FSUGMZL5Traveler 9020BT

KYE SYSTEMS CORP.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Mar 10, 2014
Application Purpose: Original Equipment
Date of Application: Mar 10, 2014
Equipment Note: Traveler 9020BT
Frequency Range: 2402.00000000 - 2480.00000000
Company: KYE SYSTEMS CORP.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

English - 1 - Hardware Installation 1. Install one AA or AAA battery in the mouse as instructed. 2. Make sure that you have switched on the power switch underneath the mouse. Mouse Button Assignments 1. Left Button: Provides traditional mouse functions like click, double click and drag. 2. Magic-Roller: Press the “Magic-Roller” to surf the Internet and Windows documents. 3. Right Button: Provides traditional mouse click functions. 4. Switch Device Button: Press this button to switch between PC or tablet device. Note: Download the programmable driver from our website: www.geniusnet.com Warning: (Troubleshooting) 1. Do not use the wireless optical/laser mouse on a desk which is made of glass or mirror. 2. The connection of the wireless device is factory preset, so when you plug the USB receiver into any USB port, the connection between the micro receiver and the mouse will be established automatically. 3. In case your PC did not install the hardware successfully, remove the micro receiver from the USB port and go Human Interface Devices under Device Manager to remove the mouse then plug in the micro receiver to a USB port again. 4. If you feel the mouse does not move smooth as usual, it is possible the battery has lost its charge so you need to replace it. Remember to put the battery in the correct direction. English - 2 - FCC : Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: _ Reorient or relocate the receiving antenna. _ Increase the separation between the equipment and receiver. English - 3 - _ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. _ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Cover Letter(s)

KYE SYSTEMS CORP. Date: 2014/2/21 Federal Communications Commission Authorization and Evaluation Division FCC ID: FSUGMZL5 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name：P.C. Lee Company name: KYE SYSTEMS CORP. Tel.：02-2995-6645 #3422 Fax：02-2995-4751

Cover Letter(s)

KYE SYSTEMS CORP. AGENCY AUTHORIZATION LETTER FCC ID: FSUGMZL5 Date: 2014/2/21 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Shenzhen Co. Ltd Dongguan Branch., to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BVDG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name ：P.C. Lee Company name: KYE SYSTEMS CORP. Tel.：02-2995-6645 #3422 Fax ：02-2995-4751

External Photos

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 3 Report Version 1 Reference No.:140220N046 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 3 Report Version 1 Reference No.:140220N046 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 3 Report Version 1 Reference No.:140220N046

Internal Photos

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 22 Report Version 1 Test Report No.: RF140220N046 TEST REPORT Applicant KYE SYSTEMS CORP. Address No. 492, Sec 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C). Manufacturer or Supplier KYE SYSTEMS CORP. Address No. 492, Sec 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C). Product Traveler 9020BT Brand Name Genius Model GM-130015 Additional Model & Model Difference N/A Date of tests Feb. 28 ~ Mar. 03, 2014 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C , Section 15.249(2012-10) CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Venless Long Project Engineer / EMC Department Approved by Glyn He Supervisor / EMC Department This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 22 Report Version 1 Test Report No.: RF140220N046 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 3 1 SUMMARY OF TEST RESULTS.................................................................................................... 4 2 MEASUREMENT UNCERTAINTY ................................................................................................ 4 3 GENERAL INFORMATION ............................................................................................................ 5 3.1 GENERAL DESCRIPTION OF EUT........................................................................................... 5 3.2 DESCRIPTION OF TEST MODES............................................................................................. 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS............................................................ 7 3.4 DESCRIPTION OF SUPPORT UNITS....................................................................................... 7 4 TEST TYPES AND RESULTS........................................................................................................ 8 4.1 RADIATED EMISSION MEASUREMENT .................................................................................. 8 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ........................................................ 8 4.1.2 TEST INSTRUMENTS......................................................................................................... 9 4.1.3 TEST PROCEDURES ....................................................................................................... 10 4.1.4 DEVIATION FROM TEST STANDARD ..............................................................................11 4.1.5 TEST SETUP......................................................................................................................11 4.1.6 EUT OPERATING CONDITIONS .......................................................................................11 4.1.7 TEST RESULTS ................................................................................................................ 12 4.2 20dB BANDWIDTH MEASUREMENT ..................................................................................... 17 4.2.1 LIMITS OF 20dB BANDWIDTH MEASUREMENT ...........................................................17 4.2.2 TEST INSTRUMENTS ...................................................................................................... 17 4.2.3 TEST PROCEDURE ......................................................................................................... 17 4.2.4 DEVIATION FROM TEST STANDARD............................................................................. 17 4.2.5 TEST SETUP .................................................................................................................... 18 4.2.6 EUT OPERATING CONDITIONS ..................................................................................... 18 4.2.7 TEST RESULTS................................................................................................................ 18 5 PHOTOGRAPHS OF THE TEST CONFIGURATION .................................................................. 21 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB................................................................................................…
