FCC ID: FSUGKZGM(Keyboard) Operational Description of the equipment PRODUCT Wireless K + M MODEL NO. KB-3008/KB POWER SUPPLY Keyboard: 1.5Vdc batteriesx2pcs CARRIER FREQUENCY Keyboard: 27.145MHz NUMBER OF CHANNEL 2 RATED RF OUTPUT POWER Keyboard: -7dBm I.F. & L.O. Keyboard: I.F.: 455KHz, L.O.: 26.69MHz MODULATION TYPE FSK ANTENNA TYPE Monopole antenna printed on PCB NOTE : The product is a wireless mouse which includes transmitter part (TX) and receiver part (RX). EUT Model No. Transmitter part (TX) KB-3008/T, KB-3008/KB Receiver part (RX) KB-3008/R For more detailed features, please refer to the manufacturer’s specification or User’s Manual.
