FSUGMZKLNX-6500

English 1 Hardware Installation 1. You can connect the receiver to a USB port of a PC. 2. Install one AA battery in the mouse as instructed. 3. Make sure that you have switched on the power switch underneath the mouse. Factory Settings 1. Left Button: Provides traditional mouse functions like click double click and drag. 2. Magic-Roller: Press the “Magic-Roller” to surf the Internet and Windows documents. 3. Right Button: Provides traditional mouse click functions. Warning: (Troubleshooting) 1. Do not use the wireless optical/laser mouse on a desk which is made of glass or mirror. 2. The connection of the wireless device is factory preset, so when you plug the USB receiver into any USB port, the connection between the micro receiver and the mouse will be established automatically. 3. In case your PC did not install the hardware successfully, remove the micro receiver from the USB port and go Human Interface Devices under Device Manager to remove the mouse then plug in the micro receiver to a USB port again. 4. If you feel the mouse does not move smooth as usual, it is possible the batteries have lost their charge so you need to replace them. Remember to put the batteries in the correct direction. Federal Communications Commission (FCC) Notice: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Notice English - 1 3 F ujitsu Technology Solut ions 31

Confidentiality Letter Date: _ January 5, 2013 Subject: Confidentiality Request for FCC ID: FSUGMZKL and IC ID: Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent User’s Manual KYE SYSTEMS CORP._ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: __________________________ _ Lee _ (Signature/Manager) (Print name)

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 12-1 12. PHOTOGRAPH OF EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 12-2 Figure 3 General Appearance of the EUT Figure 4 Inside of the EUT

FCC ID : FSUGMZKL RATING: DC1.5V 6mA(MAX) M/N: GM-120020/T Product Name: NX-6500 www.geniusnet.com WV 1 2 N X A 0 0 0 0 1 Made in China 53 m m 45 mm Label Location

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 12-3 Figure 5 Inside of the EUT Figure 6 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 12-4 Figure 7 Inside of the EUT

GM-120020/T NX-6500 BOM Listing 1/1 IDVALUEREFUNITREMARK Resistance 1RFT0402-510JTR11 2RFT0402-101JTR9.R242 3RFT0402-222JTR31 4CR0402-20K±5%R41 5CR0402-51K±1%R15.R162 6RFT0402-684JTR21 7RFT0402-105JTR6.R72 8 Capacitance 90402CG1R0C500NTC31 100402CG160J500NTC7.C82 110402B104K100NTC1.C4.C5.C9.C11.C126 120603F475Z100NTC61 130603X106M6R3NTC201 140805X226M6R3NTC13.C142 15 Inductance 16VHF100505H2N2STL11 17PK0406-221KL21 18 Diode 19SOD323-1N5819D11 20 Crystal 21G-SMD3225A-12.000MHz-4PAD/10pFX11 22 LED 23EC02-0603QRC/ELED21 24φ5MM/IR/YP034/850nmLED41 25 IC 26CE8301A192P±2%/SOT89U11 27CY7C60445-3X14C (CG7595AS)U21 28CYRF8935A-4X14CU31 29PAW3204DB-TJ3LU41 30 Switch 31MI126703D06SW1.SW2.SW33 32CEN981112R10/H=11mm/1.74mmSW131 33A06G/Φ0.6MM/Neg Spring 1/Φ0.5MM BATT"-"1 34KYE06/Φ0.6MM/Pos Spring/Φ0.5MM BATT"+"1 35KYE06-AV10 1

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 8-1 8. RADIO FRREQUENCY EXPOSURE COMPLIANCE RESULT : PASS Test standard : FCC KDB Publication 447498 Since maximum peak output power of the transmitter is<10mW=10dBm. i.e.0.009346mW<10mW, hence the EUT is exclueded from SAR evaluation according to FCC KDB Publication 447498 D01:General RF Exposure Guide.

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of KYE SYSTEMS CORP. NX-6500 Model Number: GM-120020/T FCC ID: FSUGMZKL Prepared for : KYE SYSTEMS CORP. No.492, Sec.5 Chongxin Rd., Sanchong Dist., New Taiper City 24160, Taiwan (R.O.C) Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F12278 Date of Test ： Dec.23~24, 2012 Date of Report ： Jan.09, 2013 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS.......................................................... 1-1 1.1. Description of Standards and Results .................................................................................. 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) ............................................................................................... 2-1 2.2. EUT Configuration and operation conditions for test.......................................................... 2-1 2.3. Test Facility ......................................................................................................................... 2-2 2.4. Measurement Uncertainty (95% confidence levels, k=2) .................................................... 2-2 3. POWER LINE CONDUCTED EMISSION TEST ....................................................... 3-1 4. RADIATED EMISSION TEST ...................................................................................... 4-1 4.1. Test Equipment .................................................................................................................... 4-1 4.2. Block Diagram of Test Setup ............................................................................................... 4-1 4.3. Radiated Emission Limit Standard: FCC 15.209 and 15.249 .............................................. 4-2 4.4. EUT Configuration on Test.................................................................................................. 4-3 4.5. Operating Condition of EUT................................................................................................ 4-3 4.6. Test Procedure...................................................................................................................... 4-3 4.7. Radiated Emission Test Results ........................................................................................... 4-3 5. 20 DB BANDWIDTH TEST ........................................................................................... 5-1 5.1. Test Equipment .................................................................................................................... 5-1 5.2. Limit..................................................................................................................................... 5-1 5.3. Test Results .......................................................................................................................... 5-1 6. BAND EDGE COMPLIANCE TEST ............................................................................ 6-1 6.1. Test Equipment .................................................................................................................... 6-1 6.2. Limit..................................................................................................................................... 6-1 6.3. Test Produce ......................................................................................................................... 6-1 6.4. Test Results .......................................................................................................................... 6-1 7. ANTENNA REQUIREMENT ........................................................................................ 7-1 8. RADIO FRREQUENCY EXPOSURE COMPLIANCE.............................................. 8-1 9. TEST SOFTWARE.......................................................................................................... 9-1 10. DEVIATION TO TEST SPECIFICATIONS.............................................................. 10-1 11. PHOTOGRAPH OF TEST ........................................................................................... 11-1 11.1. Photos of Radiated Emission Test (30-1000MHz) ............................................................ 11-1 12. PHOTOGRAPH OF EUT ............................................................................................. 12-1 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 1-1 1. SUMMARY OF STANDARDS AND RESULTS 1.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below. EMISSION Description of Test Item Standard Results Radiated Emission Test FCC Part 15C: 15.209 FCC Part 15C: 15.249 ANSI C63.10-2009 PASS Band Edge Compliance Test FCC Part 15: 15.249 ANSI C63.10-2009 PASS 20dB Bandwidth Test FCC Part 15: 15.215 ANSI C63.10-2009 PASS R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:FSUGMZKL page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12278 2-1 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Product Name : NX-6500 Model Number : GM-120020/T FCC ID : FSUGMZKL Operation frequency : 2402MHz-2479MHz Antenna : Integrated PCB antenna, 0dBi gain Modulation : GFSK Power Supply : DC1.5V Applicant : KYE SYSTEMS CORP. No.492, Sec.5 Chongxin Rd., Sanchong Dist., New Taiper City 24160, Taiwan (R.O.C) Manufacturer : G. tech Technology Ltd. No.21, Jinding Industrial Park, West Jinfeng Road, Tangjiawan Town, Xiangzhou District Zhuhai Guangdong China Date of Te…
