FSUGMZJ1Media Pointer T950, Media Pointer 100

KYE SYSTEMS CORP.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 08, 2009
Application Purpose: Original Equipment
Date of Application: Dec 06, 2009
Equipment Note: Media Pointer T950, Media Pointer 100
Frequency Range: 2402.00000000 - 2480.00000000
Company: KYE SYSTEMS CORP.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

English 1 Media Pointer T905 / GM-090013 How to use the Presenter: 1. Insert two AAA batteries in the Media Pointer. 2. Plug the receiver unit into any USB port. ID identification The Media Pointer ID has been factory preset. 1. The 2.4GHz DSSS technology works up to 15 meters and has a anti-interference function. Media Pointer features: 1. Power switch and mode switch. (P for presenter mode; M for media mode) 2. The mini receiver can be stored inside the Media Pointer for easy storage. Button Functions: Presenter mode Media mode 1 Mouse Sensor Mouse Sensor 2 Previous Page Volume Down 3 Next Page Volume Up 4 Laser point Laser point 5 Switch Mode Switch Mode 6 F5/ESC N/A 7 Blank screen N/A 8 N/A Forward 9 N/A Rewind 10 N/A Play / Pause This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. English 2 Media Pointer 100 / GM-090012 How to use the Presenter: 3. Insert two AAA batteries in the Media Pointer. 4. Plug the receiver unit into any USB port. ID identification The Media Pointer ID has been factory preset. 1. The 2.4GHz DSSS technology works up to 15 meters and has a anti-interference function. Media Pointer features: 3. Power switch and mode switch. (P for presenter mode; M for media mode) 4. The mini receiver can be stored inside the Media Pointer for easy storage. Button Functions: 1 Start Presentation / Exit from full screen 2 Blank screen 3 Previous Page 4 Next Page 5 Laser Beam This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

External Photos

ID Label/Location Info

KEY SYSTEMS CORP. (Genius) FCC ID.: FSUGMZJ1 NO. 492, SEC. 5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 24160, TAIWAN, R.O.C..Tel : +886-2-2995-6645 FCC ID Label KEY SYSTEMS CORP. (Genius) FCC ID.: FSUGMZJ1 NO. 492, SEC. 5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 24160, TAIWAN, R.O.C..Tel : +886-2-2995-6645 The FCC ID Label will be placed on the equipment as shown in the photograph below.

ID Label/Location Info

Internal Photos

Report No.: 09B251R-RFUSP44V01 Page : 1 Attachment 2 : EUT Detailed Photographs Media Pointer T905 / GM-090013 (1) EUT Photo (2) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 2 (3) EUT Photo (4) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 3 (5) EUT Photo (6) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 4 (7) EUT Photo (8) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 5 (9) EUT Photo (10) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 6 (11) EUT Photo (12) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 7 (13) EUT Photo (14) EUT Photo

Internal Photos

Report No.: 09B251R-RFUSP44V01 Page : 8 (15) EUT Photo Media Pointer 100 / GM-090012 (16) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 9 (17) EUT Photo (18) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 10 (19) EUT Photo (20) EUT Photo Report No.: 09B251R-RFUSP44V01 Page : 11 (21) EUT Photo

Operational Description

Report No. 09B251R-RFUSP44V01 Page: 5 of 41 1.2. Operational Description The EUT is Media Pointer T905 / 100 built-in 2.4GHz transceiver. The operation frequency is from 2402 MHz to 2480MHz with GFSK modulation. The signal will be transmitted through 2.4 GHz RF signal from the Chip antenna. DC 3V (Power by Battery) shall be provided for EUT operation.

Test Report

Report No. 09B251R-RFUSP44V01 Page: 1 of 41 Test Report Product Name Media Pointer T905, Media Pointer 100 Model No. GM-090013, GM-090012 FCC ID FSUGMZJ1 Applicant KYE SYSTEMS CORP. (Genius) Address NO. 492, SEC. 5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 24160, TAIWAN, R.O .C. Date of Receipt Nov. 02, 2009 Issued Date Nov. 25, 2009 Report No. 09B251R-RFUSP44V01 Report Version V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 09B251R-RFUSP44V01 Page: 2 of 41 Test Report Certification Issued Date: Nov. 25, 2009 Report No.: 09B251R-RFUSP44V01 Test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Product Name Media Pointer T905, Media Pointer 100 Applicant KYE SYSTEMS CORP. (Genius) Address NO. 492, SEC. 5, CHUNG HSIN RD., SAN CHUNG, TAIPEI HSIEN, 24160, TAIWAN, R.O .C. Manufacturer KYE SYSTEMS CORP. (Genius) Model No. GM-090013, GM-090012 EUT Rated Voltage DC 3V(Power by battery) EUT Test Voltage DC 3V(Power by battery) Trade Name Genius Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2003 Test Result Complied Documented By : ( Adm. Specialist / Joanne Lin ) Tested By : ( Engineer / NONO Chang) Approved By : ( Manager / Vincent Lin) Report No. 09B251R-RFUSP44V01 Page: 3 of 41 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................4 1.1. EUT Description............................................................................................................................4 1.2. Operational Description ................................................................................................................5 1.3. Tested System Datails....................................................................................................................6 1.4. Configuration of Test System ........................................................................................................6 1.5. EUT Exercise Software .................................................................................................................6 1.6. Test Facility ...................................................................................................................................7 2. Radiated Emission .......................................................................................................................8 2.1. Test Equipment..............................................................................................................................8 2.2. Test Setup ......................................................................................................................................9 2.3. Limits ..........................................................................................................................................10 2.4. Test Procedure .............................................................................................................................10 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Radiated Emission................................................................................................12 3. Band Edge ..................................................................................................................................28 3.1. Test Equipment............................................................................................................................28 3.2. Test Setup ....................................................................................................................................28 3.3. Limits ..........................................................................................................................................29 3.4. Test Procedure .............................................................................................................................29 3.5. Uncertainty ..................................................................................................................................29 3.6. Test Result of Band Edge ............................................................................................................30 4. Duty Cycle ..................................................................................................................................36 4.1. Test Equipment............................................................................................................................36 4.2. Test Setup ....................................................................................................................................36 4.3. Uncertainty ..................................................................................................................................36 4.4. Test Result of Duty Cycle............................................................................................................37 5. EMI Reduction Method During Compliance Testing ............................................................39 Attachment 1: EUT Test Photographs Attachment 2: EUT Detailed Photographs Report No. 09B251R-RFUSP44V01 Page: 4 of 41 1. GENERAL INFORMATION 1.1. EUT Description Product Name Media Pointer T905, Media Pointer 100 Trade Name Genius Model No. GM-090013, GM-090012 FCC ID FSUGMZJ1 Frequency Range 2402~2480MHz Channel Control Auto Channel Separation 1MHz Antenna Type Chip Antenna Channel Number 79 Type of Modulati…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 09B251R-RFUSP44V01 Page : 1 of 2 Attachment 1: EUT Test Setup Photographs Front View of Radiated Test Back View of Radiated Test Report No.: 09B251R-RFUSP44V01 Page : 2 of 2 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)
