottom Side Page 8 of 8 CVC-151 Circuit Board Photos 310-048116-01 Interconnect Board

Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680037 Table of Contents Rule Description Page 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 2.1033(c) General Information Required 4 2.1046(a) Carrier Output Power (Conducted) 6 2.1051 Unwanted Emissions (Transmitter Conducted) 8 2.1053(a) Field Strength of Spurious Radiation 10 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 14 2.1047(b) Modulation Limiting 24 2.1055(a)(1) Frequency Stability (Temperature Variation) 26 2.1055(b)(1) Frequency Stability (Voltage Variation) 28 2.202(g) Necessary Bandwidth and Emission Bandwidth 30 Flom Test Labs 3356 North San Marcos Place, Suite 107 Page 1 of 30 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680037 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0680037 d) Client: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 e) Identification: CVC-151 FCC ID: FRWCVC-151 EUT Description: Aviation Control Unit (SN: E0001) f) EUT Condition: Not required unless specified in individual tests. g) Report Date: August 11, 2006 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, Compliance Test Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs 3356 North San Marcos Place, Suite 107 Page 2 of 30 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680037 Sub-part 2.1033(c)(14): Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Volume II; Part 2, Sub-part J, Sections 2.947, 2.1033(c), 2.1041, 2.1046, 2.1047, 2.1079, 2.1051, 2.1053, 2.1055, 2.1057 and the following individual Parts: 21 – Domestic Public Fixed Radio Services 22 – Public Mobile Services 22 Subpart H - Cellular Radiotelephone Service 22.901(d) - Alternative technologies and auxiliary services 23 – International Fixed Public Radiocommunication services 24 – Personal Communications Services 74 Subpart H - Low Power Auxiliary Stations 80 – Stations in the Maritime Services 80 Subpart E - General Technical Standards 80 Subpart F - Equipment Authorization for Compulsory Ships 80 Subpart K - Private Coast Stations and Marine Utility Stations 80 Subpart S - Compulsory Radiotelephone Installations for Small Passenger Boats 80 Subpart T - Radiotelephone Installation Required for Vessels on the Great Lakes 80 Subpart U - Radiotelephone Installations Required by the Bridge-to-Bridge Act 80 Subpart V - Emergency Position Indicating Radio Beacons (EPIRB'S) 80 Subpart W - Global Maritime Distress and Safety System (GMDSS) 80 Subpart X - Voluntary Radio Installations x 87 – Aviation Services 90 – Private Land Mobile Radio Services 94 – Private Operational-Fixed Microwave Service 95 Subpart A - General Mobile Radio Service (GMRS) 95 Subpart C - Radio Control (R/C) Radio Service 95 Subpart D - Citizens Band (CB) Radio Service 95 Subpart E - Family Radio Service 95 Subpart F - Interactive Video and Data Service (IVDS) 97 - Amateur Radio Service 101 – Fixed Microwave Services Flom Test Labs 3356 North San Marcos Place, Suite 107 Page 3 of 30 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680037 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-2003 Draft, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 Flom Test Labs 3356 North San Marcos Place, Suite 107 Page 4 of 30 Chandler, Arizona 85225-7176 FCC ID: FRWCVC-151 (866) 311-3268 phone, (480) 926-3598 fax MFA p0670004, d0680037 List of General Information Required for Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 87 Sub-part 2.1033 (c)(1): Name and Address of Applicant: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 Manufacturer: Wulfsberg Electronics Division 6400 Wilkinson Drive Prescott, AZ 86301-6164 (c)(2): FCC ID: FRWCVC-151 Model Number: CVC-151 (c)(3): Instruction Manual(s): Please see attached exhibits (c)(4): Type of Emission: 16K0F3E (c)(5): Frequency Range, MHz: 118.0 to 151.975 (c)(6): Power Rating, Watts: 20 to 25.12 Switchable Variable…
