FSUGMZJGERGO 7000

English 1 Ergo 7000 is a classic model to celebrate Genius’s 26 th anniversary. To explore its philosophy of providing a comfort and trendy hardware, Ergo 7000 brings back the memories of the first mouse of your life and let the youth generation get a chance of a reliable fresh mouse. Hardware Installation Note: Supports Windows 7/Vista/XP 1. You can connect the receiver to a USB port of a PC. 2. Install one AA battery in the mouse as instructed. 3. Make sure that you have switched on the power switch underneath the mouse. Factory Settings 1. Next Page: Go to last page of Internet Explorer 2. Previous Page: Go to last page of Internet Explorer 3. Left Button: Provides traditional mouse functions like click, double click and drag. 4. Magic-Roller: Press the “Magic-Roller” to surf the Internet and Windows documents. 5. Right Button: Provides traditional mouse click functions. Note: Download the programmable driver from Genius website at www.geniusnet.com Warning: (Troubleshooting) 1. Do not use the wireless optical/laser mouse on a desk which is made of glass or mirror. 2. The connection of the wireless device is factory preset, so when you plug the USB receiver into any USB port, the connection between the micro receiver and the mouse will be established automatically. 3. In case your PC did not install the hardware successfully, remove the micro receiver from the USB port and go Human Interface Devices under Device Manager to remove the mouse then plug in the micro receiver to a USB port again. 4. If you feel the mouse does not move smooth as usual, it is possible the batteries have lost their charge so you need to replace them. Remember to put the batteries in the correct direction. English 2 Note: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. (15.21) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.(15.19(a)(3))

DOC Letter Mar. 01, 2011 Federal Communications Commission Authorization and Evaluation Division Dear Regulatory Authority, We, the undersigned, hereby declare that FCC Part 15B Declaration of Conformity procedures will be applied to the digital device portion of the following product: Product: Ergo 7000 Model: GM-100020/T FCC Part 15B DoC report number: F1112701 This Device complies with Part 15B DoC of the FCC rules, operation is subject to the following two conditions. This device may not cause harmful interference and, This device must accept any interference received, Including interference that may cause undesired operation TEST LABORATORY Global Certification Corp. No. 146, Shiang Charng Rd., Sec. 2, Hsi Chih, Taipei Hsien 221, Taiwan, R.O.C. Accredited Lab. Assigned under FCC number: TW1030 Sincerely,

Request for Confidentiality To: Federal Communications Commission Authorization and Evaluation Division Subject: Confidentiality Request regarding application for certification of FCC ID: FSUGMZJG Dear Madam or Sir: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: z Block diagram - Ergo 7000 Block Diagram.pdf z Operational description - Ergo 7000 Operation Description.pdf z Schematic Diagram- Ergo 7000 Schematic.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Ming Huang Lee

Global Certification Corp. PHOTO OF EUT PHOTOS OF EUT Global Certification Corp. Report No. : 1112701 PHOTO OF EUT PHOTO OF EUT Front View of EUT Rear View of EUT

Label location

Global Certification Corp. Report No. : 1112701 PHOTO OF EUT PHOTO OF EUT Inside View of EUT Global Certification Corp. Report No. : 1112701 PHOTO OF EUT PHOTO OF EUT Component Side of Main Board -1 Component Side of Main Board -1

