FSUGMZGEWireless Mouse

Page 1 ANNEX PHOTOGRAPHS OF EUT

Page 1 Label Location

Page 2 Page 3 Page 4 Page 5 Page 6

FCC ID: FSUGMZGE ADT No.901126R01 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3V Battery. The receiver is powered by host computer. Both transmitter and receiver use integral antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: FSUGMZGE Report No.: RF901126R01 1 Issued: Dec. 7, 2001 FCC TEST REPORT REPORT NO.: RF901126R01 MODEL NO.: Wireless SmartScroll RECEIVED: Nov. 26, 2001 TESTED: Nov. 30, 2001 APPLICANT: KYE SYSTEMS CORP. ADDRESS: No.492 SEC.5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN 241, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: FSUGMZGE Report No.: RF901126R01 2 Issued: Dec. 7, 2001 Table of Contents 1CERTIFICATION...................................................................................................... 3 2SUMMARY OF TEST RESULTS ............................................................................. 4 3GENERAL INFORMATION..................................................................................... 5 3.1GENERAL DESCRIPTION OF EUT........................................................................ 5 3.2DESCRIPTION OF TEST MODES .......................................................................... 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS........................................ 6 3.4DESCRIPTION OF SUPPORT UNITS ..................................................................... 6 4TEST PROCEDURE AND RESULT ........................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT......................................................... 7 4.2RADIATED EMISSION MEASUREMENT ............................................................. 7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................... 7 4.2.2 TEST INSTRUMENT....................................................................................... 8 4.2.3 TEST PROCEDURE ....................................................................................... 9 4.2.4 TEST SETUP ................................................................................................ 10 4.2.5 EUT OPERATING CONDITION .................................................................... 10 4.2.6 TEST RESULT ...............................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ........................................... 13 6INFORMATION ON THE TESTING LABORATORIES........................................ 14 FCC ID: FSUGMZGE Report No.: RF901126R01 3 Issued: Dec. 7, 2001 1 CERTIFICATION PRODUCT : Wireless Mouse BRAND NAME : Genius MODEL NO : Wireless SmartScroll APPLICANT : KYE SYSTEMS CORP. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on Nov. 30, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: FSUGMZGE Report No.: RF901126R01 4 Issued: Dec. 7, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PAR AGR APH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –13.00dBuV at 297.51MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: FSUGMZGE Report No.: RF901126R01 5 Issued: Dec. 7, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. Wireless SmartScroll POWER SUPPLY 3VDC from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.045MHz BANDWIDTH OF EACH CHANNEL 10KHz NUMBER OF CHANNEL 1 ANTENNA TYPE Integral antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is the transmitter part of a Wireless Mouse. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: FSUGMZGE Report No.: RF901126R01 6 Issued: Dec. 7, 2001 3.2 DESCRIPTION OF TEST MODES One channel is provided in this EUT. ChannelFrequency 127.045 MHz 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C (15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: FSUGMZGE Report No.: RF901126R01 7 Issued: Dec. 7, 2001 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Fundamental Frequency (MHz) Field Strength of Fundamental (dBuV/m) PeakAverage 26.96-27.28 10080 Field strength limits are at the distance of 3 meters, emissions radiated outside of the specified bands, shall be according to the general radiated limits in 15.209 as following: Field Strength of Fundamental Other Frequencies (MHz) uV/meterdBuV/meter 30-8810040.0 88-21615043.5 216-96020046.0 Above 96050054.0 As shown in 15.35(b), for frequencies above 1000MHz, the field strength limits are based on average detector, however, the peak field strength of any emission shall not …

Text truncated - open the document above for the full version.

FCC ID: FSUGMZGE Report No.: RF901126R01 13 Issued: Dec. 7, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
