FSUGMZK4WIRELESS RING PRO(GM-120001/T)

English - 1 - Getting Started: 1. Before you can use this device, it needs to be charged, so connect the micro USB cable to Ring Air and any USB port on your PC. It takes approximately two hours to fully charge. 2. Connect the USB receiver to any USB port on your PC. 3. Install the driver by following the instructions on the screen to finish the software installation. 4. After the driver is installed, you’ll find the Ring Series icon in the taskbar. Button definitions: 1. Air Cursor/Scroll switch button: Press the button to switch between air cursor and scrolling mode. -Air cursor mode: you can move the cursor with your thumb on the touch panel -Scroll mode: you can use your thumb to slide up/down/left/right. 2. Drag: To drag/move an object, press the button to begin the drag and press any button to turn the drag off. 3. Right Mouse Button: Press the button to activate right mouse button functions. 4. Back page: Return to previous page while surfing the Internet. 5. Left Mouse Button: Press the button to activate left mouse button functions or use your thumb to glide over the touch panel to move the cursor or activate scroll feature. -Switch Function: Power switch On/Off press for three seconds. -Tracing Control: Cursor movement. Note: 1. 4D scrolling and “On Screen Display” (OSD) only work when the driver is installed. 2. Ring Pro software: Click on the resolution and click apply after your selection: Dynamic/ 250 dpi/ 500 dpi/ 750 dpi/ 1000 dpi/ 1250 dpi The LED bar will flash after you press any button on the Ring Pro. 250 dpi (1 flash), 500dpi (2 flashes), 750 dpi (3 flashes), etc... 3. LED indicator: Indicates device Starting/Charging/Battery low/DPI status - Starting: Switch ON, LED lights up for three seconds to initiate. - Charging: LED light is ON. - Fully charged: LED light is OFF. - Battery low: Low power level, LED will flash at a slow speed to indicate low battery power. English - 2 - FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, according to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: 1. Reorient the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Any special accessories needed for compliance must be specified in the instruction manual. Warning: A shielded-type power cord is required in order to meet FCC emission limits and also to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord be used. Use only shielded cables to connect I/O devices to this equipment. CAUSION: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. IC statement: This Class B digital apparatus complies with Canadian ICES-003.Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. FCC ID: FSUGMZK4

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. PHOTOS OF EUT Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. Port

Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) Sample of FCC Label FCC ID：FSUGMZK4

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. TOP inside (TX) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. PCB-1 (TX) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. PCB-2 (TX) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. CASE (TX) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. BATTERY (TX) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. CABLE (TX)

TECHNOLOGICAL SPEC. 1. Product Name： Ring Pro Model： GM-120001/T 2. Power Source： ■ DC 5 V, 80 mA; □ AC V, A 3. Frequency Band： 2.4 GHz ~ 2.4835 GHz Carrier Frequency： 2.402 GHz ~ 2.478 GHz 4. Number of Channel： 20 5. Channel Spacing： 6. RF Output Power (ERP or EIRP) ： 92.55 dBuV/m W 7. I.F.： MHz; L.O.： MHz 8. Modulation Type： GFSK 9. Duty Cycle： % 10. Mode of operation (duplex, simplex, half duplex) ： Duplex 11. Bit Rate of Transmission： 12. Antenna Type： Chip Antenna 13. Antenna gain： 3 dBi 14. Operating Temperature Range： -20 ~ 50 °C 15. Channel bandwidth ： MHz

Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A12070504 Report No.:FCCA12070504 FCC ID : FSUGMZK4 Page: 1 of 47 Date: Jul. 17, 2012 FMNG-059.10 REPORT Product Name: Ring Pro Model No.: GM-120001/T Applicant: KYE SYSTEMS CORP. (Genius) No. 492, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Date of Receipt: Jul. 05, 2012 Finished date of Test: Jul. 17, 2012 Applicable Standards: 47 CFR Part 15, Subpart C 47 CFR Part 15, Subpart B ANSI C63.4: 2003 We, Spectrum Research & Testing Laboratory Inc., hereby certify that one sample of the above was tested in our laboratory with positive results according to the above-mentioned standards. The records in the report are an accurate account of the results. Details of the results are given in the subsequent pages of this report. Tested By : , Date: Approved By : (Richard Lin) , Date: ( Johnson Ho, Director ) Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A12070504 Report No.:FCC A12070504 FCC ID : FSUGMZK4 Page: 2 of 47 Date: Jul. 17, 2012 FMNG-059.10 REPORT Table of Contents 1. DOCUMENT POLICY AND TEST STATEMENT...................................................3 1.1 DOCUMENT POLICY.........................................................................................3 1.2 TEST STATEMENT............................................................................................3 1.3 EUT MODIFICATION..........................................................................................3 2. DESCRIPTION OF EUT AND TEST MODE.........................................................4 2.1 GENERAL DESCRIPTION OF EUT...................................................................4 2.2 USED CHANNEL AND FREQUENCY TABLE....................................................4 2.3 DESCRIPTION OF EUT INTERNAL DEVICE....................................................5 2.4 EUT OPERATING CONDITION..........................................................................5 2.5 DESCRIPTION OF TEST MODE........................................................................5 2.6 DESCRIPTION OF SUPPORT UNIT..................................................................6 3. DESCRIPTION OF APPLIED STANDARDS.........................................................7 3.1 SUMMARY OF TEST RESULTS........................................................................7 4. TECHNICAL CHARACTERISTICS TEST.............................................................8 4.1 BAND EDGE TEST.............................................................................................8 4.1.1 LIMIT................................................................................................................8 4.1.2 TEST EQUIPMENT.........................................................................................9 4.1.3 TEST SETUP.................................................................................................10 4.1.4 TEST PROCEDURE......................................................................................11 4.1.5 EUT OPERATING CONDITION.....................................................................11 4.1.6 TEST RESULT...............................................................................................12 4.2 CONDUCTED EMISSION TEST......................................................................16 4.2.1 LIMIT..............................................................................................................16 4.2.2 TEST EQUIPMENT.......................................................................................16 4.2.3 TEST SETUP.................................................................................................17 4.2.4 TEST PROCEDURE......................................................................................17 4.2.5 TEST RESULT...............................................................................................18 4.3 RADIATED EMISSION TEST...........................................................................21 4.3.1 LIMIT..............................................................................................................21 4.3.2 TEST EQUIPMENT.......................................................................................22 4.3.3 TEST SET-UP................................................................................................23 4.3.4 TEST PROCEDURE......................................................................................25 4.3.5 TEST RESULT...............................................................................................26 5. ANTENNA APPLICATION...................................................................................42 5.1 ANTENNA REQUIREMENT.............................................................................42 5.2 RESULT............................................................................................................42 6. PHOTOS OF TESTING......................................................................................43 7. TERMS OF ABBREVIATION..............................................................................47 Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A12070504 Report No.:FCC A12070504 FCC ID : FSUGMZK4 Page: 3 of 47 Date: Jul. 17, 2012 FMNG-059.10 REPORT 1. DOCUMENT POLICY AND TEST STATEMENT 1.1 DOCUMENT POLICY - The report shall not be reproduced except in full, without the written approval of SRT Lab, Inc. 1.2 TEST STATEMENT - The test results in the report apply only to the unit tested by SRT Lab. - There was no deviation from the requirements of test standards during the test. - DC p…

Text truncated - open the document above for the full version.

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. PHOTOS OF TESTING - Conducted test (Charge) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. - Radiated test (below 30M , TX & Standby) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. - Radiated test (below 1G , TX & Standby) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Taiwan, R.O.C. - Radiated test (above 1G , TX & Standby)
