FCC Compliance and Advisory Statement. This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to connected; 4) consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canadian DOC Statement. This digital device does not exceed the Class B limits for radio noise emissions from digital apparatus specified in the interference-causing equipment standard entitled "Digital Apparatus." ICES-003 of the Department of Communications. Cet appareil numerique respecte les limites bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le materiel brouilleur: "Appareils Numeriques," NMB-003 edictee par le Ministere des Communications. This device complies with RSS-210 of Industry and Science Canada. Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3 Page 4

Page 5 Page 6 Page 7

FCC ID Label Location FCC ID Label Location FCC ID Label Location FCC ID Label Location FCC ID Label Location

Page 8 Page 9

Page 10

FCC ID: FSUGMZG8 Report No.: RF900822R01 1 Issued: Sep. 10, 2001 FCC TEST REPORT REPORT NO.: RF900822R01 MODEL NO.: Wireless PowerScroll (The others model no. please refer to page 5) RECEIVED: August 22, 2001 TESTED: September 5, 2001 APPLICANT: KYE SYSTEMS CORP. ADDRESS: NO.492, SEC.5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 15 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: FSUGMZG8 Report No.: RF900822R01 2 Issued: Sep. 10, 2001 Table of Contents 1CERTIFICATION ............................................................................................. 3 2SUMMARY OF TEST RESULTS..................................................................... 4 3GENERAL INFORMATION ............................................................................. 5 3.1GENERAL DESCRIPTION OF EUT ............................................................... 5 3.2DESCRIPTION OF TEST MODES.................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS................................. 6 3.4DESCRIPTION OF SUPPORT UNITS............................................................ 7 4TEST PROCEDURE AND RESULT ................................................................ 8 4.1CONDUCTED EMISSION MEASUREMENT .................................................. 8 4.2RADIATED EMISSION MEASUREMENT ....................................................... 8 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................... 8 4.2.2 TEST INSTRUMENT....................................................................................... 9 4.2.3 TEST PROCEDURE ..................................................................................... 10 4.2.4 TEST SETUP .................................................................................................11 4.2.5 EUT OPERATING CONDITION .....................................................................11 4.2.6 TEST RESULT .............................................................................................. 12 5PHOTOGRAPHS OF THE TEST CONFIGURATION ................................... 14 6INFORMATION ON THE TESTING LABORATORIES .................................. 15 FCC ID: FSUGMZG8 Report No.: RF900822R01 3 Issued: Sep. 10, 2001 1 CERTIFICATION PRODUCT : Wireless Mouse BRAND NAME : Genius MODEL NO : Wireless PowerScroll (The others model no. please refer to page 5) APPLICANT : KYE SYSTEMS CORP. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on September 5, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: FSUGMZG8 Report No.: RF900822R01 4 Issued: Sep. 10, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PAR AGR APH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –10.4dBuV at 81.14MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: FSUGMZG8 Report No.: RF900822R01 5 Issued: Sep. 10, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. Wireless PowerScroll POWER SUPPLY 3VDC from battery MODULATION TYPE FSK FREQUENCY RANGE 27.045-27.195 MHz CARRIER FREQUENCY OF EACH CHANNEL 27.045 / 27.095 / 27.145 / 27.195 MHz BANDWIDTH OF EACH CHANNEL ±5KHz NUMBER OF CHANNEL 4 ANTENNA TYPE Internal loop antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is the transmitter part of a Wireless Mouse. 2. The EUT has five models which has same electrical design but different outer appearances and the following: MODEL NO.BRAND NAMEDESCRIPTION Wireless PowerScrollGenius3 Key TM2703-3Kirschenhofer (for OEM)3 Key TM2703-31Kirschenhofer (for OEM)3 Key TM2703-5Kirschenhofer (for OEM)5 Key TM2703-51Kirschenhofer (for OEM)5 Key 3. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: FSUGMZG8 Report No.: RF900822R01 6 Issued: Sep. 10, 2001 3.2 DESCRIPTION OF TEST MODES Four channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.045 MHz327.145 MHz 227.095 MHz427.195 MHz NOTE: Four channels were pre-tested in chamber. Channel 1, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C(15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. FCC ID: FSUGMZG8 Report No.: RF900822R01 7 Issued: Sep. 10, 2001 3.4 DESCRIPTION OF SUPPORT UNITS NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1PERSONAL COMPUTER HPBrio BA410SG12902751FCC DoC Approved 2MONITORHPD2842AKR93473168BEJCB910 3KEYBOARDFORWARDFDA-104GAFDKB8110111F4ZDA-104G 4PRINTERHP2225C+3123S97230DSI6XU2225 5MODEMACEEX1414980020510IFAXDM1414 NO.SIGNAL CABLE DESCRIPTION OF THE ABOVE SUPPORT UNITS 1NA 21.8 m braid shie…

Text truncated - open the document above for the full version.

FCC ID: FSUGMZG8 Report No.: RF900822R01 14 Issued: Sep. 10, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
