FSUGMZGVWIRELESS MOUSE

FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. The equipment has been certified to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by switching the equipment off and on. The user can try to correct the interference by the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or and experience radio/TV technician for help. Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 1 of 3 Part I : TX PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 2 of 3 Part II : RX PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 3 of 3 PHOTOS OF EUT

Sample of FCC ID Label FCC ID: FSUGMZGV The device is so small that the Two-Part warning statement does not have to go on the device. It will be really hard to read. We remove the Two-Part statement from the device since we already have it in the manual. Sample of FCC DoC Label The device is so small that the Two-Part warning statement does not have to go on the device. It will be really hard to read. We remove the Two-Part statement from the device since we already have it in the manual.

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 1 of 6 Part I : TX PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 2 of 6 PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 3 of 6 PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 4 of 6 Part II : RX PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 5 of 6 PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. Photo Page: 6 of 6 PHOTOS OF EUT

FCC ID:FSUGMZGV Operational Description of the equipment The EUT is an excellent tool for mobile professionals. This mouse features 800 dpi resolution, meaning it offers twice the acuracy of typical mouse movement, which is ideal for graphic designing or any other type of computing where precision matters. This unit is USB ready, Plug-n-Play and hot pluggable. PRODUCT Wireless Mouse MODEL NO. GM-04002A/T POWER SUPPLY 3Vdc from battery (1.5V x 2) for transmitter part 5Vdc from PC system for receiver part CABLE 0.5m shielded USB cable CARRIER FREQUENCY 27.045 MHz NUMBER OF CHANNEL 1 RATED RF OUTPUT POWER -9dBm I.F. & L.O. I.F.: 0, L.O.: 27.045MHz MODULATION TYPE FSK BIT RATE OF TRANSMISSION 4.8 kbps ANTENNA TYPE Loop antenna NOTE : The product is a wireless mouse which includes transmitter part (TX) and receiver part (RX). EUT Model No. Transmitter part (TX) GM-04002A/T Receiver part (RX) GM-04002A/R For more detailed features, please refer to the manufacturer’s specification or User’s Manual.

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCCA04060402 Page:2 of 20 Date:Jun. 29, 2004 FCC ID:FSUGMZGQ Table of Contents 1. DOCUMENT POLICY AND TEST STATEMENT................................................ 3 1.1 DOCUMENT POLICY ........................................................................................ 3 1.2 TEST STATEMENT............................................................................................ 3 2. DESCRIPTION OF EUT AND TEST MODE ...................................................... 4 2.1 GENERAL DESCRIPTION OF EUT .................................................................. 4 2.2 DESCRIPTION OF EUT INTERNAL DEVICE.................................................... 4 2.3 DESCRIPTION OF TEST MODE ....................................................................... 4 2.4 DESCRIPTION OF SUPPORT UNIT ................................................................. 5 3. DESCRIPTION OF APPLIED STANDARDS ...................................................... 5 4. CONDUCTED EMISSION TEST ........................................................................ 6 4.1 CONDUCTED EMISSION LIMIT........................................................................ 6 4.2 TEST EQUIPMENT............................................................................................ 6 4.3 TEST SETUP..................................................................................................... 7 4.4 TEST PROCEDURE .......................................................................................... 7 4.5 EUT OPERATING CONDITION ......................................................................... 7 4.6 TEST RESULT ................................................................................................... 8 5. RADIATED EMISSION TEST ............................................................................. 9 5.1 RADIATED EMISSION LIMIT............................................................................. 9 5.2 TEST EQUIPMENT...........................................................................................10 5.3 TEST SET-UP...................................................................................................11 5.4 TEST PROCEDURE .........................................................................................12 5.5 EUT OPERATING CONDITION ........................................................................12 5.6 RADIATED EMISSION TEST RESULT.............................................................13 6. BAND EDGE .................................................................................................... 15 6.1 BAND EDGE LIMIT ...........................................................................................15 6.2 TEST EQUIPMENT...........................................................................................15 6.3 TEST SET-UP...................................................................................................15 6.4 TEST PROCEDURE .........................................................................................15 6.5 EUT OPERATING CONDITION ........................................................................15 6.6 BAND EDGE TEST RESULT ............................................................................16 7. PHOTOS OF TESTING.................................................................................... 17 8. TERMS OF ABRIVATION................................................................................. 20 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCCA04060402 Page:3 of 20 Date:Jun. 29, 2004 FCC ID:FSUGMZGQ 1. DOCUMENT POLICY AND TEST STATEMENT 1.1 DOCUMENT POLICY - The report shall not be reproduced except in full, without the written approval of SRT Lab, Inc. - The report must not be used by the applicant to claim that the product is endorsed by NVLAP, TÜV, NEMKO and SRT. - The NVLAP logo applies only to the applicable standards specified in this report. 1.2 TEST STATEMENT - The test results in the report apply only to the unit tested by SRT Lab. - There was no deviation from the requirements of test standards during the test. - AC power source, 120 Vac/60 Hz, was used during the test. Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCCA04060402 Page:4 of 20 Date:Jun. 29, 2004 FCC ID:FSUGMZGQ 2. DESCRIPTION OF EUT AND TEST MODE 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. GM-04002A/T POWER SUPPLY 3Vdc from battery (1.5V x 2) for transmitter part 5Vdc from PC system for receiver part CABLE 0.5m shielded USB cable CARRIER FREQUENCY 27.045 MHz NUMBER OF CHANNEL 1 RATED RF OUTPUT POWER -9dBm I.F. & L.O. I.F.: 0, L.O.: 27.045MHz MODULATION TYPE FSK BIT RATE OF TRANSMISSION 4.8 kbps ANTENNA TYPE Loop antenna NOTE : The product is a wireless mouse which includes transmitter part (TX) and receiver part (RX). EUT Model No. Transmitter part (TX) GM-04002A/T Receiver part (RX) GM-04002A/R For more detailed features, please refer to the manufacturer’s specification or User’s Manual. 2.2 DESCRIPTION OF EUT INTERNAL DEVICE DEVICE BRAND / MAKER MODEL # FCC ID/DOC REMARK N/A 2.3 DESCRIPTION OF TEST MODE N/A (It is only applicable to more than one test mode.) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCCA04060402 Page:5 of 20 Date:Jun. 29, 2004 FCC ID:FSUGMZGQ 2.4 DESCRIPTION OF SUPPORT UNIT The EUT was configured by the requirement of ANSI C63.4:2003 and CISRP22:2003. All interface ports were connected to the appropriate support units via specific cables. The support u…