Global Certification Corp. Date of Issue: Feb. 09,2011 Report No:F1112701 Page1/29 FCC 47 CFR PART 15 SUBPART C TEST REPORT FOR Product Name: Ergo 7000 Model : GM-100020/T Trade Name: Genius Issued to KYE SYSTEMS CORP. No.492, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Issued by Global Certification Corp. EMC Test Site Sijhih office and Lab No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221, Taiwan (R.O.C.) Note: This test refers exclusively to the test presented test model and sample. This report shall not be reproduced except in full, without the written approval of Global Certification Corporation. This document may be altered or revised by Global Certification Corporation. Personnel only, and shall be noted in the revision section of the document. Global Certification Corp. Date of Issue: Feb. 09,2011 Report No:F1112701 Page2/29 TABLE OF CONTENTS ----------------------------------------------------------------------------------------------------- 2 1. GENERAL INFORMATION -------------------------------------------------------------------------------------------------------- 3 1.1 DESCRIPTION OF THE TESTED SAMPLES----------------------------------------------------------------------------------------------- 4 2. TEST METHODOLOGY ------------------------------------------------------------------------------------------------------------- 5 2.1 GENERAL TEST PROCEDURES --------------------------------------------------------------------------------------------------- 5 2.2 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ----------------------------------------------------------------- 5 2.3 DESCRIPTION OF TEST MODES -------------------------------------------------------------------------------------------------- 6 2.4 DESCRIPTION OF THE SUPPORT EQUIPMENTS ----------------------------------------------------------------------------- 7 3. TEST AND MEASUREMENT EQUIPMENT ----------------------------------------------------------------------------------- 9 3.1 CALIBRATION----------------------------------------------------------------------------------------------------------------------- 9 3.2 EQUIPMENT-------------------------------------------------------------------------------------------------------------------------- 9 4. SECTION 15.249 REQUIREMENTS (FUNDAMENTAL/ HARMONICS) ----------------------------------------------10 4.1 TEST SETUP------------------------------------------------------------------------------------------------------------------------10 4.2 LIMIT-------------------------------------------------------------------------------------------------------------------------------10 4.3 RESULT: PASSED --------------------------------------------------------------------------------------------------------------10 4.4 TEST DATA: ------------------------------------------------------------------------------------------------------------------------10 5. SECTION 15.205 REQUIREMENTS (BAND EDGE)-------------------------------------------------------------------------19 5.1 TEST SETUP------------------------------------------------------------------------------------------------------------------------19 5.2 LIMIT-------------------------------------------------------------------------------------------------------------------------------19 5.3 RESULT: PASSED --------------------------------------------------------------------------------------------------------------20 5.4 TEST DATA: ------------------------------------------------------------------------------------------------------------------------20 6. SECTION 15.209 REQUIREMENTS (GENERAL RADIATED EMISSION) -------------------------------------------24 6.1 TEST SETUP------------------------------------------------------------------------------------------------------------------------24 6.2 LIMIT-------------------------------------------------------------------------------------------------------------------------------25 6.3 TEST PROCEDURE-----------------------------------------------------------------------------------------------------------------26 6.4 RESULT: PASSED ----------------------------------------------------------------------------------------------------------------26 6.5 TEST DATA: ------------------------------------------------------------------------------------------------------------------------27 7. SECTION 15.207 REQUIREMENTS (POWERLINE CONDUCTED EMISSIONS) ----------------------------------29 APPENDIX 1 PHOTOS OF TEST CONFIGURATION APPENDIX 3 PHOTOS OF EUT Global Certification Corp. Date of Issue: Feb. 09,2011 Report No:F1112701 Page3/29 1. GENERAL INFORMATION Applicant :KYE SYSTEMS CORP. Address :No.492, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Manufacturer :KYE SYSTEMS CORP. Address :No.492, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) EUT : Ergo 7000 Model Name :GM-100020/T Model Differences :The difference among series model shown above is the appearance. The model, GM-100020/T, is the testing sample, and the final test data are shown on this test report Is here with confirmed to comply with the requirements set out in the FCC Rules and Regulations Part 15 Subpart C and the measurement procedures were according to ANSI C63.4-2003. The said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. FCC part 15 subpart C Receipt Date : 01/27/2011 Final Test Date : 02/09/2011 Taipei, Taiwan Feb. 09, 2011 Alex Chou / Manager (Place) (Date) (Signature) Designation Number: TW1030 Global Certification Corp. Date of Issue: Feb. 09,2011 Report No:F1112701 Page4/29 1.1 DESCRIPTION OF THE TESTED SAMPLES EUT Name : Ergo 7000 Model Number : GM-100020/T FCC ID : FSUGMZJG Input Voltage : 1.5Vdc Power From Inside Outside Adaptor BATTERY AC Power Source DC Power Source Support Unit PC Operate Frequ…

Text truncated - open the document above for the full version.

Global Certification Corp. Appendix 1 PHOTOS OF TEST CONFIGURATION Global Certification Corp. Report No. : F1112701 Appendix 1 : 1 of 1 Front View
