BT Mouse: Hardware Installation Note: Before installing or removing the mouse (either the original or the wireless one) to or from your computer, always remember to turn off your computer. Installing or removing the mouse when your computer is running will cause permanent damage to them or your computer. 1. Press the tab on the bottom of the wireless mouse. 2. Press the latch then slide the cover off the wireless mouse. 3. Insert 2 AAA batteries into the battery compartment. Pay attention to the polarity. A diagram in the battery compartment shows the correct battery installation. 4. Replace the covers to the wireless mouse until a click is heard. Warning 1. Do not use your wireless keyboard or mouse on a metal surface. Use a pad to prevent the radio channel from being interfering. 2. For optimal performance, place the dongle receiver at least 8 inches (about 20cm) away from the wireless mouse and other electrical devices, such as computer, monitor, etc. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. INFORMATION TO USER: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Request for Confidentiality letter.jpg (2496 x 3507 x 8)

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID Label Location

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10

FCC ID: FSUGMZH4 Report No.RF940103L05 Operational Description The transmitter of the EUT (Bluetooth Mini Mouse) is powered by 3Vdc from batteries or 5Vdc from host equipment via a USB cable. The antenna is Printed antenna without antenna connector. This device is a Frequency Hopping device with 79 hopping frequencies. For more detailed instruction, please take a look at the user’s manual.

FCC ID: FSUGMZH4 Report No: SA940103L05 1 RF EXPOSURE REPORT REPORT NO.: SA940103L05 MODEL NO.: BT510 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: KYE SYSTEMS CORP. ADDRESS: NO. 492, SEC.5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 241, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: FSUGMZH4 Report No: SA940103L05 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: FSUGMZH4 Report No: SA940103L05 3 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: FSUGMZH4 Report No: SA940103L05 4 5. Conclusion No Evaluation Required if power is below this threshold: F(GHz)mW Low2.402 High2.480 24.58 Maximum measured transmitter power: Pout (dBm)Pout (mW) Conducted Power-0.360.920 EIRP Power-4.740.336 *Note: The antenna is Printed antenna with –4.38dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 0.920mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

FCC ID: FSUGMZH4 Report No.: RF940103L051Report Format Version 2.0.1 FCC TEST REPORT REPORT NO.: RF940103L05 MODEL NO.: BT510 RECEIVED: Jan. 03, 2005 TESTED: Jan. 04 ~ Jan. 06, 2005 ISSUED: Jan. 10, 2005 APPLICANT: KYE SYSTEMS CORP. ADDRESS: NO. 492, SEC.5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 241, TAIWAN, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 65 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agency. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: FSUGMZH4 Report No.: RF940103L052Report Format Version 2.0.1 TABLE OF CONTENTS 1CERTIFICATION ....................................................................................................... 4 2SUMMARY OF TEST RESULTS ............................................................................... 5 2.1MEASUREMENT UNCERTAINTY............................................................................. 5 3GENERAL INFORMATION........................................................................................ 6 3.1GENERAL DESCRIPTION OF EUT .......................................................................... 6 3.2DESCRIPTION OF TEST MODES ............................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................... 8 3.4DESCRIPTION OF SUPPORT UNITS ...................................................................... 8 3.5CONFIGURATION OF SYSTEM UNDER TEST....................................................... 9 4TEST PROCEDURES AND RESULTS ................................................................... 10 4.1CONDUCTED EMISSION MEASUREMENT .......................................................... 10 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................10 4.1.2TEST INSTRUMENTS.............................................................................................10 4.1.3TEST PROCEDURES ............................................................................................. 11 4.1.4DEVIATION FROM TEST STANDARD ................................................................... 11 4.1.5TEST SETUP...........................................................................................................12 4.1.6EUT OPERATING CONDITIONS ............................................................................12 4.1.7TEST RESULTS ......................................................................................................14 4.2NUMBER OF HOPPING FREQUENCY USED ....................................................... 20 4.2.1LIMIT OF HOPPING FREQUENCY USED .............................................................20 4.2.2TEST INSTRUMENTS.............................................................................................20 4.2.3TEST PROCEDURES .............................................................................................21 4.2.4DEVIATION FROM TEST STANDARD ...................................................................21 4.2.5TEST SETUP...........................................................................................................22 4.2.6TEST RESULTS ......................................................................................................22 4.3DWELL TIME ON EACH CHANNEL ....................................................................... 24 4.3.1LIMIT OF DWELL TIME USED................................................................................24 4.3.2TEST INSTRUMENTS.............................................................................................24 4.3.3TEST PROCEDURES .............................................................................................25 4.3.4DEVIATION FROM TEST STANDARD ...................................................................25 4.3.5TEST SETUP...........................................................................................................25 4.3.6TEST RESULTS ......................................................................................................26 4.4CHANNEL BANDWIDTH ......................................................................................... 30 4.4.1LIMITS OF CHANNEL BANDWIDTH ......................................................................30 4.4.2TEST INSTRUMENTS.............................................................................................30 4.4.3TEST PROCEDURE................................................................................................31 4.4.4DEVIATION FROM TEST STANDARD ...................................................................31 4.4.5TEST SETUP...........................................................................................................31 FCC ID: FSUGMZH4 Report No.: RF940103L053Report Format Version 2.0.1 4.4.6EUT OPERATING CONDITION ..............................................................................31 4.4.7TEST RESULTS ......................................................................................................32 4.5HOPPING CHANNEL SEPARATION ...................................................................... 35 4.5.1LIMIT OF HOPPING CHANNEL SEPARATION ......................................................35 4.5.2TEST INSTRUMENTS.............................................................................................35 4.5.3TEST PROCEDURES ...........................................................................................…

Text truncated - open the document above for the full version.

FCC ID: FSUGMZH4 Report No.: RF940103L0562Report Format Version 2.0.1 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: FSUGMZH4 Report No.: RF940103L0563Report Format Version 2.0.1 RADIATED EMISSION TEST Test Mode A FCC ID: FSUGMZH4 Report No.: RF940103L0564Report Format Version 2.0.1 Test Mode B
