Micro Traveler 900S (GM-090021-V2) English 1 Hardware Installation Note: Supports Windows 7/Vista/XP 1. You can connect the receiver to a USB port of a PC. 2. Install one AAA battery in the mouse. 3. Make sure that you have switched on the power switch underneath the mouse. 4. Stick-N-Go: attach the ‘Click Mount’ on your notebook in a convenient position first, then you can attach the mouse on your notebook as shown to avoid dropping your mouse. Warning: (Troubleshooting) 1. Do not use the wireless optical/laser mouse on a desk which is made of glass or mirror. 2. The connection of the wireless device is factory preset, so when you plug the USB receiver into any USB port, the connection between the micro receiver and the mouse will be established automatically. 3. In case your PC did not install the hardware successfully, remove the micro receiver from the USB port and go Human Interface Devices under Device Manager to remove the mouse then plug in the micro receiver to a USB port again. 4. If you feel the mouse does not move smooth as usual, it is possible the batteries have lost their charge so you need to replace them. Remember to put the batteries in the correct direction. Factory Settings 1. Left Button: Provides traditional mouse functions like click, double click and drag. 2. Magic-Roller: Press the “Magic-Roller” to surf the Internet and Windows documents. 3. Right Button: Provides traditional mouse click functions. Micro Traveler 900S (GM-090021-V2) English 2 FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, according to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: 1. Reorient the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Any special accessories needed for compliance must be specified in the instruction manual. CAUSION: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
DATE 2014.Mar. 05 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Johnson Ho, SPECTRUM RESEARCH & TESTING LABORATORY, INC.,_ _, (Name and address,person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with _KYE SYSTEMS CORP. Dated this 2014/03/05 Agency agreement expiration date: Usually Give 8 - 12 Months By: MH Lee Signature Printed Title: Section Supervisor On behalf of : KYE SYSTEMS CORP. Telephone: +886-2-2995-6645
DATE 2014.Mar. 05 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: FSUGMZL6 Product Name: Micro Traveler 900S (GM-090021-V2) Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.: z Test Setup Photos z External Photos z Internal Photos z User Manual These documents contain detailed system and equipment description and related information about the product which KYE SYSTEMS CORP. considers to be proprietary, confidential, and a custom design and, otherwise would not release to the general public. Since this design is a basis from which future technological products will evolve, KYE SYSTEMS CORP. considers this information to be of benefit to its competitors, and that the disclosure of information in these documents would give competitors an unfair advantage in the market. This request is being made retroactively due to an over site on our part. We understand that the information has been publicly available 180 days after date of grant. Dated this 2014/03/05 By: MH Lee Signature Printed Title: Section Supervisor On behalf of : KYE SYSTEMS CORP. Telephone: +886-2-2995-6645
DATE 2014.Mar. 05 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: FSUGMZL6 Product Name: Micro Traveler 900S (GM-090021-V2) Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2014/03/05 By: MH Lee Signature Printed Title: Section Supervisor On behalf of : KYE SYSTEMS CORP. Telephone: +886-2-2995-6645
Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) PHOTOS OF EUT - External
Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) PHOTOS OF EUT - Internal TOP Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) PCB RF Antenna Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) CASE
Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A14020802 Report No.:FCCA14020802 FCC ID : FSUGMZL6 Page: 1 of 34 Date: Mar. 05, 2014 FMNG-059.11 REPORT Product Name: Micro Traveler 900S Model No.: GM-090021-V2 Applicant: KYE SYSTEMS CORP. (Genius) No. 492, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City 24160, Taiwan (R.O.C.) Date of Receipt: Feb. 08, 2014 Finished date of Test: Mar. 05, 2014 Applicable Standards: 47 CFR Part 15, Subpart C, 15.249 ANSI C63.4: 2003 We, Spectrum Research & Testing Laboratory Inc., hereby certify that one sample of the above was tested in our laboratory with positive results according to the above-mentioned standards. The records in the report are an accurate account of the results. Details of the results are given in the subsequent pages of this report. Tested By : , Date: Approved By : (Richard Lin) , Date: ( Johnson Ho, Director ) Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A14020802 Report No.:FCCA14020802 FCC ID : FSUGMZL6 Page: 2 of 34 Date: Mar. 05, 2014 Revisions History Report No. Issue Date Revisions FCCA14020802 Mar. 05, 2014 Initial issue Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A14020802 Report No.:FCCA14020802 FCC ID : FSUGMZL6 Page: 3 of 34 Date: Mar. 05, 2014 Table of Contents 1. DOCUMENT POLICY AND TEST STATEMENT...................................................4 1.1 DOCUMENT POLICY.....................................................................................4 1.2 TEST STATEMENT.........................................................................................4 1.3 EUT MODIFICATION......................................................................................4 2. DESCRIPTION OF EUT AND TEST MODE.........................................................5 2.1 GENERAL DESCRIPTION OF EUT................................................................5 2.2 USED CHANNEL AND FREQUENCY TABLE.................................................5 2.3 EUT OPERATING CONDITION......................................................................5 2.4 DESCRIPTION OF TEST MODE....................................................................6 3. DESCRIPTION OF APPLIED STANDARDS.........................................................7 3.1 SUMMARY OF TEST RESULTS.....................................................................7 4. TECHNICAL CHARACTERISTICS TEST.............................................................8 4.1 BAND EDGE TEST.........................................................................................8 4.1.1 TEST EQUIPMENT..................................................................................8 4.1.2 TEST SETUP............................................................................................9 4.1.3 TEST PROCEDURE...............................................................................10 4.1.4 EUT OPERATING CONDITION..............................................................10 4.1.5 TEST RESULT........................................................................................11 4.2 20DB OCCUPIED BANDWIDTH TEST.........................................................15 4.2.1 LIMIT......................................................................................................15 4.2.2 TEST EQUIPMENT................................................................................15 4.2.3 TEST SET-UP.........................................................................................15 4.2.4 EUT OPERATING CONDITION.............................................................15 4.2.5 TEST RESULT........................................................................................16 4.3 RADIATED EMISSION TEST........................................................................18 4.3.1 LIMIT......................................................................................................18 4.3.2 TEST EQUIPMENT................................................................................19 4.3.3 TEST SET-UP.........................................................................................20 4.3.4 TEST PROCEDURE...............................................................................21 4.3.5 TEST RESULT........................................................................................22 5. ANTENNA APPLICATION...................................................................................31 5.1 ANTENNA REQUIREMENT..........................................................................31 5.2 RESULT........................................................................................................31 6. PHOTOS OF TESTING......................................................................................32 7. TERMS OF ABBREVIATION..............................................................................34 Spectrum Research & Testing Lab., Inc. No.167,Ln. 780, Shan-Tong Rd.,Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan County 320, Taiwan (R.O.C.) TEST REPORT Reference No.: A14020802 Report No.:FCCA14020802 FCC ID : FSUGMZL6 Page: 4 of 34 Date: Mar. 05, 2014 1. DOCUMENT POLICY AND TEST STATEMENT 1.1 DOCUMENT POLICY - The report shall not be reproduced except in full, without the written approval of SRT Lab, Inc. 1.2 TEST STATEMENT - The test results in the report apply only to the unit tested by SRT Lab. - There was no deviation from the requirements of test standards during the test. - DC power source, 1.5Vdc of AAA battery (Tx). - New DC dry battery (AAA size) was used during testing. 1.3 EUT MODIFICATION - No modification in SRT Lab. Spectrum Research & Testing Lab.…