Text truncated - open the document above for the full version.

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCBA04031703-01 Page:2 of 15 Date:Jun. 29, 2004 Table of Contents 1. DOCUMENT POLICY AND TEST STATEMENT................................................ 3 1.1 DOCUMENT POLICY ........................................................................................ 3 1.2 TEST STATEMENT............................................................................................ 3 2. DESCRIPTION OF EUT AND TEST MODE ...................................................... 4 2.1 GENERAL DESCRIPTION OF EUT .................................................................. 4 2.2 DESCRIPTION OF EUT INTERNAL DEVICE.................................................... 4 2.3 DESCRIPTION OF TEST MODE ....................................................................... 4 2.4 DESCRIPTION OF SUPPORT UNIT ................................................................. 5 3. DESCRIPTION OF APPLIED STANDARDS ...................................................... 5 4. CONDUCTED EMISSION TEST ........................................................................ 6 4.1 CONDUCTED EMISSION LIMIT........................................................................ 6 4.2 TEST EQUIPMENT............................................................................................ 6 4.3 TEST SETUP..................................................................................................... 7 4.4 TEST PROCEDURE .......................................................................................... 7 4.5 EUT OPERATING CONDITION ......................................................................... 7 4.6 TEST RESULT ................................................................................................... 8 5. RADIATED EMISSION TEST ............................................................................. 9 5.1 RADIATED EMISSION LIMIT............................................................................. 9 5.2 TEST EQUIPMENT............................................................................................ 9 5.3 TEST SET-UP...................................................................................................10 5.4 TEST PROCEDURE .........................................................................................11 5.5 EUT OPERATING CONDITION ........................................................................11 5.6 RADIATED EMISSION TEST RESULT.............................................................12 7. PHOTOS OF TESTING.................................................................................... 13 8. TERMS OF ABRIVATION................................................................................. 15 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCBA04031703-01 Page:3 of 15 Date:Jun. 29, 2004 1. DOCUMENT POLICY AND TEST STATEMENT 1.1 DOCUMENT POLICY - The report shall not be reproduced except in full, without the written approval of SRT Lab, Inc. - The report must not be used by the applicant to claim that the product is endorsed by NVLAP, TÜV, NEMKO and SRT. - The NVLAP logo applies only to the applicable standards specified in this report. 1.2 TEST STATEMENT - The test results in the report apply only to the unit tested by SRT Lab. - There was no deviation from the requirements of test standards during the test. - AC power source, 120 Vac/60 Hz, was used during the test. Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCBA04031703-01 Page:4 of 15 Date:Jun. 29, 2004 2. DESCRIPTION OF EUT AND TEST MODE 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. GM-04002A/R POWER SUPPLY 3Vdc from battery (1.5V x 2) for transmitter part 5Vdc from PC system for receiver part CABLE 0.5m shielded USB cable NOTE : The product is a wireless mouse which includes transmitter part (TX) and receiver part (RX). EUT Model No. Transmitter part (TX) GM-04002A/T Receiver part (RX) GM-04002A/R For more detailed features, please refer to the manufacturer’s specification or User’s Manual. 2.2 DESCRIPTION OF EUT INTERNAL DEVICE DEVICE BRAND / MAKER MODEL # FCC ID/DOC REMARK N/A 2.3 DESCRIPTION OF TEST MODE N/A (It is only applicable to more than one test mode.) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCBA04031703-01 Page:5 of 15 Date:Jun. 29, 2004 2.4 DESCRIPTION OF SUPPORT UNIT The EUT was configured by the requirement of ANSI C63.4:2003 and CISRP22:2003. All interface ports were connected to the appropriate support units via specific cables. The support units and cables are listed below. NO DEVICE BRAND MODEL # FCC ID/DOC CABLE 1 NOTEBOOK DELL PP01L DOC 1.8m unshielded power cord 2 MODEM ACEEX DM-1414 DOC 1.5m unshielded power cord 1.5m shielded data cable 3 PRINTER EPSON STYLUS C20SX DOC 1.8m unshielded power cord 1.5m shielded data cable NOTE : For the actual test configuration, please refer to the photos of testing. 3. DESCRIPTION OF APPLIED STANDARDS The EUT is a kind of wireless product and to be connected with a PC system for normal use. According to the specifications provided by the applicant, it must comply with the requirements of the following standards: 47 CFR Part 15, Subpart B, Class B ANSI C63.4:2003 All tests have been performed and recorded as per the above standards. Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan, R.O.C. TEST REPORT Reference No.:A04060402 Report No.:FCBA04031703-01 Page:6 of 15 Date:Jun. 29, 2004 4. CONDUCTED EMISSION TEST 4.1 CONDUCTED EMISSION LIMIT Class A (dBμV) C…

Text truncated - open the document above for the full version.

PHOTOS OF TESTING - Conducted test - Radiated test (TX) - Radiated test (RX)
