RF Wheel Keyboard and Mouse Note! Before installing or removing the keyboard / mouse to or from your computer, always remember to turn off your computer. Installing or removing the mouse when your computer is running will cause permanent damage to the mouse or your computer. Install the Battery 1. Remove the battery compartment covers on the RF keyboard/mouse. 2. Insert batteries into the battery compartment. Pay attention to the polarity. 3. Replace the covers to the RF keyboard/mouse. Connect the Receiver The RF receiver is compatible with the PC 99 Spec. If you have a computer with the PC 99 Spec, simply plug the receiver into the corresponding PS/2 port. For your convenience, the receiver connector has a small icon on it. The color of the mouse port is green. Also refer to your main board manual for the location of the PS/2 port. Setting up the ID Channel Press the ID channel button on the receiver, then press the ID channel button on the bottom of the keyboard/mouse. Install the Software 1. Turn on your computer and start Windows. 2. Insert the CD-ROM into your CD-ROM drive. 3. Follow the on-screen instructions. 4. If Autorun is not enabled, select Run from the Start Menu on the Taskbar. Next type d:\setup.exe, where d: is the designation of the CD-ROM drive. Troubleshooting ~ If the RF keyboard and mouse does not operate correctly after installation: ¾ The batteries have not been installed in your RF keyboard and mouse or have been installed incorrectly. ¾ The batteries are weak. ¾ The RF receiver has been connected to your computer incorrectly. ¾ The ID channel setting of the RF receiver and mouse are not identical. ~ When the cursor does not move properly: ¾ The RF receiver and keyboard/mouse are placed at an improper distance. Keep the RF receiver away from the mouse, keyboard, monitor, computer, and any other electrical devices by at least 20cm (about 8 inches). ¾ Do not use your RF keyboard and mouse on a metal surface. Use a pad to prevent the ID channel from any interference. ~ How long is the average life of a battery? ¾ The surface on which you use the mouse can significantly affect battery life. Lighter surfaces extend battery life, darker ones shorten it. Bright mat (pad) surfaces (not glossy ones) are recommended. LIMITATION OF LIABILITY. THE WARRANTIES SET FORTH IN THIS AGREEMENT REPLACE ALL OTHER WARRANTIES. KYE EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES. INCLUDING. BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD-PARTY RIGHTS WITH RESPECT TO THE DOCUMENTATION, SOFTWARE. AND HARDWARE. NO KYE DEALER. AGENT. OR EMPLOYEE IS AUTHORIZED TO MAKE ANY MODIFICATION, EXTENSION. OR ADDITION TO THIS WARRANTY. IN NO EVENT WILL KYE OR ITS SUPPLIERS BE LIABLE FOR ANY COSTS OF PROCUREMENT OF SUBSTITUTE PRODUCTS OR SERVICES, LOST PROFITS, LOSS OF INFORMATION OR DATA, OR ANY OTHER SPECIAL, INDIRECT. CONSEQUENTIAL, OR INCIDENTAL DAMAGES ARISING IN ANY WAY OUT OF THE SALE OF, USE OF. OR INABILITY TO USE ANY KYE PRODUCT OR SERVICE, EVEN IF KYE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO CASE SHALL KYE’S LIABILITY EXCEED THE ACTUAL MONEY PAID FOR THE PRODUCTS AT ISSUE. Because some jurisdictions do not allow the limitation of implied warranties or liability for incidental, consequential, special, or indirect damages, the above limitation may not always apply. The above limitations will not apply in case of personal injury where and to the extent that applicable law requires such liability. FCC Compliance and Advisory Statement. This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 )this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and. if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canadian DOC Statement. This digital device does not exceed the Class B limits for radio noise emissions from digital apparatus specified in the interference-causing equipment standard entitled iDigital Apparatus,i ICES-003 of the Department of Communications. Cet appareil numErique respecte les limites bruits radioElectriques applicables aux appareils numEriques de Classe B prescrites dans la norme sur Ie matEriel brouilleur: iAppareils NumEriques,i NMB-003 EdictEe par Ie MinistEre des Communications. This device complies with RSS-210 of Industry and Science Canada. Operation is subject to the following two conditionsi 1) this device may not c…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, KYE Systems Corp. No. 492, Sec. 5 Chung Hsin Rd., San Chung, Taipei Hsien, Taiwan, R.O.C. Tel: +886 2 2995 6645 Fax: +886 2 2995 5302 FCC ID: FSUGKZG9

