FSUGMZI1Navigator 600

ENGLISH 1 Hardware Installation 1. You can connect the receiver to a PS/2 or USB port of a PC 2. Install two AA batteries in the mouse. 3. Turn on your computer. The mouse will now work. 4. After you open Windows, please press the button on the receiver first and then press the button under the mouse for channel setting. Important: Remember do not put the batteries in the wrong direction; use the same types of batteries. Also, keep all drinks away! If any spill occurs on the receiver, unplug the USB connector first and clean the receiver immediately. Please switch the button to "off" under the mouse once you don't use it for a long time, and remove the batteries if you do not use this device for at least two weeks. Warning: (Troubleshooting) 1. Please do not use the wireless optical mouse on a desk which is made of glass, mirror, iron, or black velvet. Also, a flat surface is necessary or the optical sensor will be error easily. When you use the wireless optical mouse on a desk that is made of metal, try using a pad and reduce the receiving distance. 2. Before the first installation is completed (channel setting ready), the mouse will not work in DOS. 3. The wireless optical mouse channel provides 256 ID-codes, and it automatically selects the ID # for your mouse. You can only set up one wireless optical mouse at a time. But if you have additional wireless optical mouse sets in an area of 10 square meters, more interference will occur between the receiver and your mouse. ENGLISH 2 4. If you feel the mouse does not move smooth as usual, then the batteries have lost their charge and need to be replaced. Remember do not put the batteries in the wrong direction. 5. The wireless optical mouse with radio frequency gives you free movement and an enjoyable experience. For optimal performance, place the receiver at least 8 inches (about 20cm) away from the mouse and other electrical devices, such as the computer, monitor and etc. Software Installation 1. Make sure the mouse is connected to the computer. 2. Put the CD driver into the CD drive. 3. Follow the instructions on the screen to finish the software installation. Change the Faceplate Push the button underneath the mouse towards the front and the faceplate will pop off. Mouse button definition: 1. Left Button: Provides traditional mouse functions such as click, double click and drag. 2. Right button: Provides traditional mouse click function. 3. Roller button/Middle button: Scroll the button to surf the Internet and Windows documents. 4. Turbo roller button: Provides quick roller- up. 5. Turbo roller button: Provides quick roller down. 6. Flip 3D button: Provides fast access to all opened windows in one easy 3D view.

Date May 28, 2007 Federal Communications Commission Authorization and Evaluation Division FCC ID: FSUGMZI1 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ____________________ KYE SYSTEMS CORP.

Compliance Certification Services Inc. Report No.: 70503202 Date of Issue: May 22, 2007 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 70503202 Date of Issue: May 22, 2007 Page Compliance Certification Services Inc. Report No.: 70503202 Date of Issue: May 22, 2007 Page

FCC ID LABEL FORMAT AND LOCATION KYE SYSTEMS CORP. FCC ID: FSUGMZI1 FCC ID: FSUGMZI1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Compliance Certification Services Inc. Report No.: 70503202 Date of Issue: May 22, 2007 Page Compliance Certification Services Inc. Report No.: 70503202 Date of Issue: May 22, 2007 Page

Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 1 Total Page: 18 Rev. 00 FCC CFR 47 PART 15 SUBPART C TEST REPORT For KYE SYSTEMS CORP. NAVIGATOR 600 Model: GM-070006/T Trade Name: Genius Issued to KYE SYSTEMS CORP. No. 492, Sec. 5, Chung Hsin Rd., San Chung, Taipei Hsien, 24160, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. Sindian BU No.163-1, Jhongsheng Rd., Sindian City, Taipei County 23151, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION......................................................................................3 2. EUT DESCRIPTION............................................................................................................4 3. TEST METHODOLOGY.....................................................................................................5 3.1 EUT CONFIGURATION....................................................................................................5 3.2 EUT EXERCISE..............................................................................................................5 3.3 GENERAL TEST PROCEDURES........................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.....................................6 3.5 DESCRIPTION OF TEST MODES.......................................................................................6 4. INSTRUMENT CALIBRATION..........................................................................................7 5. FACILITIES AND ACCREDITATIONS.............................................................................7 5.1 FACILITIES...................................................................................................................7 5.2 EQUIPMENT..................................................................................................................7 5.3 LABORATORY ACCREDITATIONS AND LISTINGS.............................................................7 5.4 TABLE PF ACCREDITATIONS AND LISTINGS....................................................................8 6. SETUP OF EQUIPMENT UNDER TEST............................................................................9 6.1 SETUP CONFIGURATION OF EUT....................................................................................9 6.2 SUPPORT EQUIPMENT...................................................................................................9 7. FCC PART 15.227 REQUIREMENTS...............................................................................10 7.1 26 dB BANDWIDTH.....................................................................................................10 7.2 RADIATED EMISSIONS.................................................................................................12 7.3 POWERLINE CONDUCTED EMISSIONS..........................................................................17 8. APPENDIX I - PHOTOGRAPHS OF TEST SETUP..........................................................18 Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: KYE SYSTEMS CORP. No. 492, Sec. 5, Chung Hsin Rd., San Chung, Taipei Hsien, 24160, Taiwan, R.O.C. Equipment Under Test: NAVIGATOR 600 Trade Name: Genius Model: GM-070006/T Model Difference: See Item 2 of this report Report Number: 70503202-RP1 Date of Test: May 07, 2007 & May 09, 2007 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product NAVIGATOR 600 Trade Name Genius Model GM-070006/T Power Supply 3VDC From Battery AA size X 2 pcs. Operate Frequency 27.045MHz Modulation Technique Frequency Shift Keying (FSK) Number of Channels 1 Channel Operating Mode Simplex Antenna Designation Internal loop, which is built in EUT Note: The product is a composite system which includes Transmitter and Receiver. This submittal(s) (test report) is intended for FCC ID: FSUGMZI1 filing to comply with Section 15.227 of the FCC Part 15 Subpart C Rules. The composite system (digital device) is compliance with Subpart B is authorized under a DoC procedure. Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 15 Subpart C. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The calibrated antennas used to sample the radiated field strength are mounted on a non-conductive, motorized antenna mast 3 or …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 70503202-RP1 FCC ID: FSUGMZI1 Date of Issue: May 22, 2007 Page 18 Rev. 00 8. APPENDIX I - PHOTOGRAPHS OF TEST SETUP RADIATED EMISSIONS TEST
