FSUGMZKT2.4GHz Wireless Mouse

English -1- Hardware Installation 1. You can connect the receiver to a USB port of a PC. 2. Install two AA batteries in the mouse as instructed. 3. Make sure that you have switched on the power switch underneath the mouse. Button definitions in Windows 8: 1. Switch between Apps: Pressing the side button 1 allows you to switch between all open applications. 2. Charms panel: Press side button 2 to open up the Charms panel. 3. Left Button: Provides traditional mouse functions like click, double click and drag. 4. Magic-Roller: Spin the “Magic-Roller” to surf the Internet, scroll within apps or any Windows documents. 5. Right Button: Provides traditional mouse click functions. 6. When both buttons 1 and 2 are pressed at the same time, it will allow you to toggle between Windows 8 Metro interface and the last app used. English -2- Note: When buttons 3, 4 and 5 are pressed at the same time, it will allow you to change between Windows 8 and traditional mouse function mode. Button definitions in Windows 7/XP/Vista: 1. Previous Page: Go to last page of Internet Explorer 2. Next Page: Go to next page of Internet Explorer 3. Left Button: Provides traditional mouse functions like click, double click and drag. 4. Magic-Roller: Press the “Magic-Roller” to surf the Internet and Windows documents. 5. Right Button: Provides traditional mouse click functions. 6. DPI adjustment: The LED indicates will flash after you press this button. Default is 1200 dpi, 800 dpi (1 flash), 1200 dpi (2 flashes), and 1600 dpi (3 flashes). 7. Flying Scroll: Press and hold to move vertically or horizontally for 4-way scrolling. Please download 4-way scrolling driver from Genius website at www.geniusnet.com. Note: Download the programmable driver from Genius website at www.geniusnet.com Warning: (Troubleshooting) 1. Do not use the wireless optical/laser mouse on a desk which is made of glass or mirror. 2. The connection of the wireless device is factory preset, so when you plug the USB receiver into any USB port, the connection between the micro receiver and the mouse will be established automatically. 3. In case your PC did not install the hardware successfully, remove the micro receiver from the USB port and go Human Interface Devices under Device Manager to remove the mouse then plug in the micro receiver to a USB port again. 4. If you feel the mouse does not move smooth as usual, it is possible the batteries have lost their charge so you need to replace them. Remember to put the batteries in the correct direction. English 2 Note: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. (15.21) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.(15.19(a)(3)) FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Request for Confidentiality To: Federal Communications Commission Authorization and Evaluation Division Subject: Confidentiality Request regarding application for certification of FCC ID: FSUGMZKT Dear Madam or Sir: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below:  Block diagram –FSUGMZKT Block Diagram.pdf  Operational description - FSUGMZKT Operation Description.pdf  Schematic Diagram- FSUGMZKT Schematic Diagram.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, P. C. Lee

ETC Report No. : 13-07-RBF-030 Sheet 1 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 1. 2. ETC Report No. : 13-07-RBF-030 Sheet 2 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 3. 4. ETC Report No. : 13-07-RBF-030 Sheet 3 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 5. 6.

Label location

ETC Report No. : 13-07-RBF-030 Sheet 4 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 7. 8. ETC Report No. : 13-07-RBF-030 Sheet 5 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 9. 10. ETC Report No. : 13-07-RBF-030 Sheet 6 of 6 Sheets FCC ID. : FSUGMZKT CONSTRUCTED PHOTOS of EUT 11.

I FCC Part 15 EMI TEST REPORT of E.U.T. : Ergo 8800 MODEL : GM-130007/S FCC ID. : FSUGMZKT Frequency Range : 2402MHz~2480MHz for APPLICANT : KYE SYSTEMS CORP. ADDRESS : No.492, Sec.5, Chung Hsin Rd., San Chung Dist., New Taipei City, 24160, Taiwan, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5, DINGFU VIL., LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. TEL : (02)26023052 FAX: (02)26010910 http // www.etc.org.tw; e-mail [email protected] Report Number : 13-07-RBF-030 . ETC Report No. : 13-07-RBF-030 FCC ID. : FSUGMZKT II TEST REPORT CERTIFICATION Applicant : KYE SYSTEMS CORP. No.492, Sec.5, Chung Hsin Rd., San Chung Dist., New Taipei City, 24160, Taiwan, R.O.C. Manufacturer : Dongguan Kunying Computer Products Co., Ltd Baodun Industrial District, Houjie Town, Dongguan City, Guangdong Province, 523961 China Description of EUT a) Type of EUT : Ergo 8800 b) Trade Name : Genius c) Model No. : GM-130007/S d) Power Supply : DC 3.0V f) Frequency Range : 2402MHz~2480MHz; Regulation Applied : FCC Rules and Regulations Part 15 Subpart C I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. Summary of Tests Test Results Radiated Emission Pass Conducted Emission N/A Band Edge Requirement Pass ETC Report No. : 13-07-RBF-030 FCC ID. : FSUGMZKT III Date Test Item Received : Jul. 18, 2013 Date Test Campaign Completed : Jul. 26, 2013 Date of Issue : Aug. 12, 2013 Test Engineer : ( Jiapeng Chen, Engineer ) Approve & Authorized Signer : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 13-07-RBF-030 FCC ID. : FSUGMZKT IV Table of Contents Page Cover Page........................................................................................................I TEST REPORT CERTIFICATION...........................................................................II Table of Contents............................................................................................... 1 GENERAL INFORMATION ...................................................................................................... 1 1.1 Product Description...................................................................................................................... 1 1.2 Characteristics of Device ............................................................................................................. 1 1.3 Test Methodology ........................................................................................................................ 1 1.4 Test Facility.................................................................................................................................. 1 2 PROVISIONS APPLICABLE ..................................................................................................... 2 2.1 Definition ..................................................................................................................................... 2 2.2 Requirement for Compliance ....................................................................................................... 3 2.3 Restricted Bands of Operation ..................................................................................................... 5 2.4 Labeling Requirement .................................................................................................................. 5 2.5 User Information .......................................................................................................................... 6 3. SYSTEM TEST CONFIGURATION ......................................................................................... 7 3.1 Justification .................................................................................................................................. 7 3.2 Devices for Tested System........................................................................................................... 7 4 RADIATED EMISSION MEASUREMENT.............................................................................. 8 4.1 Applicable Standard ..................................................................................................................... 8 4.2 Measurement Procedure............................................................................................................... 8 4.3 Measuring Instrument ................................................................................................................ 10 4.4 Radiated Emission Data ............................................................................................................. 11 4.4.1 RF Portion ......................................................................................................................................... 11 4.4.2 Other Emissions ................................................................................................................................. 17 4.5 Field Strength Calculation ......................................................................................................... 19 4.6 Photos of Radiation Measuring Setup........................................................................................ 20 5 CONDUCTED EMISSION MEASUREMENT ....................................................................... 21 5.1 Standard Applicable ................................................................................................................... 21 6 ANTENNA REQUIREMENT ................................................................................................... 22 6.1 Standard Applicable ........................…

Text truncated - open the document above for the full version.

ETC Report No. : 13-07-RBF-030 Sheet 20 of 26 Sheets FCC ID. : FSUGMZKT 4.6 Photos of Radiation Measuring Setup