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3

FCC ID Label Location

Page 4 Page 5

Page 6 Page 7

FCC ID: FSUGKZG9 ADT No.900914R06 Operational Description The transmitter of the EUT (Wireless keyboard) is powered by 3V Battery. The receiver is powered by host computer. Both transmitter and receiver use internal loop antenna. Because the room inside the housing is very limited, so the size of the antenna is far smaller than one wavelength (27MHz), which means the radiation efficiency is very low. But under normal use condition, the transmitter and the receiver is quite close, so high EIRP power is not needed and neither not allowed because of interference.

FCC ID: FSUGKZG9 Report No.: RF900914R06 1 Issued: Sep. 28, 2001 FCC TEST REPORT REPORT NO.: RF900914R06 MODEL NO.: Wireless TwinTouch+ / keyboard (The others model please refer to page 5) RECEIVED: September 14, 2001 TESTED: September 20, 2001 APPLICANT: KYE SYSTEMS CORP. ADDRESS: NO.492, SEC.5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: FSUGKZG9 Report No.: RF900914R06 2 Issued: Sep. 28, 2001 Table of Contents 1CERTIFICATION ............................................................................................. 3 2SUMMARY OF TEST RESULTS..................................................................... 4 3GENERAL INFORMATION ............................................................................. 5 3.1GENERAL DESCRIPTION OF EUT ............................................................... 5 3.2DESCRIPTION OF TEST MODES.................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS................................. 6 3.4DESCRIPTION OF SUPPORT UNITS............................................................ 7 4TEST PROCEDURE AND RESULT ................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT .................................................. 7 4.2RADIATED EMISSION MEASUREMENT ....................................................... 7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................... 7 4.2.2 TEST INSTRUMENT....................................................................................... 8 4.2.3 TEST PROCEDURE ....................................................................................... 9 4.2.4 TEST SETUP ................................................................................................ 10 4.2.5 EUT OPERATING CONDITION .................................................................... 10 4.2.6 TEST RESULT ...............................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ................................... 13 6INFORMATION ON THE TESTING LABORATORIES .................................. 14 FCC ID: FSUGKZG9 Report No.: RF900914R06 3 Issued: Sep. 28, 2001 1 CERTIFICATION PRODUCT : Wireless Keyboard BRAND NAME : Genius MODEL NO : Wireless TwinTouch+ / keyboard (The others model please refer to page 5) APPLICANT : KYE SYSTEMS CORP. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on September 20, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: FSUGKZG9 Report No.: RF900914R06 4 Issued: Sep. 28, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PAR AGR APH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –12.20dBuV at 352.10MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: FSUGKZG9 Report No.: RF900914R06 5 Issued: Sep. 28, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Keyboard MODEL NO. Wireless TwinTouch+ / keyboard POWER SUPPLY 3VDC from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.145 / 27.195 MHz BANDWIDTH OF EACH CHANNEL ±5KHz NUMBER OF CHANNEL 2 ANTENNA TYPE Internal loop antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is the transmitter part of a Wireless Keyboard. 2. The EUT has three models which has same electrical design but different outer appearances and the following: MODEL NO.BRAND NAMEDESCRIPTION Wireless TwinTouch+ / keyboardGenius12 keys TK2701hmam19 Keys TK2701KYE19 Keys 3. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: FSUGKZG9 Report No.: RF900914R06 6 Issued: Sep. 28, 2001 3.2 DESCRIPTION OF TEST MODES Four channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.145 MHz227.195 MHz NOTE: Two channels were pre-tested in chamber. Channel 1, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Keyboard. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C(15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. FCC ID: FSUGKZG9 Report No.: RF900914R06 7 Issued: Sep. 28, 2001 3.4 DESCRIPTION OF SUPPORT UNITS NA 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Fundamental Frequency (MHz) Field Strength of Fundamental (dBuV/m) PeakAverage 26.96-27.28 10080 Field strength limits are at the distance of 3 meters, emissions radi…

Text truncated - open the document above for the full version.

FCC ID: FSUGKZG9 Report No.: RF900914R06 13 Issued: Sep. 28, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
